Ich war auf der Verwaltungsseite eines kleinen Magento 2-Entwicklerteams. Für das Problem, das ich gleich schildern werde, können Sie eine Demoseite anfordern und sie sich auch ansehen, wenn Sie die bereitgestellten Informationen unzureichend finden. Also.
Sie haben alle ihre Magento 1-Installationen hinter nginx und php-fpm7.1 eingerichtet
Ich hatte große Probleme beim Debuggen von Varnish, da dies ein umfassendes Verständnis der Headerfelder und Varnish-Zustände erfordert.
Also beschlossen sie, Demos mit Magento 2 zu machen, aber wir stellten fest, dass die Leistung im Vergleich zu Magento 1 (gleicher Stack) schrecklich ist. Nginx konnte mit Magento 1.9.2 3.000 Anfragen pro Sekunde bedienen und es gab einen Rückgang auf 50 Anfragen pro Sekunde. Natürlich funktioniert der vollständige Seitencache von Magento 2.2.1 nicht, also baten sie mich, Varnish wie empfohlen einzurichten.
BEARBEITEN: Titel geändert, um das Problem widerzuspiegeln.
Es ging nur um die Kasse und das Admin-Panel. Ich lag falsch. Das Problem liegt eigentlich nicht nur an diesen Stellen. Das Problem liegt überall vor und wird nach einer erfolgreichen Anfrage fast eine Sekunde lang angezeigt. Wenn ich die Zielseite fünfmal hintereinander lade, wird nur beim ersten Mal eine 200 und beim Rest eine 502 angezeigt.
Die Einrichtung:
Nginx bedient die Ports 80/443 und leitet den gesamten Datenverkehr an Varnish am Port 6081 (Default-Port) weiter.
Varnish arbeitet mit von Magento generiertem VCL und leitet bei Bedarf zum Backend bei 8080 weiter.
Das Problem: Siehe die Bearbeitung oben.
Typische Backend-Jobs wie Cache leeren und www.mymagento.com/Checkout/ führen zu 502. Immer wenn ich versuche, etwas in einen Einkaufswagen zu legen und zur Kasse gehe, erhalte ich eine 502. Immer wenn ich den Cache leeren oder Daten neu indizieren möchte, erhalte ich eine 502.
Was meldet Nginx zum Zeitpunkt des Ereignisses?
2017/12/14 16:16:08 [error] 17110#17110: *236271 upstream prematurely closed connection while reading response header from upstream, client: 91.140.10.184, server: dom.com, request: "GET / HTTP/2.0", upstream: "http://127.0.0.1:6081/", host: "dom.com"
2017/12/14 16:16:08 [info] 17110#17110: *236323 recv() failed (104: Connection reset by peer) while sending to client, client: 127.0.0.1, server: dom.com, request: "GET / HTTP/1.0", upstream: "fastcgi://127.0.0.1:9007", host: "dom.com"
2017/12/14 16:16:08 [error] 17110#17110: *236271 connect() failed (111: Connection refused) while connecting to upstream, client: 91.140.10.184, server: dom.com, request: "GET / HTTP/2.0", upstream: "http://127.0.0.1:6081/", host: "dom.com"
2017/12/14 16:16:09 [error] 17110#17110: *236271 upstream prematurely closed connection while reading response header from upstream, client: 91.140.10.184, server: dom.com, request: "GET / HTTP/2.0", upstream: "http://127.0.0.1:6081/", host: "dom.com"
2017/12/14 16:16:09 [info] 17110#17110: *236332 recv() failed (104: Connection reset by peer) while sending to client, client: 127.0.0.1, server: dom.com, request: "GET / HTTP/1.0", upstream: "fastcgi://127.0.0.1:9007", host: "dom.com"
2017/12/14 16:16:09 [error] 17110#17110: *236271 connect() failed (111: Connection refused) while connecting to upstream, client: 91.140.10.184, server: dom.com, request: "GET / HTTP/2.0", upstream: "http://127.0.0.1:6081/", host: "dom.com"
