Barracuda 7200.12 hace un sonido muy fuerte (chirrido). La unidad no se muestra

Tengo un Barracuda 7200.12 de 1 TB, ningún sistema operativo detecta la unidad, antes de girar los platos yo mismo, ese disco duro emitiría un sonido de clic como si los cabezales intentaran moverse pero los platos no giran y luego un tono bajo. sonido de pitido.

Después de abrir el disco duro, lo obligué a girar en cámara lenta y luego despegó. Desde allí, surgió el extraño ruido fuerte.

Simplemente creo que el plato está desalineado, lo cual es un gran problema :) adjunto hay un video de ese sonido.

https://www.youtube.com/watch?v=2K_neijG1rE

Ahora, después de ajustar los tornillos como sugirió David. Pude ver el disco en mi lista de discos dos veces. a continuación se muestra el registro de dmesg.

[  986.211268] sd 1:0:0:0: Attached scsi generic sg1 type 0
[  986.211651] sd 1:0:0:0: [sdb] 1953525168 512-byte logical blocks: (1.00 TB/932 GiB)
[  986.211947] sd 1:0:0:0: [sdb] Write Protect is off
[  986.211952] sd 1:0:0:0: [sdb] Mode Sense: 28 00 00 00
[  986.212325] sd 1:0:0:0: [sdb] No Caching mode page found
[  986.212335] sd 1:0:0:0: [sdb] Assuming drive cache: write through
[ 1016.704426] usb 1-1: reset high-speed USB device number 8 using xhci_hcd
[ 1049.430537] usb 1-1: reset high-speed USB device number 8 using xhci_hcd
[ 1060.550003] usb 1-1: USB disconnect, device number 8
[ 1060.550028] sd 1:0:0:0: Device offlined - not ready after error recovery
[ 1060.550043] sd 1:0:0:0: [sdb] tag#0 FAILED Result: hostbyte=DID_ABORT driverbyte=DRIVER_OK
[ 1060.550048] sd 1:0:0:0: [sdb] tag#0 CDB: Read(10) 28 00 00 00 00 00 00 00 08 00
[ 1060.550052] blk_update_request: I/O error, dev sdb, sector 0
[ 1060.550061] Buffer I/O error on dev sdb, logical block 0, async page read
[ 1060.550120] sd 1:0:0:0: rejecting I/O to offline device
[ 1060.550143] ldm_validate_partition_table(): Disk read failed.
[ 1060.550176] Dev sdb: unable to read RDB block 0
[ 1060.550226]  sdb: unable to read partition table
[ 1060.550597] sd 1:0:0:0: [sdb] Read Capacity(10) failed: Result: hostbyte=DID_NO_CONNECT driverbyte=DRIVER_OK
[ 1060.550600] sd 1:0:0:0: [sdb] Sense not available.
[ 1060.550605] sd 1:0:0:0: [sdb] 0 512-byte logical blocks: (0 B/0 B)
[ 1060.550629] sd 1:0:0:0: [sdb] Attached SCSI disk
[ 1911.705428] usb 1-1: new high-speed USB device number 9 using xhci_hcd
[ 1911.846722] usb 1-1: New USB device found, idVendor=152d, idProduct=2338
[ 1911.846727] usb 1-1: New USB device strings: Mfr=1, Product=2, SerialNumber=5
[ 1911.846730] usb 1-1: Product: USB to ATA/ATAPI bridge
[ 1911.846732] usb 1-1: Manufacturer: JMicron
[ 1911.846734] usb 1-1: SerialNumber: 000000000000
[ 1911.847857] usb-storage 1-1:1.0: USB Mass Storage device detected
[ 1911.848150] scsi host1: usb-storage 1-1:1.0
[ 1912.878129] scsi 1:0:0:0: Direct-Access     ST310005 28AS                  PQ: 0 ANSI: 5
[ 1912.878875] sd 1:0:0:0: [sdb] 1953525168 512-byte logical blocks: (1.00 TB/932 GiB)
[ 1912.878927] sd 1:0:0:0: Attached scsi generic sg1 type 0
[ 1912.879139] sd 1:0:0:0: [sdb] Write Protect is off
[ 1912.879142] sd 1:0:0:0: [sdb] Mode Sense: 28 00 00 00
[ 1912.879425] sd 1:0:0:0: [sdb] No Caching mode page found
[ 1912.879431] sd 1:0:0:0: [sdb] Assuming drive cache: write through
[ 1944.367889] usb 1-1: reset high-speed USB device number 9 using xhci_hcd
[ 1977.122025] usb 1-1: reset high-speed USB device number 9 using xhci_hcd
[ 1988.265153] sd 1:0:0:0: Device offlined - not ready after error recovery
