Text über einer Zeile in Tikz funktioniert nicht

Question

Ich habe diesen Code aus meinem vorherigen Beitrag inZarkos Antwort, jetzt das Problem, wie Sie in der sehen könnenDie beigefügte Abbildung zeigt die Beschriftungen. Der Code sollte funktionieren, hat es also etwas mit meiner Latex-Version oder so zu tun? (Ich erstelle das folgende Bild mithilfe des Codes.)

\documentclass[12pt, margin=3mm]{standalone}
\usepackage{tikz}
\usetikzlibrary{angles, arrows.meta,    % new
                quotes}                 % new
\definecolor{lava}{rgb}{0.81, 0.06, 0.13}
\definecolor{myblue}{rgb}{0.0, 0.30, 0.60}
%\usepackage{gensymb} % better is to use siunitx

\begin{document}
    \begin{tikzpicture}[
ang/.style = {draw, Straight Barb-Straight Barb, anchor=west,
              angle radius = 8mm, angle eccentricity=1},
arr/.style = {cap=round,-Straight Barb},
dot/.style = {circle, fill, minimum size=3pt,inner sep=0pt},
every edge quotes/.style = {auto, font=\footnotesize, sloped},
every label/.style       = {inner sep=1pt},
                        ]
% axis
\draw[arr]  (-2.7,0)--(3.6,0)   node[below] {$\Re$}; % x axis
\draw[arr]  (0,-2.7)--(0,3) node[left]  {$\Im$}; % y axis
% circle
\draw       (0,0) circle (2.5cm);
% defining radius points
\node (n1) [dot,label= 45:$V_m$] at (90:2.5) {};
\node (n2) [dot,label= 45:$P$]   at (45:2.5) {};
\node (n3) [dot,label=-45:$V_m$] at ( 0:2.5) {};
% vector
\coordinate (O) at (0,0);
\path[draw=lava, ultra thick, arr]
    (O) to ["$V_m\mathrm{e}^{j\theta}$"]  (n2.center);
% projections
\path[draw=myblue, very thick, arr]
    (O) to ["$V_m \cos(\phi)$" ']   (n2.center |- O); % projection on x axis
\path[draw=myblue, very thick, arr]
    (O) to ["$V_m \sin(\phi)$"]     (n2.center -| O); % projection on y axis
% angle
\pic [ang, "$\omega t+\phi$"] {angle = n3--O--n2};
    \end{tikzpicture}
\end{document}

Answer 1

Das Problem wurde gelöst, indem den Beschriftungen „oben“ und „unten“ wie im folgenden Code hinzugefügt wurden.

\documentclass[12pt, margin=3mm]{standalone}
\usepackage{tikz}
\usetikzlibrary{angles, arrows.meta,
                quotes}
\definecolor{lava}{rgb}{0.81, 0.06, 0.13}
\definecolor{myblue}{rgb}{0.0, 0.30, 0.60}
\usepackage{steinmetz}
\usepackage{siunitx}     % new
\usepackage{amsmath,amsthm, amssymb, latexsym}
\renewcommand{\Re}{\operatorname{Re}}
\renewcommand{\Im}{\operatorname{Im}}

\begin{document}
    \begin{tikzpicture}[
ang/.style = {draw, Straight Barb-Straight Barb, anchor=west,
              angle radius = 8mm, angle eccentricity=1},
arr/.style = {cap=round,-Straight Barb},
dot/.style = {circle, fill, minimum size=3pt,inner sep=0pt},
every edge quotes/.style = {auto, font=\footnotesize, sloped},
every label/.style       = {inner sep=1pt},
                        ]

 \def\Rad{3.25}

% axis
\draw[arr]  (-\Rad-.3,0)--(\Rad+.5,0)   node[above] {$\Re$}; % x axis
\draw[arr]  (0,-\Rad-.3)--(0,\Rad+.5) node[left]  {$\Im$}; % y axis
% circle
\draw       (0,0) circle (\Rad cm);
% defining radius points
\node (n1) [dot,label= 45:$V_m$] at (90:\Rad) {};
\node (n2) [dot,label= 45:$P$]   at (45:\Rad) {};
\node (n3) [dot,label=-45:$V_m$] at (0:\Rad) {};
% vector
\coordinate (O) at (0,0);
\path[draw=lava, ultra thick, arr]
    (O) to ["$V_m\mathrm{e}^{j\theta}$" above]  (n2.center);
% projections
\path[draw=myblue, very thick, arr]
    (O) to ["$V_m \cos(\phi)$" below]   (n2.center |- O); % projection on x axis
\path[draw=myblue, very thick, arr]
    (O) to ["$V_m \sin(\phi)$" above ]     (n2.center -| O); % projection on y axis
% angle
\pic [ang, "$\footnotesize{\omega t+\phi}$"] {angle = n3--O--n2};
    \end{tikzpicture}
\end{document}
