¿Cómo hacer el punto en medio del cuadrado?

Question

\begin{tikzpicture}

\coordinate (1) at (0,0);
\coordinate (2) at (2,0);
\coordinate (3) at (2,2);
\coordinate (4) at (0,2);
\coordinate (5) at (0,0);
\coordinate (6) at ($(1)!.5!(2)$);
\coordinate (7) at ($(2)!.5!(3)$);
\coordinate (8) at ($(3)!.5!(4)$);
\coordinate (9) at ($(4)!.5!(1)$);


\foreach \i in {1,2}
\fill (\i) circle (1pt) node [below] {\tiny \i};
\foreach \i in {3,4}
\fill (\i) circle (1pt) node [above] {\tiny \i};
\foreach \i in {6}
\fill (\i) circle (1pt) node [below] {\tiny 5};
\foreach \i in {7}
\fill (\i) circle (1pt) node [right] {\tiny 6};
\foreach \i in {8}
\fill (\i) circle (1pt) node [above] {\tiny 7};
\foreach \i in {9}
\fill (\i) circle (1pt) node [left] {\tiny 8};

\draw (1)--(2)--(3)--(4)--(5);

\end{tikzpicture}

El código anterior para el cuadrado del lado derecho quiero hacer el punto medio que da en el punto cuadrado izquierdo (9).

Answer 1

Puede calcular el punto medio (9)a través de (1)!0.5!(3), que denota un punto 0.5desde la forma del camino (1)hasta (3). También lo he reducido a uno solo \foreach:

Código:

documentclass{article}

\usepackage{tikz}
\usetikzlibrary{calc}
\begin{document}


\begin{tikzpicture}

\coordinate (1) at (0,0);
\coordinate (2) at (2,0);
\coordinate (3) at (2,2);
\coordinate (4) at (0,2);
\coordinate (5) at ($(1)!.5!(2)$);
\coordinate (6) at ($(2)!.5!(3)$);
\coordinate (7) at ($(3)!.5!(4)$);
\coordinate (8) at ($(1)!.5!(4)$);
\coordinate (9) at ($(1)!.5!(3)$);


\foreach \i/\Position in {1/below, 2/below, 3/above, 4/above, 5/below, 6/right, 7/above, 8/left, 9/above right} {
    \fill (\i) circle (1pt) node [\Position] {\tiny \i};
}

\draw (1)--(2)--(3)--(4)-- cycle;

\end{tikzpicture}
\end{document}

Answer 2

También puedes utilizar las coordenadas otogonales.

\coordinate (9) at (8-|5);   %%% <--- new

(8-|5)significa tomar ylas mismas coordenadas que las del nodo (8)y las coordenadas x que las del nodo (5).

Además, el \foreachbucle se puede refinar.

\documentclass[tikz,varwidth]{standalone}%

\usetikzlibrary{calc,positioning}
\begin{document}

\begin{tikzpicture}

\coordinate (1) at (0,0);
\coordinate (2) at (2,0);
\coordinate (3) at (2,2);
\coordinate (4) at (0,2);
\coordinate (5) at ($(1)!.5!(2)$);
\coordinate (6) at ($(2)!.5!(3)$);
\coordinate (7) at ($(3)!.5!(4)$);
\coordinate (8) at ($(4)!.5!(1)$);
\coordinate (9) at (8-|5);   %%% <--- new


\foreach \i/\position in {1/below,2/below,3/above,4/above,5/below,6/right,7/above,8/left,9/above right}
\fill (\i) circle (1pt) node [\position] {\tiny \i};

\draw (1)--(2)--(3)--(4)--cycle;

\end{tikzpicture}
\end{document}

Otra forma sencilla es utilizar un nodo rectangular.

\documentclass[tikz,varwidth]{standalone}%

\usetikzlibrary{calc,positioning}
\begin{document}

\begin{tikzpicture}

\node[draw,minimum height=2cm,minimum width=2cm] (a) at (1,1) {};

\foreach \i/\a/\position in
{south west/1/below,south east/2/below,north east/3/above,north west/4/above,
south/5/below,east/6/right,north/7/above,west/8/left,center/9/above right} {%
  \fill (a.\i) circle (1pt) node [\position] {\tiny \a};
}
\end{tikzpicture}
\end{document}
