Ich habe einen VPN-Tunnel zwischen einem virtuellen Azure-Netzwerk und einem Cisco 881-Router aufgebaut. Ich habe eine virtuelle Maschine im virtuellen Azure-Netzwerk, aber der Router kann die virtuelle Maschine nicht anpingen. Außerdem kann der Router die virtuelle Maschine nicht anpingen. Wenn mir also jemand helfen könnte, herauszufinden, was mir fehlt, wäre das großartig! Hier sind die Konfigurationen.
interface Tunnel1
ip address 169.254.0.1 255.255.255.0
ip tcp adjust-mss 1350
tunnel source FastEthernet4
tunnel mode ipsec ipv4
tunnel destination 104.215.95.202
tunnel protection ipsec profile vti
!
interface FastEthernet4
description Interface_to_3rd_party_ISP
ip address 97.105.10.190 255.255.255.252
ip nat outside
ip virtual-reassembly in
duplex auto
speed auto
!
interface Vlan1
description Management_interface
ip address 10.0.0.1 255.255.255.0
ip nat inside
ip virtual-reassembly in
!
ip route 0.0.0.0 0.0.0.0 97.105.10.189
ip route 172.16.0.0 255.255.255.0 Tunnel1
!
access-list 1 permit 192.168.251.0 0.0.0.255
access-list 1 permit 24.173.194.0 0.0.0.255
access-list 101 permit ip 10.0.0.0 0.0.0.255 172.16.0.0 0.0.0.255
Ich hoffe, das sind genug Informationen, damit mir jemand helfen kann, herauszufinden, warum ich keinen Ping durchführen kann. Die IP der VM, die ich anzupingen versuche, ist 172.16.0.4.
Danke schön!
Ich füge wie gewünscht einige Show-Befehle hinzu.
sh interfaces tunnel 1
Tunnel1 is up, line protocol is up
Hardware is Tunnel
Internet address is 169.254.0.1/24
MTU 17878 bytes, BW 100 Kbit/sec, DLY 50000 usec,
reliability 255/255, txload 1/255, rxload 1/255
Encapsulation TUNNEL, loopback not set
Keepalive not set
Tunnel source 97.105.10.190 (FastEthernet4), destination 104.215.95.202
Tunnel Subblocks:
src-track:
Tunnel1 source tracking subblock associated with FastEthernet4
Set of tunnels with source FastEthernet4, 1 member (includes iterators ), on interface <OK>
Tunnel protocol/transport IPSEC/IP
Tunnel TTL 255
Tunnel transport MTU 1438 bytes
Tunnel transmit bandwidth 8000 (kbps)
Tunnel receive bandwidth 8000 (kbps)
Tunnel protection via IPSec (profile "vti")
Last input never, output never, output hang never
Last clearing of "show interface" counters 1d17h
Input queue: 0/75/0/0 (size/max/drops/flushes); Total output drops: 73
Queueing strategy: fifo
Output queue: 0/0 (size/max)
5 minute input rate 0 bits/sec, 0 packets/sec
5 minute output rate 0 bits/sec, 0 packets/sec
1061 packets input, 33976 bytes, 0 no buffer
Received 0 broadcasts (0 IP multicasts)
0 runts, 0 giants, 0 throttles
0 input errors, 0 CRC, 0 frame, 0 overrun, 0 ignored, 0 abort
79 packets output, 5631 bytes, 0 underruns
0 output errors, 0 collisions, 0 interface resets
0 unknown protocol drops
0 output buffer failures, 0 output buffers swapped out
sh crypto isakmp sa
IPv4 Crypto ISAKMP SA
dst src state conn-id status
IPv6 Crypto ISAKMP SA
sh crypto ipsec sa
interface: Tunnel1
Crypto map tag: Tunnel1-head-0, local addr 97.105.10.190
protected vrf: (none)
local ident (addr/mask/prot/port): (0.0.0.0/0.0.0.0/0/0)
remote ident (addr/mask/prot/port): (0.0.0.0/0.0.0.0/0/0)
current_peer 104.215.95.202 port 500
PERMIT, flags={origin_is_acl,}
#pkts encaps: 6, #pkts encrypt: 6, #pkts digest: 6
#pkts decaps: 1065, #pkts decrypt: 1065, #pkts verify: 1065
#pkts compressed: 0, #pkts decompressed: 0
#pkts not compressed: 0, #pkts compr. failed: 0
#pkts not decompressed: 0, #pkts decompress failed: 0
#send errors 0, #recv errors 0
local crypto endpt.: 97.105.10.190, remote crypto endpt.: 104.215.95.202
plaintext mtu 1438, path mtu 1500, ip mtu 1500, ip mtu idb FastEthernet4
current outbound spi: 0xD77E621E(3615384094)
PFS (Y/N): N, DH group: none
inbound esp sas:
spi: 0xF41C8A8E(4095511182)
transform: esp-256-aes esp-sha-hmac ,
in use settings ={Tunnel, }
conn id: 422, flow_id: Onboard VPN:422, sibling_flags 80000040, crypto map: Tunnel1-head-0
sa timing: remaining key lifetime (k/sec): (4228180/3545)
IV size: 16 bytes
replay detection support: Y
Status: ACTIVE(ACTIVE)
inbound ah sas:
inbound pcp sas:
outbound esp sas:
spi: 0xD77E621E(3615384094)
transform: esp-256-aes esp-sha-hmac ,
in use settings ={Tunnel, }
conn id: 421, flow_id: Onboard VPN:421, sibling_flags 80000040, crypto map: Tunnel1-head-0
sa timing: remaining key lifetime (k/sec): (4228181/3545)
IV size: 16 bytes
replay detection support: Y
Status: ACTIVE(ACTIVE)
outbound ah sas:
outbound pcp sas:
