Eduroam auf netctl

2024-6-4 • tag-icon

Meine Organisation bietet ein umfangreiches Skript zum Einrichten einer Eduroam-Verbindung an. Ich führe nicht gerne umfangreiche Skripte aus, von denen ich nicht weiß, was sie tun, und ich kann Dinge, die sie hier in Archlinux tun, nicht rückgängig machen. Also habe ich versucht, mein eigenes Netctl-Profil zu schreiben, indem ich mir das Skript angesehen habe:

#!/usr/bin/env bash
if [ -z "$BASH" ] ; then
   bash  $0
   exit
fi



my_name=$0


function setup_environment {
  bf=""
  n=""
  ORGANISATION="Šolski center Kranj"
  URL="http://www.sckr.si/tsc/eduroam"
  SUPPORT="[email protected]"
if [ ! -z "$DISPLAY" ] ; then
  if which zenity 1>/dev/null 2>&1 ; then
    ZENITY=`which zenity`
  elif which kdialog 1>/dev/null 2>&1 ; then
    KDIALOG=`which kdialog`
  else
    if tty > /dev/null 2>&1 ; then
      if  echo $TERM | grep -E -q "xterm|gnome-terminal|lxterminal"  ; then
        bf="[1m";
        n="[0m";
      fi
    else
      find_xterm
      if [ -n "$XT" ] ; then
        $XT -e $my_name
      fi
    fi
  fi
fi
}

function split_line {
echo $1 | awk  -F '\\\\n' 'END {  for(i=1; i <= NF; i++) print $i }'
}

function find_xterm {
terms="xterm aterm wterm lxterminal rxvt gnome-terminal konsole"
for t in $terms
do
  if which $t > /dev/null 2>&1 ; then
  XT=$t
  break
  fi
done
}


function ask {
     T="eduroam CAT"
#  if ! [ -z "$3" ] ; then
#     T="$T: $3"
#  fi
  if [ ! -z $KDIALOG ] ; then
     if $KDIALOG --yesno "${1}\n${2}?" --title "$T" ; then
       return 0
     else
       return 1
     fi
  fi
  if [ ! -z $ZENITY ] ; then
     text=`echo "${1}" | fmt -w60`
     if $ZENITY --no-wrap --question --text="${text}\n${2}?" --title="$T" 2>/dev/null ; then
       return 0
     else
       return 1
     fi
  fi

  yes=Y
  no=N
  yes1=`echo $yes | awk '{ print toupper($0) }'`
  no1=`echo $no | awk '{ print toupper($0) }'`

  if [ $3 == "0" ]; then
    def=$yes
  else
    def=$no
  fi

  echo "";
  while true
  do
  split_line "$1"
  read -p "${bf}$2 ${yes}/${no}? [${def}]:$n " answer
  if [ -z "$answer" ] ; then
    answer=${def}
  fi
  answer=`echo $answer | awk '{ print toupper($0) }'`
  case "$answer" in
    ${yes1})
       return 0
       ;;
    ${no1})
       return 1
       ;;
  esac
  done
}

function alert {
  if [ ! -z $KDIALOG ] ; then
     $KDIALOG --sorry "${1}"
     return
  fi
  if [ ! -z $ZENITY ] ; then
     $ZENITY --warning --text="$1" 2>/dev/null
     return
  fi
  echo "$1"

}

function show_info {
  if [ ! -z $KDIALOG ] ; then
     $KDIALOG --msgbox "${1}"
     return
  fi
  if [ ! -z $ZENITY ] ; then
     $ZENITY --info --width=500 --text="$1" 2>/dev/null
     return
  fi
  split_line "$1"
}

function confirm_exit {
  if [ ! -z $KDIALOG ] ; then
     if $KDIALOG --yesno "Really quit?"  ; then
     exit 1
     fi
  fi
  if [ ! -z $ZENITY ] ; then
     if $ZENITY --question --text="Really quit?" 2>/dev/null ; then
        exit 1
     fi
  fi
}



function prompt_nonempty_string {
  prompt=$2
  if [ ! -z $ZENITY ] ; then
    if [ $1 -eq 0 ] ; then
     H="--hide-text "
    fi
    if ! [ -z "$3" ] ; then
     D="--entry-text=$3"
    fi
  elif [ ! -z $KDIALOG ] ; then
    if [ $1 -eq 0 ] ; then
     H="--password"
    else
     H="--inputbox"
    fi
  fi


