Gleichung in \multirow ausrichten

Gleichung in \multirow ausrichten

Ich möchte diesen Text ausrichten. Für ein Kalkulationsblatt benötige ich eine einheitliche Eingabe zur wiederholten Verwendung.

Bildbeschreibung hier eingeben

Dies ist mein Code:

% Document Class
% **************************************************
\documentclass[
    paper=A4,                   %
    11pt,                       % font size
]{scrreprt}                     %

\RequirePackage{tabularx}       % table features
\RequirePackage{textcomp}       % different symbols
\usepackage{tikz}               % check marks
\usepackage{amssymb}            % for calculations
\usepackage{datatool}           % tools to load and manipulate data
\usepackage{array,multirow}     % for calculations

\begin{document}

\newenvironment{conditions*}
    {\par\vspace{\abovedisplayskip}\noindent
    \tabularx{\columnwidth}{
    @{\raggedright\arraybackslash}p{4cm}
    >{$}p{0.7cm}<{$}
    @{${}{}$}
    >{\raggedright\arraybackslash}p{6cm}|
    >{$}p{0.7cm}<{$}
    @{${}={}$}
    >{\color{blue}$}m{1.2cm}<{$}
    >{$}X<{$}
    }}{\endtabularx\par\vspace{\belowdisplayskip}}

\def\s{454}
\def\k{0.00394}

\begin{conditions*}
Spacing of stiffeners
        &
        &
        & s
        & \s
        & \mathrm{mm} \\
Factor
        &
        &
        & k
        & \k
        & \mathrm{mm} \\
\multirow{2}{*}{Required thickness} &
\multirow{2}{*}{$t_{req}$}
\multirow{2}{*}{
        $\begin{aligned}[t]
        & = k \times  s \\
        & = \k \times  \s \\
        & = 1.78876
        \end{aligned}$}
        & & \multicolumn{3}{l}{\begin{tabular}[t]{@{}l} \\[-1em]
        [1]~{Chapter 11.1} \\[0em]
        \\[0em]
        \end{tabular}} \\
        & & & t_{req}
        & 1.78876
        & \mathrm{mm} \\
\end{conditions*}

\end{document} ```

Antwort1

Fügen Sie allen Ihren Befehlen die optionale Ausrichtung [t]voran \multirow:

\multirow[t]{2}{*}{Required thickness} &
\multirow[t]{2}{*}{$t_{req}$}
\multirow[t]{2}{*}{
    $\begin{aligned}[t]
    & = k \times  s \\
    & = \k \times  \s \\
    & = 1.78876
    \end{aligned}$}

Bildbeschreibung hier eingeben
