Wie werden die Grundlinien von Bildtext und Fließtext ausgerichtet?

Wie werden die Grundlinien von Bildtext und Fließtext ausgerichtet?

Der folgende Code umschließt ein Bild und den dazugehörigen Text im Fließtext. So eingestellt (mit dem \vfills) werden Bild und Text vertikal zentriert in der Aussparung platziert.

Was ich erreichen möchte, ist, den Text unter dem Bild am Grundlinienraster auszurichten (indem ich beide absenke). Wenn ich den letzten \vfillim dritten Parameter weglasse \figflow, wird der Text zu tief gesetzt.

Ressourcen: Ich verwende XeTeX (um das Bild einzubinden),figflow.tex,graue Box.pngund Hintergrundraster ausdiese Antwort.

\newbox\gridbox
\setbox\gridbox\line{%
  \special{color push rgb .8 .8 1}%
  \vrule height\baselineskip width0pt \hrulefill
  \special{color pop}}
\def\grid{\vtop to0pt{\hrule height0pt\kern-\dimexpr\baselineskip-\topskip\topskip=10pt\relax
    \vbox to\dimexpr\vsize+2pt\relax{\leaders\copy\gridbox\vfil}\vss}}
\def\pagebody{\vbox to\vsize{\boxmaxdepth=\maxdepth \grid\pagecontents}}

\input figflow
\parskip=0pt \frenchspacing \raggedbottom
\font\smallrm=cmr8

\def\includegraphics#1#2#3#4{
{\parfillskip=0pt\par}\dimen0=#1
\dimen1=#2
\advance\dimen0 by 1pc
\setbox0=\vbox to #2{\hsize=#1
\XeTeXpicfile #3 width #1 height #2}
\setbox1=\vbox{\hsize=#1{\noindent\it #4\par}}
\advance\dimen1 by \ht1
\divide\dimen1 by \baselineskip
\multiply\dimen1 by \baselineskip
\advance\dimen1 by \baselineskip
\setbox2=\vbox to \dimen1{\vfil\box0\vskip2mm\box1}
\figflow{\dimen0}{\dimen1}{\vfill\box2\vfill}\noindent\ignorespaces}

\noindent
A work in progress, {\tt JSBox} is a self-contained
library---written in portable C---that instantiates sandbox-able,
\TeX-language interpreters within the memory space
of any C, Objective-C, or C++ 32- or 64-bit client
program. Built and documented anew, {\tt JSBox}
is faithful to the \TeX\ language's primitives,
syntax, typesetting algorithms, measurements, data
structures, and speed. At the same time, it fixes---in an
upwardly compatible manner---a variety of important
problems with or lacun\ae\ in the current \TeX\ engine's
implementation. These include integral support for
21-bit Unicode, namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more.%
\includegraphics{7cm}{7cm}{greybox.png}{Lorem ipsum dolor sit
amet, consectetur adipiscing elit. Donec a diam lectus.}
Especially pertinent to interactive applications---such as an
eBook reader---is that all of a document's pages can
optionally be kept as \TeX\ data structures in memory
after a job is done, with direct random access of any
requested page exported to the client program's screen
without file I/O or DVI or PDF conversion if unneeded.
Tracing (including recursive expansion, re-tracing
interrupted commands, alignments, math, etc.) and
all error messages have been significantly improved
over what \TeX\ does. The author will demo what
{\tt JSBox} can do now, and discuss what it
could do in the future.

A work in progress, {\tt JSBox} is a self-contained
library---written in portable C---that instantiates sandbox-able,
\TeX-language interpreters within the memory space
of any C, Objective-C, or C++ 32- or 64-bit client
program. Built and documented anew, {\tt JSBox}
is faithful to the \TeX\ language's primitives,
syntax, typesetting algorithms, measurements, data
structures, and speed. At the same time, it fixes---in an
upwardly compatible manner---a variety of important
problems with or lacun\ae\ in the current \TeX\ engine's
implementation. These include integral support for
21-bit Unicode, namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more. Especially
pertinent to interactive applications---such as an
eBook reader---is that all of a document's pages can
optionally be kept as \TeX\ data structures in memory
after a job is done, with direct random access of any
requested page exported to the client program's screen
without file I/O or DVI or PDF conversion if unneeded.
Tracing (including recursive expansion, re-tracing
interrupted commands, alignments, math, etc.) and
all error messages have been significantly improved
over what \TeX\ does. The author will demo what
{\tt JSBox} can do now, and discuss what it
could do in the future.
\bye

