Verwenden von OpenLDAP als Backend für Kerberos

Wir möchten unser bestehendes Sicherheits-Setup integrieren (Apache Knox, OpenLDAP,Apache Ranger) mit Kerberos. Ich habe also aus einigen Blogs verstanden, dass wir OpenLDAP als Backend für die Kerberos-Datenbank verwenden können.

Bei den folgenden Punkten treten jedoch einige Probleme und Verwirrungen auf:

  1. Während ich LDAP mit Kerberos integriere, kann ich keinen Container mit erstellen ou. Scheint es nur mit zu funktionieren cn?

  2. Nach dem Wechsel zu cnkann ich sehen, dass Kerberos mit OpenLDAP kommuniziert und Container und Principals erstellt hat, aber bei der Verbindung überApache Ambari, ich erhalte den beigefügten Fehler. Sowohl KDC als auch Sandbox befinden sich auf unterschiedlichen Servern.

Der Hostname für den KDC-Server ist kdcserver. Hinweis: Ich kann telnetüber den Port 749 auf den KDC-Server zugreifen.

Anhängen der Fehlermeldung krb5.confund der LDAP- ldiffDatei:

Bildbeschreibung hier eingeben

KRB5-Konf.

[logging]
 default = FILE:/var/log/krb5libs.log
 kdc = FILE:/var/log/krb5kdc.log
 admin_server = FILE:/var/log/kadmind.log
[libdefaults]
default_realm = ABC.COM
dns_lookup_realm = false
dns_lookup_kdc = false
ticket_lifetime = 24h
renew_lifetime = 7d
forwardable = true
allow_weak_crypto = true
default_tkt_enctypes = des-cbc-md5 des-cbc-crc des3-cbc-sha1
default_tgs_enctypes = des-cbc-md5 des-cbc-crc des3-cbc-sha1
[realms]
 ABC.COM = {
  kdc = kdcserver
  admin_server = kdcserver
  default_domain= kdcserver
  database_module = openldap_ldapconf
 }
[appdefaults]
pam = {
debug = false
ticket_lifetime = 36000
renew_lifetime = 36000
forwardable = true
krb4_convert = false
}
[dbmodules]
openldap_ldapconf = {
db_library = kldap
ldap_kerberos_container_dn = cn=kerberos,dc=abc,dc=com
ldap_kdc_dn = "cn=manager,dc=abc,dc=com"
ldap_kadmind_dn = "cn=manager,dc=abc,dc=com"
ldap_service_password_file = /etc/krb5.d/stash.keyfile
ldap_servers = ldap://kdcserver
ldap_conns_per_server = 5
}

LDAP-ldiff

dn: dc=abc,dc=com
objectClass: top
objectClass: dcObject
objectClass: organization
o: abchadoop
dc: ABC

dn: ou=groups,dc=abc,dc=com
objectClass: top
objectClass: organizationalUnit
ou: groups
description: LDAP Group

dn: ou=services,dc=abc,dc=com
objectClass: top
objectClass: organizationalUnit
ou: services

dn: cn=hcat,ou=services,dc=abc,dc=com
objectClass: top
objectClass: applicationProcess
objectClass: simpleSecurityObject
cn: hcat
userPassword: hcat-password

dn: cn=hdfs,ou=services,dc=abc,dc=com
objectClass: top
objectClass: applicationProcess
objectClass: simpleSecurityObject
cn: hdfs
userPassword: hdfs-password

dn: cn=yarn,ou=services,dc=abc,dc=com
objectClass: top
objectClass: applicationProcess
objectClass: simpleSecurityObject
cn: yarn
userPassword: yarn-password

dn: cn=mapred,ou=services,dc=abc,dc=com
objectClass: top
objectClass: applicationProcess
objectClass: simpleSecurityObject
cn: mapred
userPassword: mapred-password

dn: cn=hbase,ou=services,dc=abc,dc=com
objectClass: top
objectClass: applicationProcess
objectClass: simpleSecurityObject
cn: hbase
userPassword: hbase-password

dn: cn=zookeeper,ou=services,dc=abc,dc=com
objectClass: top
objectClass: applicationProcess
objectClass: simpleSecurityObject
cn: zookeeper
userPassword: zookeeper-password

dn: cn=oozie,ou=services,dc=abc,dc=com
objectClass: top
objectClass: applicationProcess
objectClass: simpleSecurityObject
cn: oozie
userPassword: oozie-password

dn: cn=hive,ou=services,dc=abc,dc=com
objectClass: top
objectClass: applicationProcess
objectClass: simpleSecurityObject
cn: hive
userPassword: hive-password

