Ich versuche, einen Initiator über IPv6 mit einem Responder zu verbinden
Beide sind eingeschaltet Ubuntu 20.04und strongswan 5.9.0
der Initiator befindet sich auf einer virtuellen Maschine (mit VMware) auf einem PC hinter einer Box, die mit meinem ISP-Netzwerk verbunden ist. Die VM verwendet ein NAT-Netzwerk mit dem Host-Computer. Der Responder ist ein Online-VPS
Der Initiator hat eine IPv6 (die seines Hosts) und kann den Responder per Ping erreichen. Seine IPv6 ist <initiator_ipv6>
Die Responder-IPv6 scheint richtig konfiguriert zu sein, ich kann damit Ping und SSH erreichen. Seine IPv6 ist<responder_ipv6>
IPv6 wurde mit der folgenden Konfiguration aktiviert (die ich von meinem VPS-Anbieter erhalten habe)
/etc/netplan/51-ipv6.yaml
network:
version: 2
ethernets:
<responder_interface>:
dhcp4: true
dhcp6: false
match:
name: <responder_interface>
addresses:
- <responder_ipv6>/128
gateway6: <responder_ipv6_gateway>
routes:
- to: <responder_ipv6_gateway>
scope: link
Beide Strongswans wurden auf dem Initiator mithilfe von configure mit den folgenden Befehlen erstellt:
./configure --prefix=<custom_dir> --with-piddir=<custom_dir>/var/run
make
make install
Sie haben die gleiche strongswan.conf, die meistens die Standarddatei mit einer Filelog-Option für einfacheres Debuggen ist
charon {
load_modular = yes
plugins {
include strongswan.d/charon/*.conf
}
filelog {
logger {
path = <custom_dir>/swanctl.log
time_format = %b %e %T
ike_name = yes
default = 1
flush_line = yes
}
}
}
include strongswan.d/*.conf
Der Responder hat die folgende swanctl.conf
connections {
# Seems to change nothing
local_addrs = <responder_ipv6>
pubkey-vm {
pools = primary-pool-ipv4, primary-pool-ipv6
local {
auth = pubkey
certs = <responder_cert>
id = <responder_id>
}
remote {
auth = pubkey
id = <initiator_id>
}
children {
client {
}
}
}
}
pools {
primary-pool-ipv4 {
# Totally arbitrary value
addrs = 10.0.0.0/24
}
primary-pool-ipv6 {
# Totally arbitrary value
addrs = 2620:0:2d0:200::7/97
}
}
Der Initiator hat folgende Konf
connections {
initiator-to-host {
remote_addrs = <responder_ip>
# Any value works, at long as vips got a value (but assigned ip will be in the respodner pool)
vips = 1.2.3.4
local {
auth = pubkey
certs = <initator_cert>
id = <initiator_id>
}
remote {
auth = pubkey
id = <responder_id>
}
children {
to-host {
start_action = none
}
}
}
}
Wenn ich versuche, eine Verbindung über den Responder IPv4 herzustellen, funktioniert es und die Verbindung wird erfolgreich hergestellt. Wenn ich die IP auf IPv6 umstelle, funktioniert es nicht und ich erhalte folgende Protokolle auf dem Responder
<pubkey-vm|4> received packet: from <initiator_ipv6>[53870] to <responder_ipv6>[4500] (80 bytes)
<pubkey-vm|4> parsed INFORMATIONAL request 2 [ D ]
<pubkey-vm|4> received DELETE for IKE_SA pubkey-vm[4]
<pubkey-vm|4> deleting IKE_SA pubkey-vm[4] between <responder_ipv6>[<responder_id>]...<initiator_ipv6>[<initiator_id>]