AKTUALISIEREN:

InDasIn diesem Fall, in dem \baselineskipdie Schriftgröße im Text unter der Abbildung mit der des Haupttextes übereinstimmt, gelang es mir, die Grundlinien auszurichten, indem ich die \figflowLinie änderte in

\figflow{\dimen0}{\dimen1}{\vfill\box2\vskip0pt}\noindent\ignorespaces}

Warum funktioniert das Einfügen eines leeren \vskipFeldes? Beachten Sie, dass dies bei anderen Schriftgrößen und auch bei anderen \baselineskipS nicht funktioniert, auch nicht beim Einfügen \strutvon S innerhalb oder außerhalb der Gruppe in Feld 1.

UPDATE 2:

Dank der Antwort von wipet habe ich ein weiteres MWE mit einem nicht so ungewöhnlichen Fall erstellt: wenn Bild und Beschriftung in der unteren rechten (oder linken) Ecke einer Seite stehen sollten:

\newbox\gridbox
\setbox\gridbox\line{%
  \special{color push rgb .8 .8 1}%
  \vrule height\baselineskip width0pt \hrulefill
  \special{color pop}}
\def\grid{\vtop to0pt{\hrule height0pt\kern-\dimexpr\baselineskip-\topskip\topskip=10pt\relax
    \vbox to\dimexpr\vsize+2pt\relax{\leaders\copy\gridbox\vfil}\vss}}
\def\pagebody{\vbox to\vsize{\boxmaxdepth=\maxdepth \grid\pagecontents}}

\input figflow
\parskip=0pt \frenchspacing \raggedbottom
\font\smallrm=cmr8

\def\includegraphics#1#2#3#4{%
   {\parfillskip=0pt\par}
   \dimen0=#1 \ifdim#1<0pt \dimen0=-\dimen0 \fi
   \dimen1=#2
   \dimen2=#1 \advance\dimen2 by \ifdim#1<0pt-\fi 1pc
   \setbox0=\vbox {\XeTeXpicfile #3 width\dimen0 height #2}
   \setbox1=\vbox{\hsize=\dimen0 \baselineskip=9.5pt\noindent\smallrm #4\par}
   \advance\dimen1 by \ht1
   \divide\dimen1 by \baselineskip
   \multiply\dimen1 by \baselineskip
   \advance\dimen1 by 1\baselineskip
   \setbox2=\vbox to\dimen1{\vss\box0\vskip2mm\box1}
   \figflow{\dimen2}{\dimen1}{}%
   \line{\ifdim#1<0pt\hfill\fi\vtop to0pt{\kern0pt\box2\vss}\hfil}
   \nobreak\vskip-\baselineskip
   \noindent\ignorespaces}

\noindent
A work in progress, {\tt JSBox} is a self-contained
library---written in portable C---that instantiates sandbox-able,
\TeX-language interpreters within the memory space
of any C, Objective-C, or C++ 32- or 64-bit client
program. Built and documented anew, {\tt JSBox}
is faithful to the \TeX\ language's primitives,
syntax, typesetting algorithms, measurements, data
structures, and speed. At the same time, it fixes---in an
upwardly compatible manner---a variety of important
problems with or lacun\ae\ in the current \TeX\ engine's
implementation. These include integral support for
21-bit Unicode, namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more.
Especially pertinent to interactive applications---such as an
eBook reader---is that all of a document's pages can
optionally be kept as \TeX\ data structures in memory
after a job is done, with direct random access of any
requested page exported to the client program's screen
without file I/O or DVI or PDF conversion if unneeded.
Tracing (including recursive expansion, re-tracing
interrupted commands, alignments, math, etc.) and
all error messages have been significantly improved
over what \TeX\ does. The author will demo what
{\tt JSBox} can do now, and discuss what it
could do in the future.

A work in progress, {\tt JSBox} is a self-contained
library---written in portable C---that instantiates sandbox-able,
\TeX-language interpreters within the memory space
of any C, Objective-C, or C++ 32- or 64-bit client
program. Built and documented anew, {\tt JSBox}
is faithful to the \TeX\ language's primitives,
syntax, typesetting algorithms, measurements, data
structures, and speed. At the same time, it fixes---in an
upwardly compatible manner---a variety of important
problems with or lacun\ae\ in the current \TeX\ engine's
implementation. These include integral support for
21-bit Unicode, namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more. Especially
pertinent to interactive applications---such as an
eBook reader---is that all of a document's pages can
optionally be kept as \TeX\ data structures in memory
after a job is done, with direct random access of any
requested page exported to the client program's screen
without file I/O or DVI or PDF conversion if unneeded.
Tracing (including recursive expansion, re-tracing
interrupted commands, alignments, math, etc.) and
all error messages have been significantly improved
over what \TeX\ does. The author will demo what
{\tt JSBox} can do now, and discuss what it
could do in the future.

