Question

Mi supervisor me pidió que hiciera tres mesas verticales en una mesa horizontal/horizontal. El código de mis tablas (al menos la parte de formato) era bastante complejo y este es mi primer intento con una tabla horizontal. Desafortunadamente, estoy un poco atascado y creo que sé dónde me estoy equivocando (el ancho de las columnas, etc.), pero no estoy seguro de cómo solucionarlo. A continuación presento una maqueta de mi tabla para comprender a qué me gustaría llegar:

Aqui esta mi MWE

\documentclass{article}
\usepackage{pdflscape}
\usepackage{afterpage}
\usepackage{booktabs}
\usepackage{siuntix}
\usepackage{array}
\usepackage{ragged2e}
\usepackage{capt-of}% or use the larger `caption` package
\begin{document}
\afterpage{
\clearpage
\thispagestyle{empty}
\begin{landscape}
\begin{table}
\centering
\begin{tabular*}
\small
{
 >{\RaggedRight\arraybackslash}p{.17\textwidth}
 S *{3}{S[table-format=2.1] >{\footnotesize}S[table-format=3.2,input-symbols=()]} }
  \caption {Descriptive Statistics (\%): Commerce, EBE and Science faculties}
\label{table:DSCF} \\
\toprule
{\bfseries Variable} &
 \multicolumn{3}{c}{\bfseries Commerce}\\
 \multicolumn{3}{c}{\bfseries EBE} \\
 \multicolumn{3}{c}{\bfseries Science} \\
 \multicolumn{3}{c}{\bfseries Total} \\
\cmidrule{2-13}
&&
\multicolumn{1}{C{.19\textwidth}}{\bfseries Graduated} & \multicolumn{1}{C{.19\textwidth}}{\bfseries Academically Excluded} &
\multicolumn{1}{C{.19\textwidth}}{\bfseries Censored}
\multicolumn{1}{C{.19\textwidth}}{\bfseries Graduated} & \multicolumn{1}{C{.19\textwidth}}{\bfseries Academically Excluded} &
\multicolumn{1}{C{.19\textwidth}}{\bfseries Censored}
\multicolumn{1}{C{.19\textwidth}}{\bfseries Graduated} & \multicolumn{1}{C{.19\textwidth}}{\bfseries Academically Excluded} &
\multicolumn{1}{C{.19\textwidth}}{\bfseries Censored}
\multicolumn{1}{C{.19\textwidth}}{\bfseries Graduated} & \multicolumn{1}{C{.19\textwidth}}{\bfseries Academically Excluded} &
 \multicolumn{1}{C{.19\textwidth}}{\bfseries Censored}\\
\midrule
\bfseries Total & 50.1 & 7.5 & 42.4 & 35.8 & 21.6 & 42.7 & 46.4 & 26.1 & 27.5 & & 45.8 & 14.9 & 39.3    \\
\addlinespace
\bfseries Gender\\
Male                 & 49.6 & 8.7  & 41.7 & 36.4 & 21.9 & 41.7 & 44.0 & 31.2 & 24.9 & 44.3 & 17.3 & 38.5 \\
Female               & 50.7 & 6.2  & 43.1 & 33.8 & 20.6 & 45.7 & 49.3 & 20.2 & 30.5 & 48.0 & 11.5 & 40.5 \\
\addlinespace
\bfseries Race\\
White & 59.8 & 3.0 & 37.2 & 50.8 & 7.8 & 41.3 & 64.5 & 5.1 & 30.4 & & 58.7 & 4.6 & 36.7  \\
Black & 38.7 & 13.1 & 48.2 & 22.2 &34.9& 43.0 & 31.0 & 44.5 & 24.5 & 32.5 & 26.3 &41.2(\\
Coloured & 49.8 & 7.4 & 42.8 & 36.4 & 21.9 & 41.6 & 40.2 & 30.6 & 29.2 & 44.5 & 16.1 & 39.5   \\