<pubkey-vm|4> IKE_SA deleted
<pubkey-vm|4> generating INFORMATIONAL response 2 [ ]
<pubkey-vm|4> sending packet: from <responder_ipv6>[4500] to <initiator_ipv6>[53870] (80 bytes)
<pubkey-vm|4> lease 10.0.0.1 by '<initiator_id>' went offline
<5> received packet: from <initiator_ipv6>[1016] to <responder_ipv6>[500] (392 bytes)
<5> parsed IKE_SA_INIT request 0 [ SA KE No N(NATD_S_IP) N(NATD_D_IP) N(FRAG_SUP) N(HASH_ALG) N(REDIR_SUP) ]
<5> <initiator_ipv6> is initiating an IKE_SA
<5> selected proposal: IKE:AES_CBC_128/HMAC_SHA2_256_128/PRF_AES128_XCBC/CURVE_25519
<5> remote host is behind NAT
<5> sending cert request for "C=FR, O=Test, CN=Test CA"
<5> generating IKE_SA_INIT response 0 [ SA KE No N(NATD_S_IP) N(NATD_D_IP) CERTREQ N(FRAG_SUP) N(HASH_ALG) N(CHDLESS_SUP) N(MULT_AUTH) ]
<5> sending packet: from <responder_ipv6>[500] to <initiator_ipv6>[1016] (273 bytes)
<5> received packet: from <initiator_ipv6>[53870] to <responder_ipv6>[4500] (356 bytes)
<5> parsed IKE_AUTH request 1 [ EF(2/2) ]
<5> received fragment #2 of 2, waiting for complete IKE message
<5> received packet: from <initiator_ipv6>[53870] to <responder_ipv6>[4500] (1220 bytes)
<5> parsed IKE_AUTH request 1 [ EF(1/2) ]
<5> received fragment #1 of 2, reassembled fragmented IKE message (1504 bytes)
<5> parsed IKE_AUTH request 1 [ IDi CERT N(INIT_CONTACT) CERTREQ IDr AUTH CPRQ(ADDR DNS) SA TSi TSr N(MOBIKE_SUP) N(ADD_4_ADDR) N(MULT_AUTH) N(EAP_ONLY) N(MSG_ID_SYN_SUP) ]
<5> received cert request for "C=FR, O=Test, CN=Test CA"
<5> received end entity cert "C=FR, O=Test, CN=<initiator_id>"
<5> looking for peer configs matching <responder_ipv6>[<responder_id>]...<initiator_ipv6>[<initiator_id>]
<pubkey-vm|5> selected peer config 'pubkey-vm'
<pubkey-vm|5> using trusted ca certificate "C=FR, O=Test, CN=Test CA"
<pubkey-vm|5> checking certificate status of "C=FR, O=Test, CN=<initiator_id>"
<pubkey-vm|5> certificate status is not available
<pubkey-vm|5> reached self-signed root ca with a path length of 0
<pubkey-vm|5> using trusted certificate "C=FR, O=Test, CN=<initiator_id>"
<pubkey-vm|5> authentication of '<initiator_id>' with RSA_EMSA_PKCS1_SHA2_256 successful
<pubkey-vm|5> peer supports MOBIKE
<pubkey-vm|5> authentication of '<responder_id>' (myself) with RSA_EMSA_PKCS1_SHA2_256 successful
<pubkey-vm|5> IKE_SA pubkey-vm[5] established between <responder_ipv6>[<responder_id>]...<initiator_ipv6>[<initiator_id>]
<pubkey-vm|5> scheduling rekeying in 14286s
<pubkey-vm|5> maximum IKE_SA lifetime 15726s
<pubkey-vm|5> sending end entity cert "C=FR, O=Test, CN=<responder_id>"
<pubkey-vm|5> peer requested virtual IP 1.2.3.4
<pubkey-vm|5> reassigning offline lease to '<initiator_id>'
<pubkey-vm|5> assigning virtual IP 10.0.0.1 to peer '<initiator_id>'
<pubkey-vm|5> selected proposal: ESP:AES_GCM_16_128
<pubkey-vm|5> received netlink error: Invalid argument (22)