A work in progress, {\tt JSBox} is a self-contained
library---written in portable C---that instantiates sandbox-able,
\TeX-language interpreters within the memory space
of any C, Objective-C, or C++ 32- or 64-bit client
program. Built and documented anew, {\tt JSBox}
is faithful to the \TeX\ language's primitives,
syntax, typesetting algorithms, measurements, data
structures, and speed. At the same time, it fixes---in an
upwardly compatible manner---a variety of important
problems with or lacun\ae\ in the current \TeX\ engine's
implementation. These include integral support for
21-bit Unicode, namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more. Especially
pertinent to interactive applications---such as an
eBook reader---is that all of a document's pages%
\includegraphics{-7cm}{7cm}{greybox.png}{Lorem ipsum dolor sit
amet, consectetur adipiscing elit. Donec a diam lectus.}
can optionally be kept as \TeX\ data structures in memory
after a job is done, with direct random access of any
requested page exported to the client program's screen
without file I/O or DVI or PDF conversion if unneeded.
Tracing (including recursive expansion, re-tracing
interrupted commands, alignments, math, etc.) and
all error messages have been significantly improved
over what \TeX\ does. The author will demo what
{\tt JSBox} can do now, and discuss what it
could do in the future.

A work in progress, {\tt JSBox} is a self-contained
library---written in portable C---that instantiates sandbox-able,
\TeX-language interpreters within the memory space
of any C, Objective-C, or C++ 32- or 64-bit client
program. Built and documented anew, {\tt JSBox}
is faithful to the \TeX\ language's primitives,
syntax, typesetting algorithms, measurements, data
structures, and speed. At the same time, it fixes---in an
upwardly compatible manner---a variety of important
problems with or lacun\ae\ in the current \TeX\ engine's
implementation. These include integral support for
21-bit Unicode, namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more. Especially
pertinent to interactive applications---such as an
eBook reader---is that all of a document's pages can
optionally be kept as \TeX\ data structures in memory
after a job is done, with direct random access of any
requested page exported to the client program's screen
without file I/O or DVI or PDF conversion if unneeded.
Tracing (including recursive expansion, re-tracing
interrupted commands, alignments, math, etc.) and
all error messages have been significantly improved
over what \TeX\ does. The author will demo what
{\tt JSBox} can do now, and discuss what it
could do in the future.
\bye

Das Problem ist (glaube ich), dass irgendwo ein eingefügt wird, was durch das am Ende des Makros \baselineskiprückgängig gemacht wird . Dadurch erscheinen das ganze Bild und der Text neben dem Bild auf der nächsten Seite. Wenn man den Aufruf eine Zeile nach oben verschiebt (vor ), erscheint das Bild auf der ersten Seite, aber mit einer Zeile Fließtext unter dem Bild und dem Bildunterschriftentext.\vskip-\baselineskip\baselineskip\includegraphicsEspecially …

UPDATE 3:

Das Auswerfen der Seite erfolgte beim Einfügen des Bildes in figflow.tex. Ich habe \nobreakan einer Stelle ein hinzugefügt (mit markiert ^^^) und das Auswerfen war weg:

% FIGFLOW:  plain TEX macro by Ian Hutchinson, 21 Oct 95.
% Copyright 1995 Ian Hutchinson.
% You may freely use, modify, and/or distribute this file, without limitation.
% Make text flow round figure.
% Usage: \figflow{<width>}{<height>}{<[Figure+][Caption]>}
% at start of new paragraph. Figure top starts at insert.
% #1 figure width dimen. If negative, fig on right, else left.
% #2 figure height (including caption) dimen. (E.g.: 4 truein)
% #3 \special for figure if desired, then \vfill caption. (Both optional).
% Example: figflow{4 truein}{5 truein}{\epsfbox{figure.ps}\vfill Figure 1.}
% User is responsible for the figure fitting within the space defined.
% If figure won't fit on page, it is moved over the page break.
% If a new figflow starts before the old one is finished, a message is given
% and the second figure is skipped. Fix manually.
% Does not work for Latex.