Indian/Asian & 48.9  & 7.9 & 43.3 & 32.7 & 20.5 & 46.9 & 32.7 & 20.5 & 46.9 & 44.6 & 13.3 & 42.1\\
\addlinespace
\bfseries Financial Aid\\
Ineligible for Financial Aid & 52.1  & 5.5  & 42.4 & 38.0 & 17.7 & 44.3 & 38.0 & 17.7 & 44.3 & 48.7 & 10.6 & 40.7  \\
Eligible for Financial Aid  & 40.7 & 17.2 & 42.1 & 26.5 & 37.5 & 36.1 & 33.8 & 42.9 & 23.3 & 35.2 & 30.3 & 34.5 \\
\addlinespace
\bfseries Programme\\
Mainstream  & 55.4  & 5.7 & 38.9 & 40.5 & 17.3 & 42.3 & 54.3 & 16.4 & 29.3 & 51.3 & 10.8 & 37.9  \\
Academic Development & 32.5 & 13.7 & 53.8 & 14.1 & 41.4 & 44.5 & 25.3 & 51.8 & 22.8 & 27.1 & 28.7 & 44.2 \\
\addlinespace
\bfseries English Home Language\\
Yes  & 55.1 & 4.9 & 39.9 & 44.1 & 13.3 & 42.6 & 56.3 & 14.1 & 29.6 & 52.8 & 8.6 & 38.6 \\
No & 38.8 & 13.4  & 47.8 & 22.3 &  35.0 & 42.7 & 32.7 & 42.7 & 24.6 & 32.8 & 26.6 & 40.6 \\
\addlinespace
\bfseries School Quintile\\
1  & 34.6 & 30.8 & 34.6 & 14.1 & 49.3 & 36.6 & 34.0 & 45.3 & 20.8 & 26.1 & 42.6 & 31.3  \\
2  & 30.2 & 16.0 & 53.8 & 25.6 & 36.4 & 38.0 & 28.8 & 50.9 & 20.3 & 28.1 & 35.1 & 36.8 \\
3  & 32.0 & 17.5 & 50.5 & 21.7 & 41.9 & 36.5 & 30.0 & 45.8 & 24.2 & 27.7 & 35.3 & 37.0 \\
4  & 37.7 & 17.7 & 44.5 & 17.7 & 38.0 & 44.3 & 30.0 & 46.7 & 23.3 & 29.5 & 32.0 & 38.5 \\
5  & 52.0 & 6.9 & (41.1 & 41.0 & 16.2 & 42.9 & 54.3 & 14.8 & 31.0 & 49.2 & 12.0 & 38.9  \\
Independent  & 52.5 & 5.3 & 42.2 & 40.7 & 13.9 & 45.5 & 54.3 &14.8 & 31.0  50.4 & 8.6 & 41.0 \\
\addlinespace
{\bfseries Province}\\
Western Cape & 55.1 & 5.9 &39.0 & 42.1 &16.2 &41.7 & 52.0 &20.0 & 28.0 & 51.3 & 11.6 &37.0 \\
Non-Western Cape &46.8 & 8.6 & 44.6 & 31.6 & 25.1 & 43.3 & 41.5 & 31.5 & 27.1 & 41.9 & 17.2 &41.0\\
\addlinespace
{\bfseries Year of First Registration} \\
{2006}  87.8 & 11.3 & 0.9 & 70.3 & 29.0 & 0.7 & 69.5 & 28.2 & 2.3 & 79.9 & 18.9 &1.2  \\
{2007} 88.2 & 10.1 &  1.7 & 68.7 & 30.0 & 1.4 & 68.5 & 30.8 & 0.7 & 79.4 &19.2 &1.4\\
{2008} 87.1 & 10.3 &  2.6 & 63.6 & 30.6 & 5.8 & 66.2 & 32.3 & 1.6 & 76.7 & 20.3 & 3.0 \\
{2009} 80.9 & 9.7 & 9.4 & 51.2   & 32.3 &16.5 & 51.9 & 43.9 & 4.2 & 64.9 & 24.9 & 10.2 \\
{2010} 62.6 & 6.4 & 31.1 & 36.8 & 19.0 & 44.2 & 69.8 & 21.0 & 9.3 & 57.5 & 12.7 & 29.8 \\
{2011} 15.8 & 7.2 & 77.0 & 0.0 & 18.2  & 81.8 & 37.3 & 23.4 & 39.8 & 15.3 & 12.8 & 71.9 \\
{2012} 0.0 & 5.4 & 94.6 &  0.0 & 7.5 & 92.5 & 0.0 & 13.4 & 86.6 & 0.0 & 7.5 & 92.5 \\
{2013} 0.0 & 1.7 & 98.3 & 0.0 & 4.9  & 95.1 & 0.0 & 5.1  & 94.9 & 0.0 & 3.0 & 97.0 \\
\end{tabular*}
\end{table}
\end{landscape}
\clearpage
 }
\end{document}

Answer 1

Recomendaría reemplazar los títulos de las columnas bastante largos (Graduado, Excluido académicamente, Censurado) con abreviaturas (G, AE, C) y describir la clave en el título. Luego podrá colocar fácilmente todas las columnas en una página horizontal.

