Ich arbeite an meinem Tooltip-Paket custom-tooltip.sty. Bitte sehen Sie untencustom-tooltip.sty
\NeedsTeXFormat{LaTeX2e}[2020/02/20]
\ProvidesPackage{custom-tooltip}[2020/11/30 custom-tooltip Package]
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
%
% tooltips with LaTeX v. 2019/09/26
%
% \tooltip[*[*[*[*]]]]
% [<link colour>]{<link text>}
% [<tip box colour>]{<tip text>}
% [<x-offset>,<y-offset>]
%
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
%
% \tooltip --> draggable tip, visible on mouse-over, hidden on mouse-out
%
% \tooltip* --> draggable tip, toggle visiblity on mouse-over
%
% \tooltip** --> NON-draggable tip, visible on mouse-over, hidden on mouse-out
%
% \tooltip*** --> NON-draggable tip, toggle visiblity on mouse-over
%
% \tooltip**** --> NON-draggable tip, toggle visiblity on mouse-click (Evince!)
%
% Default link colour can be set with
%
% \usepackage[linkcolor=<colour>]{hyperref}
%
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\usepackage{pdfbase}[2017/03/16]
\usepackage{xparse,ocgbase}
\usepackage{tikzpagenodes,linegoal}
\usetikzlibrary{calc}
\ExplSyntaxOn
\let\tpPdfLink\pbs_pdflink:nn
\let\tpPdfAnnot\pbs_pdfannot:nnnn\let\tpPdfLastAnn\pbs_pdflastann:
\let\tpAppendToFields\pbs_appendtofields:n
\def\tpPdfXform{\pbs_pdfxform:nnnnn{1}{1}{}{}}
\let\tpPdfLastXform\pbs_pdflastxform:
\let\cListSet\clist_set:Nn\let\cListItem\clist_item:Nn
\ExplSyntaxOff
%\makeatletter
\NewDocumentCommand{\tooltip}{%
ssssO{\ifdefined\@linkcolor\@linkcolor\else blue\fi}mO{yellow!20}mO{0pt,0pt}%
}{{%
\leavevmode%
\IfBooleanT{#2}{%
%for variants with two and more stars, put tip box on a PDF Layer (OCG)
\ocgbase@new@ocg{tipOCG.\thetcnt}{%
/Print<</PrintState/OFF>>/Export<</ExportState/OFF>>%
}{false}%
\xdef\tpTipOcg{\ocgbase@last@ocg}%
%prevent simultaneous visibility of multiple non-draggable tooltips
\ocgbase@add@ocg@to@radiobtn@grp{tool@tips}{\ocgbase@last@ocg}%
}%
\tpPdfLink{%
\IfBooleanTF{#4}{%
/Subtype/Link/Border[0 0 0]/A <</S/SetOCGState/State [/Toggle \tpTipOcg]>>
}{%
/Subtype/Screen%
/AA<<%
\IfBooleanTF{#3}{%
/E<</S/SetOCGState/State [/Toggle \tpTipOcg]>>%
}{%
\IfBooleanTF{#2}{%
/E<</S/SetOCGState/State [/ON \tpTipOcg]>>%
/X<</S/SetOCGState/State [/OFF \tpTipOcg]>>%
}{
\IfBooleanTF{#1}{%
/E<</S/JavaScript/JS(%
var fd=this.getField('tip.\thetcnt');%
if(typeof(click\thetcnt)=='undefined'){%
var click\thetcnt=false;%
var fdor\thetcnt=fd.rect;var dragging\thetcnt=false;%
}%
if(fd.display==display.hidden){%
fd.delay=true;fd.display=display.visible;fd.delay=false;%
}else{%
if(!click\thetcnt&&!dragging\thetcnt){fd.display=display.hidden;}%
if(!dragging\thetcnt){click\thetcnt=false;}%
}%
this.dirty=false;%
)>>%
}{%
/E<</S/JavaScript/JS(%
var fd=this.getField('tip.\thetcnt');%
if(typeof(click\thetcnt)=='undefined'){%
var click\thetcnt=false;%
var fdor\thetcnt=fd.rect;var dragging\thetcnt=false;%
}%
if(fd.display==display.hidden){%
fd.delay=true;fd.display=display.visible;fd.delay=false;%
}%
this.dirty=false;%
)>>%
/X<</S/JavaScript/JS(%
if(!click\thetcnt&&!dragging\thetcnt){fd.display=display.hidden;}%
if(!dragging\thetcnt){click\thetcnt=false;}%
this.dirty=false;%
)>>%
}%
/U<</S/JavaScript/JS(click\thetcnt=true;this.dirty=false;)>>%
/PC<</S/JavaScript/JS (%
var fd=this.getField('tip.\thetcnt');%
try{fd.rect=fdor\thetcnt;}catch(e){}%
fd.display=display.hidden;this.dirty=false;%
)>>%
/PO<</S/JavaScript/JS(this.dirty=false;)>>%
}%
}%
>>%
}%
}{{\color{#5}#6}}%
\sbox\tiptext{%
\IfBooleanT{#2}{%
\ocgbase@oc@bdc{\tpTipOcg}\ocgbase@open@stack@push{\tpTipOcg}}%
%\fcolorbox{black}{#7}{#8}%
\tcbox[colframe=black,colback=#7,size=fbox,arc=0ex,
sharp corners=southwest]{\parbox{0.70\textwidth}{\raggedright #8}}%
\IfBooleanT{#2}{\ocgbase@oc@emc\ocgbase@open@stack@pop\tpNull}%
}%
\cListSet\tpOffsets{#9}%
\edef\twd{\the\wd\tiptext}%
