Intel-Server mit 3 LAN-Karten.
Board Mfg : Intel
Board Product : S5000PHB
06:00.0 Ethernet controller: Intel Corporation 82571EB Gigabit Ethernet Controller (rev 06)
06:00.1 Ethernet controller: Intel Corporation 82571EB Gigabit Ethernet Controller (rev 06)
07:00.0 Ethernet controller: Intel Corporation 80003ES2LAN Gigabit Ethernet Controller (Copper) (rev 01)
07:00.1 Ethernet controller: Intel Corporation 80003ES2LAN Gigabit Ethernet Controller (Copper) (rev 01)
08:03.0 Ethernet controller: Intel Corporation 82546GB Gigabit Ethernet Controller (rev 03)
08:03.1 Ethernet controller: Intel Corporation 82546GB Gigabit Ethernet Controller (rev 03)
Vorheriger Fahrer:
root@server2[/root]#modinfo e1000
filename: /lib/modules/2.6.18-53.el5PAE/kernel/drivers/net/e1000/e1000.ko
version: 7.3.20-k2-NAPI
license: GPL
description: Intel(R) PRO/1000 Network Driver
author: Intel Corporation, <[email protected]>
Version 8 heruntergeladen und wie gewohnt gemäß der README-Datei des Treibers installiert:
root@server2[/var/tmp/e1000-8.0.35/src]#make install
make -C /lib/modules/2.6.18-53.el5PAE/build SUBDIRS=/var/tmp/e1000-8.0.35/src modules
make[1]: Entering directory `/usr/src/kernels/2.6.18-53.el5-PAE-i686'
CC [M] /var/tmp/e1000-8.0.35/src/e1000_main.o
CC [M] /var/tmp/e1000-8.0.35/src/e1000_82540.o
CC [M] /var/tmp/e1000-8.0.35/src/e1000_82542.o
CC [M] /var/tmp/e1000-8.0.35/src/e1000_82541.o
CC [M] /var/tmp/e1000-8.0.35/src/e1000_82543.o
CC [M] /var/tmp/e1000-8.0.35/src/e1000_mac.o
CC [M] /var/tmp/e1000-8.0.35/src/e1000_nvm.o
CC [M] /var/tmp/e1000-8.0.35/src/e1000_phy.o
CC [M] /var/tmp/e1000-8.0.35/src/e1000_manage.o
CC [M] /var/tmp/e1000-8.0.35/src/e1000_param.o
CC [M] /var/tmp/e1000-8.0.35/src/e1000_ethtool.o
CC [M] /var/tmp/e1000-8.0.35/src/kcompat.o
CC [M] /var/tmp/e1000-8.0.35/src/e1000_api.o
LD [M] /var/tmp/e1000-8.0.35/src/e1000.o
Building modules, stage 2.
MODPOST
CC /var/tmp/e1000-8.0.35/src/e1000.mod.o
LD [M] /var/tmp/e1000-8.0.35/src/e1000.ko
make[1]: Leaving directory `/usr/src/kernels/2.6.18-53.el5-PAE-i686'
gzip -c ../e1000.7 > e1000.7.gz
# remove all old versions of the driver
find /lib/modules/2.6.18-53.el5PAE -name e1000.ko -exec rm -f {} \; || true
find /lib/modules/2.6.18-53.el5PAE -name e1000.ko.gz -exec rm -f {} \; || true
install -D -m 644 e1000.ko /lib/modules/2.6.18-53.el5PAE/kernel/drivers/net/e1000/e1000.ko
/sbin/depmod -a || true
install -D -m 644 e1000.7.gz /usr/share/man/man7/e1000.7.gz
man -c -P'cat > /dev/null' e1000 || true
No manual entry for e1000
Danach liefrmmod e1000UndModprobe e1000. Alle Konfigurationsdateien sind noch da, wo sie waren. Abonnierenzeigt an, dass das Modul geladen ist.
Modinfo zeigt die neue Version des Treibers an.
root@server2[/]#modinfo e1000
filename: /lib/modules/2.6.18-53.el5PAE/kernel/drivers/net/e1000/e1000.ko
version: 8.0.35-NAPI
license: GPL
description: Intel(R) PRO/1000 Network Driver
author: Intel Corporation, <[email protected]>
Allerdings sind jetzt nur noch die Schnittstellen eth0 und eth1 verfügbar. eth2, eth3, eth4 und eth5 sind also nicht mehr verfügbar.
root@server2[/]#service network restart
Shutting down interface bond0: [ OK ]
Shutting down interface bond1: [ OK ]
Shutting down loopback interface: [ OK ]
Bringing up loopback interface: [ OK ]
Bringing up interface bond0: e1000 device eth2 does not seem to be present, delaying initialization.
[ OK ]
Bringing up interface bond1: e1000 device eth3 does not seem to be present, delaying initialization.
[ OK ]
Bringing up interface eth4: e1000 device eth4 does not seem to be present, delaying initialization.
[FAILED]
root@server2[/sys/class/net]#ls -la
total 0
drwxr-xr-x 7 root root 0 Feb 17 17:22 .
drwxr-xr-x 26 root root 0 Feb 17 10:40 ..
drwxr-xr-x 4 root root 0 Feb 17 10:40 bond0
drwxr-xr-x 4 root root 0 Feb 17 10:40 bond1
-rw-r--r-- 1 root root 0 Feb 17 10:40 bonding_masters
drwxr-xr-x 3 root root 0 Feb 17 17:22 eth0
drwxr-xr-x 3 root root 0 Feb 17 17:22 eth1
drwxr-xr-x 3 root root 0 Feb 17 10:40 lo
Neustart hat nicht geholfen. dmesg zeigt keinen Versuch, andere Schnittstellen bereitzustellen:
root@server2[/root]#dmesg | grep -i eth
e1000: eth0: e1000_probe: Intel(R) PRO/1000 Network Connection
e1000: eth1: e1000_probe: Intel(R) PRO/1000 Network Connection
Ethernet Channel Bonding Driver: v3.1.2 (January 20, 2007)
bonding: bond0: Unable to set eth0 as primary slave as it is not a slave.
bonding: bond0: Adding slave eth0.
bonding: bond0: enslaving eth0 as a backup interface with a down link.
bonding: bond0: Setting eth0 as primary slave.
e1000: eth0: e1000_watchdog_task: NIC Link is Up 1000 Mbps Full Duplex, Flow Control: RX/TX
bonding: bond1: Unable to set eth3 as primary slave as it is not a slave.
bonding: bond1: Adding slave eth1.
bonding: bond1: enslaving eth1 as a backup interface with a down link.
bonding: bond1: Unable to set eth3 as primary slave as it is not a slave.
e1000: eth1: e1000_watchdog_task: NIC Link is Up 1000 Mbps Full Duplex, Flow Control: RX/TX
bonding: bond0: link status definitely up for interface eth0.
bonding: bond0: making interface eth0 the new active one.
bonding: bond1: link status definitely up for interface eth1.
bonding: bond1: making interface eth1 the new active one.
Ich habe viel Zeit damit verbracht, es zum Laufen zu bringen. Ich kann mich nicht an alles erinnern, was ich versucht habe. Ich wäre dankbar für alle Vorschläge, Tipps oder Informationen darüber, wie das System Netzwerkschnittstellen anzeigt und was der Grund dafür sein könnte, dass es jetzt nicht funktioniert.