Hay muchos otros pequeños cambios aquí y allá. No estoy seguro de recordarlo todo, pero:

• Nueva especificación de columna. Una pcolumna seguida de 12 Scolumnas.
• Se eliminaron algunos paréntesis de un par de números.
• Se eliminaron algunos elementos adicionales &y también se agregaron algunos cuando fuera necesario.
• longtablese utiliza. Creo que la tabla es demasiado larga para caber en una sola página.
• Tenía saltos de línea después de cada uno de los encabezados de las columnas superiores (Comercio, EBE, etc.), esos deberían ser &.
• Cuatro cmidrules separadas con algo de recorte, en lugar de una larga.

---

\documentclass{article}
\usepackage{pdflscape,ragged2e,array,siunitx,longtable,booktabs}
\usepackage{afterpage}
\usepackage{capt-of}% or use the larger `caption` package
\begin{document}
\begin{landscape}
\centering
\small
\begin{longtable}{
 >{\RaggedRight\arraybackslash}p{.35\textwidth}
 *{12}{S[table-format=2.1]}}
  \caption{Descriptive Statistics (\%): Commerce, EBE and Science faculties. Key: \textbf{G}: Graduate, \textbf{AE}: Academically Excluded, \textbf{C}: Censored}
\label{table:DSCF} \\
\toprule
{\bfseries Variable} &
 \multicolumn{3}{c}{\bfseries Commerce} &
 \multicolumn{3}{c}{\bfseries EBE} &
 \multicolumn{3}{c}{\bfseries Science} &
 \multicolumn{3}{c}{\bfseries Total} \\
\cmidrule(rl){2-4}
\cmidrule(rl){5-7}
\cmidrule(rl){8-10}
\cmidrule(rl){11-13}
&
{\bfseries G} & {\bfseries AE} &
{\bfseries C} &
{\bfseries G} & {\bfseries AE} &
{\bfseries C} &
{\bfseries G} & {\bfseries AE} &
{\bfseries C} &
{\bfseries G} & {\bfseries AE} &
 {\bfseries C}\\
\midrule
\bfseries Total & 50.1 & 7.5 & 42.4 & 35.8 & 21.6 & 42.7 & 46.4 & 26.1 & 27.5 & 45.8 & 14.9 & 39.3    \\
\addlinespace
\bfseries Gender\\
Male                 & 49.6 & 8.7  & 41.7 & 36.4 & 21.9 & 41.7 & 44.0 & 31.2 & 24.9 & 44.3 & 17.3 & 38.5 \\
Female               & 50.7 & 6.2  & 43.1 & 33.8 & 20.6 & 45.7 & 49.3 & 20.2 & 30.5 & 48.0 & 11.5 & 40.5 \\
\addlinespace
\bfseries Race\\
White & 59.8 & 3.0 & 37.2 & 50.8 & 7.8 & 41.3 & 64.5 & 5.1 & 30.4 &  58.7 & 4.6 & 36.7  \\
Black & 38.7 & 13.1 & 48.2 & 22.2 &34.9& 43.0 & 31.0 & 44.5 & 24.5 & 32.5 & 26.3 &41.2\\
Coloured & 49.8 & 7.4 & 42.8 & 36.4 & 21.9 & 41.6 & 40.2 & 30.6 & 29.2 & 44.5 & 16.1 & 39.5   \\
Indian/Asian & 48.9  & 7.9 & 43.3 & 32.7 & 20.5 & 46.9 & 32.7 & 20.5 & 46.9 & 44.6 & 13.3 & 42.1\\
\addlinespace
