Instalé Arch en mi computadora portátil ayer y desde entonces no puedo abrir i3. Instalé xorg, i3-gaps y cambié mi archivo ~/.xinitrc para que diga:
xrandr --setprovideroutputsource modesetting NVIDIA-0
xrandr --auto
exec i3
Sin embargo, no puedo abrir i3. Cada vez que intento ejecutar startx, aparece un error que indica que hay un error fatal en el servidor y que no se encuentran pantallas. A veces dice lo siguiente:
xinit: giving up
xinit: unable to connect to X server: Connection refused
xinit: server error
Pero a veces no dice eso y simplemente se cuelga después de decir que no se encontraron pantallas.
Aquí está el registro de errores en /var/log/Xorg.0.log
[ 1425.899] (WW) Failed to open protocol names file lib/xorg/protocol.txt
[ 1425.900]
X.Org X Server 1.20.5
X Protocol Version 11, Revision 0
[ 1425.904] Build Operating System: Linux Arch Linux
[ 1425.905] Current Operating System: Linux mohammed-laptop 5.1.14-arch1-1-ARCH #1 SMP PREEMPT Sat Jun 22 16:28:48 UTC 2019 x86_64
[ 1425.905] Kernel command line: BOOT_IMAGE=/vmlinuz-linux root=UUID=6557ebc3-02f1-4d88-a79d-1afb43df18c7 rw quiet
[ 1425.906] Build Date: 30 May 2019 06:44:40PM
[ 1425.907]
[ 1425.908] Current version of pixman: 0.38.4
[ 1425.909] Before reporting problems, check http://wiki.x.org
to make sure that you have the latest version.
[ 1425.909] Markers: (--) probed, (**) from config file, (==) default setting,
(++) from command line, (!!) notice, (II) informational,
(WW) warning, (EE) error, (NI) not implemented, (??) unknown.
[ 1425.912] (==) Log file: "/var/log/Xorg.0.log", Time: Mon Jun 24 16:48:41 2019
[ 1425.913] (==) Using config file: "/etc/X11/xorg.conf"
[ 1425.914] (==) Using system config directory "/usr/share/X11/xorg.conf.d"
[ 1425.914] (==) ServerLayout "Layout0"
[ 1425.914] (**) |-->Screen "Screen0" (0)
[ 1425.914] (**) | |-->Monitor "Monitor0"
[ 1425.914] (**) | |-->Device "Device0"
[ 1425.914] (**) |-->Input Device "Keyboard0"
[ 1425.914] (**) |-->Input Device "Mouse0"
[ 1425.914] (==) Automatically adding devices
[ 1425.914] (==) Automatically enabling devices
[ 1425.914] (==) Automatically adding GPU devices
[ 1425.914] (==) Automatically binding GPU devices
[ 1425.914] (==) Max clients allowed: 256, resource mask: 0x1fffff
[ 1425.914] (WW) `fonts.dir' not found (or not valid) in "/usr/share/fonts/misc".
[ 1425.914] Entry deleted from font path.
[ 1425.914] (Run 'mkfontdir' on "/usr/share/fonts/misc").
[ 1425.914] (WW) The directory "/usr/share/fonts/TTF" does not exist.
[ 1425.914] Entry deleted from font path.
[ 1425.914] (WW) The directory "/usr/share/fonts/OTF" does not exist.
[ 1425.914] Entry deleted from font path.
[ 1425.914] (WW) The directory "/usr/share/fonts/Type1" does not exist.
[ 1425.914] Entry deleted from font path.
[ 1425.914] (==) FontPath set to:
/usr/share/fonts/100dpi,
/usr/share/fonts/75dpi
[ 1425.914] (==) ModulePath set to "/usr/lib/xorg/modules"
[ 1425.914] (WW) Hotplugging is on, devices using drivers 'kbd', 'mouse' or 'vmmouse' will be disabled.
