Ich habe einen Server mit Ubuntu Servereiner Xubuntuvirtuellen Maschine darauf, die Virtualisierungssoftware ist virt-manager.
Ubuntu Server IP: 172.16.63.140
Xubuntu Virtual Machine IP: 192.168.122.4
ich kann
ssh 172.16.63.140
zu verbinden Ubuntu Server, und von dieser SSH-Shell aus kann ich
ssh 192.168.122.4
um eine Verbindung herzustellen Xubuntu Virtual Machine.
Mithilfe von iptables möchte ich den SSH-Port weiterleiten, um die virtuelle Maschine von außen sichtbar zu machen. Dies sind die Befehle, die ich verwende:
sudo /sbin/iptables -t nat -I PREROUTING -p tcp -i em1 --dport 22222 -j DNAT --to-destination 192.168.122.4:22
sudo /sbin/iptables -I FORWARD -p tcp -d 192.168.122.4 --dport 22 -m state --state NEW,ESTABLISHED,RELATED -j ACCEPT
dies ist die Ausgabe von iptables:
user@hostname:~$ sudo iptables -L
Chain INPUT (policy ACCEPT)
target prot opt source destination
Chain FORWARD (policy ACCEPT)
target prot opt source destination
ACCEPT tcp -- anywhere 192.168.122.4 tcp dpt:ssh state NEW,RELATED,ESTABLISHED
Chain OUTPUT (policy ACCEPT)
target prot opt source destination
user@hostname:~$ sudo iptables -t nat -L
Chain PREROUTING (policy ACCEPT)
target prot opt source destination
DNAT tcp -- anywhere anywhere tcp dpt:22222 to:192.168.122.4:22
Chain INPUT (policy ACCEPT)
target prot opt source destination
Chain OUTPUT (policy ACCEPT)
target prot opt source destination
Chain POSTROUTING (policy ACCEPT)
target prot opt source destination
aber wenn ich es mache:
ssh -p 22222 172.16.63.140
Dies ist der Inhalt von /etc/network/interfacesOn Host
# This file describes the network interfaces available on your system
# and how to activate them. For more information, see interfaces(5).
# The loopback network interface
auto lo
iface lo inet loopback
# The primary network interface
auto em1
#iface em1 inet dhcp
#MICHELE MODIFIED: delete from here
iface em1 inet static
address 172.16.63.140
netmask 255.255.255.0
network 172.16.63.0
broadcast 172.16.63.255
gateway 172.16.63.254
Dies ist der Inhalt von /etc/network/interfacesOn Guest
# interfaces(5) file used by ifup(8) and ifdown(8)
auto lo
iface lo inet loopback
dies ist der Inhalt von /etc/libvirt/qemu/UbuntuSynth.xml
<!--
WARNING: THIS IS AN AUTO-GENERATED FILE. CHANGES TO IT ARE LIKELY TO BE
OVERWRITTEN AND LOST. Changes to this xml configuration should be made using:
virsh edit UbuntuSynth
or other application using the libvirt API.
-->
<domain type='kvm'>
<name>UbuntuSynth</name>
<uuid>21851d31-25f2-940b-8cff-afa09e329713</uuid>
<memory unit='KiB'>4194304</memory>
<currentMemory unit='KiB'>4194304</currentMemory>
<vcpu placement='static'>8</vcpu>
<os>
<type arch='x86_64' machine='pc-i440fx-trusty'>hvm</type>
<boot dev='hd'/>
</os>
<features>
<acpi/>
<apic/>
<pae/>
</features>
<clock offset='utc'/>
<on_poweroff>destroy</on_poweroff>
<on_reboot>restart</on_reboot>
<on_crash>restart</on_crash>
<devices>
<emulator>/usr/bin/kvm-spice</emulator>
<disk type='file' device='disk'>
<driver name='qemu' type='raw'/>
<source file='/var/lib/libvirt/images/UbuntuSynth.img'/>
<target dev='hda' bus='ide'/>
<address type='drive' controller='0' bus='0' target='0' unit='0'/>
</disk>
<disk type='block' device='cdrom'>
<driver name='qemu' type='raw'/>
<target dev='hdc' bus='ide'/>
<readonly/>
<address type='drive' controller='0' bus='1' target='0' unit='0'/>
</disk>
<controller type='usb' index='0'>
<address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x2'/>
</controller>
<controller type='pci' index='0' model='pci-root'/>
<controller type='ide' index='0'>
<address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x1'/>
</controller>
<interface type='network'>
<mac address='52:54:00:75:4c:d3'/>
<source network='default'/>
<model type='rtl8139'/>
<address type='pci' domain='0x0000' bus='0x00' slot='0x03' function='0x0'/>
</interface>
<serial type='pty'>
<target port='0'/>
</serial>