dn: cn=hcat,ou=groups,dc=abc,dc=com
objectClass: top
objectClass: groupOfNames
cn: hcat
member: cn=hcat,ou=services,dc=abc,dc=com

dn: cn=hdfs,ou=groups,dc=abc,dc=com
objectClass: top
objectClass: groupOfNames
cn: hdfs
member: cn=hdfs,ou=services,dc=abc,dc=com

dn: cn=yarn,ou=groups,dc=abc,dc=com
objectClass: top
objectClass: groupOfNames
cn: yarn
member: cn=yarn,ou=services,dc=abc,dc=com

dn: cn=mapred,ou=groups,dc=abc,dc=com
objectClass: top
objectClass: groupOfNames
cn: mapred
member: cn=mapred,ou=services,dc=abc,dc=com

dn: cn=hbase,ou=groups,dc=abc,dc=com
objectClass: top
objectClass: groupOfNames
cn: hbase
member: cn=hbase,ou=services,dc=abc,dc=com

dn: cn=zookeeper,ou=groups,dc=abc,dc=com
objectClass: top
objectClass: groupOfNames
cn: zookeeper
member: cn=zookeeper,ou=services,dc=abc,dc=com

dn: cn=oozie,ou=groups,dc=abc,dc=com
objectClass: top
objectClass: groupOfNames
cn: oozie
member: cn=oozie,ou=services,dc=abc,dc=com

dn: cn=hive,ou=groups,dc=abc,dc=com
objectClass: top
objectClass: groupOfNames
cn: hive
member: cn=hive,ou=services,dc=abc,dc=com

dn: cn=hadoop,ou=groups,dc=abc,dc=com
objectClass: top
objectClass: groupOfNames
cn: hadoop
member: cn=hcat,ou=services,dc=abc,dc=com
member: cn=hdfs,ou=services,dc=abc,dc=com
member: cn=yarn,ou=services,dc=abc,dc=com
member: cn=mapred,ou=services,dc=abc,dc=com
member: cn=hbase,ou=services,dc=abc,dc=com
member: cn=zookeeper,ou=services,dc=abc,dc=com
member: cn=oozie,ou=services,dc=abc,dc=com
member: cn=hive,ou=services,dc=abc,dc=com

dn: ou=temp,dc=abc,dc=com
objectClass: top
objectClass: organizationalUnit
ou: temp

dn: cn=kerberos,dc=abc,dc=com
objectClass: krbContainer
cn: kerberos

dn: cn=ABC.COM,cn=kerberos,dc=abc,dc=com
cn: ABC.COM
objectClass: top
objectClass: krbRealmContainer
objectClass: krbTicketPolicyAux
krbSubTrees: dc=abc,dc=com

dn: krbPrincipalName=K/[email protected],cn=ABC.COM,cn=kerberos,dc=abc,dc=com
krbLoginFailedCount: 0
krbMaxTicketLife: 86400
krbMaxRenewableAge: 0
krbTicketFlags: 64
krbPrincipalName: K/[email protected]
krbPrincipalExpiration: 19700101000000Z
krbPrincipalKey:: MG6gAwIBAaEDAgEBogMCAQGjAwIBAKRYMFYwVKAHMAWgAwIBAKFJMEegAwIBEq
 FABD4gACudDckNzjqfNLNduN5RERcEp/phS6+G/h0Wdup2/y+Y9bNOP0PMQdE3Fu6UJRKixPiMUPH59
 mprnoPpkQ==
krbLastPwdChange: 19700101000000Z
krbExtraData:: AAkBAAEALWmiWg==
krbExtraData:: AAItaaJaZGJfY3JlYXRpb25AU1RDSERQLkNPTQA=
krbExtraData:: AAcBAAIAAhMIAQAAAAA=
objectClass: krbPrincipal
objectClass: krbPrincipalAux
objectClass: krbTicketPolicyAux