\newdimen\pageremains\newdimen\pdepth
\newdimen\figwidth
\newdimen\figheight
\newcount\figlines
\newcount\flevel

\def\figflow#1#2#3{
\ifnum\flevel>0
\message{******Figure collision. Ignoring second figure.******}
\else
\figwidth=#1
\figheight=#2
\def\contents{#3}
% Put figure contents in an appropriate box.
\def\figure{\let\temp=\par \let\par=\plainpar
  \line{\overfullrule=0pt%  Avoid black box.
   \ifdim \figwidth<0pt \hsize=-\figwidth \hss\else \hsize=\figwidth\fi
   \advance \hsize by -10pt% Give a little extra hspace.
   \vbox to \figheight{\vfil\noindent\contents}
   \ifdim \figwidth>0pt \hss\fi
  }\nobreak\vskip-\figheight
%  ^^^^^^^^ inserted by MK
  \let\par=\temp%
}
% […] remainder of file is the same

Das einzige Problem, das jetzt noch besteht, ist, dass die letzten beiden Zeilen auf der Seite auf die nächste verschoben werden (einschließlich der Verkürzung). Ich denke, es hat etwas mit \widowpenaltyund zu tun \clubpenalty, aber das Herumspielen mit diesen Variablen hat das Problem nicht gelöst.

Wir sind auch für jede bessere Lösung der oben genannten Probleme dankbar.

UPDATE 4:

Das manuelle Hinzufügen eines \nobreak\̺nach dem letzten Wort im Fließtext auf der ersten Seite (also nach a variety of important) löst zwar das in Update 3 angesprochene Problem, allerdings ist nun auch an dieser Stelle ein Zeilenumbruch verboten, was zu einer (zu) engen Zeile und unnötiger Silbentrennung führt. Wie lässt sich das lösen und natürlich auch automatisieren?

UPDATE 5:

Bei einer Art Stresstest bin ich auf ein weiteres Problem gestoßen. Ich habe zwei Makros hinzugefügt \toppicture, um vor dem Start \midpicturejeweils ein \ejectoder ein hinzuzufügen (bitte schrecken Sie nicht vor der Länge dieses Codes zurück, der Großteil davon ist Blindtext):\par\includegraphics

\newbox\gridbox
\setbox\gridbox\line{%
  \special{color push rgb .8 .8 1}%
  \vrule height\baselineskip width0pt \hrulefill
  \special{color pop}}
\def\grid{\vtop to0pt{\hrule height0pt\kern-\dimexpr\baselineskip-\topskip\topskip=10pt\relax
    \vbox to\dimexpr\vsize+2pt\relax{\leaders\copy\gridbox\vfil}\vss}}
\def\pagebody{\vbox to\vsize{\boxmaxdepth=\maxdepth \grid\pagecontents}}

\input figflow
\parskip=0pt \frenchspacing \raggedbottom
\widowpenalty=10000 \clubpenalty=10000
\font\smallrm=cmr8

%\toppicture params:
%  #1 <dimen>  width of picture
%  #2 <dimen>  height of picture
%  #3 <string> file name
%  #4 <string> caption text
\def\toppicture#1#2#3#4{%
   {\parfillskip=0pt\par}\eject%
   \includegraphics{#1}{#2}{#3}{#4}
}

%\midpicture params:
%  #1 <dimen>  width of picture
%  #2 <dimen>  height of picture
%  #3 <string> file name
%  #4 <string> caption text
\def\midpicture#1#2#3#4{%
   {\parfillskip=0pt\par}
   \includegraphics{#1}{#2}{#3}{#4}
}

\def\includegraphics#1#2#3#4{%
   \dimen0=#1 \ifdim#1<0pt \dimen0=-\dimen0 \fi
   \dimen2=#2
   \dimen4=#1 \advance\dimen4 by \ifdim#1<0pt-\fi 1pc
   \setbox0=\vbox {\XeTeXpicfile #3 width\dimen0 height #2}
   \setbox2=\vbox{\hsize=\dimen0 \baselineskip=9.5pt\noindent\smallrm #4\par}
   \advance\dimen2 by \ht2
   \divide\dimen2 by \baselineskip
   \multiply\dimen2 by \baselineskip
   \advance\dimen2 by \baselineskip
   \setbox4=\vbox to\dimen2{\vss\box0\vskip2mm\box2}
   \figflow{\dimen4}{\dimen2}{}
   \line{\ifdim#1<0pt\hfill\fi\vtop to0pt{\kern0pt\box4\vss}\hfil}
   \nobreak\vskip-\baselineskip
   \noindent\ignorespaces}