\edef\tht{\the\ht\tiptext}%
\edef\tdp{\the\dp\tiptext}%
\tipshift=12pt%
\IfBooleanTF{#2}{%
%OCG-based (that is, all non-draggable) boxes should not extend beyond the
%current column as they may get overlaid by text in the neighbouring column
\setlength\whatsleft{\linegoal}%
}{%
\measureremainder{\whatsleft}%
}%
\ifdim\whatsleft<\dimexpr\twd+\cListItem\tpOffsets{1}\relax%
\setlength\tipshift{\whatsleft-\twd-\cListItem\tpOffsets{1}}\fi%
\IfBooleanF{#2}{\tpPdfXform{\tiptext}}%
\raisebox{\heightof{#6}+\tdp+\cListItem\tpOffsets{2}}[0pt][0pt]{%
\makebox[0pt][l]{\hspace*{112pt}\hspace{\dimexpr\tipshift+\cListItem\tpOffsets{1}\relax}%
\IfBooleanTF{#2}{\usebox{\tiptext}}{%
\tpPdfAnnot{\twd}{\tht}{\tdp}{%
/Subtype/Widget/FT/Btn/T (tip.\thetcnt)
/Subtype/Widget/FT/Btn/TU (tip.\thetcnt)%%%24-01-2024 Srinivasan
/AP<</N \tpPdfLastXform>>%
/MK<</TP 1/I \tpPdfLastXform/IF<</S/A/FB true/A [0.0 0.0]>>>>%
/Ff 65536/F 3%
/AA <<%
/U <<%
/S/JavaScript/JS(%
var fd=event.target;%
var mX=this.mouseX;var mY=this.mouseY;%
var drag=function(){%
var nX=this.mouseX;var nY=this.mouseY;%
var dX=nX-mX;var dY=nY-mY;%
var fdr=fd.rect;%
fdr[0]+=dX;fdr[1]+=dY;fdr[2]+=dX;fdr[3]+=dY;%
fd.rect=fdr;mX=nX;mY=nY;%
};%
% if(!dragging\thetcnt){%
% dragging\thetcnt=true;Int=app.setInterval("drag()",1);%
% }%
% else{app.clearInterval(Int);dragging\thetcnt=false;}%
this.dirty=false;%
)%
>>%
>>%
}%
\tpAppendToFields{\tpPdfLastAnn}%
}%
}}%
\stepcounter{tcnt}%
}}
%\makeatother
\newsavebox\tiptext\newcounter{tcnt}
\newlength{\whatsleft}\newlength{\tipshift}
\newcommand{\measureremainder}[1]{%
\begin{tikzpicture}[overlay,remember picture]
\path let \p0 = (0,0), \p1 = (current page.east) in
[/utils/exec={\pgfmathsetlength#1{\x1-\x0}\global#1=#1}];
\end{tikzpicture}%
}
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
Und meine LaTeX-DateiMyBook.tex
\documentclass{book}
\usepackage[intlimits,tbtags]{amsmath}
\usepackage[utf8]{inputenc}
\usepackage{amssymb}
\usepackage{calc}
\usepackage{tcolorbox}
\usepackage{custom-tooltip}
\begin{document}
\setcounter{chapter}{0}
\chapter{This is sample title}\label{chap:1}
This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text.This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text.This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text.This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text.This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text.This is sample text. This is sample text.
\begin{figure}[!t]
\tooltip{\includegraphics[scale=0.65]{LaTeX_logo.png}}{This is LaTeX log.}[-450pt,3pt]
\caption{This is LaTeX logo.}
\end{figure}
This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text.This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text.This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text.This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text.This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text. This is sample text.This is sample text. This is sample text.
\end{document}
NOTIZIn pdfbase.styAR Bugzeilen wurde für das Löschen der kommentiertFeldbeschreibungenFehler müssenBestandenim Zugänglichkeits-Checker. Bitte siehe unten
Mein Problem WährenddessenBarrierefreiheitsprüfung, es wurde der Fehler erzeugtMarkierte Formularfelder – Fehlgeschlagenin Abode Acrobat Pro DC. Bitte sehen Sie sich meinen Screenshot unten an.
Ich ändere die unmarkierten Anmerkungen manuell in markierte Anmerkungen in Adobe, indem ichHIER. Ich meine einige der Buch hatte mehr Bilder. Ich bin verweisen auf diePDF-Skriptcodeund versuche, den Fehler zu beheben. Aber ich kann den Fehler nicht beheben, indem ich mein custom-tooltip.styPaket anpasse.
Kann mir jemand dabei helfen, das Paket so anzupassen, custom-tooltip.stydass der Fehler automatisch gelöscht wird?Markierte Formularfelder - Bestanden