\bfseries Financial Aid\\
Ineligible for Financial Aid & 52.1  & 5.5  & 42.4 & 38.0 & 17.7 & 44.3 & 38.0 & 17.7 & 44.3 & 48.7 & 10.6 & 40.7  \\
Eligible for Financial Aid  & 40.7 & 17.2 & 42.1 & 26.5 & 37.5 & 36.1 & 33.8 & 42.9 & 23.3 & 35.2 & 30.3 & 34.5 \\
\addlinespace
\bfseries Programme\\
Mainstream  & 55.4  & 5.7 & 38.9 & 40.5 & 17.3 & 42.3 & 54.3 & 16.4 & 29.3 & 51.3 & 10.8 & 37.9  \\
Academic Development & 32.5 & 13.7 & 53.8 & 14.1 & 41.4 & 44.5 & 25.3 & 51.8 & 22.8 & 27.1 & 28.7 & 44.2 \\
\addlinespace
\bfseries English Home Language\\
Yes  & 55.1 & 4.9 & 39.9 & 44.1 & 13.3 & 42.6 & 56.3 & 14.1 & 29.6 & 52.8 & 8.6 & 38.6 \\
No & 38.8 & 13.4  & 47.8 & 22.3 &  35.0 & 42.7 & 32.7 & 42.7 & 24.6 & 32.8 & 26.6 & 40.6 \\
\addlinespace
\bfseries School Quintile\\
1  & 34.6 & 30.8 & 34.6 & 14.1 & 49.3 & 36.6 & 34.0 & 45.3 & 20.8 & 26.1 & 42.6 & 31.3  \\
2  & 30.2 & 16.0 & 53.8 & 25.6 & 36.4 & 38.0 & 28.8 & 50.9 & 20.3 & 28.1 & 35.1 & 36.8 \\
3  & 32.0 & 17.5 & 50.5 & 21.7 & 41.9 & 36.5 & 30.0 & 45.8 & 24.2 & 27.7 & 35.3 & 37.0 \\
4  & 37.7 & 17.7 & 44.5 & 17.7 & 38.0 & 44.3 & 30.0 & 46.7 & 23.3 & 29.5 & 32.0 & 38.5 \\
5  & 52.0 & 6.9 & 41.1 & 41.0 & 16.2 & 42.9 & 54.3 & 14.8 & 31.0 & 49.2 & 12.0 & 38.9  \\
Independent  & 52.5 & 5.3 & 42.2 & 40.7 & 13.9 & 45.5 & 54.3 &14.8 & 31.0 & 50.4 & 8.6 & 41.0 \\
\addlinespace
{\bfseries Province}\\
Western Cape & 55.1 & 5.9 &39.0 & 42.1 &16.2 &41.7 & 52.0 &20.0 & 28.0 & 51.3 & 11.6 &37.0 \\
Non-Western Cape &46.8 & 8.6 & 44.6 & 31.6 & 25.1 & 43.3 & 41.5 & 31.5 & 27.1 & 41.9 & 17.2 &41.0\\
\addlinespace
{\bfseries Year of First Registration} \\
{2006} &  87.8 & 11.3 & 0.9 & 70.3 & 29.0 & 0.7 & 69.5 & 28.2 & 2.3 & 79.9 & 18.9 &1.2  \\
{2007} & 88.2 & 10.1 &  1.7 & 68.7 & 30.0 & 1.4 & 68.5 & 30.8 & 0.7 & 79.4 &19.2 &1.4\\
{2008} & 87.1 & 10.3 &  2.6 & 63.6 & 30.6 & 5.8 & 66.2 & 32.3 & 1.6 & 76.7 & 20.3 & 3.0 \\
{2009} & 80.9 & 9.7 & 9.4 & 51.2   & 32.3 &16.5 & 51.9 & 43.9 & 4.2 & 64.9 & 24.9 & 10.2 \\
{2010} & 62.6 & 6.4 & 31.1 & 36.8 & 19.0 & 44.2 & 69.8 & 21.0 & 9.3 & 57.5 & 12.7 & 29.8 \\
{2011} & 15.8 & 7.2 & 77.0 & 0.0 & 18.2  & 81.8 & 37.3 & 23.4 & 39.8 & 15.3 & 12.8 & 71.9 \\
{2012} & 0.0 & 5.4 & 94.6 &  0.0 & 7.5 & 92.5 & 0.0 & 13.4 & 86.6 & 0.0 & 7.5 & 92.5 \\
{2013} & 0.0 & 1.7 & 98.3 & 0.0 & 4.9  & 95.1 & 0.0 & 5.1  & 94.9 & 0.0 & 3.0 & 97.0 \\
\end{longtable}
\end{landscape}
\end{document}