\noindent
A work in progress, {\tt JSBox} is a self-contained
library---written in portable C---that instantiates sandbox-able,
\TeX-language interpreters within the memory space
of any C, Objective-C, or C++ 32- or 64-bit client
program. Built and documented anew, {\tt JSBox}
is faithful to the \TeX\ language's primitives,
syntax, typesetting algorithms, measurements, data
structures, and speed. At the same time, it fixes---in an
upwardly compatible manner---a variety of important
problems with or lacun\ae\ in the current \TeX\ engine's
implementation. These include integral support for
21-bit Unicode, namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more.
Especially pertinent to interactive applications---such as an
eBook reader---is that all of a document's pages can
optionally be kept as \TeX\ data structures in memory
after a job is done, with direct random access of any
requested page exported to the client program's screen
without file I/O or DVI or PDF conversion if unneeded.
Tracing (including recursive expansion, re-tracing
interrupted commands, alignments, math, etc.) and
all error messages have been significantly improved
over what \TeX\ does. The author will demo what
{\tt JSBox} can do now, and discuss what it
could do in the future.

A work in progress, {\tt JSBox} is a self-contained
library---written in portable C---that instantiates sandbox-able,
\TeX-language interpreters within the memory space
of any C, Objective-C, or C++ 32- or 64-bit client
program. Built and documented anew, {\tt JSBox}
is faithful to the \TeX\ language's primitives,
syntax, typesetting algorithms, measurements, data
structures, and speed. At the same time, it fixes---in an
upwardly compatible manner---a variety of important
problems with or lacun\ae\ in the current \TeX\ engine's
implementation. These include integral support for
21-bit Unicode, namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more. Especially
pertinent to interactive applications---such as an
eBook reader---is that all of a document's pages can
optionally be kept as \TeX\ data structures in memory
after a job is done, with direct random access of any
requested page exported to the client program's screen
without file I/O or DVI or PDF conversion if unneeded.
Tracing (including recursive expansion, re-tracing
interrupted commands, alignments, math, etc.) and
all error messages have been significantly improved
over what \TeX\ does. The author will demo what
{\tt JSBox} can do now, and discuss what it
could do in the future.

A work in progress, {\tt JSBox} is a self-contained
library---written in portable C---that instantiates sandbox-able,
\TeX-language interpreters within the memory space
of any C, Objective-C, or C++ 32- or 64-bit client
program. Built and documented anew, {\tt JSBox}
is faithful to the \TeX\ language's primitives,
syntax, typesetting algorithms, measurements, data
structures, and speed. At the same time, it fixes---in an
upwardly compatible manner---a variety of important
problems with or lacun\ae\ in the current \TeX\ engine's
implementation. These include integral support for
21-bit Unicode, namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more.
Especially pertinent to interactive applications---such as an
eBook reader---is that all of a document's pages
\midpicture{-7cm}{7cm}{greybox.png}{Lorem ipsum dolor sit amet, consectetur adipiscing elit. Donec a diam lectus.}
can optionally be kept as \TeX\ data structures in memory
after a job is done, with direct random access of any
requested page exported to the client program's screen
without file I/O or DVI or PDF conversion if unneeded.
Tracing (including recursive expansion, re-tracing
interrupted commands, alignments, math, etc.) and
all error messages have been significantly improved
over what \TeX\ does. The author will demo what
{\tt JSBox} can do now, and discuss what it
could do in the future.

A work in progress, {\tt JSBox} is a self-contained
library---written in portable C---that instantiates sandbox-able,
\TeX-language interpreters within the memory space
of any C, Objective-C, or C++ 32- or 64-bit client
program. Built and documented anew, {\tt JSBox}
is faithful to the \TeX\ language's primitives,
syntax, typesetting algorithms, measurements, data
structures, and speed. At the same time, it fixes---in an
upwardly compatible manner---a variety of important
problems with or lacun\ae\ in the current \TeX\ engine's
implementation. These include integral support for
21-bit Unicode,
%\midpicture{7cm}{7cm}{greybox.png}{Lorem ipsum dolor sit amet, consectetur adipiscing elit. Donec a diam lectus.}
namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more.
These include integral support for
21-bit Unicode, namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more. These include integral support for
21-bit Unicode, namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more. Especially
pertinent to interactive applications---such as an
eBook reader---is that all of a document's pages can
optionally be kept as \TeX\ data structures in memory
after a job is done, with direct random access of any
requested page exported to the client program's screen
without file I/O or DVI
\midpicture{7cm}{7cm}{greybox.png}{Lorem ipsum dolor sit amet, consectetur adipiscing elit. Donec a diam lectus.}
or PDF conversion if unneeded.
Tracing (including recursive expansion, re-tracing
interrupted commands, alignments, math, etc.) and
all error messages have been significantly improved
over what \TeX\ does. The author will demo what
{\tt JSBox} can do now, and discuss what it
could do in the future.

