Ich habe versucht, OpenStack mit Ceph Pool Erasure Code Backend zu konfigurieren
Ich versuche, —data-poolauf ceph.conf mit rbd default data poolwie dem folgenden Blog zu verwendenhttps://themeanti.me/technology/2018/08/23/ceph_erasure_openstack.html, aber ich habe immer noch Probleme beim Erstellen von Bildern mit einem Fehler wie diesem
HttpException: 500: Server Error for url: https://10.24.11.100:9292/v2/images/601d113d-8f61-49e8-bde1-bb0fa7eedd75/file, Internal Server Error
(os-venv) root@mon1:~# tail -f /var/log/kolla/glance/glance-api.log
2020-12-26 19:50:40.499 777 ERROR glance.common.wsgi File "/var/lib/kolla/venv/lib/python3.6/site-packages/glance_store/capabilities.py", line 176, in op_checker
2020-12-26 19:50:40.499 777 ERROR glance.common.wsgi return store_op_fun(store, *args, **kwargs)
2020-12-26 19:50:40.499 777 ERROR glance.common.wsgi File "/var/lib/kolla/venv/lib/python3.6/site-packages/glance_store/_drivers/rbd.py", line 519, in add
2020-12-26 19:50:40.499 777 ERROR glance.common.wsgi image_size, order)
2020-12-26 19:50:40.499 777 ERROR glance.common.wsgi File "/var/lib/kolla/venv/lib/python3.6/site-packages/glance_store/_drivers/rbd.py", line 397, in _create_image
2020-12-26 19:50:40.499 777 ERROR glance.common.wsgi features=int(features))
2020-12-26 19:50:40.499 777 ERROR glance.common.wsgi File "rbd.pyx", line 1266, in rbd.RBD.create
2020-12-26 19:50:40.499 777 ERROR glance.common.wsgi rbd.PermissionError: [errno 1] RBD permission error (error creating image)
Mein Pooldetail
(os-venv) root@mon1:~# ceph osd pool ls detail
pool 1 'device_health_metrics' replicated size 3 min_size 2 crush_rule 0 object_hash rjenkins pg_num 1 pgp_num 1 autoscale_mode on last_change 43 flags hashpspool stripe_width 0 pg_num_min 1 application mgr_devicehealth
pool 2 'images' replicated size 3 min_size 2 crush_rule 0 object_hash rjenkins pg_num 16 pgp_num 16 autoscale_mode off last_change 72 flags hashpspool,selfmanaged_snaps stripe_width 0 application rbd
pool 3 'volumes' replicated size 3 min_size 2 crush_rule 0 object_hash rjenkins pg_num 32 pgp_num 32 autoscale_mode off last_change 76 flags hashpspool,selfmanaged_snaps stripe_width 0 application rbd
pool 4 'vms' replicated size 3 min_size 2 crush_rule 0 object_hash rjenkins pg_num 32 pgp_num 32 autoscale_mode off last_change 79 flags hashpspool,selfmanaged_snaps stripe_width 0 application rbd
pool 5 'images_data' erasure profile images_data-profile size 6 min_size 5 crush_rule 1 object_hash rjenkins pg_num 64 pgp_num 64 autoscale_mode off last_change 82 flags hashpspool,ec_overwrites,selfmanaged_snaps stripe_width 16384 application rbd
pool 6 'volumes_data' erasure profile volumes_data-profile size 6 min_size 5 crush_rule 2 object_hash rjenkins pg_num 128 pgp_num 128 autoscale_mode off last_change 85 flags hashpspool,ec_overwrites,selfmanaged_snaps stripe_width 16384 application rbd
pool 7 'vms_data' erasure profile vms_data-profile size 6 min_size 5 crush_rule 3 object_hash rjenkins pg_num 128 pgp_num 128 autoscale_mode off last_change 88 flags hashpspool,ec_overwrites,selfmanaged_snaps stripe_width 16384 application rbd
Meine ceph.conf-Konfiguration:
[global]
cluster network = 10.24.15.0/24
fsid = 0ce82009-a4b8-4c0f-b2ac-badac219f7ea
mon host = [v2:10.24.14.11:3300,v1:10.24.14.11:6789],[v2:10.24.14.12:3300,v1:10.24.14.12:6789],[v2:10.24.14.13:3300,v1:10.24.14.13:6789]
mon initial members = mon01,mon02,mon03
osd pool default crush rule = -1
public network = 10.24.14.0/24
auth_cluster_required = cephx
auth_service_required = cephx
auth_client_required = cephx
[osd]
osd memory target = 4294967296
[client.glance]
rbd default data pool = images_data
[client.cinder]
rbd default data pool = volumes_data
[client.nova]
rbd default data pool = vms_data
OpenStack stellt eine Verbindung zu Ceph über den Schlüsselbund her, den ich aus den Replikationspools (Glance, Cinder, Nova) erstellt habe.
Irgendwelche Ideen, um dieses Problem zu lösen?
Wenn eine Konfiguration fehlt oder unklar ist, kommentieren Sie bitte unten
Antwort1
Das Hauptproblem bei diesem Fehler ist, dass der Schlüsselbund keinen Zugriff auf den Datenpool hat
der vorherige Schlüssel sieht so aus
ceph auth get-or-create client.glance mon 'allow r' osd 'allow class-read object_prefix rbd_children, allow rwx pool=images -o /etc/ceph/ceph.client.glance.keyring
und der richtige Schlüssel sollte so aussehen
ceph auth get-or-create client.glance mon 'allow r' osd 'allow class-read object_prefix rbd_children, allow rwx pool=images, allow rwx pool=images_data' -o /etc/ceph/ceph.client.glance.keyring
