ich habe Probleme beim Einrichten eines externen XMPP-Servers für Nextcloud mit meinem Ejabberd-Server in Kombination mit jsxc/xmpp-cloud-auth.
In der externen Nextcloud-Serverkonfiguration wird der Fehler angezeigt: XMPP-Domäne:https://cloud.XXX.com:5280 BOSH-URL: /http-bind/ Ungültiges XML empfangen. Vielleichthttps://cloud.XXX.com/http-bind/wurde umgeleitet. Sie sollten eine absolute URL verwenden.
Wenn ich mit dem Browser navigiere, erhalte ich die Meldung „404 Not Found at /http-bind“, außerdem wird mein Admin-Panel etwas seltsam angezeigt und zeigt nicht alles an (wie Sie auf dem Foto sehen können).
Ich verwende: Ubuntu 20.04.1 Apache2 2.4.41 ejabberd 20.12 Nextcloud JavaScript XMPP Chat 4.2.0 xmpp-cloud-auth v2.0.4
Zur Einrichtung des Systems habe ich diesen Artikel verwendet:https://github.com/jsxc/xmpp-cloud-auth/wiki/raspberry-pi-en
Hat jemand eine Idee, warum das passiert? Was könnte der Grund für einen 404-Fehler sein? Wer fragt http-bind, um eine Antwort zu erhalten? Und was sollte die gewünschte Ausgabe sein?
Die Firewall-Einstellungen scheinen in Ordnung zu sein. Im Moment sind keine DNS-Einstellungen vorgenommen, da es nur lokal ausgeführt wird. Im Netzwerk läuft ein Windows-DNS-Server, der dem Server den Hostnamen cloud.XXX.com zuweist.
Schritte zum Reproduzieren des Verhaltens
- Tippenhttps://cloud.XXX.com:5280/http-bindim Browser
- bekomme 404-Fehler
Umfeld
- JSXC-Version: JavaScript XMPP Chat 4.2.0 xmpp-cloud-auth v2.0.4
- Hostsystem und Version: Nextcloud 20.0.4 Ubuntu 20.04.1 Apache2 2.4.41
- Browseranbieter und -version: Firefox 84.0.1
- Sind irgendwelche Browser-Plugins aktiviert? NEIN
- Anbieter und Version des XMPP-Servers: ejabberd 20.12
- Funktioniert Ihr XMPP-Server wie erwartet mit anderen Clients?
NEIN...
Der virtuelle Apache2-Host ist angepasst für:
<VirtualHost *:80>
ServerAdmin webmaster@localhost
DocumentRoot /var/www
<FilesMatch ".php$">
<If "-f %{SCRIPT_FILENAME}">
SetHandler "proxy:unix:/run/php/php7.4-fpm.nextcloud.sock|fcgi://localhost"
</If>
</FilesMatch>
ErrorLog ${APACHE_LOG_DIR}/error.log
CustomLog ${APACHE_LOG_DIR}/access.log combined
ProxyPass /http-bind/ http://localhost:5280/http-bind/
ProxyPassReverse /http-bind/ http://localhost:5280/http-bind/
ProxyPreserveHost On
RewriteEngine on
RewriteCond %{SERVER_NAME} =cloud.XXX.com
RewriteRule ^ https://%{SERVER_NAME}%{REQUEST_URI} [END,NE,R=permanent]
</VirtualHost>
meine ejabberd.yml:
---
loglevel: 4
log_rotate_count: 0
log_rotate_date: ""
hosts:
- "cloud.spacyal.com"
certfiles:
- "/etc/ejabberd/ejabberd.pem"
## TLS configuration
define_macro:
'TLS_CIPHERS': "HIGH:!aNULL:!eNULL:!3DES:@STRENGTH"
'TLS_OPTIONS':
- "no_sslv3"
- "no_tlsv1"
- "no_tlsv1_1"
- "cipher_server_preference"
- "no_compression"
## 'DH_FILE': "/path/to/dhparams.pem"
## generated with: openssl dhparam -out dhparams.pem 2048
c2s_ciphers: 'TLS_CIPHERS'
s2s_ciphers: 'TLS_CIPHERS'
c2s_protocol_options: 'TLS_OPTIONS'
s2s_protocol_options: 'TLS_OPTIONS'
## c2s_dhfile: 'DH_FILE'
## s2s_dhfile: 'DH_FILE'
listen:
-
port: 5222
ip: "::"
module: ejabberd_c2s
max_stanza_size: 262144
shaper: c2s_shaper
access: c2s
starttls_required: true
protocol_options: 'TLS_OPTIONS'
-
port: 5223
ip: "::"
module: ejabberd_c2s
max_stanza_size: 262144
shaper: c2s_shaper
access: c2s
tls: true
protocol_options: 'TLS_OPTIONS'
-
port: 5269
ip: "::"
module: ejabberd_s2s_in
max_stanza_size: 524288
-
port: 5443
ip: "::"
module: ejabberd_http
tls: true
protocol_options: 'TLS_OPTIONS'
request_handlers:
/api: mod_http_api
/bosh: mod_bosh
## /captcha: ejabberd_captcha
## /upload: mod_http_upload
/ws: ejabberd_http_ws
-
port: 5280
ip: "::"
module: ejabberd_http
tls: true
protocol_options: 'TLS_OPTIONS'
request_handlers:
/admin: ejabberd_web_admin
/.well-known/acme-challenge: ejabberd_acme
-
port: 1883
ip: "::"