%\toppicture{7cm}{7cm}{greybox.png}{Lorem ipsum dolor sit amet, consectetur adipiscing elit. Donec a diam lectus.}
A work in progress, {\tt JSBox} is a self-contained
library---written in portable C---that instantiates sandbox-able,
\TeX-language interpreters within the memory space
of any C, Objective-C, or C++ 32- or 64-bit client
program. Built and documented anew, {\tt JSBox}
is faithful to the \TeX\ language's primitives,
syntax, typesetting algorithms, measurements, data
structures, and speed. At the same time, it fixes---in an
upwardly compatible manner---a variety of important %\nobreak\
problems with or lacun\ae\ in the current \TeX\ engine's
implementation. These include integral support for
21-bit Unicode, namespaces, OpenType font tables
and metrics, job-specific 8-bit to 21-bit Unicode
mapping, run-time settable compatibility levels,
full 32-bit fixed-point math, and more. Especially
pertinent to interactive applications---such as an
eBook reader---is that all of a document's pages can
optionally be kept as \TeX\ data structures in memory
after a job is done, with direct random access of any
requested page exported to the client program's screen
without file I/O or DVI or PDF conversion if unneeded.
Tracing (including recursive expansion, re-tracing
interrupted commands, alignments, math, etc.) and
all error messages have been significantly improved
over what \TeX\ does. The author will demo what
{\tt JSBox} can do now, and discuss what it
could do in the future.
\bye

Kommentiere zuerst den zweiten \midpictureaus (er sollte in Zeile 169 stehen) und führe XeTeX aus. So oder so kann ich jetzt die Änderungen, die ich in Update 3 (Hinzufügen \nobreakzu figflow.tex) und Update 4 (Hinzufügen \nobreak\zur Quellkopie) vorgenommen habe, weglassen und alles ist einwandfrei gesetzt. Das ist sehr merkwürdig, da ich meines Wissens sonst nichts geändert habe. Der Text fließt korrekt um das Bild und die Bildunterschrift.

Bitte heben Sie jetzt den Kommentar aus dem \midpicturegerade auskommentierten Aufruf auf und führen Sie TeX erneut aus. Jetzt beschwert es sich über das Einfügen eines }direkt vor einem \endgroup. Das klingt für mich seltsam. Was passiert hier?

Drittens, kommentieren Sie diese Zeile erneut aus und entfernen Sie die Kommentarzeichen \midpicturein Zeile 149. Jetzt wird figflow.tex eine Bildkollision bemängeln, wahrscheinlich weil die Verarbeitung der Zeilen neben dem ersten Bild noch nicht abgeschlossen ist, obwohl ich das \midpictureMakro nach dem letzten Wort in der Zeile aufgerufen habe. Dies bedeutet, dass man zwei Bilder nicht direkt untereinander platzieren kann (sie sollten nicht kollidieren). Wie kann man diese Kollision vermeiden?

Viertens, kommentieren Sie Zeile 149 erneut aus und entfernen Sie das einzige \toppicture, in Zeile 178, aus dem Kommentar. Seltsamerweise versagt TeX diesmal nicht bei einem zweiten Aufruf von \figflowlike, als Zeile 169 aus dem Kommentar entfernt wurde. Das Ergebnis sind zwei korrekt gesetzte Seiten und eine neue Seite mit dem Bild oben links. Nur ist jetzt alles (Haupttext, Bild und Bildunterschrift) etwas ungleichmäßig. Was ist hier falsch?

Antwort1

Ich schlage vor, dies nur zu verwenden, \figflowum geeigneten Platz für das Bild zu schaffen und die Bildplatzierung unter unserer Kontrolle zu lassen.

\def\includegraphics#1#2#3#4{
{\parfillskip=0pt\par}\dimen0=#1
\dimen1=#2
\advance\dimen0 by 1pc
\setbox0=\vbox to #2{\hsize=#1
\XeTeXpicfile #3 width #1 height #2}
\setbox1=\vbox{\hsize=#1{\noindent\it #4\par}}
\advance\dimen1 by \ht1
\divide\dimen1 by \baselineskip
\multiply\dimen1 by \baselineskip
\advance\dimen1 by 1\baselineskip
\setbox2=\vbox to \dimen1{\vfil\box0\vskip2mm\box1}
   % PO changes in OP's code:
  \figflow{\dimen0}{\dimen1}{}%
  \vtop to0pt{\kern0pt\box2\vss}\nobreak\vskip-\baselineskip
\noindent\ignorespaces}

Wenn Sie „setzen“ \kern-\baselineskipstatt „ \kern0ptinnen“ wählen \vtop, wird das Bild eine Zeile weiter oben platziert.

