Estoy intentando preparar una presentación usando el modo proyector de LaTeX. Por alguna razón, las subsecciones de mi última sección no aparecen en el TOC.
Aquí está mi MWE (incluidos todos los paquetes que estoy usando):
\documentclass[a4paper,11pt,fleqn,compress]{beamer}
\usepackage[english,ngerman]{babel} % language listed last is default setting
\usepackage[utf8x]{inputenc}
\usepackage{amsmath, amsthm, amssymb, amsbsy}
\usepackage{nccmath} % includes {fleqn} environment
\usepackage{bbm} % includes \mathbbm{} symbols
\usepackage{braket} % Bra-Ket notation in quantum mechanics
\usepackage{helvet} % font set to "helvetica"
\usepackage[normalem]{ulem}
\usepackage{microtype}
\parindent=0mm % indent to indicate new paragraph prohibited
\makeatletter
\@addtoreset{section}{chapter}
\makeatother % section count set to 0 when new chapter begins
\usepackage{listliketab}
\usepackage{tabto}
\usepackage{isotope}
\usepackage{extarrows}
\usepackage{graphicx}
\usepackage{grffile} % changes the algorithm to check for known file extensions instead of using the first dot "." to find the file extension as conducted by "graphicx" and also "graphcis"
\DeclareMathSizes{12}{9}{7}{5}
\usepackage{caption}
\usepackage{subfigure}
\let\origitem\item
\renewcommand{\item}{\normalfont\origitem}
\newcommand{\bolditem}{\normalfont\bfseries\origitem}
\newcommand{\eqqcolon}{\mathrel{=\!\!\mathop:}}
\newcommand{\coloneqq}{\mathrel{\mathop:\!\!=}}
\usepackage{pdfpages}
% following content recommended for LaTeX beamer mode
\title{\textbf{Title}}
\subtitle{Subtitle}
\author{Author}
\institute{Institute}
\date{\scriptsize{Date}}
\setbeamertemplate{navigation symbols}{} % default navigation symbols hidden
\usetheme{Berlin}
\setbeamertemplate{section in toc}[sections numbered]
\setbeamertemplate{subsection in toc}[subsections numbered]
\setbeamertemplate{section in head/foot} {\hfill\insertsectionheadnumber.~\insertsectionhead}
\setbeamertemplate{section in head/foot shaded}{\color{structure!50}\hfill\insertsectionheadnumber.~\insertsectionhead}
\setbeamertemplate{section in toc}{\inserttocsectionnumber.~\inserttocsection}
\AtBeginSection[]
{
\begin{frame}
\frametitle{Table of Contents}
\small \tableofcontents[currentsection,hideothersubsections]
\end{frame}
} % display table of contents with current section higlighted automatically
\begin{document}
{ % to delimit a block (changes apply for this block only)
\makeatletter % to change template
\setbeamertemplate{headline}[default]
\def\beamer@entrycode{\vspace*{-\headheight}}
\setbeamertemplate{footline}[default]
\def\beamer@entrycode{\vspace*{-\footheight}}
\makeatother
\frame{\titlepage}
}
{ % to delimit a block (changes apply for this block only)
\makeatletter % to change template
\setbeamertemplate{headline}[default]
\def\beamer@entrycode{\vspace*{-\headheight}}
\makeatother
\begin{frame}
\frametitle{Table of Contents} \small \tableofcontents
\end{frame}
}
\section{Section 1}
\subsection{Subsection 1.1}
\subsection{Subsection 1.2}
\subsection{Subsection 1.3}
\subsection{Subsection 1.4}
\section{Section 2}
\subsection{Subsection 2.1}
\subsection{Subsection 2.2}
\section{Section 3}
\subsection{Subsection 3.1}
\subsection{Subsection 3.2}
\subsection{Subsection 3.3}
\subsection{Subsection 3.4}
\section{Section 4}
\section{Section 5}
\subsection{Subsection 5.1}
\subsection{Subsection 5.2}
\end{document}
Parece que no puedo encontrar mi error. Gracias por su ayuda.
Respuesta1
Para que las secciones aparezcan en el TOC, deben agregarse al .tocarchivo. Parece que para que esto suceda, es necesario que se escriba algo después del comando de sección correspondiente. Porque \sectionestá configurado paracomponeruna versión de la tabla de contenido, \sectionsiempre agregará la sección al TOC. Sin embargo, en el caso de \subsection, este no es el caso, por lo que para agregarlos, se debe agregar algo explícitamente después del comando correspondiente. Como señala Torbjørn T., esto podría ser un marco que contenga contenido. Pero podría ser otro \sectioncomando:
\documentclass[a4paper,11pt,fleqn,compress]{beamer}
% following content recommended for LaTeX beamer mode
\title{\textbf{Title}}
\subtitle{Subtitle}
\author{Author}
\institute{Institute}
\date{\scriptsize{Date}}
\setbeamertemplate{navigation symbols}{} % default navigation symbols hidden
\usetheme{Berlin}
\setbeamertemplate{section in toc}[sections numbered]
\setbeamertemplate{subsection in toc}[subsections numbered]
\setbeamertemplate{section in head/foot} {\hfill\insertsectionheadnumber.~\insertsectionhead}
\setbeamertemplate{section in head/foot shaded}{\color{structure!50}\hfill\insertsectionheadnumber.~\insertsectionhead}
\setbeamertemplate{section in toc}{\inserttocsectionnumber.~\inserttocsection}
\AtBeginSection[]
{
\begin{frame}
\frametitle{Table of Contents}
\small \tableofcontents[currentsection,hideothersubsections]
\end{frame}
} % display table of contents with current section higlighted automatically
\begin{document}
\frame[plain]{\titlepage}
{ % to delimit a block (changes apply for this block only)
\makeatletter % to change template
\setbeamertemplate{headline}[default]
\def\beamer@entrycode{\vspace*{-\headheight}}
\makeatother
\begin{frame}
\frametitle{Table of Contents} \small \tableofcontents
\end{frame}
}
\section{Section 1}
\subsection{Subsection 1.1}
\subsection{Subsection 1.2}
\subsection{Subsection 1.3}
\subsection{Subsection 1.4}
\section{Section 2}
\subsection{Subsection 2.1}
\subsection{Subsection 2.2}
\section{Section 3}
\subsection{Subsection 3.1}
\subsection{Subsection 3.2}
\subsection{Subsection 3.3}
\subsection{Subsection 3.4}
\section{Section 4}
\section{Section 5}
\subsection{Subsection 5.1}
\subsection{Subsection 5.2}
\section{Section 6}
\end{document}