<console type='pty'>
<target type='serial' port='0'/>
</console>
<input type='mouse' bus='ps2'/>
<input type='keyboard' bus='ps2'/>
<graphics type='vnc' port='-1' autoport='yes'/>
<sound model='ich6'>
<address type='pci' domain='0x0000' bus='0x00' slot='0x04' function='0x0'/>
</sound>
<video>
<model type='cirrus' vram='9216' heads='1'/>
<address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x0'/>
</video>
<memballoon model='virtio'>
<address type='pci' domain='0x0000' bus='0x00' slot='0x05' function='0x0'/>
</memballoon>
</devices>
</domain>
Host-Rechnerifconfig
em1 Link encap:Ethernet HWaddr f0:1f:af:ef:1b:b5
inet addr:172.16.63.140 Bcast:172.16.63.255 Mask:255.255.255.0
inet6 addr: fe80::f21f:afff:feef:1bb5/64 Scope:Link
UP BROADCAST RUNNING MULTICAST MTU:1500 Metric:1
RX packets:28474137 errors:0 dropped:0 overruns:0 frame:0
TX packets:65644719 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:1000
RX bytes:2701543645 (2.7 GB) TX bytes:86462963020 (86.4 GB)
Memory:da500000-da600000
lo Link encap:Local Loopback
inet addr:127.0.0.1 Mask:255.0.0.0
inet6 addr: ::1/128 Scope:Host
UP LOOPBACK RUNNING MTU:65536 Metric:1
RX packets:12327288 errors:0 dropped:0 overruns:0 frame:0
TX packets:12327288 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:0
RX bytes:2986574536 (2.9 GB) TX bytes:2986574536 (2.9 GB)
virbr0 Link encap:Ethernet HWaddr fe:54:00:75:4c:d3
inet addr:192.168.122.1 Bcast:192.168.122.255 Mask:255.255.255.0
UP BROADCAST RUNNING MULTICAST MTU:1500 Metric:1
RX packets:15817438 errors:0 dropped:0 overruns:0 frame:0
TX packets:28427336 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:0
RX bytes:82982143933 (82.9 GB) TX bytes:2706857124 (2.7 GB)
vnet0 Link encap:Ethernet HWaddr fe:54:00:8e:0b:d3
inet6 addr: fe80::fc54:ff:fe8e:bd3/64 Scope:Link
UP BROADCAST RUNNING MULTICAST MTU:1500 Metric:1
RX packets:12504257 errors:0 dropped:0 overruns:0 frame:0
TX packets:25522667 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:500
RX bytes:81619900128 (81.6 GB) TX bytes:1884322484 (1.8 GB)
vnet1 Link encap:Ethernet HWaddr fe:54:00:75:4c:d3
inet6 addr: fe80::fc54:ff:fe75:4cd3/64 Scope:Link
UP BROADCAST RUNNING MULTICAST MTU:1500 Metric:1
RX packets:3313181 errors:0 dropped:0 overruns:0 frame:0
TX packets:3248438 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:500
RX bytes:1583687937 (1.5 GB) TX bytes:842952463 (842.9 MB)
Gastmaschineifconfig
eth0 Link encap:Ethernet HWaddr 52:54:00:75:4c:d3
inet addr:192.168.122.4 Bcast:192.168.122.255 Mask:255.255.255.0
inet6 addr: fe80::5054:ff:fe75:4cd3/64 Scope:Link
UP BROADCAST RUNNING MULTICAST MTU:1500 Metric:1
RX packets:3163707 errors:0 dropped:1 overruns:0 frame:0
TX packets:3313229 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:1000
RX bytes:794261483 (794.2 MB) TX bytes:1583695154 (1.5 GB)
lo Link encap:Local Loopback
inet addr:127.0.0.1 Mask:255.0.0.0
inet6 addr: ::1/128 Scope:Host
UP LOOPBACK RUNNING MTU:65536 Metric:1
RX packets:10588809 errors:0 dropped:0 overruns:0 frame:0
TX packets:10588809 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:0
RX bytes:3603005625 (3.6 GB) TX bytes:3603005625 (3.6 GB)
tun0 Link encap:UNSPEC HWaddr 00-00-00-00-00-00-00-00-00-00-00-00-00-00-00-00
inet addr:10.8.0.1 P-t-P:10.8.0.2 Mask:255.255.255.255
UP POINTOPOINT RUNNING NOARP MULTICAST MTU:1500 Metric:1
RX packets:0 errors:0 dropped:0 overruns:0 frame:0
TX packets:0 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:100
RX bytes:0 (0.0 B) TX bytes:0 (0.0 B)
Von meinem Laptop aus wird die Verbindung mit einem Timeout-Fehler wiederhergestellt. Wo liegt das Problem?
Antwort1
Sie haben in Ihrem iptables-Regelsatz keinen Rückgabepfad angegeben. Sie benötigen:
sudo /sbin/iptables -t nat -I POSTROUTING -o em1 -j SNAT --to 172.16.63.140
Sie müssen außerdem sicherstellen, dass die Weiterleitung aktiviert ist. Beispiel:
$ cat /proc/sys/net/ipv4/ip_forward
1