  out_s="";
  if [ ! -z $ZENITY ] ; then
    while [ ! "$out_s" ] ; do
      out_s=`$ZENITY --entry --width=300 $H $D --text "$prompt" 2>/dev/null`
      if [ $? -ne 0 ] ; then
        confirm_exit
      fi
    done
  elif [ ! -z $KDIALOG ] ; then
    while [ ! "$out_s" ] ; do
      out_s=`$KDIALOG $H "$prompt" "$3"`
      if [ $? -ne 0 ] ; then
        confirm_exit
      fi
    done
  else
    while [ ! "$out_s" ] ; do
      read -p "${prompt}: " out_s
    done
  fi
  echo "$out_s";
}

function user_cred {
  PASSWORD="a"
  PASSWORD1="b"

  if ! USER_NAME=`prompt_nonempty_string 1 "enter your userid"` ; then
    exit 1
  fi

  while [ "$PASSWORD" != "$PASSWORD1" ]
  do
    if ! PASSWORD=`prompt_nonempty_string 0 "enter your password"` ; then
      exit 1
    fi
    if ! PASSWORD1=`prompt_nonempty_string 0 "repeat your password"` ; then
      exit 1
    fi
    if [ "$PASSWORD" != "$PASSWORD1" ] ; then
      alert "passwords do not match"
    fi
  done
}
setup_environment
show_info "This installer has been prepared for ${ORGANISATION}\n\nMore information and comments:\n\nEMAIL: ${SUPPORT}\nWWW: ${URL}\n\nInstaller created with software from the GEANT project."
if ! ask "This installer will only work properly if you are a member of ${bf}Šolski center Kranj${n} and the user group: ${bf}ŠC Kranj - zaposleni in predavatelji.${n}" "Continue" 1 ; then exit; fi
if [ -d $HOME/.cat_installer ] ; then
   if ! ask "Directory $HOME/.cat_installer exists; some of its files may be overwritten." "Continue" 1 ; then exit; fi
else
  mkdir $HOME/.cat_installer
fi
# save certificates
echo "-----BEGIN CERTIFICATE-----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-----END CERTIFICATE-----

" > $HOME/.cat_installer/ca.pem
function run_python_script {
PASSWORD=$( echo "$PASSWORD" | sed "s/'/\\\'/g" )
if python << EEE1 > /dev/null 2>&1
import dbus
EEE1
then
    PYTHON=python
elif python3 << EEE2 > /dev/null 2>&1
import dbus
EEE2
then
    PYTHON=python3
else
    PYTHON=none
    return 1
fi

$PYTHON << EOF > /dev/null 2>&1
#-*- coding: utf-8 -*-
import dbus
import re
import sys
import uuid
import os

class EduroamNMConfigTool:

    def connect_to_NM(self):
        #connect to DBus
        try:
            self.bus = dbus.SystemBus()
        except dbus.exceptions.DBusException:
            print("Can't connect to DBus")
            sys.exit(2)
        #main service name
        self.system_service_name = "org.freedesktop.NetworkManager"
        #check NM version
        self.check_nm_version()
        if self.nm_version == "0.9" or self.nm_version == "1.0":
            self.settings_service_name = self.system_service_name
            self.connection_interface_name = "org.freedesktop.NetworkManager.Settings.Connection"
            #settings proxy
            sysproxy = self.bus.get_object(self.settings_service_name, "/org/freedesktop/NetworkManager/Settings")
            #settings intrface
            self.settings = dbus.Interface(sysproxy, "org.freedesktop.NetworkManager.Settings")
        elif self.nm_version == "0.8":
            #self.settings_service_name = "org.freedesktop.NetworkManagerUserSettings"
            self.settings_service_name = "org.freedesktop.NetworkManager"
            self.connection_interface_name = "org.freedesktop.NetworkManagerSettings.Connection"
            #settings proxy
            sysproxy = self.bus.get_object(self.settings_service_name, "/org/freedesktop/NetworkManagerSettings")
            #settings intrface
            self.settings = dbus.Interface(sysproxy, "org.freedesktop.NetworkManagerSettings")
        else:
            print("This Network Manager version is not supported")
            sys.exit(2)