[ 1425.914] (WW) Disabling Keyboard0
[ 1425.914] (WW) Disabling Mouse0
[ 1425.914] (II) Module ABI versions:
[ 1425.914] X.Org ANSI C Emulation: 0.4
[ 1425.914] X.Org Video Driver: 24.0
[ 1425.914] X.Org XInput driver : 24.1
[ 1425.914] X.Org Server Extension : 10.0
[ 1425.914] (++) using VT number 1
[ 1425.915] (II) systemd-logind: took control of session /org/freedesktop/login1/session/_31
[ 1425.916] (II) xfree86: Adding drm device (/dev/dri/card1)
[ 1425.916] (II) systemd-logind: got fd for /dev/dri/card1 226:1 fd 10 paused 0
[ 1425.917] (II) xfree86: Adding drm device (/dev/dri/card0)
[ 1425.917] (II) systemd-logind: got fd for /dev/dri/card0 226:0 fd 11 paused 0
[ 1425.919] (--) PCI:*(0@0:2:0) 8086:0416:17aa:221e rev 6, Mem @ 0xb1400000/4194304, 0xa0000000/268435456, I/O @ 0x00005000/64, BIOS @ 0x????????/131072
[ 1425.919] (--) PCI: (1@0:0:0) 10de:11fc:17aa:221e rev 161, Mem @ 0xb0000000/16777216, 0x80000000/268435456, 0x90000000/33554432, I/O @ 0x00004000/128, BIOS @ 0x????????/524288
[ 1425.919] (WW) Open ACPI failed (/var/run/acpid.socket) (No such file or directory)
[ 1425.919] (II) LoadModule: "glx"
[ 1425.919] (II) Loading /usr/lib/xorg/modules/extensions/libglx.so
[ 1425.920] (II) Module glx: vendor="X.Org Foundation"
[ 1425.920] compiled for 1.20.5, module version = 1.0.0
[ 1425.920] ABI class: X.Org Server Extension, version 10.0
[ 1425.920] (II) LoadModule: "nvidia"
[ 1425.920] (II) Loading /usr/lib/xorg/modules/drivers/nvidia_drv.so
[ 1425.920] (II) Module nvidia: vendor="NVIDIA Corporation"
[ 1425.920] compiled for 1.6.99.901, module version = 1.0.0
[ 1425.920] Module class: X.Org Video Driver
[ 1425.920] (II) NVIDIA dlloader X Driver 430.26 Tue Jun 4 17:52:10 CDT 2019
[ 1425.920] (II) NVIDIA Unified Driver for all Supported NVIDIA GPUs
[ 1425.920] (II) systemd-logind: releasing fd for 226:1
[ 1425.921] (II) Loading sub module "fb"
[ 1425.921] (II) LoadModule: "fb"
[ 1425.921] (II) Loading /usr/lib/xorg/modules/libfb.so
[ 1425.921] (II) Module fb: vendor="X.Org Foundation"
[ 1425.921] compiled for 1.20.5, module version = 1.0.0
[ 1425.921] ABI class: X.Org ANSI C Emulation, version 0.4
[ 1425.921] (II) Loading sub module "wfb"
[ 1425.921] (II) LoadModule: "wfb"
[ 1425.921] (II) Loading /usr/lib/xorg/modules/libwfb.so
[ 1425.921] (II) Module wfb: vendor="X.Org Foundation"
[ 1425.921] compiled for 1.20.5, module version = 1.0.0
[ 1425.921] ABI class: X.Org ANSI C Emulation, version 0.4
[ 1425.921] (II) Loading sub module "ramdac"
[ 1425.921] (II) LoadModule: "ramdac"
[ 1425.921] (II) Module "ramdac" already built-in
[ 1425.921] (**) NVIDIA(0): Depth 24, (--) framebuffer bpp 32
[ 1425.921] (==) NVIDIA(0): RGB weight 888
[ 1425.921] (==) NVIDIA(0): Default visual is TrueColor
[ 1425.921] (==) NVIDIA(0): Using gamma correction (1.0, 1.0, 1.0)
[ 1425.921] (**) NVIDIA(0): Enabling 2D acceleration
[ 1425.921] (II) Loading sub module "glxserver_nvidia"
[ 1425.921] (II) LoadModule: "glxserver_nvidia"
[ 1425.921] (WW) Warning, couldn't open module glxserver_nvidia
[ 1425.921] (EE) NVIDIA: Failed to load module "glxserver_nvidia" (module does not exist, 0)
[ 1425.921] (EE) NVIDIA(0): Failed to initialize the GLX module; please check in your X
[ 1425.921] (EE) NVIDIA(0): log file that the GLX module has been loaded in your X
[ 1425.921] (EE) NVIDIA(0): server, and that the module is the NVIDIA GLX module. If
[ 1425.921] (EE) NVIDIA(0): you continue to encounter problems, Please try
[ 1425.921] (EE) NVIDIA(0): reinstalling the NVIDIA driver.