[ 1988.265173] sd 1:0:0:0: [sdb] tag#0 FAILED Result: hostbyte=DID_ABORT driverbyte=DRIVER_OK
[ 1988.265180] sd 1:0:0:0: [sdb] tag#0 CDB: Read(10) 28 00 00 00 00 00 00 00 08 00
[ 1988.265184] blk_update_request: I/O error, dev sdb, sector 0
[ 1988.265188] usb 1-1: USB disconnect, device number 9
[ 1988.265197] Buffer I/O error on dev sdb, logical block 0, async page read
[ 1988.265250] sd 1:0:0:0: rejecting I/O to offline device
[ 1988.265274] sd 1:0:0:0: rejecting I/O to offline device
[ 1988.265281] ldm_validate_partition_table(): Disk read failed.
[ 1988.265290] sd 1:0:0:0: rejecting I/O to offline device
[ 1988.265301] sd 1:0:0:0: rejecting I/O to offline device
[ 1988.265312] sd 1:0:0:0: rejecting I/O to offline device
[ 1988.265323] sd 1:0:0:0: rejecting I/O to offline device
[ 1988.265329] Dev sdb: unable to read RDB block 0
[ 1988.265338] sd 1:0:0:0: rejecting I/O to offline device
[ 1988.265349] sd 1:0:0:0: rejecting I/O to offline device
[ 1988.265387]  sdb: unable to read partition table
[ 1988.267016] sd 1:0:0:0: [sdb] Read Capacity(10) failed: Result: hostbyte=DID_NO_CONNECT driverbyte=DRIVER_OK
[ 1988.267022] sd 1:0:0:0: [sdb] Sense not available.
[ 1988.267032] sd 1:0:0:0: [sdb] 0 512-byte logical blocks: (0 B/0 B)
[ 1988.267075] sd 1:0:0:0: [sdb] Attached SCSI disk
[ 2167.158983] usb 1-1: new high-speed USB device number 10 using xhci_hcd
[ 2167.300232] usb 1-1: New USB device found, idVendor=152d, idProduct=2338
[ 2167.300237] usb 1-1: New USB device strings: Mfr=1, Product=2, SerialNumber=5
[ 2167.300240] usb 1-1: Product: USB to ATA/ATAPI bridge
[ 2167.300242] usb 1-1: Manufacturer: JMicron
[ 2167.300244] usb 1-1: SerialNumber: 000000000000
[ 2167.301229] usb-storage 1-1:1.0: USB Mass Storage device detected
[ 2167.301516] scsi host1: usb-storage 1-1:1.0
[ 2168.319867] scsi 1:0:0:0: Direct-Access     ST310005 28AS                  PQ: 0 ANSI: 5
[ 2168.321028] sd 1:0:0:0: Attached scsi generic sg1 type 0
[ 2168.321243] sd 1:0:0:0: [sdb] 1953525168 512-byte logical blocks: (1.00 TB/932 GiB)
[ 2168.321571] sd 1:0:0:0: [sdb] Write Protect is off
[ 2168.321577] sd 1:0:0:0: [sdb] Mode Sense: 28 00 00 00
[ 2168.321863] sd 1:0:0:0: [sdb] No Caching mode page found
[ 2168.321875] sd 1:0:0:0: [sdb] Assuming drive cache: write through
[ 2200.381339] usb 1-1: reset high-speed USB device number 10 using xhci_hcd
[ 2233.107466] usb 1-1: reset high-speed USB device number 10 using xhci_hcd
[ 2244.250856] sd 1:0:0:0: Device offlined - not ready after error recovery
[ 2244.250860] usb 1-1: USB disconnect, device number 10
[ 2244.250875] sd 1:0:0:0: [sdb] tag#0 FAILED Result: hostbyte=DID_ABORT driverbyte=DRIVER_OK
[ 2244.250881] sd 1:0:0:0: [sdb] tag#0 CDB: Read(10) 28 00 00 00 00 00 00 00 08 00
[ 2244.250884] blk_update_request: I/O error, dev sdb, sector 0
[ 2244.250894] Buffer I/O error on dev sdb, logical block 0, async page read
[ 2244.250949] sd 1:0:0:0: rejecting I/O to offline device
[ 2244.250969] sd 1:0:0:0: rejecting I/O to offline device
[ 2244.250975] ldm_validate_partition_table(): Disk read failed.
[ 2244.251008] Dev sdb: unable to read RDB block 0
[ 2244.251059]  sdb: unable to read partition table
[ 2244.251470] sd 1:0:0:0: [sdb] Read Capacity(10) failed: Result: hostbyte=DID_NO_CONNECT driverbyte=DRIVER_OK
[ 2244.251474] sd 1:0:0:0: [sdb] Sense not available.
[ 2244.251484] sd 1:0:0:0: [sdb] 0 512-byte logical blocks: (0 B/0 B)
[ 2244.251525] sd 1:0:0:0: [sdb] Attached SCSI disk