    def check_opts(self):
        self.cacert_file = '${HOME}/.cat_installer/ca.pem'
        self.pfx_file = '${HOME}/.cat_installer/user.p12'
        if not os.path.isfile(self.cacert_file):
            print("Certificate file not found, looks like a CAT error")
            sys.exit(2)

    def check_nm_version(self):
        try:
            proxy = self.bus.get_object(self.system_service_name, "/org/freedesktop/NetworkManager")
            props = dbus.Interface(proxy, "org.freedesktop.DBus.Properties")
            version = props.Get("org.freedesktop.NetworkManager", "Version")
        except dbus.exceptions.DBusException:
            version = "0.8"
        if re.match(r'^1\.', version):
            self.nm_version = "1.0"
            return
        if re.match(r'^0\.9', version):
            self.nm_version = "0.9"
            return
        if re.match(r'^0\.8', version):
            self.nm_version = "0.8"
            return
        else:
            self.nm_version = "Unknown version"
            return

    def byte_to_string(self, barray):
        return "".join([chr(x) for x in barray])


    def delete_existing_connections(self, ssid):
        "checks and deletes earlier connections"
        try:
            conns = self.settings.ListConnections()
        except dbus.exceptions.DBusException:
            print("DBus connection problem, a sudo might help")
            exit(3)
        for each in conns:
            con_proxy = self.bus.get_object(self.system_service_name, each)
            connection = dbus.Interface(con_proxy, "org.freedesktop.NetworkManager.Settings.Connection")
            try:
               connection_settings = connection.GetSettings()
               if connection_settings['connection']['type'] == '802-11-wireless':
                   conn_ssid = self.byte_to_string(connection_settings['802-11-wireless']['ssid'])
                   if conn_ssid == ssid:
                       connection.Delete()
            except dbus.exceptions.DBusException:
               pass

    def add_connection(self,ssid):
        server_alt_subject_name_list = dbus.Array({'DNS:orle.arnes.si'})
        server_name = 'orle.arnes.si'
        if self.nm_version == "0.9" or self.nm_version == "1.0":
             match_key = 'altsubject-matches'
             match_value = server_alt_subject_name_list
        else:
             match_key = 'subject-match'
             match_value = server_name

        s_con = dbus.Dictionary({
            'type': '802-11-wireless',
            'uuid': str(uuid.uuid4()),
            'permissions': ['user:$USER'],
            'id': ssid
        })
        s_wifi = dbus.Dictionary({
            'ssid': dbus.ByteArray(ssid.encode('utf8')),
            'security': '802-11-wireless-security'
        })
        s_wsec = dbus.Dictionary({
            'key-mgmt': 'wpa-eap',
            'proto': ['rsn',],
            'pairwise': ['ccmp',],
            'group': ['ccmp', 'tkip']
        })
        s_8021x = dbus.Dictionary({
            'eap': ['ttls'],
            'identity': '$USER_NAME',
            'ca-cert': dbus.ByteArray("file://{0}\0".format(self.cacert_file).encode('utf8')),
             match_key: match_value,
            'password': '$PASSWORD',
            'phase2-auth': 'pap',
            'anonymous-identity': '[email protected]',
        })
        s_ip4 = dbus.Dictionary({'method': 'auto'})
        s_ip6 = dbus.Dictionary({'method': 'auto'})
        con = dbus.Dictionary({
            'connection': s_con,
            '802-11-wireless': s_wifi,
            '802-11-wireless-security': s_wsec,
            '802-1x': s_8021x,
            'ipv4': s_ip4,
            'ipv6': s_ip6
        })
        self.settings.AddConnection(con)

    def main(self):
        self.check_opts()
        ver = self.connect_to_NM()
        self.delete_existing_connections('eduroam')
        self.add_connection('eduroam')

if __name__ == "__main__":
    ENMCT = EduroamNMConfigTool()
    ENMCT.main()
EOF
}
function create_wpa_conf {
cat << EOFW >> $HOME/.cat_installer/cat_installer.conf