2017/12/14 16:16:09 [error] 17110#17110: *236271 connect() failed (111: Connection refused) while connecting to upstream, client: 91.140.10.184, server: dom.com, request: "GET / HTTP/2.0", upstream: "http://127.0.0.1:6081/", host: "dom.com"
Lackprotokoll
* << BeReq >> 294951
- Begin bereq 294950 pass
- Timestamp Start: 1513009334.530160 0.000000 0.000000
- BereqMethod GET
- BereqURL /checkout/
- BereqProtocol HTTP/1.0
- BereqHeader Host: www.mymagento.com
- BereqHeader X-Forwarded-Host: www.mymagento.com
- BereqHeader X-Real-IP: 37.6.210.242
- BereqHeader X-Forwarded-Proto: https
- BereqHeader X-Forwarded-Port: 443
- BereqHeader X-Forwarded-Proto: https
- BereqHeader Content-Length: 0
- BereqHeader user-agent: Mozilla/5.0 (Windows NT 10.0; Win64; x64; rv:57.0) Gecko/20100101 Firefox/57.0
- BereqHeader accept: text/html,application/xhtml+xml,application/xml;q=0.9,*/*;q=0.8
- BereqHeader accept-language: en-US,en;q=0.5
- BereqHeader accept-encoding: gzip, deflate, br
- BereqHeader referer: https://www.mymagento.com/catalog/product/view/id/3350/s/1510911799-kalson-elafaki-mayro/category/41/
- BereqHeader upgrade-insecure-requests: 1
- BereqHeader cookie: _ga=GA1.2.2063407653.1510934108; __zlcmid=jpgwnJ1tBFQDKV; intercom-session-xmx5ec9n=dWh5bmg4Y29Sb2FZUW9ybEN6YzJSVGpycE1CZkQvK0hhZnFJYmhNOTJmems0d3p3NkgvSWNORmVVcFRneTVFMy0tOG5JTXJ3aHFYRFlnaTUvbmM4Z1BQZz09--5a2e1ecdcaf4577b3b82a02ad1271c00b50931b1
- BereqHeader X-Forwarded-For: 37.6.210.242, 127.0.0.1
- BereqHeader X-Varnish: 294951
- VCL_call BACKEND_FETCH
- VCL_return fetch
- Backend 14 default default(127.0.0.1,,8080)
- Timestamp Bereq: 1513009334.530267 0.000107 0.000107
- Timestamp Beresp: 1513009334.720461 0.190301 0.190194
- BerespProtocol HTTP/1.1
- BerespStatus 200
- BerespReason OK
- BerespHeader Server: nginx
- BerespHeader Date: Mon, 11 Dec 2017 16:22:14 GMT
- BerespHeader Content-Type: text/html; charset=UTF-8
- BerespHeader Connection: close
- BerespHeader Vary: Accept-Encoding
- BerespHeader X-Powered-By: PHP/7.1
- BerespHeader Set-Cookie: form_key=HitLxJK4OFvkFpFq; expires=Mon, 11-Dec-2017 17:22:14 GMT; Max-Age=3600; path=/; domain=mage2secure.magedeploy.com
- BerespHeader Set-Cookie: form_key=HitLxJK4OFvkFpFq; expires=Mon, 11-Dec-2017 17:22:14 GMT; Max-Age=3600; path=/; domain=mage2secure.magedeploy.com
- BerespHeader Set-Cookie: PHPSESSID=suasda12321sgrb840ebodav186; expires=Mon, 11-Dec-2017 17:22:14 GMT; Max-Age=3600; path=/; domain=www.mymagento.com; secure; HttpOnly
- BerespHeader Set-Cookie: X-Magento-Vary=7f0ec19209469e9c448407b53fa5e756e55a0200; path=/; secure; HttpOnly
- BerespHeader Pragma: no-cache
- BerespHeader Cache-Control: max-age=0, must-revalidate, no-cache, no-store
- BerespHeader Expires: Sun, 11 Dec 2016 16:22:14 GMT
- BerespHeader X-Content-Type-Options: nosniff
- BerespHeader X-XSS-Protection: 1; mode=block
- BerespHeader X-Frame-Options: SAMEORIGIN
- TTL RFC 0 -1 -1 1513009335 1513009335 1513009334 1481473334 0
- VCL_call BACKEND_RESPONSE
- TTL VCL -1 259200 0 1513009335
- TTL VCL 120 259200 0 1513009335
- VCL_return deliver
- BerespHeader Content-Encoding: gzip
