Estoy escribiendo un artículo en formato de Avisos Mensuales de la Real Sociedad Astronómica (MNRAS). Tengo varias mesas que necesito ajardinadas porque son demasiado anchas. He usado el comando de mesa lateral y, aunque la mesa está ajardinada, está muy inclinada hacia la izquierda y la mitad de la mesa no es visible.
El preámbulo de mi artículo es este.
\documentclass[useAMS,usenatbib]{mn2e}
%\documentclass[a4paper,11pt,twoside]{article} %showframe
% set up sensible margins (same as for cssethesis)
%\usepackage[paper=a4paper,left=30mm,width=150mm,top=25mm,bottom=25mm] {geometry}
%\usepackage{setspace} % Word spacing
%\singlespacing %(or \doublespacing \onehalfspacing)
\usepackage{txfonts}
\usepackage{mathtools} % can add [fleqn]: fleqn argument shifts equations to the left rather than centred
\usepackage{amssymb} % adds math symbols easily
\usepackage[load-configurations=astronomy]{siunitx} % astro symbols made easy. eg: \num{2e-4} \si{\kilo\metre} \SI{2e-4}{\kilo\metre\per\second}
\DeclareSIUnit\parsec{pc}
\DeclareSIUnit\kilo{K}
\DeclareSIUnit\ergs{ergs}
\usepackage[version=3]{mhchem} % chem symbols made easy eg: \ce{H20}
%\numberwithin{equation}{section} %gives eqns as 1.1 in section 1 and 2.1 in section 2 and so on.
\usepackage{graphicx} % Helps with graphics and tables
%\usepackage[width=0.8\textwidth]{caption} % justification=centering,Captions on figures labelfont=bf,font=it,
\usepackage{float}
\usepackage{subfigure}
\usepackage{subcaption} %subcaptions on figures
%\numberwithin{figure}{section}
\usepackage{titlesec}
\titlespacing\section{0pt}{12pt plus 4pt minus 2pt}{6pt plus 2pt minus 2pt}
\titlespacing\subsection{0pt}{12pt plus 4pt minus 2pt}{6pt plus 2pt minus 2pt}
\titlespacing\subsubsection{0pt}{12pt plus 4pt minus 2pt}{6pt plus 2pt minus 2pt}
\usepackage{morefloats}
\usepackage{lscape}
\usepackage{pdflscape}
%\usepackage{afterpage}
%\newcommand\blankpage{%
%\null
%\thispagestyle{empty}%
%\addtocounter{page}{-1}%
%\newpage}
\usepackage{color}
%\usepackage{pdfpages}
\usepackage{perpage} %the perpage package
\MakePerPage{footnote} %the perpage package command
\usepackage [author year, colon, round]{natbib}
%\usepackage{bibtex} % Use the natbib bibliography and citation package (author, year style, with round brackets)
\usepackage{hyperref} % hyperlinks to reference
\usepackage{booktabs}
\usepackage{multirow}
\usepackage{array}
\usepackage{longtable}
\usepackage{tabu}
\usepackage{threeparttable} %table with notes
\usepackage{threeparttablex} %longtable with notes
\usepackage{rotating}
\usepackage{xtab}
\usepackage{multicol}
\usepackage[title,titletoc,toc]{appendix} % \appendix
%\newcommand{\sol}[1]{\odot{#1}} % short code for sun symbol
% {$\mathrm{}$} = Math mode in non-italized form
\newcommand{\textsubscript}[1]{$_\textrm{#1}$} %short code for subscripting
\newcommand{\Ha}{H${\alpha}$} % short code for H-alpha
\newcommand{\HB}{H$\beta$} % short code for H-beta
\newcommand{\EHaHB}{E(H$\alpha$-H$\beta$)} % short code for E(Ha-HB)
\newcommand{\CHa} {C$_{{\textrm{H}\alpha}}$} % short code for CHa
\newcommand{\CHB}{C$_{{\textrm{H}\beta}}$} % short code for CH-beta
\newcommand{\AV}{$\textrm{A}_{\textrm{V}}$} % short code for Av
\newcommand{\Av}{$\textrm{A}_{\textrm{V}}$} % short code for Av
\newcommand{\AvCHB}{A_{\textrm{V}}(\textrm{C}$_{{\textrm{H}\beta}}$)} % short code for Av(CH-beta)
\newcommand{\AvCHa}{A_{\textrm{V}}(\textrm{C}$_{{\textrm{H}\alpha}}$)} % short code for Av(CH-alpha)
\newcommand{\AvE}{A_{\textrm{V}}[\textrm{E}(\textrm{H}$\alpha$-\textrm{H}$\beta$)]} % short code for E(Ha-HB)
\newcommand{\app}[1]{\textup{\textsc{\MakeLowercase{#1}}}}
\newcommand{\comm}[1]{\texttt{#1}}
\title[}
\author[]
\date{Received:}
\begin{document}
\maketitle
\begin{abstract}
.....