debajo de lsusb -v

Bus 001 Device 011: ID 152d:2338 JMicron Technology Corp. / JMicron USA Technology Corp. JM20337 Hi-Speed USB to SATA & PATA Combo Bridge
Couldn't open device, some information will be missing

Device Descriptor:
  bLength                18
  bDescriptorType         1
  bcdUSB               2.00
  bDeviceClass            0 (Defined at Interface level)
  bDeviceSubClass         0
  bDeviceProtocol         0
  bMaxPacketSize0        64
  idVendor           0x152d JMicron Technology Corp. / JMicron USA Technology Corp.
  idProduct          0x2338 JM20337 Hi-Speed USB to SATA & PATA Combo Bridge
  bcdDevice            1.00
  iManufacturer           1
  iProduct                2
  iSerial                 5
  bNumConfigurations      1
  Configuration Descriptor:
    bLength                 9
    bDescriptorType         2
    wTotalLength           32
    bNumInterfaces          1
    bConfigurationValue     1
    iConfiguration          4
    bmAttributes         0xc0
      Self Powered
    MaxPower                2mA
    Interface Descriptor:
      bLength                 9
      bDescriptorType         4
      bInterfaceNumber        0
      bAlternateSetting       0
      bNumEndpoints           2
      bInterfaceClass         8 Mass Storage
      bInterfaceSubClass      6 SCSI
      bInterfaceProtocol     80 Bulk-Only
      iInterface              6
      Endpoint Descriptor:
        bLength                 7
        bDescriptorType         5
        bEndpointAddress     0x81  EP 1 IN
        bmAttributes            2
          Transfer Type            Bulk
          Synch Type               None
          Usage Type               Data
        wMaxPacketSize     0x0200  1x 512 bytes
        bInterval               0
      Endpoint Descriptor:
        bLength                 7
        bDescriptorType         5
        bEndpointAddress     0x02  EP 2 OUT
        bmAttributes            2
          Transfer Type            Bulk
          Synch Type               None
          Usage Type               Data
        wMaxPacketSize     0x0200  1x 512 bytes
        bInterval               0

Respuesta1

En tu video veo que la parte superior del disco está apagada. Haciendo caso omiso de mis comentarios anteriores sobre el polvo (que todavía mantengo, y de hecho, ejecutar el disco con los platos expuestos será aún peor), la tapa de la unidad es un elemento estructural de la unidad y debe estar colocada con el torque correcto en los tornillos. -esteEl vídeo de YouTube demuestra la importancia del torque correcto.