- Storage malloc Transient
- ObjProtocol HTTP/1.1
- ObjStatus 200
- ObjReason OK
- ObjHeader Server: nginx
- ObjHeader Date: Mon, 11 Dec 2017 16:22:14 GMT
- ObjHeader Content-Type: text/html; charset=UTF-8
- ObjHeader Vary: Accept-Encoding
- ObjHeader X-Powered-By: PHP/7.0.26
- ObjHeader Set-Cookie: form_key=HitLxJK4OFvkFpFq; expires=Mon, 11-Dec-2017 17:22:14 GMT; Max-Age=3600; path=/; domain=mage2secure.magedeploy.com
- ObjHeader Set-Cookie: form_key=HitLxJK4OFvkFpFq; expires=Mon, 11-Dec-2017 17:22:14 GMT; Max-Age=3600; path=/; domain=mage2secure.magedeploy.com
- ObjHeader Set-Cookie: PHPSESSID=su53asdad223sgrb83dav186; expires=Mon, 11-Dec-2017 17:22:14 GMT; Max-Age=3600; path=/; domain=mage2secure.magedeploy.com; secure; HttpOnly
- ObjHeader Set-Cookie: X-Magento-Vary=7f0ec19209469e9c448407b53fa5e756e55a0200; path=/; secure; HttpOnly
- ObjHeader Pragma: no-cache
- ObjHeader Cache-Control: max-age=0, must-revalidate, no-cache, no-store
- ObjHeader Expires: Sun, 11 Dec 2016 16:22:14 GMT
- ObjHeader X-Content-Type-Options: nosniff
- ObjHeader X-XSS-Protection: 1; mode=block
- ObjHeader X-Frame-Options: SAMEORIGIN
- ObjHeader Content-Encoding: gzip
- Fetch_Body 4 eof -
- VSL flush
- End synth
Lack VCL
vcl 4.0; import std;
# The minimal Varnish version is 4.0 For SSL offloading, pass the following header in your proxy server or load balancer: 'X-Forwarded-Proto:
# https'
backend default {
.host = "localhost";
.port = "8080";
.first_byte_timeout = 900s;
.probe = {
.url = "/health_check.php";
.timeout = 2s;
.interval = 5s;
.window = 10;
.threshold = 5;
}
}
acl purge {
"localhost";
}
sub vcl_recv {
if (req.method == "PURGE") {
if (client.ip !~ purge) {
return (synth(405, "Method not allowed"));
}
# To use the X-Pool header for purging varnish during automated deployments, make sure the X-Pool header has been added to the response in
# your backend server config. This is used, for example, by the capistrano-magento2 gem for purging old content from varnish during it's
# deploy routine.
if (!req.http.X-Magento-Tags-Pattern && !req.http.X-Pool) {
return (synth(400, "X-Magento-Tags-Pattern or X-Pool header required"));
}
if (req.http.X-Magento-Tags-Pattern) {
ban("obj.http.X-Magento-Tags ~ " + req.http.X-Magento-Tags-Pattern);
}
if (req.http.X-Pool) {
ban("obj.http.X-Pool ~ " + req.http.X-Pool);
}
return (synth(200, "Purged"));
}
if (req.method != "GET" &&
req.method != "HEAD" &&
req.method != "PUT" &&
req.method != "POST" &&
req.method != "TRACE" &&
req.method != "OPTIONS" &&
req.method != "DELETE") {
/* Non-RFC2616 or CONNECT which is weird. */
#was pi pe
return (pass);
}
# We only deal with GET and HEAD by default
if (req.method != "GET" && req.method != "HEAD") {
return (pass);
}
# Bypass shopping cart, checkout and search requests
if (req.url ~ "/checkout" || req.url ~ "/catalogsearch") {
return (pass);
}
# Bypass health check requests
if (req.url ~ "/health_check.php") {
return (pass);
}
# Set initial grace period usage status
set req.http.grace = "none";
# normalize url in case of leading HTTP scheme and domain
set req.url = regsub(req.url, "^http[s]?://", "");
# collect all cookies
std.collect(req.http.Cookie);
# Compression filter. See https://www.varnish-cache.org/trac/wiki/FAQ/Compression
if (req.http.Accept-Encoding) {
