Errores de OpenSSL 1.0.1g al intentar compilar Apache 2.4.16 desde el código fuente en SUSE Linux Enterprise Server 11 (x86_64)

Question

Información del servidor:

# cat /etc/*-release
SUSE Linux Enterprise Server 11 (x86_64)
VERSION = 11
PATCHLEVEL = 0
LSB_VERSION="core-2.0-noarch:core-3.2-noarch:core-4.0-noarch:core-2.0-x86_64:core-3.2-x86_64:core-4.0-x86_64"

Primero instalé OpenSSL 1.0.1g:

# tar -zxf openssl-1.0.1g.tar.gz
# cd /usr/src/openssl-1.0.1g
# make clean
# ./config --prefix=/usr --openssldir=/usr/local/openssl enable-tlsext no-shared no-zlib -fPIC no-gost
# make depend
# make
# make test
# make install
# mv /usr/bin/openssl /root/
# ln -s /usr/local/ssl/bin/openssl /usr/bin/openssl
# openssl version
  OpenSSL 1.0.1g 7 Apr 2014

Luego instalé APR y APR-UTIL

# cd /usr/src

# tar -zxf apr-1.5.2.tar.gz
# cd /usr/src/apr-1.5.2
# ./configure
# make
# make test
# make install

# tar -zxf apr-util-1.5.4.tar.gz
# cd /usr/src/apr-util-1.5.4/
# ./configure --with-apr=/usr/local/apr --with-ldap=ldap  --with-crypto
# make
# make test
# make install

# cp /usr/local/apr/bin/* /usr/bin

Luego instalo Apache 2.4.16:

# tar -zxf httpd-2.4.16.tar.gz
# cd /usr/src/httpd-2.4.16/

# make clean

# env LDFLAGS=-ldl
# export LIBS=-ldl

# CFLAGS="-fmessage-length=0 -O2 -Wall -D_FORTIFY_SOURCE=2 -fstack-protector -funwind-tables  -g -fPIC -Wall -fno-strict-aliasing -DLDAP_DEPRECATED"; export CFLAGS

# CPPFLAGS="-DSSL_EXPERIMENTAL_ENGINE -DMAX_SERVER_LIMIT=200000 -DLDAP_DEPRECATED -DMAXLINE=4096"; export CPPFLAGS

# ./configure  --prefix=/usr/sbin/httpd \
--enable-shared \
--enable-layout=SuSE \
--with-apr=/usr/bin/apr-1-config \
--with-apr-util=/usr/bin/apu-1-config \
--enable-exception-hook \
--with-pcre \
--enable-pie \
--enable-ssl \
--with-ssl=/usr/local/ssl \
--enable-ssl-staticlib-deps \
--enable-mods-static=ssl \
--enable-mod_php5 \
--enable-mod_fcgid \
--enable-mod_perl \
--enable-mod_session_crypto \
--disable-isapi \
--enable-deflate \
--enable-echo \
--enable-filter \
--enable-ext-filter \
--enable-charset-lite \
--enable-file-cache \
--enable-logio \
--enable-dumpio \
--enable-bucketeer \
--enable-case_filter \
--enable-case_filter_in \
--with-ldap \
--enable-ldap \
--enable-authnz_ldap \
--enable-proxy \
--enable-proxy-connect \
--enable-proxy-ftp \
--enable-proxy-http \
--enable-cache \
--enable-disk-cache \
--enable-mem-cache \
--enable-VERSION \
--enable-dav-lock \
--enable-authn-alias \
--enable-optional-hook-export \
--enable-optional-hook-import \
--enable-optional-fn-import \
--enable-optional-fn-export \
--enable-suexec \
--with-suexec-bin=/usr/sbin/suexec2 \
--with-suexec-caller=wwwrun \
--with-suexec-docroot=/srv/www \
--with-suexec-logfile=/var/log/apache2/suexec.log \
--with-suexec-userdir=public_html \
--with-suexec-uidmin=96 \
--with-suexec-gidmin=96 \
--with-suexec-safepath=/usr/local/bin:/usr/bin:/bin

Configurar parece funcionar sin errores

Luego emito:

# make

Recibo estos errores:

