Estoy intentando establecer la cantidad de muestras por tikzpicture a nivel mundial:
\documentclass{standalone}
\usepackage{pgfplots}
\pgfmathdeclarefunction{gauss}{2}{%
\pgfmathparse{1/(#2*sqrt(2*pi))*exp(-((x-#1)^2)/(2*#2^2))}%
}
%\samplesize = <number>% How do I get this one to work?
\begin{document}
\section{Gaussian distribution}
\begin{tikzpicture}
\begin{axis}[
hide y axis,
axis lines*=center,
axis on top,
no markers,
domain=2.5:25.5,
samples=\samplesize,
xlabel=\empty,
ylabel=\empty,
every axis x label/.style={at=(current axis.right of origin),anchor=west},
every axis y label/.style={at=(current axis.above origin),anchor=south},
height=5cm, width=12cm,
xmin = 4, xmax=24,
xtick={14}, ytick=\empty,
enlargelimits=false,
clip=false,
grid=major
]
\addplot [fill=cyan!20, draw=cyan!80, domain=4:7] {gauss(14,3.41696)} \closedcycle;
\addplot [very thick,cyan!50!black] {gauss(14,3.416969)};
\end{axis}
\end{tikzpicture}
\end{document}
No pude hacer que esto funcionara con contadores primitivos TeX, \value
, \def
, \let
, \newcommand
etc.
Respuesta1
Puedes usar \newcommand
para esto, por ejemplo
\newcommand\samplesize{100}
Tenga en cuenta también que, de forma predeterminada, la standalone
clase no parece manejar encabezados de sección (entre otras cosas), pero si los agrega, varwidth=true
funcionará. (Aunque \section
quizás era solo una reliquia de un documento completo).
Código completo:
\documentclass[varwidth=true]{standalone}
\usepackage{pgfplots}
\pgfmathdeclarefunction{gauss}{2}{%
\pgfmathparse{1/(#2*sqrt(2*pi))*exp(-((x-#1)^2)/(2*#2^2))}%
}
\newcommand\samplesize{100}
\begin{document}
\section{Gaussian distribution}
\begin{tikzpicture}
\begin{axis}[
hide y axis,
axis lines*=center,
axis on top,
no markers,
domain=2.5:25.5,
samples=\samplesize,
xlabel=\empty,
ylabel=\empty,
every axis x label/.style={at=(current axis.right of origin),anchor=west},
every axis y label/.style={at=(current axis.above origin),anchor=south},
height=5cm, width=12cm,
xmin = 4, xmax=24,
xtick={14}, ytick=\empty,
enlargelimits=false,
clip=false,
grid=major
]
\addplot [fill=cyan!20, draw=cyan!80, domain=4:7] {gauss(14,3.41696)} \closedcycle;
\addplot [very thick,cyan!50!black] {gauss(14,3.416969)};
\end{axis}
\end{tikzpicture}
\end{document}