\end{abstract}
\begin{keywords}
......
\end{keywords}
\input{./Tables/Table1}
%\include{Appendix}
\bibliographystyle{chicago}
\bibliography{fullbib}
\end{document}
El código de la tabla es este:
\begin{sidewaystable*}
\centering
\caption [Table 1]{Table 1}
\label{Table 1}
\begin{threeparttable}
\begin{tabular}{lllllllp{1.5cm}p{1.3cm}p{1.3cm}p{1.3cm}p{1.5cm}l}
\toprule
\textbf{} & \textbf{} & \textbf{} & \textbf{} & \multicolumn{3}{c}{\textbf{CCD Data}} & \multicolumn{4}{c}{\textbf{Aperture Radii}} & \multicolumn{2}{c}{\textbf{Source Intensity}} \\
\cmidrule(lr){5-7}
\cmidrule(lr){8-11}
\cmidrule(lr){12-13}
\textbf{PN Name} & \textbf{RA} & \textbf{Dec} & \textbf{Run} & \textbf{CCD} & \textbf{X} & \textbf{Y} & \textbf{Shape} & \textbf{Centroid} & \textbf{Inner Sky} & \textbf{Outer Sky} & \textbf{intensity (counts)} & \textbf{unc.} \\
(1) & (2) & (3) & (4) & (5) & (6) & (7) & (8) & (9) & (10) & (11) & (12) & (13)\\
\midrule
PN G119.64+03.2 & 00:19:09.79 & +65:53:26.00 & 414 153 & 4 & 539 & 743 & C & 4 & 9 & 14 & 1013.10 & 38.87 \\
& & & 414551 & 2 & 1968 & 1612 & & & & & 1050.30 & 43.22 \\
& & & 414554 & 2 & 1061 & 2513 & & & & & 1075.10 & 38.98 \\
PN G121.68+03.6 & 00:38:54.00 & +66:23:49.00 & 417705 & 3 & 1124 & 795 & C & 41 & 47 & 52 & 128616.00 & 1154.20 \\
& & & 418383 & 2 & 1832 & 99 & & & & & 155089.00 & 930.89 \\
& & & 419386 & 2 & - & - & & & & & 157573.00 & 931.57 \\
PN G126.30+02.9 & 01:24:58.60 & +65:38:36.00 & 367533 & 3 & 1305 & 249 & C & 24 & 27 & 30 & 326749.00 & 1057.60 \\
& & & 703469 & 4 & 354 & 3756 & & & & & 317515.00 & 1069.20 \\
& & & 703472 & 2 & 1562 & 1191 & & & & & 309835.00 & 1017.60 \\
PN G126.60+01.3 & 01:25:07.90 & +63:56:53.00 & 367778 & 4 & 827.00 & 612.00 & E & Maj=60 & 67 & 75 & 292152.00 & 1253.30 \\
& & & 367781 & 4 & 1744.90 & 1521.70 & Rot=+28$\si{\degree}$ & Min=34 & & & 276108.00 & 1770.50 \\
& & & 367894 & 2 & 1098.60 & 2801.60 & Rot=-46$\si{\degree}$ & & 60 & 70 & 288338.00 & 2313.70 \\
& & & 367897 & 2 & 173.80 & 3708.60 & & & & & 289128.00 & 2314.60 \\
\bottomrule
\end{tabular}
\begin{tablenotes}
\footnotesize
\item .......
\end{tablenotes}
\end{threeparttable}
\end{sidewaystable*}
He probado los comandos de rotación y \hspace, \vspacepero \newgeometry{margin=1cm}ninguno parece funcionar. ¿Cómo puedo solucionar esto?
Respuesta1
Parece que la mn2eclase de documento experimenta algunos conflictos con el rotatingpaquete (que proporciona el sidewaystableentorno), o posiblemente con el graphicxpaquete, que carga el rotatingpaquete.
Una solución alternativa (no una solución completa, por cierto) consiste en insertar la instrucción
\RequirePackage{rotating}
antesla \documentclassinstrucción.
Con esta configuración, la tabla en su documento de muestra se coloca correctamente.
