Wie verwalte ich Farblinien in Tabellen?

Question

Ich habe mithilfe der Website eine Tabelle erstellt:https://www.tablesgenerator.com/, aber ich habe ein Problem mit einigen Zeilen. Wie kann ich weiße Zeilen in der ersten Spalte der folgenden Tabelle löschen (die mit den roten Pfeilen gekennzeichneten)?

Dies ist der Code, den ich von der Website erhalten habe:

\begin{table}[H]
\begin{adjustbox}{width=\columnwidth,center}
\begin{tabular}{|c|c|c|}
\hline
\rowcolor[HTML]{FDDCD3}
\cellcolor[HTML]{F54A19}{\color[HTML]{FFFFFF} } &
 \textbf{Weight} &
 34 g (sun sensor) + 1 g (mounting hardware) \\ \cline{2-3}
\rowcolor[HTML]{FFFFFF}
\cellcolor[HTML]{F54A19}{\color[HTML]{FFFFFF} } &
 \textbf{Size} &
 34 mm x 32 mm x 21 mm \\ \cline{2-3}
\rowcolor[HTML]{FDDCD3}
\cellcolor[HTML]{F54A19}{\color[HTML]{FFFFFF} } &
 \textbf{Power} &
 37.5 mW average, 130 mW peak \\ \cline{2-3}
\rowcolor[HTML]{FFFFFF}
\multirow{-4}{*}{\cellcolor[HTML]{F54A19}{\color[HTML]{FFFFFF} \textbf{PHYSICAL CHARACTERISTICS}}} &
 \textbf{Outer Surfaces} &
 Low emissivity gold, scratch-proof sapphire \\ \hline
\rowcolor[HTML]{FDDCD3}
\cellcolor[HTML]{F54A19}{\color[HTML]{FFFFFF} } &
 \textbf{Accuracy} &
 ±0.1° over ±70° Field-of-View \\ \cline{2-3}
\rowcolor[HTML]{FFFFFF}
\cellcolor[HTML]{F54A19}{\color[HTML]{FFFFFF} } &
 \textbf{Bandwidth} &
 5 vector solutions / second \\ \cline{2-3}
\rowcolor[HTML]{FDDCD3}
\multirow{-3}{*}{\cellcolor[HTML]{F54A19}{\color[HTML]{FFFFFF} \textbf{PERFORMANCES}}} &
 \textbf{Earth Albedo Error} &
 Rejected by internal digital processor \\ \hline
\rowcolor[HTML]{FFFFFF}
\cellcolor[HTML]{F54A19}{\color[HTML]{FFFFFF} \textbf{COMMAND/TELEMETRY}} &
 \multicolumn{2}{c|}{\cellcolor[HTML]{FFFFFF}RS-485} \\ \hline
\rowcolor[HTML]{FDDCD3}
\cellcolor[HTML]{F54A19}{\color[HTML]{FFFFFF} } &
 \textbf{Supply Voltage} &
 5.0 V to 50.0 V \\ \cline{2-3}
\rowcolor[HTML]{FFFFFF}
\cellcolor[HTML]{F54A19}{\color[HTML]{FFFFFF} } &
 \textbf{Supply Current} &
 7.5 mA average, 27 mA peak \\ \cline{2-3}
\rowcolor[HTML]{FDDCD3}
\cellcolor[HTML]{F54A19}{\color[HTML]{FFFFFF} } &
 \cellcolor[HTML]{FDDCD3} &
 \cellcolor[HTML]{FDDCD3} \\
\rowcolor[HTML]{FDDCD3}
\cellcolor[HTML]{F54A19}{\color[HTML]{FFFFFF} } &
 \multirow{-2}{*}{\cellcolor[HTML]{FDDCD3}\textbf{Idle Current Consumption}} &
 \multirow{-2}{*}{\cellcolor[HTML]{FDDCD3}\begin{tabular}[c]{@{}c@{}}3 mA, bootloader mode\\ 8 mA, application mode\end{tabular}} \\ \cline{2-3}
\rowcolor[HTML]{FFFFFF}
\multirow{-5}{*}{\cellcolor[HTML]{F54A19}{\color[HTML]{FFFFFF} \textbf{POWER IN}}} &
 \textbf{Active Current Consumption} &
 \textless{}30 mA \\ \hline
\rowcolor[HTML]{FDDCD3}
\cellcolor[HTML]{F54A19}{\color[HTML]{FFFFFF} } &
 \textbf{Operating Temperature Range} &
 -25 °C to +75 °C \\ \cline{2-3}
\rowcolor[HTML]{FFFFFF}
\cellcolor[HTML]{F54A19}{\color[HTML]{FFFFFF} } &
 \textbf{Survival Temperature Range} &
 -40 °C to +85 °C \\ \cline{2-3}
\rowcolor[HTML]{FDDCD3}
\cellcolor[HTML]{F54A19}{\color[HTML]{FFFFFF} } &
 \textbf{Shock} &
 5000 g \\ \cline{2-3}
\rowcolor[HTML]{FFFFFF}
\cellcolor[HTML]{F54A19}{\color[HTML]{FFFFFF} } &
 \textbf{Random Vibration} &
 16 g rms \\ \cline{2-3}
\rowcolor[HTML]{FDDCD3}
\multirow{-5}{*}{\cellcolor[HTML]{F54A19}{\color[HTML]{FFFFFF} \textbf{ENVIRONMENT}}} &
 \textbf{Radiation Tolerant} &
 20 krad total dose at components \\ \hline
\end{tabular}
\end{adjustbox}
\caption{SS-411 Two-Axis Digital Sun Sensors technical data [1], [2]. }
\label{tabella}
\end{table}