Bearbeiten: Unter Berücksichtigung des Kommentars habe ich eine zweite Version des Codes hinzugefügt, bei der der \baselineskipText unter dem Bild beliebig sein kann und der erste Parameter des \includegraphicsMakros negativ sein kann. Dann \dimen0ist der absolute Wert dieses Parameters und der \dimen2wird neu als plus oder minus 1pc eingeführt #1(fügt den Rand in Abhängigkeit vom Vorzeichen des hinzu #1).

\def\includegraphics#1#2#3#4{%
   {\parfillskip=0pt\par}
   \dimen0=#1 \ifdim#1<0pt \dimen0=-\dimen0 \fi
   \dimen1=#2
   \dimen2=#1 \advance\dimen2 by \ifdim#1<0pt-\fi 1pc
   \setbox0=\vbox {\XeTeXpicfile #3 width\dimen0 height #2}
   \setbox1=\vbox{\hsize=\dimen0 \noindent\it #4\par}
   \advance\dimen1 by \ht1
   \divide\dimen1 by \baselineskip
   \multiply\dimen1 by \baselineskip
   \advance\dimen1 by 1\baselineskip
   \setbox2=\vbox to\dimen1{\vss\box0\vskip2mm\box1}
   \figflow{\dimen2}{\dimen1}{}%
   \line{\ifdim#1<0pt\hfill\fi\vtop to0pt{\kern0pt\box2\vss}\hfil}
   \nobreak\vskip-\baselineskip
   \noindent\ignorespaces}

Bearbeitung2:In Anbetracht der Aktualisierungen Ihrer Frage habe ich beschlossen, dass Sie das Makro \oblomaus meinem Buch ausprobieren könnenTeXbook naruby(Seiten 236 und 237). Die vollständige PDF-Version dieses Buches ist verfügbar, allerdings nur in tschechischer Sprache.

Der Name des Makros \oblomleitet sich vom tschechischen Wort „etwas umsetzen“ ab. Dieses Makro erstellt im nächsten Absatz (oder in mehreren Absätzen) einen weißen rechteckigen Raum. Mein nächster Code hier verwendet dieses Makro (benennt aber die Trennwörter um). Die Verwendung dieses Makros ist:

\oblom <width> from <linenum1> indent <linenum2>

wobei <width>die Breite des rechteckigen Bereichs, <linenum1>die Nummer der ersten eingerückten Zeile und <linenum2>die Anzahl der eingerückten Zeilen ist. Wenn <width>negativ ist, befindet sich der rechteckige Bereich auf der rechten Seite. Beispiel:

\oblom 5cm from 3 indent 5

bedeutet, dass fünf Zeilen (einschließlich dieser) um 5 cm von der dritten Zeile eingerückt werden. Die ersten beiden Zeilen werden nicht eingerückt und haben ihre normale Breite.

Das Makro \oblommuss zwischen Absätzen verwendet werden und beeinflusst die Form des nächsten oder mehrerer Absätze. Der Hauptvorteil besteht darin, dass Sie den Absatz nicht genau an der Stelle beenden müssen, an der die Einrückung beginnt. Beachten Sie Ihre vorherigen Beispiele, in denen Sie dies tun müssen, {\parfillskip=0pt\par}was zu Komplikationen führt.

Mein nächster Code verwendet \oblomund definiert das Makro \flowpic:

\flowpic from <linenum> width <width> {<picfile>} {<caption>}

Zum Beispiel

\flowpic from 3 width -7cm {greybox.png}
    {Lorem ipsum dolor sit amet, consectetur adipiscing elit. Donec a diam lectus.}

fügt das Bild greybox.pngmit der angegebenen Überschrift aus der dritten Zeile des nächsten Absatzes auf der rechten Seite ein. Die Breite des Bildes beträgt 7 cm minus 1 cm, da 1 cm der Abstand zwischen Bild und Text ist. Sie müssen das Paket nicht verwenden figflow.