dn: krbPrincipalName=krbtgt/[email protected],cn=ABC.COM,cn=kerberos,dc=abc,dc=com
krbLoginFailedCount: 0
krbMaxTicketLife: 86400
krbMaxRenewableAge: 0
krbTicketFlags: 0
krbPrincipalName: krbtgt/[email protected]
krbPrincipalExpiration: 19700101000000Z
krbPrincipalKey:: MIIBTKADAgEBoQMCAQGiAwIBAaMDAgEApIIBNDCCATAwVKAHMAWgAwIBAKFJME
 egAwIBEqFABD4gAHaAH+zsuGSt6J3isOKXez4Nu2LRShW6wreSizhdEyqxBO+3aJDXgLWi4WvWzc86F
 7wKyab1qt4ZwiQ16jBEoAcwBaADAgEAoTkwN6ADAgERoTAELhAAwYBS8GIaaJH4PQYo8FFMsA/GSNmv
 cjweFhdJq6NYs0mmJDJHiBIeKifNPP0wTKAHMAWgAwIBAKFBMD+gAwIBEKE4BDYYAIfx7NqeVW0Qdj3
 VY3r7A/EWzE39RTeU4YfVvOiLLF7llwnmhVBOwxS6//+8VhfbLthC/CMwRKAHMAWgAwIBAKE5MDegAw
 IBF6EwBC4QAD/64qF/jbLScov2PillRnkUwTZZC9cWqs8g2YQMNlldaGMAo5pJyGTjxAWB
krbLastPwdChange: 19700101000000Z
krbExtraData:: AAItaaJaZGJfY3JlYXRpb25AU1RDSERQLkNPTQA=
krbExtraData:: AAcBAAIAAhMIAQAAAAA=
objectClass: krbPrincipal
objectClass: krbPrincipalAux
objectClass: krbTicketPolicyAux

dn: krbPrincipalName=kadmin/[email protected],cn=ABC.COM,cn=kerberos,dc=abc,dc=com
krbLoginFailedCount: 0
krbMaxTicketLife: 10800
krbMaxRenewableAge: 0
krbTicketFlags: 4
krbPrincipalName: kadmin/[email protected]
krbPrincipalExpiration: 19700101000000Z
krbPrincipalKey:: MIIBTKADAgEBoQMCAQGiAwIBAaMDAgEApIIBNDCCATAwVKAHMAWgAwIBAKFJME
 egAwIBEqFABD4gAC2wcqF48ii/FgncQ0tCL1RoeKaJvzKduUG53bVCAVnQZgaKmD/7yU90fWLqXvw04
 0eaoGoOd3h7OUNVkjBEoAcwBaADAgEAoTkwN6ADAgERoTAELhAAaGRk0ddcEM5kHP48daKTkwOMSpA9
 OcEA5eIC8MkrTWvBCdfv051k1VlZmzcwTKAHMAWgAwIBAKFBMD+gAwIBEKE4BDYYAHfX7kKE1WMVjT6
 XO2fiGH2gKmHP2HIPohKSksmS/hkBlLT137bt4CEbkBftJO5UDBTts0IwRKAHMAWgAwIBAKE5MDegAw
 IBF6EwBC4QAPLSVWzkyPn9jsqVmqVjtNWE78Q7VlYKfzMmOLfbi75QwfUn4LdUiM5bt0dF
krbLastPwdChange: 19700101000000Z
krbExtraData:: AAItaaJaZGJfY3JlYXRpb25AU1RDSERQLkNPTQA=
krbExtraData:: AAcBAAIAAnQuQ09NAAA=
objectClass: krbPrincipal
objectClass: krbPrincipalAux
objectClass: krbTicketPolicyAux

dn: krbPrincipalName=kadmin/[email protected],cn=ABC.COM,cn=kerberos,dc=abc,dc=com
krbLoginFailedCount: 0
krbMaxTicketLife: 300
krbMaxRenewableAge: 0
krbTicketFlags: 8196
krbPrincipalName: kadmin/[email protected]
krbPrincipalExpiration: 19700101000000Z
krbPrincipalKey:: MIIBTKADAgEBoQMCAQGiAwIBAaMDAgEApIIBNDCCATAwVKAHMAWgAwIBAKFJME
 egAwIBEqFABD4gAFX+BT8lg5ixjLNaj+a7CMoZ+XXNmiyo7Ts4ULJudMIorvAYqb6Dv6jmY3fH1vXpM
 2sfzClzYPrHB7KTHjBEoAcwBaADAgEAoTkwN6ADAgERoTAELhAA5mBHHHWdu2/OcdDqLMs68DohSYjs
 c6TyhN1YElOtMm6gJVhc5uwo2G5XK2UwTKAHMAWgAwIBAKFBMD+gAwIBEKE4BDYYAGyzwsAHmYL93eN
 8sPzWEvBXuFMrRuYg4DhFBthYCWPOdb6VRx9ZCbXdSp4RHZY/M1PtN2wwRKAHMAWgAwIBAKE5MDegAw
 IBF6EwBC4QAFdl8GPHWYz1wd1aqwH5PwdoQLxUOnyVTalDphHZsNnS7EOcTttENZGl32ks
krbLastPwdChange: 19700101000000Z
krbExtraData:: AAItaaJaZGJfY3JlYXRpb25AU1RDSERQLkNPTQA=
krbExtraData:: AAcBAAIAAnQuQ09NAAA=
objectClass: krbPrincipal
objectClass: krbPrincipalAux
objectClass: krbTicketPolicyAux