if (req.url ~ "\.(jpg|jpeg|png|gif|gz|tgz|bz2|tbz|mp3|ogg|swf|flv)$") {
# No point in compressing these
unset req.http.Accept-Encoding;
} elsif (req.http.Accept-Encoding ~ "gzip") {
set req.http.Accept-Encoding = "gzip";
} elsif (req.http.Accept-Encoding ~ "deflate" && req.http.user-agent !~ "MSIE") {
set req.http.Accept-Encoding = "deflate";
} else {
# unkown algorithm
unset req.http.Accept-Encoding;
}
}
# Remove Google gclid parameters to minimize the cache objects
set req.url = regsuball(req.url,"\?gclid=[^&]+$",""); # strips when QS = "?gclid=AAA"
set req.url = regsuball(req.url,"\?gclid=[^&]+&","?"); # strips when QS = "?gclid=AAA&foo=bar"
set req.url = regsuball(req.url,"&gclid=[^&]+",""); # strips when QS = "?foo=bar&gclid=AAA" or QS = "?foo=bar&gclid=AAA&bar=baz"
# Static files caching
if (req.url ~ "^/(pub/)?(media|static)/") {
# Static files should not be cached by default
# return (hash);
# But if you use a few locales and don't use CDN you can enable caching static files by commenting previous line (#return (pass);) and
#uncommenting next 3 lines
unset req.http.Https;
unset req.http.X-Forwarded-Proto;
unset req.http.Cookie;
}
return (hash);
}
sub vcl_hash {
if (req.http.cookie ~ "X-Magento-Vary=") {
hash_data(regsub(req.http.cookie, "^.*?X-Magento-Vary=([^;]+);*.*$", "\1"));
}
# For multi site configurations to not cache each other's content
if (req.http.host) {
hash_data(req.http.host);
} else {
hash_data(server.ip);
}
# To make sure http users don't see ssl warning
if (req.http.X-Forwarded-Proto) {
hash_data(req.http.X-Forwarded-Proto);
}
if (req.http.user-agent ~ "(?i)iPhone") {
hash_data("8");
} elsif (req.http.user-agent ~ "(?i)iPod") {
hash_data("8");
} elsif (req.http.user-agent ~ "(?i)BlackBerry") {
hash_data("8");
} elsif (req.http.user-agent ~ "(?i)Palm") {
hash_data("8");
} elsif (req.http.user-agent ~ "(?i)Googlebot\-Mobile") {
hash_data("8");
} elsif (req.http.user-agent ~ "(?i)Windows Mobile") {
hash_data("8");
} elsif (req.http.user-agent ~ "(?i)Android") {
hash_data("8");
} elsif (req.http.user-agent ~ "(?i)Opera") {
hash_data("8");
}
}
sub vcl_backend_response {
set beresp.grace = 3d;
if (beresp.http.content-type ~ "text") {
set beresp.do_esi = true;
}
if (bereq.url ~ "\.js$" || beresp.http.content-type ~ "text") {
set beresp.do_gzip = true;
}
# cache only successfully responses and 404s
if (beresp.status != 200 && beresp.status != 404) {
set beresp.ttl = 0s;
set beresp.uncacheable = true;
return (deliver);
} elsif (beresp.http.Cache-Control ~ "private") {
set beresp.uncacheable = true;
set beresp.ttl = 86400s;
return (deliver);
}
if (beresp.http.X-Magento-Debug) {
set beresp.http.X-Magento-Cache-Control = beresp.http.Cache-Control;
}
# validate if we need to cache it and prevent from setting cookie
if (beresp.ttl > 0s && (bereq.method == "GET" || bereq.method == "HEAD")) {
unset beresp.http.set-cookie;
}
# If page is not cacheable then bypass varnish for 2 minutes as Hit-For-Pass
if (beresp.ttl <= 0s ||
beresp.http.Surrogate-control ~ "no-store" ||
(!beresp.http.Surrogate-Control && beresp.http.Vary == "*")) {
# Mark as Hit-For-Pass for the next 2 minutes
set beresp.ttl = 120s;
set beresp.uncacheable = true;
}
