Estuve usando matlab2tikz el año pasado en Mac y funcionó perfectamente bien. Ahora lo estoy usando en Ubuntu y encuentro algunos problemas. Para su información, instalé texlive-full que incluye pgf 2.1 y en mi preámbulo agregué \usepackage{tikz} y \usepackage{pgfplots}. Cuando compilo mi documento de látex (clase beamer) en KILE, aparece el siguiente mensaje de error:
`(./TIKZTest.tikz
! Missing \endcsname inserted.
<to be read again>
\def
l.25 };
! LaTeX Error: Something's wrong--perhaps a missing \item.
See the LaTeX manual or LaTeX Companion for explanation.
Type H <return> for immediate help.
...
l.25 };
! LaTeX Error: Something's wrong--perhaps a missing \item.
See the LaTeX manual or LaTeX Companion for explanation.
Type H <return> for immediate help.
...
l.25 };
! Missing control sequence inserted.
<inserted text>
\inaccessible
l.25 };
! LaTeX Error: Something's wrong--perhaps a missing \item.
See the LaTeX manual or LaTeX Companion for explanation.
Type H <return> for immediate help.
...
l.25 };
! LaTeX Error: Something's wrong--perhaps a missing \item.
See the LaTeX manual or LaTeX Companion for explanation.
Type H <return> for immediate help.
...
l.25 };
! Undefined control sequence.
<recently read> \pgfplotstable@loc@TMPa
l.25 };
! Package pgfplots Error: The requested list entry with index 0 of \pgfplots@ta
ble is too large; this list has not enough elements..
See the pgfplots package documentation for explanation.
Type H <return> for immediate help.
...
l.25 };
! Package pgfplots Error: Sorry, could not retrieve column '' from table '\\pgf
plots@table@@table@name '. Please check spelling (or introduce name aliases)..
See the pgfplots package documentation for explanation.
Type H <return> for immediate help.
...
l.25 };
! Package pgfplots Error: The requested list entry with index 1 of \pgfplots@ta
ble is too large; this list has not enough elements..
See the pgfplots package documentation for explanation.
Type H <return> for immediate help.
...
l.25 };
! Package pgfplots Error: Sorry, could not retrieve column '' from table '\\pgf
plots@table@@table@name '. Please check spelling (or introduce name aliases)..
See the pgfplots package documentation for explanation.
Type H <return> for immediate help.
...
l.25 };
! Package pgfplots Warning: the current plot has no coordinates (left?)
! Package pgfkeys Error: I do not know the key '/tikz/legend cell align' and I
am going to ignore it. Perhaps you misspelled it.
See the pgfkeys package documentation for explanation.
Type H <return> for immediate help.
...
l.28 \end{axis}
) <use Queenslscapelogocmyk-eps-converted-to.pdf>
<use Aqua-spot-rgb-clear10025.jpg> <use TUHHLogo-eps-converted-to.pdf> [10]
(./GroupSemPres.aux)
LaTeX Font Warning: Size substitutions with differences
(Font) up to 1.0pt have occurred.
LaTeX Font Warning: Some font shapes were not available, defaults substituted.
)`
Muestra el sistema de coordenadas y la leyenda, pero no traza ningún dato. Acabo de descubrir que traza algo cuando doy los datos como coordenadas y no como una tabla. ¿Podría haber un problema general con la tabla en tikz en Linux o me falta algo? De lo contrario, tendría que convertir todo el archivo tikz que me proporciona matlab2tikz en una lista de coordenadas.
Aquí está el archivo tikz que obtengo de matlab2tikz (borré algunos datos para hacerlo más corto):
% This file was created by matlab2tikz v0.4.7 running on MATLAB 8.1.
% Copyright (c) 2008--2014, Nico Schlömer <[email protected]>
% All rights reserved.
% Minimal pgfplots version: 1.3
%
% The latest updates can be retrieved from
% http://www.mathworks.com/matlabcentral/fileexchange/22022-matlab2tikz
% where you can also make suggestions and rate matlab2tikz.
%
\begin{tikzpicture}
\begin{axis}[%
width=5cm,
height=4cm,
scale only axis,
xmin=0,
xmax=0.018,
ymin=0.00015,
ymax=0.0005,
legend style={draw=black,fill=white,legend cell align=left}
]
\addplot [color=blue,solid]
table[row sep=crcr]{0 0.000311697265625003\\
0.001953125 0.000321697265625003\\
};
\addlegendentry{wp1Exp};
\end{axis}
\end{tikzpicture}%