Segunda opción

Al reescribir/acortar las entradas en la primera columna y reducirlas, \tabcolseppuede comprimir todo en una sola página en modo vertical. Si el bloque de texto en su documento real es más ancho que el predeterminado, articletendrá más para continuar, por lo que puede hacer las cosas más anchas que en el siguiente código. (El marco en la captura de pantalla proviene de la carga del showframepaquete, solo está ahí para demostrar que la tabla está realmente dentro del ancho del bloque de texto).

\documentclass{article}
\usepackage{ragged2e,array,siunitx,longtable,booktabs}
\begin{document}
\begin{table}
\centering
\small
\setlength{\tabcolsep}{3.7pt}
 \caption{Descriptive Statistics (\%): Commerce, EBE and Science faculties. Key: \textbf{G}: Graduate, \textbf{AE}: Academically Excluded, \textbf{C}: Censored}
\label{table:DSCF}
\begin{tabular}{
 >{\RaggedRight\arraybackslash}p{.15\textwidth}
 *{12}{S[table-format=2.1]}}
\toprule
{\bfseries Variable} &
 \multicolumn{3}{c}{\bfseries Commerce} &
 \multicolumn{3}{c}{\bfseries EBE} &
 \multicolumn{3}{c}{\bfseries Science} &
 \multicolumn{3}{c}{\bfseries Total} \\
\cmidrule(rl){2-4}
\cmidrule(rl){5-7}
\cmidrule(rl){8-10}
\cmidrule(rl){11-13}
&
{\bfseries G} & {\bfseries AE} &
{\bfseries C} &
{\bfseries G} & {\bfseries AE} &
{\bfseries C} &
{\bfseries G} & {\bfseries AE} &
{\bfseries C} &
{\bfseries G} & {\bfseries AE} &
 {\bfseries C}\\
\midrule
\bfseries Total & 50.1 & 7.5 & 42.4 & 35.8 & 21.6 & 42.7 & 46.4 & 26.1 & 27.5 & 45.8 & 14.9 & 39.3    \\
\addlinespace
\bfseries Gender\\
Male                 & 49.6 & 8.7  & 41.7 & 36.4 & 21.9 & 41.7 & 44.0 & 31.2 & 24.9 & 44.3 & 17.3 & 38.5 \\
Female               & 50.7 & 6.2  & 43.1 & 33.8 & 20.6 & 45.7 & 49.3 & 20.2 & 30.5 & 48.0 & 11.5 & 40.5 \\
\addlinespace
\bfseries Race\\
White & 59.8 & 3.0 & 37.2 & 50.8 & 7.8 & 41.3 & 64.5 & 5.1 & 30.4 &  58.7 & 4.6 & 36.7  \\
Black & 38.7 & 13.1 & 48.2 & 22.2 &34.9& 43.0 & 31.0 & 44.5 & 24.5 & 32.5 & 26.3 &41.2\\
Coloured & 49.8 & 7.4 & 42.8 & 36.4 & 21.9 & 41.6 & 40.2 & 30.6 & 29.2 & 44.5 & 16.1 & 39.5   \\
Indian/Asian & 48.9  & 7.9 & 43.3 & 32.7 & 20.5 & 46.9 & 32.7 & 20.5 & 46.9 & 44.6 & 13.3 & 42.1\\
\addlinespace
\multicolumn{4}{l}{\bfseries Financial Aid}\\
Ineligible& 52.1  & 5.5  & 42.4 & 38.0 & 17.7 & 44.3 & 38.0 & 17.7 & 44.3 & 48.7 & 10.6 & 40.7  \\