return (deliver);
}
sub vcl_deliver {
if (resp.http.X-Magento-Debug) {
if (resp.http.x-varnish ~ " ") {
set resp.http.X-Magento-Cache-Debug = "HIT";
set resp.http.Grace = req.http.grace;
} else {
set resp.http.X-Magento-Cache-Debug = "MISS";
}
} else {
unset resp.http.Age;
}
unset resp.http.X-Magento-Debug;
unset resp.http.X-Magento-Tags;
unset resp.http.X-Powered-By;
unset resp.http.Server;
unset resp.http.X-Varnish;
unset resp.http.Via;
unset resp.http.Link;
}
sub vcl_hit {
if (obj.ttl >= 0s) {
# Hit within TTL period
return (deliver);
}
if (std.healthy(req.backend_hint)) {
if (obj.ttl + 300s > 0s) {
# Hit after TTL expiration, but within grace period
set req.http.grace = "normal (healthy server)";
return (deliver);
} else {
# Hit after TTL and grace expiration
return (fetch);
}
} else {
# server is not healthy, retrieve from cache
set req.http.grace = "unlimited (unhealthy server)";
return (deliver);
}
}
Nginx-Site-Konfiguration
server {
listen 80;
server_name www.mymagento.com;
location /.well-known/ {
default_type "text/plain";
try_files $uri =404;
}
return 301 https://$host$request_uri;
}
server {
server_name www.mymagento.com;
listen 443 ssl http2;
ssl_certificate /etc/letsencrypt/live/magento/fullchain.pem;
ssl_certificate_key /etc/letsencrypt/live/magento/privkey.pem;
# port_in_redirect off;
include https_basic.conf;
keepalive_timeout 0s;
location / {
proxy_pass http://127.0.0.1:6081;
proxy_set_header Host $http_host;
proxy_set_header X-Forwarded-Host $http_host;
proxy_set_header X-Real-IP $remote_addr;
proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
# proxy_set_header Ssl-Offloaded "1";
proxy_set_header X-Forwarded-Proto https;
proxy_set_header X-Forwarded-Port 443;
proxy_set_header X-Forwarded-Proto $scheme;
}
}
server {
server_name www.mymagento.com;
listen 8080;
root /home/magento/public_html/pub/;
set $HTTPS_FORWARD on;
index index.php;
charset UTF-8;
error_page 404 403 = /errors/404.php;
expires off;
# PHP entry point for setup application
location ~* ^/setup($|/) {
root /home/kirakalo/public_html/;
location ~ ^/setup/index.php {
# if (!-e $request_filename) { rewrite / /index.php last; }
fastcgi_pass 127.0.0.1:9007;
fastcgi_index index.php;
fastcgi_read_timeout 600s;
fastcgi_connect_timeout 600s;
fastcgi_param SCRIPT_FILENAME $document_root$fastcgi_script_name;
# fastcgi_param PATH_TRANSLATED $document_root$fastcgi_script_name;
include fastcgi_params;
# access_log /var/log/nginx/phpfpmonly-access.log;
}
location ~ ^/setup/(?!pub/). {
deny all;
}
location ~ ^/setup/pub/ {
add_header X-Frame-Options "SAMEORIGIN";
}
}
# PHP entry point for update application
location ~* ^/update($|/) {
root /home/kirakalo/public_html/;
location ~ ^/update/index.php {
fastcgi_split_path_info ^(/update/index.php)(/.+)$;
fastcgi_pass 127.0.0.1:9007;
fastcgi_index index.php;
fastcgi_param SCRIPT_FILENAME $document_root$fastcgi_script_name;
fastcgi_param PATH_INFO $fastcgi_path_info;
# fastcgi_param PATH_TRANSLATED $document_root$fastcgi_script_name;
include fastcgi_params;
# access_log /var/log/nginx/phpfpmonly-access.log;
}
# Deny everything but index.php
location ~ ^/update/(?!pub/). {
deny all;
}
location ~ ^/update/pub/ {
add_header X-Frame-Options "SAMEORIGIN";
}
}