<pubkey-vm|5> unable to add SAD entry with SPI cffdef3f (FAILED)
<pubkey-vm|5> received netlink error: Invalid argument (22)
<pubkey-vm|5> unable to add SAD entry with SPI c028512b (FAILED)
<pubkey-vm|5> unable to install inbound and outbound IPsec SA (SAD) in kernel
<pubkey-vm|5> failed to establish CHILD_SA, keeping IKE_SA
<pubkey-vm|5> generating IKE_AUTH response 1 [ IDr CERT AUTH CPRP(ADDR) N(MOBIKE_SUP) N(ADD_4_ADDR) N(NO_PROP) ]
<pubkey-vm|5> sending packet: from <responder_ipv6>[4500] to <initiator_ipv6>[53870] (1216 bytes)
Clientseitige Protokolle finden Sie hier
Starting IKE charon daemon (strongSwan 5.9.0, Linux 5.4.0-56-generic, x86_64)
loading ca certificates from '<custom_path>/etc/ipsec.d/cacerts'
loading aa certificates from '<custom_path>/etc/ipsec.d/aacerts'
loading ocsp signer certificates from '<custom_path>/etc/ipsec.d/ocspcerts'
loading attribute certificates from '<custom_path>/etc/ipsec.d/acerts'
loading crls from '<custom_path>/etc/ipsec.d/crls'
loading secrets from '<custom_path>/etc/ipsec.secrets'
loaded plugins: charon aes eap-aka eap-dynamic eap-identity eap-sim eap-tls des rc2 sha2 sha1 md5 mgf1 random nonce x509 revocation constraints pubkey pkcs1 pkcs7 pkcs8 pkcs12 pgp dnskey sshkey pem fips-prf gmp curve25519 xcbc cmac hmac drbg attr kernel-netlink resolve socket-default stroke vici updown xauth-generic counters
spawning 16 worker threads
loaded certificate 'C=FR, O=Test, CN=<responder_id>'
loaded certificate 'C=FR, O=Test, CN=<initiator_id>'
loaded certificate 'C=FR, O=Test, CN=Test CA'
loaded RSA private key
loaded RSA private key
added vici connection: host-host
vici initiate CHILD_SA 'to-host'
<host-host|1> initiating IKE_SA host-host[1] to <responder_ipv6>
<host-host|1> generating IKE_SA_INIT request 0 [ SA KE No N(NATD_S_IP) N(NATD_D_IP) N(FRAG_SUP) N(HASH_ALG) N(REDIR_SUP) ]
<host-host|1> sending packet: from <initiator_ipv6>[500] to <responder_ipv6>[500] (392 bytes)
<host-host|1> received packet: from <responder_ipv6>[500] to <initiator_ipv6>[500] (273 bytes)
<host-host|1> parsed IKE_SA_INIT response 0 [ SA KE No N(NATD_S_IP) N(NATD_D_IP) CERTREQ N(FRAG_SUP) N(HASH_ALG) N(CHDLESS_SUP) N(MULT_AUTH) ]
<host-host|1> selected proposal: IKE:AES_CBC_128/HMAC_SHA2_256_128/PRF_AES128_XCBC/CURVE_25519
<host-host|1> local host is behind NAT, sending keep alives
<host-host|1> received cert request for "C=FR, O=Test, CN=Test CA"
<host-host|1> sending cert request for "C=FR, O=Test, CN=Test CA"
<host-host|1> authentication of '<initiator_id>' (myself) with RSA_EMSA_PKCS1_SHA2_256 successful
<host-host|1> sending end entity cert "C=FR, O=Test, CN=<initiator_id>"
<host-host|1> establishing CHILD_SA to-host{1}
<host-host|1> generating IKE_AUTH request 1 [ IDi CERT N(INIT_CONTACT) CERTREQ IDr AUTH CPRQ(ADDR DNS) SA TSi TSr N(MOBIKE_SUP) N(ADD_4_ADDR) N(MULT_AUTH) N(EAP_ONLY) N(MSG_ID_SYN_SUP) ]
<host-host|1> splitting IKE message (1504 bytes) into 2 fragments
