Wie verschiebt man tcolorbox
den eingerahmten Titel in den Vordergrund (an eine Stelle vor dem Rahmen)? Wie Sie im Screenshot sehen können (rotes Rechteck, meine Hervorhebungen), überlappt das Raster den Titel. Dieses Verhalten ist unerwünscht.
\documentclass[]{article}
\usepackage[most]{tcolorbox}
\NewTColorBox{solution}{+O{}}{%
breakable,
enhanced,
sharpish corners,
colframe=blue!50,
colback=white,
coltitle=blue!50,
parbox = false,
fonttitle=\bfseries,
title={Solution},
attach boxed title to top center ={yshift=-\tcboxedtitleheight/2,yshifttext=-\tcboxedtitleheight/2},
halign title=flush center,
boxed title style={%
colback=white,
},
boxrule=0.5mm,top=0mm,bottom=0mm,
underlay={%
\draw[help lines,step=5mm,blue!20!white,shift={(interior.north west)}]
(interior.south west) grid (interior.north east);
},
lowerbox=ignored,
#1
}
\begin{document}
\begin{solution}
Some text
\end{solution}
\end{document}
Antwort1
Mit wird underlay boxed title
stattdessen underlay
das Raster gezeichnet, bevor der eingerahmte Titel hinzugefügt wird, wodurch der eingerahmte Titel im Vordergrund erscheint (siehe auch Seite 200 des tcolorbox
Handbuchs):
\documentclass[]{article}
\usepackage[most]{tcolorbox}
\NewTColorBox{solution}{+O{}}{%
breakable,
enhanced,
sharpish corners,
colframe=blue!50,
colback=white,
coltitle=blue!50,
parbox = false,
fonttitle=\bfseries,
title={Solution},
attach boxed title to top center ={yshift=-\tcboxedtitleheight/2,yshifttext=-\tcboxedtitleheight/2},
halign title=flush center,
boxed title style={%
colback=white,
},
boxrule=0.5mm,top=0mm,bottom=0mm,
underlay boxed title={%
\draw[help lines,step=5mm,blue!20!white,shift={(interior.north west)}]
(interior.south west) grid (interior.north east);
},
lowerbox=ignored,
#1
}
\begin{document}
\begin{solution}
Some text
\end{solution}
\end{document}