location / {
try_files $uri $uri/ /index.php$is_args$args;
}
location /pub/ {
location ~ ^/pub/media/(downloadable|customer|import|theme_customization/.*.xml) {
deny all;
}
alias /home/kirakalo/public_html/pub/;
add_header X-Frame-Options "SAMEORIGIN";
location ~ ^/pub/static/version {
rewrite ^/pub/static/(version\d*/)?(.*)$ /pub/static/$2 last;
}
}
location /static/ {
# Uncomment the following line in production mode
# expires max;
# Remove signature of the static files that is used to overcome the browser cache
location ~ ^/static/version {
rewrite ^/static/(version\d*/)?(.*)$ /static/$2 last;
}
location ~* .(ico|jpg|jpeg|png|gif|svg|js|css|swf|eot|ttf|otf|woff|woff2)$ {
add_header Cache-Control "public";
add_header X-Frame-Options "SAMEORIGIN";
expires +1y;
if (!-f $request_filename) {
rewrite ^/static/?(.*)$ /static.php?resource=$1 last;
}
}
location ~* .(zip|gz|gzip|bz2|csv|xml)$ {
add_header Cache-Control "no-store";
add_header X-Frame-Options "SAMEORIGIN";
expires off;
if (!-f $request_filename) {
rewrite ^/static/?(.*)$ /static.php?resource=$1 last;
}
}
if (!-f $request_filename) {
rewrite ^/static/?(.*)$ /static.php?resource=$1 last;
}
add_header X-Frame-Options "SAMEORIGIN";
}
location /media/ {
try_files $uri $uri/ /get.php$is_args$args;
location ~ ^/media/theme_customization/.*.xml {
deny all;
}
location ~* .(ico|jpg|jpeg|png|gif|svg|js|css|swf|eot|ttf|otf|woff|woff2)$ {
add_header Cache-Control "public";
add_header X-Frame-Options "SAMEORIGIN";
# expires +1y;
try_files $uri $uri/ /get.php$is_args$args;
}
location ~* .(zip|gz|gzip|bz2|csv|xml)$ {
add_header Cache-Control "no-store";
add_header X-Frame-Options "SAMEORIGIN";
expires off;
try_files $uri $uri/ /get.php$is_args$args;
}
add_header X-Frame-Options "SAMEORIGIN";
}
location /media/customer/ {
deny all;
}
location /media/downloadable/ {
deny all;
}
location /media/import/ {
deny all;
}
location ~ (health_check|op1337|index|get|static|report|404|503).php$ {
try_files $uri =404;
fastcgi_pass 127.0.0.1:9007;
fastcgi_param HTTPS $HTTPS_FORWARD;
# fastcgi_read_timeout 600s;
# fastcgi_connect_timeout 600s;
fastcgi_index index.php;
fastcgi_param SCRIPT_FILENAME $document_root$fastcgi_script_name;
fastcgi_param PATH_INFO $fastcgi_path_info;
include fastcgi_params;
access_log /var/log/nginx/phpfpmonly-access.log;
}
location ~* (.php$|.htaccess$|.git) {
deny all;
}
}
Wo versteckt sich das Problem? Liegt es an der Konfiguration oder vielleicht am Code des Teams? Ich bin völlig neu bei Varnish und der Versuch, das herauszufinden, ist zu einem echten Albtraum geworden.
Bearbeiten: Mir ist aufgefallen, dass der Warenkorb gefüllt ist, wenn ich mich als Benutzer auf der Seite anmelde, selbst wenn ich mich an-/abmelde. Beachten Sie, dass es eine Seite gibt, auf der Sie die Artikel in Ihrem Warenkorb sehen können. Die Antwort dieser Seite scheint zu sein: „Ihr Warenkorb ist leer“, auch wenn oben ein Feld vorhanden ist, in dem die zu kaufenden Artikel und die Menge/der Preis angezeigt werden.
Notiz: Dieses Problem besteht erst seit Varnish. Wie ich bereits sagte, konnte der Server mit Magento 2 nur bis zu ~100 Anfragen pro Sekunde verarbeiten, was eigentlich eine schreckliche Zahl ist.
Vielen Dank an alle, die versuchen zu helfen.