<host-host|1> generating IKE_AUTH request 1 [ EF(1/2) ]
<host-host|1> generating IKE_AUTH request 1 [ EF(2/2) ]
<host-host|1> sending packet: from <initiator_ipv6>[4500] to <responder_ipv6>[4500] (1220 bytes)
<host-host|1> sending packet: from <initiator_ipv6>[4500] to <responder_ipv6>[4500] (356 bytes)
<host-host|1> received packet: from <responder_ipv6>[4500] to <initiator_ipv6>[4500] (1216 bytes)
<host-host|1> parsed IKE_AUTH response 1 [ IDr CERT AUTH CPRP(ADDR) N(MOBIKE_SUP) N(ADD_4_ADDR) N(NO_PROP) ]
<host-host|1> received end entity cert "C=FR, O=Test, CN=<responder_id>"
<host-host|1> using trusted ca certificate "C=FR, O=Test, CN=Test CA"
<host-host|1> checking certificate status of "C=FR, O=Test, CN=<responder_id>"
<host-host|1> certificate status is not available
<host-host|1> reached self-signed root ca with a path length of 0
<host-host|1> using trusted certificate "C=FR, O=Test, CN=<responder_id>"
<host-host|1> authentication of '<responder_id>' with RSA_EMSA_PKCS1_SHA2_256 successful
<host-host|1> IKE_SA host-host[1] established between <initiator_ipv6>[<initiator_id>]...<responder_ipv6>[<responder_id>]
<host-host|1> scheduling rekeying in 13877s
<host-host|1> maximum IKE_SA lifetime 15317s
<host-host|1> installing new virtual IP 10.0.0.1
<host-host|1> received NO_PROPOSAL_CHOSEN notify, no CHILD_SA built
<host-host|1> failed to establish CHILD_SA, keeping IKE_SA
<host-host|1> peer supports MOBIKE
Irgendeine Idee, wie man das lösen könnte?
Ich habe eine Lösung mit --enable-kernel-libipsecder Option „Konfigurieren“ ausprobiert. Jetzt habe ich
./configure --prefix=<custom_dir> --with-piddir=<custom_dir>/var/run --enable-kernel-libipsec
Die Protokolle auf der Initiatorseite blieben gleich, aber ich habe unten neue Protokolle auf der Responderseite erhalten
[CFG] <pubkey-vm|1> selected proposal: ESP:AES_GCM_16_128
[ESP] <pubkey-vm|1> failed to create ESP context: unsupported AEAD algorithm AES_GCM_16
[ESP] <pubkey-vm|1> failed to create SAD entry
[ESP] <pubkey-vm|1> failed to create ESP context: unsupported AEAD algorithm AES_GCM_16
[ESP] <pubkey-vm|1> failed to create SAD entry
[IKE] <pubkey-vm|1> unable to install inbound and outbound IPsec SA (SAD) in kernel
[IKE] <pubkey-vm|1> failed to establish CHILD_SA, keeping IKE_SA
Antwort1
Wenn zwischen Ihren Hosts ein NAT besteht, wie hier von den Peers erkannt:
<5> remote host is behind NAT
Und
<host-host|1> local host is behind NAT, sending keep alives
Für die IPsec SAs (NAT-Traversal) wird UDP-Kapselung für ESP aktiviert. Dies erfordert allerdings die Unterstützung durch den IPsec-Stack, die Linux erst seit 5.8 für IPv6 bietet. Mit älteren Kerneln funktioniert dies also nicht.
Sie müssen entweder einen neueren Kernel verwenden, das NAT entfernen, wieder IPv4 verwenden oder einen alternativen IPsec-Stack verwenden (wie beispielsweise strongSwans eigenenlibipsec).
