Quería crear un script SIPP para crear un escenario para establecer una conexión IPSEC entre UE y PCSCF usando lo siguiente;
Por ejemplo:-
setkey -c << EOF
spdadd $pcscf/32[$port_pc] $ue/32[$port_us] tcp -P in ipsec esp/transport//require ;
spdadd $pcscf/32[$port_pc] $ue/32[$port_us] udp -P in ipsec esp/transport//require ;
add $pcscf $ue esp $spi_us -m transport -E $ealg $ck -A $alg $ik
EOF
Se ha creado 4 SA que verifiqué usando setkey -D.
192.168.137.98 192.168.137.39
esp mode=transport spi=1024(0x00000400) reqid=16625(0x000040f1)
E: 3des-cbc d0c1e6cd d58c07f7 fe4a6715 83d60210 d0c1e6cd d58c07f7
A: hmac-md5 320fe4a8 ab88a62d f406ccb9 76346602
seq=0x00000000 replay=4 flags=0x00000000 state=mature
created: Jun 24 17:01:11 2019 current: Jun 24 17:01:22 2019
diff: 11(s) hard: 0(s) soft: 0(s)
last: hard: 0(s) soft: 0(s)
current: 0(bytes) hard: 0(bytes) soft: 0(bytes)
allocated: 0 hard: 0 soft: 0
sadb_seq=1 pid=9623 refcnt=0
192.168.137.98 192.168.137.39
esp mode=transport spi=2048(0x00000800) reqid=16624(0x000040f0)
E: 3des-cbc d0c1e6cd d58c07f7 fe4a6715 83d60210 d0c1e6cd d58c07f7
A: hmac-md5 320fe4a8 ab88a62d f406ccb9 76346602
seq=0x00000000 replay=4 flags=0x00000000 state=mature
created: Jun 24 17:01:11 2019 current: Jun 24 17:01:22 2019
diff: 11(s) hard: 0(s) soft: 0(s)
last: hard: 0(s) soft: 0(s)
current: 0(bytes) hard: 0(bytes) soft: 0(bytes)
allocated: 0 hard: 0 soft: 0
sadb_seq=2 pid=9623 refcnt=0
192.168.137.39 192.168.137.98
esp mode=transport spi=147047421(0x08c3c3fd) reqid=16623(0x000040ef)
E: 3des-cbc d0c1e6cd d58c07f7 fe4a6715 83d60210 d0c1e6cd d58c07f7
A: hmac-md5 320fe4a8 ab88a62d f406ccb9 76346602
seq=0x00000000 replay=4 flags=0x00000000 state=mature
created: Jun 24 17:01:11 2019 current: Jun 24 17:01:22 2019
diff: 11(s) hard: 0(s) soft: 0(s)
last: hard: 0(s) soft: 0(s)
current: 0(bytes) hard: 0(bytes) soft: 0(bytes)
allocated: 0 hard: 0 soft: 0
sadb_seq=3 pid=9623 refcnt=0
192.168.137.39 192.168.137.98
esp mode=transport spi=70783604(0x04381274) reqid=16622(0x000040ee)
E: 3des-cbc d0c1e6cd d58c07f7 fe4a6715 83d60210 d0c1e6cd d58c07f7
A: hmac-md5 320fe4a8 ab88a62d f406ccb9 76346602
seq=0x00000000 replay=4 flags=0x00000000 state=mature
created: Jun 24 17:01:11 2019 current: Jun 24 17:01:22 2019
diff: 11(s) hard: 0(s) soft: 0(s)
last: hard: 0(s) soft: 0(s)
current: 0(bytes) hard: 0(bytes) soft: 0(bytes)
allocated: 0 hard: 0 soft: 0
sadb_seq=0 pid=9623 refcnt=0
Pero cuando envío el segundo registro desde el puerto seguro del cliente UE al puerto seguro del servidor PCSCF. No envía el paquete ESP. Por favor ayuda. Si usted necesita más información. Puedo proveer.