/usr/local/apr/build-1/libtool --silent --mode=link gcc -std=gnu99  -pthread  -fmessage-length=0 -O2 -Wall -D_FORTIFY_SOURCE=2 -fstack-protector -funwind-tables -g -fPIC -Wall -fno-strict-aliasing -DLDAP_DEPRECATED -L/usr/local/ssl/lib -lssl -lcrypto -ldl -luuid -lrt -lcrypt -lpthread -pie \
                 -o ab  ab.lo        /usr/local/apr/lib/libaprutil-1.la -lexpat /usr/local/apr/lib/libapr-1.la -luuid -lrt -lcrypt -lpthread -lm
/usr/lib64/gcc/x86_64-suse-linux/4.3/../../../../x86_64-suse-linux/bin/ld: /usr/local/ssl/lib/libssl.a(s2_clnt.o): relocation R_X86_64_32 against `a local symbol' can not be used when making a shared object; recompile with -fPIC
/usr/local/ssl/lib/libssl.a: could not read symbols: Bad value
collect2: ld returned 1 exit status
make[2]: *** [ab] Error 1
make[2]: Leaving directory `/usr/src/httpd-2.4.16/support'
make[1]: *** [all-recursive] Error 1
make[1]: Leaving directory `/usr/src/httpd-2.4.16/support'
make: *** [all-recursive] Error 1

Recibo los siguientes errores en config.log

133  conftest.c:9:28: error: ac_nonexistent.h: No such file or directory

147  conftest.c:59: error: expected ';', ',' or ')' before 'text'

148-157
conftest.c: In function 'main':
conftest.c:111: warning: implicit declaration of function 'test_restrict'
conftest.c:113: error: expected '=', ',', ';', 'asm' or '__attribute__' before 'newvar'
conftest.c:113: error: 'newvar' undeclared (first use in this function)
conftest.c:113: error: (Each undeclared identifier is reported only once
conftest.c:113: error: for each function it appears in.)
conftest.c:123: error: 'for' loop initial declaration used outside C99 mode
configure:6017: $? = 1
configure: failed program was:
| /* confdefs.h */


380/438  conftest.c:52:26: error: minix/config.h: No such file or directory

535/607  conftest.c:66:27: error: sys/processor.h: No such file or directory

658/731  conftest.c:67:21: error: sys/sdt.h: No such file or directory

773/846  conftest.c:67:25: error: sys/loadavg.h: No such file or directory

1490/1588  conftest.c:92:21: error: bstring.h: No such file or directory

Answer 1

Bueno, ¡felicitaciones por hacer una compilación personalizada! ¡Me recuerda a los buenos viejos tiempos!

Dicho esto, este parece ser el error clave:

/usr/local/ssl/lib/libssl.a: could not read symbols: Bad value

En mi experiencia, eso proviene de cuando una biblioteca estática es de 32 bits frente a los requisitos de la marca, que serían de 64 bits. Y dado que es un elemento SSL, parece que todo proviene del propio OpenSSL 1.0.1g.

Mirando alas instrucciones de compilación en el sitio oficial de OpenSSLmuestra que existen varias configuraciones para diferentes sistemas y se pueden ver ejecutando este ./configurecomando desde el código fuente;descargado desde aquí:

./configure LIST

El resultado que obtengo es:

