Wie kann ich diese Figur von rechts nach links beginnen lassen?

Question

Ich möchte diese Figur erstellen, aber sie soll von rechts nach links beginnen und nicht von links nach rechts. Wie kann ich das machen?

Ich habe den Code aus dieser Antwort auf derVisuelle Darstellung eines Deep Neural Network

Code:

\documentclass{article}
\usepackage{tikz}
\usetikzlibrary{positioning}
\begin{document}

\tikzset{%
  every neuron/.style={
    circle,
    draw,
    blue, % <----------- Add the color you want.
    minimum size=1cm
  },
  neuron missing/.style={
    draw=none,
    scale=4,
    text height=0.333cm,
    execute at begin node=\color{black}$\vdots$
  },
}

\begin{tikzpicture}[x=1.5cm, y=1.5cm, >=stealth]

\foreach \m/\l [count=\y] in {1,2,3,missing,4}
{
  \node [every neuron/.try,neuron \m/.try] (input-\m) at (0,2.5-\y) {};
}
\foreach \m [count=\y] in {1,missing,2}
  \node [every neuron/.try, neuron \m/.try ] (hidden-\m) at (2,2-\y*1.25) {};

\foreach \m [count=\y] in {1,missing,2}
  \node [every neuron/.try, neuron \m/.try ] (hidden2-\m) at (4,2-\y*1.25) {};

\foreach \m [count=\y] in {1,missing,2}
  \node [every neuron/.try, neuron \m/.try ] (output-\m) at (6,1.5-\y) {};

\foreach \l [count=\i] in {1,2,3,n}
  \draw [<-] (input-\i) -- ++(-1,0)
    node [above, midway] {$x_\l$};

\foreach \l [count=\i] in {1,n}
  {\node [above] at (hidden-\i.north) {$h_{1\l}$};
  \node [above] at (hidden2-\i.north) {$h_{2\l}$};}

\foreach \l [count=\i] in {1,n}
  \draw [->] (output-\i) -- ++(1,0)
    node [above, midway] {$y_\l$};

\foreach \i in {1,...,4}
  \foreach \j in {1,...,2}
    \draw [->] (input-\i) -- (hidden-\j);

\foreach \i in {1,...,2}
  \foreach \j in {1,...,2}
    \draw [->] (hidden-\i) -- (hidden2-\j);

\foreach \i in {1,...,2}
  \foreach \j in {1,...,2}
    \draw [->] (hidden2-\i) -- (output-\j);

\foreach \l [count=\x from 0] in {Input, Hidden, Hidden, Ouput}
  \node [align=center, above] at (\x*2,2) {\l \\ layer};

\end{tikzpicture}

\end{document}

Answer 1

Mit der Taste können Sie xscale=-1das Bild spiegeln:

\documentclass{article}
\usepackage{tikz}
\usetikzlibrary{positioning}
\begin{document}

\tikzset{%
  every neuron/.style={
    circle,
    draw,
    blue, % <----------- Add the color you want.
    minimum size=1cm
  },
  neuron missing/.style={
    draw=none,
    scale=4,
    text height=0.333cm,
    execute at begin node=\color{black}$\vdots$
  },
}

\begin{tikzpicture}[x=1.5cm, y=1.5cm, >=stealth,xscale=-1]

\foreach \m/\l [count=\y] in {1,2,3,missing,4}
{
  \node [every neuron/.try,neuron \m/.try] (input-\m) at (0,2.5-\y) {};
}
\foreach \m [count=\y] in {1,missing,2}
  \node [every neuron/.try, neuron \m/.try ] (hidden-\m) at (2,2-\y*1.25) {};

\foreach \m [count=\y] in {1,missing,2}
  \node [every neuron/.try, neuron \m/.try ] (hidden2-\m) at (4,2-\y*1.25) {};

\foreach \m [count=\y] in {1,missing,2}
  \node [every neuron/.try, neuron \m/.try ] (output-\m) at (6,1.5-\y) {};

\foreach \l [count=\i] in {1,2,3,n}
  \draw [<-] (input-\i) -- ++(-1,0)
    node [above, midway] {$x_\l$};

\foreach \l [count=\i] in {1,n}
  {\node [above] at (hidden-\i.north) {$h_{1\l}$};
  \node [above] at (hidden2-\i.north) {$h_{2\l}$};}

\foreach \l [count=\i] in {1,n}
  \draw [->] (output-\i) -- ++(1,0)
    node [above, midway] {$y_\l$};

\foreach \i in {1,...,4}
  \foreach \j in {1,...,2}
    \draw [->] (input-\i) -- (hidden-\j);

\foreach \i in {1,...,2}
  \foreach \j in {1,...,2}
    \draw [->] (hidden-\i) -- (hidden2-\j);

\foreach \i in {1,...,2}
  \foreach \j in {1,...,2}
    \draw [->] (hidden2-\i) -- (output-\j);

\foreach \l [count=\x from 0] in {Input, Hidden, Hidden, Ouput}
  \node [align=center, above] at (\x*2,2) {\l \\ layer};

\end{tikzpicture}

\end{document}