[ 1426.074] (--) NVIDIA(0): Valid display device(s) on GPU-0 at PCI:1:0:0
[ 1426.074] (--) NVIDIA(0): DFP-0
[ 1426.074] (--) NVIDIA(0): DFP-1
[ 1426.075] (II) NVIDIA(0): NVIDIA GPU Quadro K2100M (GK106GL) at PCI:1:0:0 (GPU-0)
[ 1426.075] (--) NVIDIA(0): Memory: 2097152 kBytes
[ 1426.075] (--) NVIDIA(0): VideoBIOS: 80.06.63.00.1a
[ 1426.075] (II) NVIDIA(0): Detected PCI Express Link width: 16X
[ 1426.075] (--) NVIDIA(GPU-0): DFP-0: disconnected
[ 1426.075] (--) NVIDIA(GPU-0): DFP-0: Internal TMDS
[ 1426.075] (--) NVIDIA(GPU-0): DFP-0: 165.0 MHz maximum pixel clock
[ 1426.075] (--) NVIDIA(GPU-0):
[ 1426.075] (--) NVIDIA(GPU-0): DFP-1: disconnected
[ 1426.075] (--) NVIDIA(GPU-0): DFP-1: Internal DisplayPort
[ 1426.075] (--) NVIDIA(GPU-0): DFP-1: 960.0 MHz maximum pixel clock
[ 1426.075] (--) NVIDIA(GPU-0):
[ 1426.075] (EE) NVIDIA(0): Failed to assign any connected display devices to X screen 0.
[ 1426.075] (EE) NVIDIA(0): Set AllowEmptyInitialConfiguration if you want the server
[ 1426.075] (EE) NVIDIA(0): to start anyway
[ 1426.075] (EE) NVIDIA(0): Failing initialization of X screen
[ 1426.107] (II) UnloadModule: "nvidia"
[ 1426.107] (II) UnloadSubModule: "wfb"
[ 1426.107] (II) UnloadSubModule: "fb"
[ 1426.107] (EE) Screen(s) found, but none have a usable configuration.
[ 1426.107] (EE)
Fatal server error:
[ 1426.107] (EE) no screens found(EE)
[ 1426.107] (EE)
Please consult the The X.Org Foundation support
at http://wiki.x.org
for help.
[ 1426.107] (EE) Please also check the log file at "/var/log/Xorg.0.log" for additional information.
[ 1426.107] (EE)
[ 1426.117] (EE) Server terminated with error (1). Closing log file.
