¿Cómo dibujar un diagrama esquemático de la industria en LaTeX?

Question

¿Es posible crear el siguiente diagrama en LaTeX? Estoy interesado en el cuerpo principal, cualquier color dentro de la caja está bien.

Answer 1

\documentclass{standalone}
\usepackage{tikz}

\usetikzlibrary{positioning}
\usetikzlibrary{decorations.pathreplacing}

\begin{document}


\begin{tikzpicture} [align=left]
    \node [draw] (home) {Home\\(capital-abundant)};
    \draw (home.east) -- ++(2,0) node [above] (cloth) {Cloth}
        -- ++(2,0) node [above] (food) {Food} -- ++(1,0) node [coordinate] (topend) {};
    \node[below=of home] (mid) {};
    \draw[dashed] (cloth |- mid) -- (topend |- mid);
    \node [draw, below=of mid] (foreign) {Foreign\\(labor-abundant)};
    \draw (foreign.east) -- (topend |- foreign);
    \draw[->] (cloth) -- (cloth |- foreign);
    \draw[->] (food |- mid) -- (food);
    \node [coordinate,right=0.1cm of cloth] (c1) {};
    \draw[->] (c1 |- foreign) -- (c1 |- mid);
    \draw[decorate,decoration={brace, amplitude=4pt}]
            (topend) -- (topend |- mid) node[midway, right=3pt]{Interindustry};
    \draw[decorate,decoration={brace, amplitude=4pt}]
            (topend |- mid) -- (topend |- foreign) node[midway, right=3pt]{Intraindustry};
\end{tikzpicture}

\end{document}