BC-32
BS2000-OSD
BSD-generic32
BSD-generic64
BSD-ia64
BSD-sparc64
BSD-sparcv8
BSD-x86
BSD-x86-elf
BSD-x86_64
Cygwin
Cygwin-pre1.3
DJGPP
MPE/iX-gcc
OS2-EMX
OS390-Unix
QNX6
QNX6-i386
ReliantUNIX
SINIX
SINIX-N
UWIN
VC-CE
VC-WIN32
VC-WIN64A
VC-WIN64I
aix-cc
aix-gcc
aix3-cc
aix64-cc
aix64-gcc
android
android-armv7
android-x86
aux3-gcc
beos-x86-bone
beos-x86-r5
bsdi-elf-gcc
cc
cray-j90
cray-t3e
darwin-i386-cc
darwin-ppc-cc
darwin64-ppc-cc
darwin64-x86_64-cc
debug
debug-BSD-x86-elf
debug-Cygwin
debug-VC-WIN32
debug-VC-WIN64A
debug-VC-WIN64I
debug-ben
debug-ben-darwin64
debug-ben-debug
debug-ben-debug-64
debug-ben-macos
debug-ben-macos-gcc46
debug-ben-no-opt
debug-ben-openbsd
debug-ben-openbsd-debug
debug-ben-strict
debug-bodo
debug-darwin-i386-cc
debug-darwin-ppc-cc
debug-geoff32
debug-geoff64
debug-levitte-linux-elf
debug-levitte-linux-elf-extreme
debug-levitte-linux-noasm
debug-levitte-linux-noasm-extreme
debug-linux-elf
debug-linux-elf-noefence
debug-linux-generic32
debug-linux-generic64
debug-linux-ia32-aes
debug-linux-pentium
debug-linux-ppro
debug-linux-x86_64
debug-rse
debug-solaris-sparcv8-cc
debug-solaris-sparcv8-gcc
debug-solaris-sparcv9-cc
debug-solaris-sparcv9-gcc
debug-steve-opt
debug-steve32
debug-steve64
debug-ulf
debug-vos-gcc
dgux-R3-gcc
dgux-R4-gcc
dgux-R4-x86-gcc
dist
gcc
hpux-cc
hpux-gcc
hpux-ia64-cc
hpux-ia64-gcc
hpux-parisc-cc
hpux-parisc-cc-o4
hpux-parisc-gcc
hpux-parisc1_1-cc
hpux-parisc1_1-gcc
hpux-parisc2-cc
hpux-parisc2-gcc
hpux64-ia64-cc
hpux64-ia64-gcc
hpux64-parisc2-cc
hpux64-parisc2-gcc
hurd-x86
iphoneos-cross
irix-cc
irix-gcc
irix-mips3-cc
irix-mips3-gcc
irix64-mips4-cc
irix64-mips4-gcc
linux-alpha+bwx-ccc
linux-alpha+bwx-gcc
linux-alpha-ccc
linux-alpha-gcc
linux-aout
linux-armv4
linux-elf
linux-generic32
linux-generic64
linux-ia32-icc
linux-ia64
linux-ia64-ecc
linux-ia64-icc
linux-ppc
linux-ppc64
linux-sparcv8
linux-sparcv9
linux-x86_64
linux32-s390x
linux64-s390x
linux64-sparcv9
mingw
mingw64
ncr-scde
netware-clib
netware-clib-bsdsock
netware-clib-bsdsock-gcc
netware-clib-gcc
netware-libc
netware-libc-bsdsock
netware-libc-bsdsock-gcc
netware-libc-gcc
newsos4-gcc
nextstep
nextstep3.3
osf1-alpha-cc
osf1-alpha-gcc
purify
qnx4
rhapsody-ppc-cc
sco5-cc
sco5-gcc
solaris-sparcv7-cc
solaris-sparcv7-gcc
solaris-sparcv8-cc
solaris-sparcv8-gcc
solaris-sparcv9-cc
solaris-sparcv9-gcc
solaris-x86-cc
solaris-x86-gcc
solaris64-sparcv9-cc
solaris64-sparcv9-gcc
solaris64-x86_64-cc
solaris64-x86_64-gcc
sunos-gcc
tandem-c89
tru64-alpha-cc
uClinux-dist
uClinux-dist64
ultrix-cc
ultrix-gcc
unixware-2.0
unixware-2.1
unixware-7
unixware-7-gcc
vos-gcc
vxworks-mips
vxworks-ppc405
vxworks-ppc60x
vxworks-ppc750
vxworks-ppc750-debug
vxworks-ppc860
vxworks-ppcgen
vxworks-simlinux

No veo nada que se parezca explícitamente a SUSE Linux Enterprise Server 11, pero asumiré entonces que tal vez el ./configureproceso compiló una versión de 32 bits. Supongo que tal vez su ./configurecomando para OpenSSL debería indicar explícitamente para qué arquitectura desea compilar.

Como un comando como:

./configure linux-generic64

E incluso agregando las opciones utilizadas anteriormente de esta manera:

./configure linux-generic64 --prefix=/usr --openssldir=/usr/local/openssl enable-tlsext no-shared no-zlib -fPIC no-gost

Y luego recorra todo makey make installprocese nuevamente.

Pero mi instinto me dice que todo esto depende de que algo de 32 bits estropee la compilación en un sistema de 64 bits.