Ejecuté xrandr, pero me dijo que no puede abrir la pantalla. Supuse que esto podría deberse a que xorg no se configuró automáticamente, así que lo reinstalé, pero aún así no funcionó. Entonces agregué:
Section "Device"
Identifier "Screen0"
Driver "nouveau"
BusID "PCI:0:12:0"
EndSection
Section "Monitor"
Identifier "dummy_monitor"
HorizSync 28.0-80.0
VertRefresh 60.0
Modeline "1920x1080" 172.80 1920 2040 2248 2576 1080 1081 1084 1118
EndSection
Luego recibí un error diferente que decía "no se pudo configurar IOPL para E/S (operación no permitida)" antes del mismo error de que no se encontraron pantallas y el archivo de registro estaba en una ubicación diferente. Esta vez decía lo siguiente:
[ 240.358] (WW) Failed to open protocol names file lib/xorg/protocol.txt
[ 240.358]
X.Org X Server 1.20.5
X Protocol Version 11, Revision 0
[ 240.359] Build Operating System: Linux Arch Linux
[ 240.360] Current Operating System: Linux mohammed-laptop 5.1.14-arch1-1-ARCH #1 SMP PREEMPT Sat Jun 22 16:28:48 UTC 2019 x86_64
[ 240.360] Kernel command line: BOOT_IMAGE=/vmlinuz-linux root=UUID=6557ebc3-02f1-4d88-a79d-1afb43df18c7 rw quiet
[ 240.361] Build Date: 30 May 2019 06:44:40PM
[ 240.361]
[ 240.362] Current version of pixman: 0.38.4
[ 240.363] Before reporting problems, check http://wiki.x.org
to make sure that you have the latest version.
[ 240.363] Markers: (--) probed, (**) from config file, (==) default setting,
(++) from command line, (!!) notice, (II) informational,
(WW) warning, (EE) error, (NI) not implemented, (??) unknown.
[ 240.365] (==) Log file: "/home/mohammed/.local/share/xorg/Xorg.0.log", Time: Mon Jun 24 19:08:52 2019
[ 240.366] (==) Using config file: "/etc/X11/xorg.conf"
[ 240.367] (==) Using system config directory "/usr/share/X11/xorg.conf.d"
[ 240.367] (==) ServerLayout "Layout0"
[ 240.367] (**) |-->Screen "Screen0" (0)
[ 240.367] (**) | |-->Monitor "Monitor0"
[ 240.367] (**) | |-->Device "Device0"
[ 240.367] (**) | |-->GPUDevice "Device0"
[ 240.367] (**) |-->Input Device "Keyboard0"
[ 240.367] (**) |-->Input Device "Mouse0"
[ 240.367] (==) Automatically adding devices
[ 240.367] (==) Automatically enabling devices
[ 240.367] (==) Automatically adding GPU devices
[ 240.367] (==) Automatically binding GPU devices
[ 240.367] (==) Max clients allowed: 256, resource mask: 0x1fffff
[ 240.367] (WW) `fonts.dir' not found (or not valid) in "/usr/share/fonts/misc".
[ 240.367] Entry deleted from font path.
[ 240.367] (Run 'mkfontdir' on "/usr/share/fonts/misc").
[ 240.367] (WW) The directory "/usr/share/fonts/TTF" does not exist.
[ 240.367] Entry deleted from font path.
[ 240.367] (WW) The directory "/usr/share/fonts/OTF" does not exist.
[ 240.367] Entry deleted from font path.
[ 240.367] (WW) The directory "/usr/share/fonts/Type1" does not exist.
[ 240.367] Entry deleted from font path.
[ 240.367] (==) FontPath set to:
/usr/share/fonts/100dpi,
/usr/share/fonts/75dpi
[ 240.367] (==) ModulePath set to "/usr/lib/xorg/modules"
[ 240.367] (WW) Hotplugging is on, devices using drivers 'kbd', 'mouse' or 'vmmouse' will be disabled.
