Schattierung der Region in PStricks entfernen

Schattierung der Region in PStricks entfernen

Mein Code ist im Wesentlichen der folgende.

\documentclass{article}
\usepackage{pstricks}
\begin{document}
 \psset{xunit=1cm, yunit=1cm, algebraic= true}
 \begin{pspicture}(-6,-7)(6,7)
 \pspolygon[showpoints = false, linearc = 0.2](5,6.2)(5,-6.2)(-5,-6.2)(-5, 6.2)
 \pscircle[](0,0){4.9} %outermost circle
 \pscircle[](0,0){3.5} %inner large circle
 \pscircle[](0,2.2){.5} %tiny circle
 \pscircle[](1.55,2.2){.6} %another tiny circle
\pscustom[fillstyle=solid, fillcolor=lightgray]{
 \psellipse[](-1.3,-.3)(3.2,2) %shaded ellipse
 }
\pscustom[fillstyle=solid, fillcolor=white]{\psellipse[](-.5,-.5)(1.5, 1.5)} %circle within shaded ellipse
 \pscircle[](-.8,-.5){.68}
 \pscircle[](0,0){3.5} % restoring portion of inner circle shaded over
 \uput{1.7}[180]
        (-1.95,0){xxx}
\end{pspicture}
\end{document}

Es wird die folgende Abbildung erzeugt

Schattierungsbild

das ist genau das, was ich will, mit einer Ausnahme: Nur der Bereich der Ellipse außerhalb des großen inneren Kreises, der mit xxx markiert ist, sollte ohne weitere Änderungen unschattiert bleiben. Gibt es eine einfache Möglichkeit, dies zu tun? Vielen Dank im Voraus.

Antwort1

Hier ist der Code tikz(in Ihrem Code fehlen die Position und die Dimension des zweiten Kreises innerhalb der Ellipse):

\documentclass{article}
\usepackage{tikz}
\begin{document}

    \begin{tikzpicture}
        %\draw[gray!25](-6,-7) grid (6,7);
        \draw[rounded corners] (-5,-6.2) rectangle (5, 6.2);
        \draw circle(4.9);
        \draw (0,2.2) circle(.5);
        \draw (1.55,2.2) circle(.6);
        \draw (-.8,-.5) circle(.68);
        \begin{scope}
            \clip circle(3.5);
            \fill[lightgray] (-1.3,-.3) ellipse(3.2 and 2);
        \end{scope}
        \draw circle(3.5);
        \draw (1.55,2.2) circle(.6);
        \draw (-.8,-.5) circle(.68);
    \end{tikzpicture}
\end{document}

Ausgabe:

Bildbeschreibung hier eingeben

Antwort2

\documentclass{article}
\usepackage{pstricks}
\begin{document}
\psset{xunit=1cm, yunit=1cm, algebraic= true}
\begin{pspicture}(-6,-7)(6,7)
    \pspolygon[showpoints = false, linearc = 0.2](5,6.2)(5,-6.2)(-5,-6.2)(-5, 6.2)
    \pscircle[](0,0){4.9} %outermost circle
    \pscircle[](0,2.2){.5} %tiny circle
    \pscircle[](1.55,2.2){.6} %another tiny circle
    \psclip{\pscircle(0,0){3.5}} %inner large circle
        \psellipse[fillstyle=solid, fillcolor=lightgray](-1.3,-.3)(3.2,2) %shaded ellipse
    \endpsclip
    \psellipse[fillstyle=solid, fillcolor=white](-.5,-.5)(1.5, 1.5) %circle within shaded ellipse
    \pscircle[](-.8,-.5){.68}
    \pscircle[](0,0){3.5} % restoring portion of inner circle shaded over
    \uput{1.7}[180](-1.95,0){xxx}
\end{pspicture}
\end{document}

Bildbeschreibung hier eingeben
