Ich bin ein bisschen neu bei Tikz und habe zum ersten Mal versucht, den Befehl \onslide zu verwenden. Ich verstehe nicht, warum mein Code keinen Fehler, aber auch keinen Effekt erzeugt (erzeugt 3 identische Diagramme auf 3 Folien mit dem gesamten Inhalt).
Hier ist mein MWE:
\documentclass[10pt]{beamer}
\usetheme{Madrid}
% Plot
\usepackage{tikz}
\usepackage{tkz-euclide} % Coordinate axes
\usepackage{pgfplots} % Another axes package
\pgfdeclarelayer{background}% determine background layer
\pgfsetlayers{background,main}% order of layers
\begin{document}
\begin{frame}{Sample}
\begin{figure}
\centering
\pgfplotsset{xmin=0, xmax=1, ymin=0, ymax=1}
\pgfplotsset{compat=1.17}
\begin{tikzpicture}[scale=1]
\begin{axis}[domain=0:1,
ylabel near ticks,
xlabel near ticks,
xlabel={$m$},
ylabel={$n$},
clip mode=individual]
\addplot[black,dashed,domain=0:1,smooth] plot ({\x}, {\x });
\addplot[black,thick,domain=0:1,smooth,samples=500] plot ({ 3*\x/(3*\x + (1-\x)) }, {\x});
\node[anchor=south] at (0.75,0.55) {$\color{black}g_b$};
\onslide<2->{
\addplot[black,thick,domain=0:1,smooth,samples=500] plot ({ 9*\x/(9*\x + (1-\x)) }, {\x});
\node[anchor=south] at (0.8,0.4) {$\color{black}g_b^2$}; }
\onslide<3->{
\addplot[black,thick,domain=0:1,smooth,samples=500] plot ({ 81*\x/(81*\x + (1-\x)) }, {\x});
\node[anchor=south] at (0.9,0.2) {$\color{black}g_b^3$}; }
\end{axis}
\end{tikzpicture}
\end{figure}
\end{frame}
\end{document}
Antwort1
Ich denke, es zu ändern in
\only<overlay specification>{\addplot { ... };}
funktioniert. Hoffe, anderen Leuten zu helfen, die auf dieses Problem gestoßen sind!
