El certificado SSL no funciona con la dirección IP para SAN

Question

Estoy intentando crear un certificado SSL para un servidor que funcionará internamente sin dar advertencias en Chrome. Lo creé usando SAN con múltiples nombres alternativos de sujeto de localhost y la dirección IP. Por alguna razón, funciona en localhost pero da un error al usar la dirección IP tanto en Chrome como curlen Chrome.

$ curl https://192.168.1.50
curl: (51) Unable to communicate securely with peer: requested domain name does not match the server's certificate.

$ curl https://localhost
<a href="https://localhost:9090/">Moved Permanently</a>.

Verificarlo en la línea de comandos muestra ambos nombres en la sección SAN, así que no estoy seguro de por qué esto no funciona:

$ openssl x509 -text -noout -in server.crt
Certificate:
    Data:
        Version: 3 (0x2)
        Serial Number:
            8d:93:a1:be:d1:03:8f:59
    Signature Algorithm: sha256WithRSAEncryption
        Issuer: C=US, ST=California, L=Los Angeles, O=Alt Systems, OU=Internal, CN=Elliott/emailAddress=xxxxxx
        Validity
            Not Before: Nov  5 21:32:19 2019 GMT
            Not After : Mar 19 21:32:19 2021 GMT
        Subject: C=US, ST=CA, L=Los Angeles, O=Alt Systems, OU=Internal/emailAddress=xxxxxx, CN=alt-pix-la
        Subject Public Key Info:
            Public Key Algorithm: rsaEncryption
                Public-Key: (2048 bit)
                Modulus:
                    00:b0:53:b6:0b:f0:94:c1:a8:26:93:79:5a:45:86:
                    36:ac:60:c2:40:a2:bf:25:69:90:9f:8b:b9:3f:63:
                    30:ae:48:cc:f9:f0:9d:d4:15:3d:1c:20:bc:29:6f:
                    57:8f:7d:e9:a5:db:2b:2c:ac:1a:6f:6d:b9:17:98:
                    0e:a0:17:1f:3e:28:4e:42:bd:af:2e:54:dd:ec:ff:
                    7b:00:a5:ed:59:97:8a:6f:95:04:c9:eb:3a:6c:ec:
                    9e:c9:7e:12:ee:ce:cc:be:b7:c1:d3:fe:f6:cf:1d:
                    0d:68:07:68:52:7a:30:5f:f1:29:36:64:b2:a5:e8:
                    5e:a7:f9:75:ab:4b:aa:4b:12:aa:44:59:a3:df:18:
                    45:81:52:b1:4d:00:a4:f2:eb:7e:0d:3e:05:f9:94:
                    1a:aa:e4:2e:9a:ee:0c:59:91:b9:63:f3:5d:98:3b:
                    32:4e:f7:1b:47:e5:a7:54:5c:ba:75:9b:88:09:07:
                    cc:93:06:c3:8a:76:78:83:98:69:1a:8b:e2:fd:cf:
                    70:51:35:09:ba:67:ca:c1:81:f4:65:72:0a:15:7a:
                    12:2d:bc:65:04:7f:b8:c3:22:2b:79:8d:9a:62:54:
                    d2:89:3f:4a:02:72:36:27:6c:ad:50:4d:96:e5:a1:
                    df:8b:fe:51:0b:67:1b:44:4e:57:fc:bb:d7:1d:77:
                    9f:c3
                Exponent: 65537 (0x10001)
        X509v3 extensions:
            X509v3 Authority Key Identifier:
                keyid:BC:39:94:F0:DC:DF:5D:8E:12:E1:DA:5F:8F:7C:C8:02:B4:0E:19:19

            X509v3 Basic Constraints:
                CA:FALSE
            X509v3 Key Usage:
                Digital Signature, Non Repudiation, Key Encipherment, Data Encipherment
            X509v3 Subject Alternative Name:
                DNS:localhost, DNS:192.168.1.50
    Signature Algorithm: sha256WithRSAEncryption
         54:8e:98:93:53:c2:af:fc:b7:03:5c:6d:d3:7d:9a:d9:2f:99:
         ac:29:dc:0f:02:55:36:9e:70:57:68:df:27:5f:5e:a8:43:05:
         ff:a4:7e:bd:15:99:ff:aa:67:35:93:90:35:e0:e7:20:b4:77:
         7c:bf:6f:29:13:46:fc:56:81:58:60:67:14:ae:a1:1b:44:80:
         92:81:7f:ed:5c:bc:75:36:a9:11:52:9b:28:e1:18:d6:a4:17:
         35:13:6c:bd:be:64:db:70:a5:d4:7f:3e:16:26:73:f9:27:ed:
         7b:03:44:b3:59:2d:53:8d:e2:77:f1:6d:8d:21:c0:d0:2c:96:
         27:0c:c6:4e:6f:63:35:61:3e:b5:62:05:88:76:b5:99:ca:7d:
         64:f9:6b:f4:9b:18:8e:3a:77:82:59:d2:13:c0:14:3c:0a:dc:
         8d:82:38:ca:af:e9:43:06:83:ae:6e:4f:73:29:1d:0a:da:91:
         ea:72:f4:26:f3:59:98:8d:ca:1a:ad:19:17:fd:bb:9f:62:bf:
         85:e0:12:bd:9b:93:26:73:2b:9a:77:ff:c4:34:29:25:fc:c7:
         13:8f:94:b3:28:d7:79:dc:54:57:6c:3d:01:f0:37:5c:a9:28:
         23:13:89:7b:c5:63:51:eb:fc:ad:37:d1:31:cf:f4:2f:8c:9c:
         5f:35:07:79

Answer 1

Estás utilizando el tipo de SAN incorrecto: solo el dominio realnombresestán permitidos en SAN de tipo "DNS"; para las direcciones IP existe el tipo "iPAddress" ( [7] OCTET STRING).

Para OpenSSL puedes usar:

subjectAltName=IP:192.168.1.50

subjectAltName=IP:2001:db8:1234::4567

Answer 2

Debe agregar su dirección IP a SAN. Este código funciona para mí. Agregue su dirección IP de esta manera.

[alternate_names]
IP.1 = 127.0.0.1

Answer 3

Ejemplo de un extremo a otro usando OpenSSL: debe crear una configuración llamada openssl-san.cnf (tomado de:https://help.bizagi.com/bpm-suite/es/index.html?subjectaltname_support.htm):

[ req ]

default_bits           = 4096

distinguished_name     = req_distinguished_name

req_extensions         = req_ext



[ req_distinguished_name ]

countryName            = Country Name (2 letter code)

stateOrProvinceName    = State or Province Name (full name)

localityName           = Locality Name (eg, city)

organizationName       = Organization Name (eg, company)

commonName             = Common Name (e.g. server FQDN or YOUR name)



# Optionally, specify some defaults.
countryName_default           = [Country]
stateOrProvinceName_default   = [State]
localityName_default           = [City]
0.organizationName_default     = [Organization]
organizationalUnitName_default = [Organization unit]
emailAddress_default           = [Email]



[ req_ext ]

subjectAltName = @alt_names



[alt_names]

DNS.1   = [DNS1]

DNS.2   = [DNS2]

IP.1    = [IP Adddress]

Y luego ejecute este comando para crear una clave y una solicitud de firma de certificado (csr):

openssl req -newkey rsa:4096 -keyout key.key -out keycsr.csr -config openssl-san.cnf

Para verificar la CSR que creó, haga lo siguiente:

openssl req -text -noout -verify -in keycsr.csr

Luego puede firmar la CSR usted mismo, pasarla a una CA para que la firme, etc.