dn: krbPrincipalName=kadmin/[email protected],cn=ABC.COM,cn=kerberos,dc=abc,dc=com
krbLoginFailedCount: 0
krbMaxTicketLife: 86400
krbMaxRenewableAge: 0
krbTicketFlags: 0
krbPrincipalName: kadmin/[email protected]
krbPrincipalExpiration: 19700101000000Z
krbPrincipalKey:: MG6gAwIBAaEDAgEBogMCAQGjAwIBAKRYMFYwVKAHMAWgAwIBAKFJMEegAwIBEq
 FABD4gAFY4hn8yhgHzwKY5TbObosMf9OWNXbo27WuB6fuFqbZsNZHTyaipRxXJhHv48pSRnf8BVlcdv
 8K+DTKBVQ==
krbLastPwdChange: 19700101000000Z
krbExtraData:: AAItaaJaZGJfY3JlYXRpb25AU1RDSERQLkNPTQA=
krbExtraData:: AAcBAAIAAnQuQ09NAAA=
objectClass: krbPrincipal
objectClass: krbPrincipalAux
objectClass: krbTicketPolicyAux

dn: krbPrincipalName=kadmin/[email protected],cn=ABC.COM,cn=kerberos,dc=abc,dc=com
krbLoginFailedCount: 0
krbMaxTicketLife: 10800
krbMaxRenewableAge: 0
krbTicketFlags: 4
krbPrincipalName: kadmin/[email protected]
krbPrincipalExpiration: 19700101000000Z
krbPrincipalKey:: MIIBTKADAgEBoQMCAQGiAwIBAaMDAgEApIIBNDCCATAwVKAHMAWgAwIBAKFJME
 egAwIBEqFABD4gADyFdZ7JiK9Pba54oF0hbjGPYSBq6H+qnM+U8o1oZ33mZ1BAACqEQHOrAt8qDXZYY
 UWEfb5y8V6utGc3ejBEoAcwBaADAgEAoTkwN6ADAgERoTAELhAAJT06wv7xrB6z+3+o/wfaILDr2x4U
 piJbyfkNWEe1oNJZLjvE9UMIxnfn+wYwTKAHMAWgAwIBAKFBMD+gAwIBEKE4BDYYADAgGFWbWOaeRFS
 zKcjTDJMJX4QXV1rCrZEYuE0hcaDTQjCoMXleLiD4uB0LtIqqyarCmOwwRKAHMAWgAwIBAKE5MDegAw
 IBF6EwBC4QADjw1CyXbfBBAxJqTkQrLDRwTtzDcJ8IqPVDmTGL1nzMOkNrWz7qlCJnCDkx
krbLastPwdChange: 19700101000000Z
krbExtraData:: AAItaaJaZGJfY3JlYXRpb25AU1RDSERQLkNPTQA=
krbExtraData:: AAcBAAIAAhMIAWlwYWw=
objectClass: krbPrincipal
objectClass: krbPrincipalAux
objectClass: krbTicketPolicyAux

dn: krbPrincipalName=admin/[email protected],cn=ABC.COM,cn=kerberos,dc=abc,dc=com
krbPrincipalName: admin/[email protected]
krbPrincipalKey:: MFagAwIBAaEDAgEBogMCAQGjAwIBAaRAMD4wPKAHMAWgAwIBAKExMC+gAwIBAa
 EoBCYIAM4316dUizxrzzChKklYEj+jWWooaIE1pDuORugR4rbQH5DV+w==
krbLastPwdChange: 20180309155715Z
objectClass: krbPrincipal
objectClass: krbPrincipalAux
objectClass: krbTicketPolicyAux
krbLoginFailedCount: 3
krbLastFailedAuth: 20180309155925Z
krbExtraData:: AALbrqJacm9vdC9hZG1pbkBTVENIRFAuQ09NAA==
krbExtraData:: AAgBAA==

dn: ou=people,dc=abc,dc=com
objectClass: top
objectClass: organizationalUnit
ou: people

dn: cn=ud_anwaar,ou=people,dc=abc,dc=com
objectClass: top
objectClass: person
objectClass: organizationalPerson
objectClass: inetOrgPerson
cn: ud_anwaar
sn: ud_anwaar
uid: ud_anwaar
userPassword: abcd1234
