Ich versuche, meinen eigenen Mailserver mit Authentifizierung gegen LDAP (FreeIPA) einzurichten. Alle müssen in einem Docker-Container ausgeführt werden. Ich weiß nicht, was ich falsch mache. Vielleicht liegt es an meiner LDAP-Konfiguration.
version: '3.9'
services:
freeipa:
image: freeipa/freeipa-server:centos-9-stream-4.10.0
container_name: ipa
restart: unless-stopped
tty: true
stdin_open: true
hostname: ipa
domainname: ipa.example.local
#read_only: true
networks:
priv_network:
ipv4_address: 172.16.1.10
extra_hosts:
- "ipa.example.local:172.16.1.10"
environment:
- IPA_SERVER_HOSTNAME=ipa.example.local
- IPA_SERVER_IP=172.16.1.10
- TZ=Europe/Berlin
command:
- --realm=example.local
- --domain=example.local
- --ds-password=secret123
- --admin-password=secret123
- --no-host-dns
- --setup-dns
- --auto-forwarders
- --allow-zone-overlap
- --no-dnssec-validation
- --unattended
- --skip-mem-check
- --auto-forwarders
- --auto-reverse
sysctls:
- net.ipv6.conf.all.disable_ipv6=0
- net.ipv6.conf.lo.disable_ipv6=0
volumes:
- ./vol/freeipa/data:/data
- ./vol/freeipa/logs:/var/logs
- ./vol/freeipa/config:/root/pw-portal/config
- /sys/fs/cgroup:/sys/fs/cgroup:ro
tmpfs:
- /run
- /var/cache
- /tmp
cap_add:
- SYS_TIME
- NET_ADMIN
ports:
- 443:443
- 389:389
roundcubemail:
image: roundcube/roundcubemail:latest
container_name: roundcubemail
volumes:
- ./vol/roundcube/www:/var/www/html
- ./vol/roundcube/db/sqlite:/var/roundcube/db
ports:
- 9002:80
environment:
- ROUNDCUBEMAIL_DB_TYPE=sqlite
- ROUNDCUBEMAIL_SKIN=elastic
- ROUNDCUBEMAIL_DEFAULT_HOST=tls://172.16.1.11
- ROUNDCUBEMAIL_SMTP_SERVER=tls://172.16.1.11
networks:
priv_network:
mailserver:
image: docker.io/mailserver/docker-mailserver:latest
container_name: mailserver
hostname: mail
domainname: mail.example.local
restart: unless-stopped
volumes:
- ./vol/mailserver/data/:/var/mail/
- ./vol/mailserver/state/:/var/mail-state/
- ./vol/mailserver/logs/:/var/log/mail/
- ./vol/mailserver/config/:/tmp/docker-mailserver/
- /etc/localtime:/etc/localtime:ro
environment:
- ENABLE_SPAMASSASSIN=0
- ENABLE_CLAMAV=0
- ENABLE_FAIL2BAN=0
- ENABLE_POSTGREY=0
- ACCOUNT_PROVISIONER=LDAP
- LDAP_SERVER_HOST=ldap://ipa
- LDAP_BIND_DN=uid=admin,cn=users,cn=accounts,dc=example,dc=local
- LDAP_BIND_PW=secret123
- LDAP_SEARCH_BASE=cn=users,cn=accounts,dc=example,dc=local
- LDAP_QUERY_FILTER_DOMAIN=(mail=*@%s)
- LDAP_QUERY_FILTER_USER=(mail=%U@%s)
- LDAP_QUERY_FILTER_ALIAS=(|) # doesn't match anything
- LDAP_QUERY_FILTER_GROUP=(|) # doesn't match anything
- LDAP_QUERY_FILTER_SENDERS=(mail=%s)
- SPOOF_PROTECTION=1
- ENABLE_SASLAUTHD=1
- SASLAUTHD_MECHANISMS=ldap
- SASLAUTHD_LDAP_FILTER=(&(mail=%[email protected])(objectClass=inetOrgPerson))
- ONE_DIR=1
- PERMIT_DOCKER=host
- DOVECOT_USER_FILTER=(&(objectClass=inetOrgPerson)(mail=%u))
- DOVECOT_PASS_ATTRS==password=%{ldap:userPassword},=user=%{ldap:uid}
- DOVECOT_USER_ATTRS==home=/var/mail/%{ldap:uid},=mail=maildir:~/Maildir,uidNumber=uid,gidNumber=gid
cap_add:
- NET_ADMIN
networks:
priv_network:
ipv4_address: 172.16.1.11
networks:
priv_network:
name: ext_priv_network
driver: bridge
ipam:
driver: default
config:
- subnet: 172.16.1.0/24
gateway: 172.16.1.1
Ich habe einen Benutzer erstellt und mich zum ersten Mal bei IPA angemeldet, um ein Passwort festzulegen. Wenn ich versuche, mich bei meinem Roundcube anzumelden, erhalte ich nur eine Anmeldefehlermeldung. Der Mailserver hat die folgende Meldung ausgegeben.
Dec 25 08:59:52 mail dovecot: auth: ldap(test.user,172.16.1.2,<m+/uPaPw4pasEAEC>): unknown user (SHA1 of given password: f2b14f)
Dec 25 08:59:54 mail dovecot: imap-login: Disconnected (auth failed, 1 attempts in 2 secs): user=<test.user>, method=PLAIN, rip=172.16.1.2, lip=172.16.1.11, session=<m+/uPaPw4pasEAEC>
Dec 25 09:00:39 mail postfix/pickup[1906]: 517F864B0E: uid=101 from=<root>
Dec 25 09:00:39 mail postfix/cleanup[1910]: 517F864B0E: message-id=<[email protected]>
Dec 25 09:00:39 mail postfix/cleanup[1910]: warning: dict_ldap_lookup: Search error 2: Protocol error
Dec 25 09:00:39 mail postfix/cleanup[1910]: warning: ldap:/etc/postfix/ldap-aliases.cf lookup error for "[email protected]"
Dec 25 09:00:39 mail postfix/cleanup[1910]: warning: 517F864B0E: virtual_alias_maps map lookup problem for [email protected] -- message not accepted, try again later
Dec 25 09:00:39 mail postfix/pickup[1906]: 5228D64B0E: uid=0 from=<root>
Dec 25 09:00:39 mail postfix/cleanup[1923]: 5228D64B0E: message-id=<[email protected]>
Dec 25 09:00:39 mail postfix/cleanup[1923]: warning: dict_ldap_lookup: Search error 2: Protocol error
Dec 25 09:00:39 mail postfix/cleanup[1923]: warning: ldap:/etc/postfix/ldap-aliases.cf lookup error for "[email protected]"
Was ist die korrekte LDAP-Syntax für Dovecot DOVECOT_USER_FILTER, DOVECOT_PASS_ATTRS und DOVECOT_USER_ATTRS?
