Probleme mit Nginx hinter Haproxy

Question

Ich hoste eine Ajax-Site (AngularJS) und ihre Assets/Partials befinden sich auf meinen statischen Asset-Servern, auf denen Nginx hinter Haproxy ausgeführt wird.

Mein Setup sieht wie folgt aus:

Web -> Haproxy -> App (custom) and Static (nginx) servers

Nun kommt es von Zeit zu Zeit vor, dass bestimmte Assets (HTML-Partials) einfach nicht geladen werden oder erst nach einer oder mehreren Browser-Aktualisierungen geladen werden (die Netzwerk-Devtools von Chrome zeigen für diese Anfrage „ausstehend“ an).

Ich weiß nicht, woran das liegt, da sich die Assets/Partials alle im selben Ordner befinden und andere einfach problemlos geladen werden.

Hier sind die beiden Konfigurationen. Vielleicht fällt Ihnen etwas Verdächtiges auf?
Wie kann ich solche Probleme effizient debuggen?

haproxy.cfg.j2:(Dies ist eine Jinja2-Vorlage. Lassen Sie sich also nicht von der Vorlagensyntax verwirren.)

# requires haproxy 1.5+

global
  log 127.0.0.1 local0
  log 127.0.0.1 local1 notice
  maxconn 4096
  user haproxy
  group haproxy
  daemon


defaults
  log global
  mode http
  maxconn 4096

  # Add x-forwarded-for header
  option forwardfor
  option redispatch
  option dontlognull
  option http-server-close

  timeout connect         5s
  timeout client          30s
  timeout server          30s
  timeout tunnel          15m
  timeout http-keep-alive 1s
  timeout http-request    15s
  timeout queue           30s
  timeout tarpit          60s


frontend public
  mode http

  bind :80
  bind :443 ssl crt /etc/ssl/haproxy.pem

  acl is_app    hdr_end(Host) -i api.example.com api-stage.example.com
  acl is_static hdr_end(Host) -i example.com stage.example.com
  acl is_io     hdr_end(Host) -i example.io stage.example.io
  acl is_ws     hdr(Upgrade)  -i WebSocket

  # Redirect HTTP to HTTPS
  #
  # Make sure we don't redirect WebSocket requests otherwise
  # the browser might complain because of the returned 302 status
  #
  redirect scheme https if !{ ssl_fc } is_app !is_ws
  redirect scheme https if !{ ssl_fc } is_static !is_ws

  # To force example.io on SSL we'd need a 2nd certificate
  #
  # redirect scheme https if !{ ssl_fc } is_io !is_ws

  use_backend bk_notify if is_ws
  use_backend bk_app if is_app
  use_backend bk_files if is_io

  default_backend bk_static


backend bk_static
  reqadd X-Forwarded-Proto:\ https
  balance leastconn
  {% for m in servers.static %}
  server {{ m.name }} {{ m.private_ip_address }}:80 weight 1 maxconn 1024 check
  {% endfor %}


backend bk_app
  reqadd X-Forwarded-Proto:\ https
  balance hdr(Authorization)
  {% for m in servers.app %}
  server {{ m.name }} {{ m.private_ip_address }}:8001 weight 1 maxconn 1024 check
  {% endfor %}


backend bk_notify
  balance leastconn
  {% for m in servers.app %}
  server {{ m.name }} {{ m.private_ip_address }}:8001 weight 1 maxconn 1024 check
  {% endfor %}


backend bk_files
  reqadd X-Forwarded-Proto:\ https
  balance leastconn
  {% for m in servers.app %}
  server {{ m.name }} {{ m.private_ip_address }}:8002 weight 1 maxconn 1024 check
  {% endfor %}


listen stats :1936
  mode http
  stats enable
  stats hide-version
  stats realm Haproxy\ Statistics
  stats uri /
  stats auth iwant:thestats

nginx.conf:

user www-data;
worker_processes 4;
pid /var/run/nginx.pid;

events {
    worker_connections 768;
    # multi_accept on;
}

http {
    sendfile on;
    tcp_nopush on;
    tcp_nodelay on;
    keepalive_timeout 65;
    types_hash_max_size 2048;

    include /etc/nginx/mime.types;
    default_type application/octet-stream;

    access_log /var/log/nginx/access.log;
    error_log /var/log/nginx/error.log;

    gzip on;
    gzip_disable "msie6";
    gzip_vary on;
    gzip_proxied any;
    gzip_comp_level 6;
    gzip_buffers 16 8k;
    gzip_http_version 1.1;
    gzip_types text/plain text/css application/json application/x-javascript text/xml application/xml application/xml+rss text/javascript;

    server {
        #listen   80; ## listen for ipv4; this line is default and implied
        #listen   [::]:80 default ipv6only=on; ## listen for ipv6

        root /usr/share/nginx/www;
        index index.html index.htm;
        server_name localhost;

        location / {
            try_files $uri $uri/ /index.html;
        }

        # This block will catch static file requests, such as images, css, js
        # The ?: prefix is a 'non-capturing' mark, meaning we do not require
        # the pattern to be captured into $1 which should help improve performance
        location ~* \.(?:ico|css|js|gif|jpe?g|png|woff|eot|ttf|svg)$ {
            expires max;
            add_header Pragma public;
            add_header Cache-Control "public, must-revalidate, proxy-revalidate";
        }

        # Content that should not be cached
        location ~* \.(?:html|htm|txt)$ {
            expires 0;
            add_header Cache-Control "private, must-revalidate, proxy-revalidate";
        }

        # this prevents hidden files (beginning with a period) from being served
        location ~ /\. {
            access_log off;
            log_not_found off;
            deny all;
        }
    }
}