Answer 1

Mit der Umgebung {NiceTabular}von nicematrix:

\documentclass[landscape]{article}

\usepackage{xcolor}
\usepackage{nicematrix}
\usepackage{adjustbox}
\usepackage{makecell}

\begin{document}

\begin{adjustbox}{width=\columnwidth,center}
\begin{NiceTabular}{c>{\bfseries}cc}%
  [
    cell-space-top-limit=3pt ,
    cell-space-bottom-limit=3pt ,
    hvlines ,
    code-before = \rowcolors[HTML]{1}{FDDCD3}{} \columncolor[HTML]{F54A19}{1}
  ]
 \Block{4-1}{\color{white}\makecell{PHYSICAL\\ CHARACTERISTICS}}
 &  Weight &  34 g (sun sensor) + 1 g (mounting hardware) \\
 &  Size &  34 mm x 32 mm x 21 mm \\
 &  Power &  37.5 mW average, 130 mW peak \\
 &  Outer Surfaces &  Low emissivity gold, scratch-proof sapphire \\
 \Block{3-1}{\color{white}PERFORMANCES}
 & Accuracy & ±0.1° over ±70° Field-of-View \\
 & Bandwidth & 5 vector solutions / second \\
 & Earth Albedo Error &  Rejected by internal digital processor \\
 \color{white}COMMAND/TELEMETRY
 & \Block{1-2}{RS-485} \\
 \Block{4-1}{\color{white}POWER IN}
 & Supply Voltage & 5.0 V to 50.0 V \\
 & Supply Current & 7.5 mA average, 27 mA peak \\
 & Idle Current Consumption  &
 \begin{tabular}[c]{@{}c@{}}3 mA, bootloader mode\\ 8 mA, application mode\end{tabular} \\
 &  Active Current Consumption & \textless{}30 mA \\
 \Block{5-1}{\color{white}ENVIRONMENT}
 & Operating Temperature Range & $-25$ °C to $+75$ °C \\
 & Survival Temperature Range & $-40$ °C to $+85$ °C \\
 & Shock & 5000 g \\
 & Random Vibration & 16 g rms \\
 &  Radiation Tolerant & 20 krad total dose at components \\
\end{NiceTabular}
\end{adjustbox}

\end{document}

• In {NiceTabular}verwenden Sie den Befehl, \Blockum Zellen sowohl vertikal als auch horizontal zu verbinden.

• Der Schlüssel hvlineszeichnet alle Regeln auf, außer in den Blöcken.

• Der Befehl \rowcolors(in der Taste code-before) färbt die Zeilen abwechselnd und der Befehl \columncolor(danach verwendet) färbt die erste Spalte.