module: mod_mqtt
backlog: 1000
## Disabling digest-md5 SASL authentication. digest-md5 requires plain-text
## password storage (see auth_password_format option).
disable_sasl_mechanisms:
- "digest-md5"
- "X-OAUTH2"
s2s_use_starttls: required
## Store the plain passwords or hashed for SCRAM:
auth_password_format: scram
auth_method: external
extauth_program: "/usr/bin/socket localhost 23662"
auth_use_cache: false
## Full path to a script that generates the image.
## captcha_cmd: "/usr/share/ejabberd/captcha.sh"
acl:
admin:
user:
- "admin"
local:
user_regexp: ""
loopback:
ip:
- 127.0.0.0/8
- ::1/128
access_rules:
local:
allow: local
c2s:
deny: blocked
allow: all
announce:
allow: admin
configure:
allow: admin
muc_create:
allow: local
pubsub_createnode:
allow: local
trusted_network:
allow: loopback
api_permissions:
"console commands":
from:
- ejabberd_ctl
who: all
what: "*"
"admin access":
who:
access:
allow:
acl: loopback
acl: admin
oauth:
scope: "ejabberd:admin"
access:
allow:
acl: loopback
acl: admin
what:
- "*"
- "!stop"
- "!start"
"public commands":
who:
ip: 127.0.0.1/8
what:
- status
- connected_users_number
shaper:
normal: 1000
fast: 50000
shaper_rules:
max_user_sessions: 10
max_user_offline_messages:
5000: admin
100: all
c2s_shaper:
none: admin
normal: all
s2s_shaper: fast
modules:
mod_adhoc: {}
mod_admin_extra: {}
mod_announce:
access: announce
mod_avatar: {}
mod_blocking: {}
mod_bosh: {}
mod_caps: {}
mod_carboncopy: {}
mod_client_state: {}
mod_configure: {}
## mod_delegation: {} # for xep0356
mod_disco: {}
mod_echo: {}
mod_fail2ban: {}
mod_http_api: {}
## mod_http_upload:
## put_url: https://@HOST@:5443/upload
mod_last: {}
## mod_mam:
## ## Mnesia is limited to 2GB, better to use an SQL backend
## ## For small servers SQLite is a good fit and is very easy
## ## to configure. Uncomment this when you have SQL configured:
## ## db_type: sql
## assume_mam_usage: true
## default: always
mod_mqtt: {}
mod_muc:
access:
- allow
access_admin:
- allow: admin
access_create: muc_create
access_persistent: muc_create
access_mam:
- allow
default_room_options:
mam: true
mod_muc_admin: {}
mod_offline:
access_max_user_messages: max_user_offline_messages
mod_ping: {}
mod_pres_counter:
count: 5
interval: 60
mod_privacy: {}
mod_private: {}
mod_proxy65:
access: local
max_connections: 5
mod_pubsub:
access_createnode: pubsub_createnode
plugins:
- flat
- pep
force_node_config:
"eu.siacs.conversations.axolotl.*":
access_model: open
## Avoid buggy clients to make their bookmarks public
storage:bookmarks:
