Gibt es eine Möglichkeit, anchor
ein vollständiges Bild tikzpicture
an einer bestimmten Koordinate mit den Argumenten north
, east
, center
, ... anzuzeigen? Ich habe ein Raster konfiguriert, das Hintergrundkoordinaten anzeigt, wenn es in der Option frame
„by “ aktiviert wird g
. Dann habe ich ein Tikzpicture darüber gezeichnet (in diesem Fall bei (0,3.5)
), was die obere linke Ecke meiner Beamer-Folie ist. Jetzt frage ich mich, wie ich das vollständige Tikzpicture vertikal bei 0,0 mit Anker west
oder bei 7,0 mit Anker ausrichten center
kann. Normalerweise nutze ich es, overlay
um Tikzpictures unabhängig auf meinen Folien zeichnen zu können.
Code:
\documentclass[8pt,aspectratio=169]{beamer}
\usepackage[british]{babel}
\usepackage{tikz}
\usetikzlibrary{shapes,shapes.geometric,arrows,fit,positioning,arrows.meta,arrows.spaced,angles,quotes,decorations.pathmorphing,decorations.shapes,decorations.text,patterns,overlay-beamer-styles,external,calc,math,backgrounds,automata}
\tikzstyle{every picture}+=[overlay,remember picture,shift={([xshift=1cm,yshift=-0.41cm]current page.west)}]
\defbeamertemplate{background}{mydefault}{%
%
}
\defbeamertemplate{background}{g}{%
\begin{tikzpicture}
\foreach \y in {3.5,3,...,-3.5}
\draw[opacity=0.3,line width=0.1] (0,\y) -- (14,\y);
\foreach \x in {0,0.5,...,14}
\draw[opacity=0.3,line width=0.1] (\x,3.5) -- (\x,-3.5);
\begin{scope}[opacity=0.4]
\foreach \x in {0,1,...,14}
\foreach \y in {3.5,3,2.5,...,-3.5}
\node[font=\footnotesize] at (\x,\y) {\x, \y};
\end{scope}
\end{tikzpicture}%
}
\BeforeBeginEnvironment{frame}{%
\setbeamertemplate{background}[mydefault]%
}
\makeatletter
\define@key{beamerframe}{g}[true]{%
\setbeamertemplate{background}[g]%
}
\makeatother
\begin{document}
\begin{frame}[g]
\frametitle{Agenda}
\begin{tikzpicture}[Numbox/.style={rectangle,draw=magenta,fill=magenta,text=white,font=\bfseries,text width=12pt, minimum height=28pt,anchor=north west,align=center},
Textbox/.style={rectangle,draw=magenta,text width=7cm, minimum height=28pt,anchor=north west,align=left,font=\bfseries,inner xsep=9pt}
]
\tikzmath{
\numskip=9pt;
\textnumskip=3pt;
}
]
\node[Numbox] (I) at (0,3.5) {I.};
\node[Textbox] (IT) at ([xshift=\textnumskip]I.north east) {Problemstellung und Forschungsfragen};
\node[Numbox] (II) at ([yshift=-\numskip]I.south west) {II.};
\node[Textbox] (IIT) at ([xshift=\textnumskip]II.north east) {Problemstellung und Forschungsfragen};
\node[Numbox] (III) at ([yshift=-\numskip]II.south west) {III.};
\node[Textbox] (IIIT) at ([xshift=\textnumskip]III.north east) {Problemstellung und Forschungsfragen};
\node[Numbox] (IV) at ([yshift=-\numskip]III.south west) {IV.};
\node[Textbox] (IVT) at ([xshift=\textnumskip]IV.north east) {Problemstellung und Forschungsfragen};
\node[Numbox] (V) at ([yshift=-\numskip]IV.south west) {V.};
\node[Textbox] (VT) at ([xshift=\textnumskip]V.north east) {Problemstellung und Forschungsfragen};
\end{tikzpicture}
\end{frame}
\end{document}
