Intenté extender este marco de flujo a la página siguiente, lo cual no sucede. Incluso intenté definir los números de página [1-2], pero el compilador aún no alinea el texto. Necesito que el flujo continúe en la página siguiente. Me está restringiendo a una sola página.
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% Document properties and packages
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\documentclass[a4paper,12pt,final]{memoir}
% misc
\renewcommand{\familydefault}{bch} % font
\pagestyle{empty} % no pagenumbering
\setlength{\parindent}{0pt} % no paragraph indentation
% required packages (add your own)
\usepackage{flowfram} % column layout
\usepackage[top=1cm,left=1cm,right=1cm,bottom=1cm]{geometry}% margins
\usepackage{graphicx} % figures
\usepackage{url} % URLs
\usepackage[usenames,dvipsnames]{xcolor} % color
\usepackage{multicol} % columns env.
\setlength{\multicolsep}{0pt}
\usepackage{paralist} % compact lists
\usepackage{tikz}
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% Create column layout
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% define length commands
\setlength{\vcolumnsep}{\baselineskip}
\setlength{\columnsep}{\vcolumnsep}
% frame setup (flowfram package)
% left frame
\newflowframe{0.2\textwidth}{\textheight}{0pt}{0pt}[left]
\newlength{\LeftMainSep}
\setlength{\LeftMainSep}{0.2\textwidth}
\addtolength{\LeftMainSep}{2\columnsep}
% right frame
\newflowframe{0.7\textwidth}{\textheight}{\LeftMainSep}{0pt}[main01]
% horizontal rule between frames (using TikZ)
\renewcommand{\ffvrule}[3]{%
\hfill
\tikz{%
\draw[loosely dotted,color=RoyalBlue,line width=1.5pt,yshift=-#1]
(0,0) -- (0pt,#3);}%
\hfill\mbox{}}
\insertvrule{flow}{1}{flow}{2}
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% define macros (for convience)
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\newcommand{\Sep}{\vspace{1.5em}}
\newcommand{\SmallSep}{\vspace{0.5em}}
\newenvironment{AboutMe}
{\ignorespaces\textbf{\color{RoyalBlue} About me}}
{\Sep\ignorespacesafterend}
\newcommand{\CVSection}[1]
{\Large\textbf{#1}\par
\SmallSep\normalsize\normalfont}
\newcommand{\CVItem}[1]
{\textbf{\color{RoyalBlue} #1}}
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% Begin document
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\begin{document}
% Left frame
%%%%%%%%%%%%%%%%%%%%
%
% Upload your own photo using the files menu
\begin{figure}
\hfill
\includegraphics[width=0.6\columnwidth]{cv-photo.png}
\vspace{-7cm}
\end{figure}
\begin{flushright}\small
Johnathan S. Doe \\
\url{[email protected]} \\
\url{www.website.com} \\
(555) 555-3333
\end{flushright}\normalsize
\framebreak
% Right frame
%%%%%%%%%%%%%%%%%%%%
\Huge\bfseries {\color{RoyalBlue} John Doe} \\
\Large\bfseries Graphics designer \\
\normalsize\normalfont
% About me
\begin{AboutMe}
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Vivamus vel bibendum metus. Proin rutrum pharetra molestie. Cras sollicitudin nulla nec leo lobortis in tristique purus pretium. Ut eu felis nulla. Pellentesque condimentum justo ut ligula feugiat nec facilisis tellus ultricies. Nullam sit amet dictum ipsum. Sed lacus neque, hendrerit eu rhoncus nec, pellentesque vitae sem.
\end{AboutMe}
% Experience
\CVSection{Experience}
\CVItem{May 2010 - present, Lorem ipsum}\\
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Vivamus vel bibendum metus. Proin rutrum pharetra molestie. Cras sollicitudin nulla nec leo lobortis in tristique purus pretium. Ut eu felis nulla.
\SmallSep
\CVItem{Aug 2007 - Feb 2010, Vivamus vel}\\
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Vivamus vel bibendum metus.
\Sep
% Education
\CVSection{Education}
\CVItem{2010 - present, Lorem ipsum dolor}\\
MSc. Lorem ipsum, Cras sollicitudin
\SmallSep
\CVItem{2007 - 2010, Lorem ipsum dolor}\\
MSc. Lorem ipsum, Cras sollicitudin
\SmallSep
\CVItem{2005 - 2007, Vivamus vel bibendum}\\
Proin rutrum pharetra molestie. Cras sollicitudin nulla nec leo lobortis in tristique purus pretium. Ut eu felis nulla.
\Sep
% Skills
\CVSection{Skills}
\CVItem{Platforms}
\begin{multicols}{3}
\begin{compactitem}[\color{RoyalBlue}$\circ$]
\item Lorem
\item Ipsum
\end{compactitem}
\end{multicols}
\SmallSep
\CVItem{Computer software}
\begin{multicols}{3}
\begin{compactitem}[\color{RoyalBlue}$\circ$]
\item Lorem
\item Ipsum
\item Dolor
\item Sit
\item Amet
\item Consectetur
\item Adipiscing
\item Elit
\item \ldots
\end{compactitem}
\end{multicols}
\Sep
% References
\CVSection{References}
References upon request.