access_model: whitelist
mod_push: {}
mod_push_keepalive: {}
## mod_register:
## ## Only accept registration requests from the "trusted"
## ## network (see access_rules section above).
## ## Think twice before enabling registration from any
## ## address. See the Jabber SPAM Manifesto for details:
## ## https://github.com/ge0rg/jabber-spam-fighting-manifesto
## ip_access: trusted_network
mod_roster:
versioning: true
mod_s2s_dialback: {}
mod_shared_roster: {}
mod_sic: {}
mod_stream_mgmt:
resend_on_timeout: if_offline
mod_vcard:
search: false
mod_vcard_xupdate: {}
mod_version: {}
ejabberd.log sagt:
2020-12-25 22:03:38.847 [notice] <0.128.0>@lager_file_backend:154 Changed loghwm of /var/log/ejabberd/error.log to 100
2020-12-25 22:03:38.847 [notice] <0.128.0>@lager_file_backend:154 Changed loghwm of /var/log/ejabberd/ejabberd.log to 100
2020-12-25 22:03:38.908 [info] <0.114.0>@ejabberd_config:load:80 Loading configuration from /etc/ejabberd/ejabberd.yml
2020-12-25 22:03:38.919 [warning] <0.114.0>@ejabberd_config_transformer:warn_removed_module:514 Module mod_echo is deprecated and was automatically removed from the configuration. Please adjust your configuration file accordingly. Hint: run `ejabberdctl dump-config` command to view current configuration as it is seen by ejabberd.
2020-12-25 22:03:39.010 [warning] <0.114.0>@gen_mod:warn_soft_dep_fail:576 Module mod_mam is recommended for module mod_muc but is not found in the config
2020-12-25 22:03:39.023 [info] <0.114.0>@ejabberd_config:load:87 Configuration loaded successfully
2020-12-25 22:03:39.262 [info] <0.359.0>@gen_mod:start_modules:124 Loading modules for cloud.spacyal.com
2020-12-25 22:03:39.431 [info] <0.473.0>@mod_mqtt:init_topic_cache:523 Building MQTT cache for cloud.spacyal.com, this may take a while
2020-12-25 22:03:39.490 [info] <0.114.0>@ejabberd_cluster_mnesia:wait_for_sync:123 Waiting for Mnesia synchronization to complete
2020-12-25 22:03:39.629 [info] <0.114.0>@ejabberd_app:start:62 ejabberd 20.01-1 is started in the node ejabberd@localhost in 0.91s
2020-12-25 22:03:39.629 [info] <0.380.0>@ejabberd_listener:init:151 Start accepting TCP connections at [::]:5222 for ejabberd_c2s
2020-12-25 22:03:39.629 [info] <0.381.0>@ejabberd_listener:init:151 Start accepting TLS connections at [::]:5223 for ejabberd_c2s
2020-12-25 22:03:39.629 [info] <0.382.0>@ejabberd_listener:init:151 Start accepting TCP connections at [::]:5269 for ejabberd_s2s_in
2020-12-25 22:03:39.631 [info] <0.383.0>@ejabberd_listener:init:151 Start accepting TLS connections at [::]:5443 for ejabberd_http
2020-12-25 22:03:39.631 [info] <0.384.0>@ejabberd_listener:init:151 Start accepting TLS connections at [::]:5280 for ejabberd_http
2020-12-25 22:03:39.632 [info] <0.385.0>@ejabberd_listener:init:151 Start accepting TCP connections at [::]:1883 for mod_mqtt
2020-12-25 22:03:39.632 [info] <0.477.0>@ejabberd_listener:init:151 Start accepting TCP connections at 10.0.0.4:7777 for mod_proxy65_stream
2020-12-25 22:03:59.226 [info] <0.384.0>@ejabberd_listener:accept:256 (<0.531.0>) Accepted connection [::ffff:10.0.0.3]:60338 -> [::ffff:10.0.0.4]:5280
irgendwelche Ideen?? Ich wäre sehr dankbar! Ich versuche es seit 2 Tagen und kann es nicht lösen
VIELEN DANK !!
und frohe Weihnachten :-)
Antwort1
Überprüfen Sie, wie Sie die Konfiguration vornehmen. Wenn Sie ejabberd anweisen, in path zu lauschen /bosh, dann ist das die URL, die Sie verwenden müssen. Beispiel:
listen:
...
-
port: 5280
ip: "::"
module: ejabberd_http
tls: false
request_handlers:
/bosh: mod_bosh
-
port: 5443
ip: "::"
module: ejabberd_http
tls: true
request_handlers:
/bosh: mod_bosh
Das funktioniert:
$ curl http://localhost:5280/bosh/
<?xml version='1.0'?>
<!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN" "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">
<html xmlns='http://www.w3.org/1999/xhtml'><head><title>ejabberd mod_bosh</title><style>body {
...
$ curl -k https://localhost:5443/bosh/
<?xml version='1.0'?>
<!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN" "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">
<html xmlns='http://www.w3.org/1999/xhtml'><head><title>ejabberd mod_bosh</title><style>body {
...
