Dibuja un elemento especial (línea con una cruz en el medio) en circuitoikz

Dibuja un elemento especial (línea con una cruz en el medio) en circuitoikz

Necesito dibujar un cable que se parezca

ingrese la descripción de la imagen aquí

Ése es el símbolo que utiliza mi conferenciante para el cruce Josephson. Busqué en Google un poco y parece ser el símbolo comúnmente usado para dicho elemento, por lo que sería útil tener una manera de implementarlo en circuitoikz.

Utilizo pgfplotstambién tikzexternalize, lo que me obliga a iniciar los entornos de circuito con \begin{tikzpicture}, si eso hace alguna diferencia.


EDITAR (como se solicita en el comentario): me gustaría usar el elemento entreayden el siguiente circuito:

\begin{figure}[ht]
  \centering
\begin{tikzpicture}
      \draw (0,0)
        node[label={[font=\footnotesize]above:a}] {}
      to[short,*-*] (1.732,1)
        node[label={[font=\footnotesize]above:d}] {};
      \draw (0,0)
      to[C=$C$,*-*] (-1.732,1)
        node[label={[font=\footnotesize]above:b}] {};
      \draw (0,0)
      to[L=$L$,*-*] (0,-2)
        node[label={[font=\footnotesize]east:c}] {};
\end{tikzpicture}
    \caption{Explaining conventions}
\end{figure}

El código produce lo siguiente en mi documento: ingrese la descripción de la imagen aquí

Respuesta1

Usando un circuitikzsímbolo nativo conocido como barrier:

ingrese la descripción de la imagen aquí

\documentclass{article}
\usepackage{circuitikz}
\begin{document}

\begin{figure}[ht]
  \centering
\begin{tikzpicture}
      \draw (0,0)
        node[label={[font=\footnotesize]above:a}] {}
      to[barrier,*-*] (1.732,1)
        node[label={[font=\footnotesize]above:d}] {};
      \draw (0,0)
      to[C=$C$,*-*] (-1.732,1)
        node[label={[font=\footnotesize]above:b}] {};
      \draw (0,0)
      to[L=$L$,*-*] (0,-2)
        node[label={[font=\footnotesize]east:c}] {};
\end{tikzpicture}
    \caption{Explaining conventions}
\end{figure}

\end{document}

Respuesta2

Puede crear su propio componente, aquí hay un ejemplo, aunque es posible que necesite algunos ajustes:

ingrese la descripción de la imagen aquí

Puede ajustar el ancho y el alto usando:

\ctikzset{bipoles/josephsonjunction/height/.initial=.30}   % box height
\ctikzset{bipoles/josephsonjunction/width/.initial=.30}    % box width

... y el ancho de línea usando:

\pgfsetlinewidth{3\pgfstartlinewidth}

El código:

\documentclass[tikz,border=10pt]{standalone}
\usepackage{tikz}
\usepackage{circuitikz}

\makeatletter
% used to process styles for to-path
\def\TikzBipolePath#1#2{\pgf@circ@bipole@path{#1}{#2}}
% restore size value for bipole definitions
\pgf@circ@Rlen = \pgfkeysvalueof{/tikz/circuitikz/bipoles/length}
\makeatother
\newlength{\ResUp}
\newlength{\ResDown}
\newlength{\ResLeft}
\newlength{\ResRight}

%  josephsonjunction
\ctikzset{bipoles/josephsonjunction/height/.initial=.30}   % box height
\ctikzset{bipoles/josephsonjunction/width/.initial=.30}    % box width
\pgfcircdeclarebipole{}                                    % no extra anchors
{\ctikzvalof{bipoles/josephsonjunction/height}}
{josephsonjunction}                                        % component name
{\ctikzvalof{bipoles/josephsonjunction/height}}
{\ctikzvalof{bipoles/josephsonjunction/width}}
{                                                          % component symbol drawing...
  \pgfextracty{\ResUp}{\northeast}                         % coordinates
  \pgfextracty{\ResDown}{\southwest}
  \pgfextractx{\ResLeft}{\southwest}
  \pgfextractx{\ResRight}{\northeast}
  \pgfsetlinewidth{3\pgfstartlinewidth}
  \pgfmoveto{\pgfpoint{\ResLeft}{\ResDown}}
  \pgflineto{\pgfpoint{\ResRight}{\ResUp}}
  \pgfmoveto{\pgfpoint{\ResRight}{\ResDown}}
  \pgflineto{\pgfpoint{\ResLeft}{\ResUp}}
  \pgfusepath{draw}
  \pgfsetlinewidth{\pgfstartlinewidth}
  \pgfmoveto{\pgfpoint{\ResLeft}{0}}
  \pgflineto{\pgfpoint{\ResRight}{0}}
  \pgfusepath{draw}
}
\def\circlepath#1{\TikzBipolePath{josephsonjunction}{#1}}
\tikzset{josephsonjunction/.style = {\circuitikzbasekey, /tikz/to path=\circlepath, l=#1}}

\begin{document}
\begin{tikzpicture}
  \draw (0,0)
    node[label={[font=\footnotesize]above:a}] {}
    to[josephsonjunction,*-*] (1.732,1) % using the josephsonjunction
    node[label={[font=\footnotesize]above:d}] {};
  \draw (0,0)
    to[C=$C$,*-*] (-1.732,1)
    node[label={[font=\footnotesize]above:b}] {};
  \draw (0,0)
    to[L=$L$,*-*] (0,-2)
    node[label={[font=\footnotesize]east:c}] {};
\end{tikzpicture}
\end{document}