network={
  ssid="eduroam"
  key_mgmt=WPA-EAP
  pairwise=CCMP
  group=CCMP TKIP
  eap=TTLS
  ca_cert="${HOME}/.cat_installer/ca.pem"
  identity="${USER_NAME}"
  domain_suffix_match="orle.arnes.si"
  phase2="auth=PAP"
  password="${PASSWORD}"
  anonymous_identity="[email protected]"
}
EOFW
chmod 600 $HOME/.cat_installer/cat_installer.conf
}
#prompt user for credentials
  user_cred
  if run_python_script ; then
   show_info "Installation successful"
else
   show_info "Network Manager configuration failed, generating wpa_supplicant.conf"
   if ! ask "Network Manager configuration failed, but we may generate a wpa_supplicant configuration file if you wish. Be warned that your connection password will be saved in this file as clear text." "Write the file" 1 ; then exit ; fi

if [ -f $HOME/.cat_installer/cat_installer.conf ] ; then
  if ! ask "File $HOME/.cat_installer/cat_installer.conf exists; it will be overwritten." "Continue" 1 ; then confirm_exit; fi
  rm $HOME/.cat_installer/cat_installer.conf
  fi
   create_wpa_conf
   show_info "Output written to $HOME/.cat_installer/cat_installer.conf"
fi

Als Erstes habe ich das Zertifikat extrahiert und in einer separaten Datei gespeichert /home/ziga/Dropbox/workspace/operacijski/archlinux/eduroam/eduroam.pem– und es sieht so aus:

Dann habe ich in einem Skript den Konfigurationsabschnitt gefunden und versucht, ihn mit meinem Netctl-Profil abzugleichen, das eduroam_wwie folgt benannt ist:

Connection='wireless'
Interface=wlp3s0
Security='wpa-configsection'
Description="eduroam network"
IP='dhcp'
TimeoutWPA=30
WPAConfigSection=(
    'ssid="eduroam"'
    'pairwise=CCMP'
    'group=CCMP TKIP'
    'key_mgmt=WPA-EAP'
    'eap=TTLS'
    'identity="[email protected]"'
    'domain_suffix_match="orle.arnes.si"'
    'phase2="auth=PAP"'
    'ca_cert="/home/ziga/Dropbox/workspace/operacijski/archlinux/eduroam/eduroam.pem"'
    'password="my_password"'
    'anonymous_identity="[email protected]"'
)

Aber nachdem ich das Profil damit gestartet habe, sudo netctl start eduroam_wschlägt es fehl und ich erhalte Folgendes von systemd:

● netctl@eduroam_w.service - Networking for netctl profile eduroam_w
   Loaded: loaded (/usr/lib/systemd/system/[email protected]; static; vendor preset: disabled)
   Active: failed (Result: exit-code) since Mon 2016-10-03 07:29:34 CEST; 26min ago
     Docs: man:netctl.profile(5)
  Process: 13456 ExecStart=/usr/lib/network/network start %I (code=exited, status=1/FAILURE)
 Main PID: 13456 (code=exited, status=1/FAILURE)

Oct 03 07:29:02 ziga-laptop systemd[1]: Starting Networking for netctl profile eduroam_w...
Oct 03 07:29:02 ziga-laptop network[13456]: Starting network profile 'eduroam_w'...
Oct 03 07:29:34 ziga-laptop network[13456]: WPA association/authentication failed for interface 'wlp3s0'
Oct 03 07:29:34 ziga-laptop network[13456]: Failed to bring the network up for profile 'eduroam_w'
Oct 03 07:29:34 ziga-laptop systemd[1]: netctl@eduroam_w.service: Main process exited, code=exited, status=1/FAILURE
Oct 03 07:29:34 ziga-laptop systemd[1]: Failed to start Networking for netctl profile eduroam_w.
Oct 03 07:29:34 ziga-laptop systemd[1]: netctl@eduroam_w.service: Unit entered failed state.
Oct 03 07:29:34 ziga-laptop systemd[1]: netctl@eduroam_w.service: Failed with result 'exit-code'.

Und laut Exit-Status WPA association/authentication failed for interface 'wlp3s0'scheint bei der Authentifizierung etwas nicht zu stimmen... Kann mir jemand helfen? Muss ich mein Passwort irgendwie verschlüsseln oder so?

Unter Arch Linux habe ich sichergestellt, dass ich das Paket installiert habe pptpclient, das manchmal benötigt wird, je nachArchWiki.

verwandte Informationen