[ 240.367] (WW) Disabling Keyboard0
[ 240.367] (WW) Disabling Mouse0
[ 240.367] (II) Module ABI versions:
[ 240.367] X.Org ANSI C Emulation: 0.4
[ 240.367] X.Org Video Driver: 24.0
[ 240.367] X.Org XInput driver : 24.1
[ 240.367] X.Org Server Extension : 10.0
[ 240.368] (++) using VT number 1
[ 240.369] (II) systemd-logind: took control of session /org/freedesktop/login1/session/_31
[ 240.370] (II) xfree86: Adding drm device (/dev/dri/card0)
[ 240.371] (II) systemd-logind: got fd for /dev/dri/card0 226:0 fd 10 paused 0
[ 240.372] (--) PCI:*(0@0:2:0) 8086:0416:17aa:221e rev 6, Mem @ 0xb1400000/4194304, 0xa0000000/268435456, I/O @ 0x00005000/64, BIOS @ 0x????????/131072
[ 240.372] (--) PCI: (1@0:0:0) 10de:11fc:17aa:221e rev 161, Mem @ 0xb0000000/16777216, 0x80000000/268435456, 0x90000000/33554432, I/O @ 0x00004000/128, BIOS @ 0x????????/524288
[ 240.372] (WW) Open ACPI failed (/var/run/acpid.socket) (No such file or directory)
[ 240.372] (II) LoadModule: "glx"
[ 240.372] (II) Loading /usr/lib/xorg/modules/extensions/libglx.so
[ 240.373] (II) Module glx: vendor="X.Org Foundation"
[ 240.373] compiled for 1.20.5, module version = 1.0.0
[ 240.373] ABI class: X.Org Server Extension, version 10.0
[ 240.373] (II) LoadModule: "nvidia"
[ 240.373] (II) Loading /usr/lib/xorg/modules/drivers/nvidia_drv.so
[ 240.374] (II) Module nvidia: vendor="NVIDIA Corporation"
[ 240.374] compiled for 1.6.99.901, module version = 1.0.0
[ 240.374] Module class: X.Org Video Driver
[ 240.374] (II) NVIDIA dlloader X Driver 430.26 Tue Jun 4 17:52:10 CDT 2019
[ 240.374] (II) NVIDIA Unified Driver for all Supported NVIDIA GPUs
[ 240.374] xf86EnableIOPorts: failed to set IOPL for I/O (Operation not permitted)
[ 240.374] (EE) No devices detected.
[ 240.374] (EE)
Fatal server error:
[ 240.374] (EE) no screens found(EE)
[ 240.374] (EE)
Please consult the The X.Org Foundation support
at http://wiki.x.org
for help.
[ 240.374] (EE) Please also check the log file at "/home/mohammed/.local/share/xorg/Xorg.0.log" for additional information.
[ 240.374] (EE)
[ 240.397] (EE) Server terminated with error (1). Closing log file.
¿Qué tengo que hacer?
Respuesta1
El problema que estás teniendo se debe a que Xidentificadostarjetas en (obviamente) 2 ranuras diferentes. La razón por la que parece obtener resultados diferentes es que Xlas sondas están eligiendo una tarjeta u otra.
Hay un par de direcciones diferentes que puedes tomar;
- elimine (comente) la ranura que ha elegido y vea si
X[1] elige la tarjeta probada con un puerto activo (conectado a su monitor) - comenta el slot que tienes en tu configuración y declara el otro
Esta es la entrada de tu registro que indica de lo que estoy hablando.
[ 1425.919] (--) PCI:*(0@0:2:0) 8086:0416:17aa:221e rev 6, Mem @ 0xb1400000/4194304, 0xa0000000/268435456, I/O @ 0x00005000/64, BIOS @ 0x????????/131072
[ 1425.919] (--) PCI: (1@0:0:0) 10de:11fc:17aa:221e rev 161, Mem @ 0xb0000000/16777216, 0x80000000/268435456, 0x90000000/33554432, I/O @ 0x00004000/128, BIOS @ 0x????????/524288
Por último, deberías intentar poner lo menos posible en tu archivo de configuración. As Xse ha vuelto bastante bueno en tomar todas las decisiones correctas.
IOW Sólo haga adiciones cuando los resultados no sean los deseados. :)
1) antes
BusID "PCI:0:12:0"
después
# BusID "PCI:0:12:0"
Respuesta2
Has configurado Xorg para usarnuevo, pero sus registros de inicio muestran que está intentando utilizar el propietarionvidiaconductor. No puedes mezclar los dos.
Desinstalar elnvidiacontrolador por completo, elimine toda la configuración de Xorg y vuelva a intentarlo. (Si usa nvidia, proporcionará su propia configuración. Si usa nouveau, Xorg detectará automáticamente los dispositivos sin ninguna configuración manual).