Der Code besteht aus drei Teilen. Der erste Teil ist die Definition des \oblomMakros, das ausTeXbook naruby. Dieses Makro berechnet \parshapeParameter und verwendet \parshape. Der zweite Teil definiert das Makro \piczum Einfügen von Bildern mit vorgegebener Breite. Die Definitionen hängen davon ab, ob XeTeX verwendet wird oder nicht. Der dritte Teil gibt an, \flowpicwas \oblomund verwendet \pic. Das Makro flowpic fügt das Bild auf derselben Seite ein, auf der es verwendet wird, wenn genügend Platz vorhanden ist. Wenn nicht, fügt flowpic das Bild auf der nächsten Seite ein, wo der letzte Absatz mit geänderter Form endet.

\newcount\shapenum \newcount\tempnum \newcount\globpar
\newdimen\ii \newdimen\ww
\newdimen\picwidth  \newbox\picbox
\catcode`\@=11
\def\oblom #1 from #2 indent #3 {\par \ii=#1 \ww=\hsize
   \ifdim\ii>\z@ \advance\ww by-\ii
   \else \advance\ww by\ii \ii=\z@ \fi
   \shapenum=1 \tempnum=0 \def\shapelist{}
   \loop \ifnum\shapenum<#2 \edef\shapelist{\shapelist\z@\hsize}
      \advance\shapenum by1 \repeat
   \loop \edef\shapelist{\shapelist\ii\ww}
      \advance\tempnum by1 \ifnum\tempnum<#3 \repeat
   \advance\shapenum by#3 \edef\shapelist{\shapelist\z@\hsize}
   \doshape}
\catcode`\@=12
\def\doshape{\globpar=0 \def\par{\ifhmode\shapepar\fi}}
\def\shapepar{\prevgraf=\globpar \parshape\shapenum\shapelist
   \endgraf \globpar=\prevgraf
   \ifnum \prevgraf<\shapenum\else \global\let\par=\endgraf \doshapeA \fi}

\ifx\XeTeXpicfile\undefined
   \def\pic #1{\hbox{\pdfximage width\picwidth {#1}\pdfrefximage\pdflastximage}}
\else
   \def\pic #1{\hbox{\XeTeXpicfile #1 width\picwidth}}
\fi

\def\flowpic from #1 width #2 #3#4{\par
   \dimen0=#2 \ifdim\dimen0<0pt \dimen0=-\dimen0 \fi
   \advance\dimen0 by -1pc %(margin around picture)
   \picwidth=\dimen0
   \setbox0=\vbox{\hsize\dimen0 \pic{#3}\kern 2mm
                  \emergencystretch=2em \noindent\it #4}
   \dimen0=\ht0
   \divide\dimen0 by\baselineskip \advance\dimen0 by1sp
   \oblom #2 from #1 indent \dimen0
   \multiply\dimen0  by\baselineskip
   \setbox\picbox=\vbox to\dimen0{\vss\box0}
   \dimen0=\pagegoal \ifdim\pagegoal=\maxdimen \dimen0=\vsize\fi
   \advance\dimen0 by-\pagetotal \advance\dimen0 by-#1\baselineskip
   \ifdim\dimen0<0pt
      \def\doshapeA{\tempnum=\prevgraf \advance\tempnum by-#1 \advance\tempnum by2
         \line{\ifdim#2<0pt \hfill\fi \vbox to0pt{\vss\vtop to0pt{\kern0pt\box\picbox\vss}%
                   \kern\the\tempnum\baselineskip}\hfil}
         \nobreak\vskip-\baselineskip
      }
   \else \def\doshapeA{}
      \line{\ifdim#2<0pt \hfill\fi
            \vtop to0pt{\kern-2\baselineskip\kern#1\baselineskip\box\picbox\vss}\hfil}
      \nobreak\vskip-\baselineskip
   \fi
}
\parindent=0pt \raggedbottom % we need the grid

Die Einschränkung dieses Makros ist: Sie können das Bild nicht am „Rand“ der Seite platzieren, wo der Seitenumbruch ist. Nur vor oder nach einem solchen Seitenumbruch. Sie können nicht zwei Bilder in einen Absatz einfügen. Die nächste Verwendung von \flowpicist nur vor dem Absatz zulässig, wo keine Zeilen durch vorherige eingerückt sind \flowpic. Wenn Sie einen sehr langen Absatz haben und hier zwei s platzieren müssen, \flowpicmüssen Sie den bekannten Trick von verwenden, {\parfillskip=0pt\par}um den vorherigen „unsichtbaren“ Absatz zu schließen.

verwandte Informationen