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% End document
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\end{document}
Respuesta1
Su MWE en realidad no tiene dos páginas de texto, por lo que agregué texto ficticio adicional usando ellipsumpaquete. El problema es que el texto en el marco derecho de la página uno fluye hacia el marco izquierdo mucho más estrecho de la página dos, lo que causa un problema en TeX ya que no puede ajustar el ancho de la línea a mitad del párrafo. Sin embargo, sospecho que en realidad desea que el texto en el marco derecho de la página uno fluya hacia el marco derecho de la página dos. En cuyo caso, el marco izquierdo es más adecuado como marco dinámico y el contenido se puede configurar usando el entorno dynamiccontents(o dynamiccontents*) o uno de los comandos como \setdynamiccontents. Aquí tienes una modificación de tu MWE:
\documentclass[a4paper,12pt,final,oneside]{memoir}
% misc
\renewcommand{\familydefault}{bch} % font
\pagestyle{empty} % no pagenumbering
\setlength{\parindent}{0pt} % no paragraph indentation
% required packages (add your own)
\usepackage{flowfram} % column layout
\usepackage[top=1cm,left=1cm,right=1cm,bottom=1cm]{geometry}% margins
\usepackage{graphicx} % figures
\usepackage{url} % URLs
\usepackage[usenames,dvipsnames]{xcolor} % color
\usepackage{multicol} % columns env.
\setlength{\multicolsep}{0pt}
\usepackage{paralist} % compact lists
\usepackage{tikz}
\usepackage{lipsum}
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% Create column layout
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% define length commands
\setlength{\vcolumnsep}{\baselineskip}
\setlength{\columnsep}{\vcolumnsep}
% frame setup (flowfram package)
% left frame
\newdynamicframe{0.2\textwidth}{\textheight}{0pt}{0pt}[left]
\newlength{\LeftMainSep}
\setlength{\LeftMainSep}{0.2\textwidth}
\addtolength{\LeftMainSep}{2\columnsep}
\setdynamicframe*{left}{clear}
% right frame
\newflowframe{0.7\textwidth}{\textheight}{\LeftMainSep}{0pt}[main01]
% horizontal rule between frames (using TikZ)
\renewcommand{\ffvrule}[3]{%
\hfill
\tikz{%
\draw[loosely dotted,color=RoyalBlue,line width=1.5pt,yshift=-#1]
(0,0) -- (0pt,#3);}%
\hfill\mbox{}}
\insertvrule*{dynamic}{left}{flow}{main01}
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% define macros (for convience)
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\newcommand{\Sep}{\vspace{1.5em}}
\newcommand{\SmallSep}{\vspace{0.5em}}
\newenvironment{AboutMe}
{\ignorespaces\textbf{\color{RoyalBlue} About me}}
{\Sep\ignorespacesafterend}
\newcommand{\CVSection}[1]
{\Large\textbf{#1}\par
\SmallSep\normalsize\normalfont}
\newcommand{\CVItem}[1]
{\textbf{\color{RoyalBlue} #1}}
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% Begin document
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\begin{document}
% Left frame
%%%%%%%%%%%%%%%%%%%%
%
% Upload your own photo using the files menu
\begin{dynamiccontents*}{left}
{\centering
\includegraphics[width=0.6\linewidth]{example-image}
\par
}
\begin{flushright}\small
Johnathan S. Doe \\
\url{[email protected]} \\
\url{www.website.com} \\
(555) 555-3333
\end{flushright}\normalsize
\end{dynamiccontents*}
% Right frame
%%%%%%%%%%%%%%%%%%%%
\Huge\bfseries {\color{RoyalBlue} John Doe} \\
\Large\bfseries Graphics designer \\
\normalsize\normalfont
% About me
\begin{AboutMe}
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Vivamus vel bibendum metus. Proin rutrum pharetra molestie. Cras sollicitudin nulla nec leo lobortis in tristique purus pretium. Ut eu felis nulla. Pellentesque condimentum justo ut ligula feugiat nec facilisis tellus ultricies. Nullam sit amet dictum ipsum. Sed lacus neque, hendrerit eu rhoncus nec, pellentesque vitae sem.
\end{AboutMe}
% Experience
\CVSection{Experience}
\CVItem{May 2010 - present, Lorem ipsum}\\
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Vivamus vel bibendum metus. Proin rutrum pharetra molestie. Cras sollicitudin nulla nec leo lobortis in tristique purus pretium. Ut eu felis nulla.
\SmallSep
\CVItem{Aug 2007 - Feb 2010, Vivamus vel}\\
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Vivamus vel bibendum metus.
\Sep
% Education
\CVSection{Education}
\CVItem{2010 - present, Lorem ipsum dolor}\\
MSc. Lorem ipsum, Cras sollicitudin
\SmallSep
\CVItem{2007 - 2010, Lorem ipsum dolor}\\
MSc. Lorem ipsum, Cras sollicitudin
\SmallSep
\CVItem{2005 - 2007, Vivamus vel bibendum}\\
Proin rutrum pharetra molestie. Cras sollicitudin nulla nec leo lobortis in tristique purus pretium. Ut eu felis nulla.
\Sep
% Skills
\CVSection{Skills}
\CVItem{Platforms}
\begin{multicols}{3}
\begin{compactitem}[\color{RoyalBlue}$\circ$]
\item Lorem
\item Ipsum
\end{compactitem}
\end{multicols}
\SmallSep
\CVItem{Computer software}
\begin{multicols}{3}
\begin{compactitem}[\color{RoyalBlue}$\circ$]
\item Lorem
\item Ipsum
\item Dolor
\item Sit
\item Amet
\item Consectetur
\item Adipiscing
\item Elit
\item \ldots
\end{compactitem}
\end{multicols}
\Sep
% References
\CVSection{References}
References upon request.
\lipsum
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
% End document
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
\end{document}
Las principales diferencias son: la onesideopción de clase, cambiar el marco izquierdo a un marco dinámico y configurar su contenido usando el dynamiccontents*entorno. yo también he usado
\setdynamicframe*{left}{clear}
Para borrar el marco izquierdo después de cada salto de página. Elimina esta línea si no quieres que eso suceda.