Eligible & 40.7 & 17.2 & 42.1 & 26.5 & 37.5 & 36.1 & 33.8 & 42.9 & 23.3 & 35.2 & 30.3 & 34.5 \\
\addlinespace
\multicolumn{4}{l}{\bfseries Programme}\\
Mainstream  & 55.4  & 5.7 & 38.9 & 40.5 & 17.3 & 42.3 & 54.3 & 16.4 & 29.3 & 51.3 & 10.8 & 37.9  \\
Academic Dev. & 32.5 & 13.7 & 53.8 & 14.1 & 41.4 & 44.5 & 25.3 & 51.8 & 22.8 & 27.1 & 28.7 & 44.2 \\
\addlinespace
\multicolumn{4}{l}{\bfseries English Home Language}\\
Yes  & 55.1 & 4.9 & 39.9 & 44.1 & 13.3 & 42.6 & 56.3 & 14.1 & 29.6 & 52.8 & 8.6 & 38.6 \\
No & 38.8 & 13.4  & 47.8 & 22.3 &  35.0 & 42.7 & 32.7 & 42.7 & 24.6 & 32.8 & 26.6 & 40.6 \\
\addlinespace
\multicolumn{4}{l}{\bfseries School Quintile}\\
1  & 34.6 & 30.8 & 34.6 & 14.1 & 49.3 & 36.6 & 34.0 & 45.3 & 20.8 & 26.1 & 42.6 & 31.3  \\
2  & 30.2 & 16.0 & 53.8 & 25.6 & 36.4 & 38.0 & 28.8 & 50.9 & 20.3 & 28.1 & 35.1 & 36.8 \\
3  & 32.0 & 17.5 & 50.5 & 21.7 & 41.9 & 36.5 & 30.0 & 45.8 & 24.2 & 27.7 & 35.3 & 37.0 \\
4  & 37.7 & 17.7 & 44.5 & 17.7 & 38.0 & 44.3 & 30.0 & 46.7 & 23.3 & 29.5 & 32.0 & 38.5 \\
5  & 52.0 & 6.9 & 41.1 & 41.0 & 16.2 & 42.9 & 54.3 & 14.8 & 31.0 & 49.2 & 12.0 & 38.9  \\
Independent  & 52.5 & 5.3 & 42.2 & 40.7 & 13.9 & 45.5 & 54.3 &14.8 & 31.0 & 50.4 & 8.6 & 41.0 \\
\addlinespace
\multicolumn{4}{l}{\bfseries Western cape province}\\
Yes & 55.1 & 5.9 &39.0 & 42.1 &16.2 &41.7 & 52.0 &20.0 & 28.0 & 51.3 & 11.6 &37.0 \\
No &46.8 & 8.6 & 44.6 & 31.6 & 25.1 & 43.3 & 41.5 & 31.5 & 27.1 & 41.9 & 17.2 &41.0\\
\addlinespace
\multicolumn{4}{l}{\bfseries Year of First Registration} \\
{2006} &  87.8 & 11.3 & 0.9 & 70.3 & 29.0 & 0.7 & 69.5 & 28.2 & 2.3 & 79.9 & 18.9 &1.2  \\
{2007} & 88.2 & 10.1 &  1.7 & 68.7 & 30.0 & 1.4 & 68.5 & 30.8 & 0.7 & 79.4 &19.2 &1.4\\
{2008} & 87.1 & 10.3 &  2.6 & 63.6 & 30.6 & 5.8 & 66.2 & 32.3 & 1.6 & 76.7 & 20.3 & 3.0 \\
{2009} & 80.9 & 9.7 & 9.4 & 51.2   & 32.3 &16.5 & 51.9 & 43.9 & 4.2 & 64.9 & 24.9 & 10.2 \\
{2010} & 62.6 & 6.4 & 31.1 & 36.8 & 19.0 & 44.2 & 69.8 & 21.0 & 9.3 & 57.5 & 12.7 & 29.8 \\
{2011} & 15.8 & 7.2 & 77.0 & 0.0 & 18.2  & 81.8 & 37.3 & 23.4 & 39.8 & 15.3 & 12.8 & 71.9 \\
{2012} & 0.0 & 5.4 & 94.6 &  0.0 & 7.5 & 92.5 & 0.0 & 13.4 & 86.6 & 0.0 & 7.5 & 92.5 \\
{2013} & 0.0 & 1.7 & 98.3 & 0.0 & 4.9  & 95.1 & 0.0 & 5.1  & 94.9 & 0.0 & 3.0 & 97.0 \\
\end{tabular}
\end{table}
\end{document}
