Estoy intentando reproducir fielmente la primera sección del estándar de la policía del Reino Unido.Formulario de declaración de testigo, conocido como MG11.
Tengo dificultades para alinear los cuadros de la portada con el cuadro que debe contener el cuerpo de la declaración.
Más importante aún, los cuadros permiten que el texto se extienda en varias páginas, pero esto hace que no tengan líneas en la parte inferior o superior de las páginas donde se divide. Esto también se superpone al encabezado de la Declaración Testimonial en las páginas siguientes.
Aquí está el código LaTeX que genera mi pdf hasta ahora:
\documentclass{article}
\usepackage{dashrule}
\usepackage{listings}
\usepackage{float}
\usepackage{scrpage2}
\usepackage{mdframed}
\usepackage[english]{babel}
\usepackage{blindtext}
\usepackage{helvet}
\renewcommand{\familydefault}{\sfdefault}
\pagestyle{scrheadings}
\clearscrheadfoot
\usepackage{lastpage}
\usepackage[margin=0.5in]{geometry}
\ihead{}
\chead{\\\framebox[1.1\width]{RESTRICTED}\\ \LARGE{Witness Statement}\\ \footnotesize{Criminal Procedure Rules, r 27.2; Criminal Justice Act 1967, s. 9; Magistrate's Courts Act 1980, s. 5B}\\}
\ohead{\\\framebox[1.1\width]{MG11} \vspace*{0.1 in} \\Page \textbf{\pagemark} of \pageref{LastPage}}
\ifoot{Signature: \hdashrule{26em}{1pt}{1.5mm} Signature Witnessed by: \textbf{N/A}}
\cfoot{}
\ofoot{}
\setlength\parindent{0pt} % Removes all indentation from paragraphs
\begin{document}
% URN boxes drawn using table
\begin{table}
\vspace*{0.35 in}
\begin{flushright}
\begin{tabular}{llllll}
\cline{2-5}
URN:& \multicolumn{1}{|@{\hspace{2em}}l|@{\hspace{2em}}}{} & \multicolumn{1}{l|@{\hspace{2em}}}{} & \multicolumn{1}{l|@{\hspace{2em}}}{} & \multicolumn{1}{l|}{} &\\ \cline{2-5}
\end{tabular}
\end{flushright}
\end{table}
% Front page boxes drawn inside fboxes
\fbox{
\parbox{\textwidth}{
Statement of: \textbf{John Smith} \\ \\
Age of witness: \textbf{Over 18} {\hspace{23em}} Occupation: \textbf{Paper-pusher}\\
This statement (consisting of \pageref{LastPage} pages each signed by me) is true to the best of my knowledge and belief and I make it knowing that, if it is tendered in evidence, I shall be liable to prosecution if I have wilfully stated in it, anything which I know to be false, or do not believe to be true.
}
}
\fbox{
\parbox[b][2em]{\textwidth}{
Signature: \hdashrule{29em}{1pt}{1.5mm} Date: \textbf{\today}
}
}
% mdframed box for main textbox
\global\mdfdefinestyle{exampledefault}{%
linecolor=black,linewidth=1pt,%
leftmargin=0cm,rightmargin=0cm
}
\begin{mdframed}[style=exampledefault]
\Blindtext[14]
\end{mdframed}
\end{document}
¿Alguien podría aconsejarme sobre cómo arreglar los cuadros para que copien los que se encuentran en el enlace de referencia?
¡Muchas gracias!
Respuesta1
Una primera prueba con tcolorbox: El problema principal es la headerconfiguración del pie de página, lo que provoca superposición.
\documentclass{article}
\usepackage{dashrule}
\usepackage[english]{babel}
\usepackage{blindtext}
\usepackage{helvet}
\renewcommand{\familydefault}{\sfdefault}
\usepackage[most]{tcolorbox}
\usepackage{fancyhdr}
\usepackage{lastpage}
\usepackage[margin=0.5in,top=1.25in,headheight=45pt,bottom=1in]{geometry}
\fancyhf{}
\renewcommand{\headrulewidth}{0pt}
\fancyhead[C]{\begin{tabular}[b]{c}\fbox{RESTRICTED}\tabularnewline\tabularnewline\multicolumn{1}{c}{\LARGE Witness Statement}\tabularnewline\multicolumn{1}{c}{\footnotesize Criminal Procedure Rules, r 27.2; Criminal Justice Act 1967, s. 9; Magistrate's Courts Act 1980, s. 5B}\end{tabular}}
\fancyhead[RO]{\begin{tabular}[b]{|p{1.1cm}|}\hline MG11\tabularnewline\hline\multicolumn{1}{c}{}\tabularnewline \multicolumn{1}{l}{Page \textbf{\thepage} of \pageref{LastPage}}\end{tabular}}
\fancyfoot[L]{Signature: \hdashrule{26em}{1pt}{1.5mm} Signature Witnessed by: \textbf{N/A}}
\pagestyle{fancy}
\setlength\parindent{0pt} % Removes all indentation from paragraphs
\newlength{\effectiveboxwidth}
\setlength{\effectiveboxwidth}{\dimexpr\textwidth-2\fboxsep-2\fboxrule}
\begin{document}
\hfill\begin{tabular}{llllll}
\cline{2-5}
URN:& \multicolumn{1}{|@{\hspace{2em}}l|@{\hspace{2em}}}{} & \multicolumn{1}{l|@{\hspace{2em}}}{} & \multicolumn{1}{l|@{\hspace{2em}}}{} & \multicolumn{1}{l|}{} &\\ \cline{2-5}
\end{tabular}
\tcbset{witness/.style={colframe=black,sharp corners,enhanced jigsaw, colback=white}} % Common settings
\begin{tcolorbox}[after={},witness]
Statement of: \textbf{John Smith} \par
\vskip\baselineskip
Age of witness: \textbf{Over 18} \hfill Occupation: \textbf{Paper-pusher}\\
This statement (consisting of \pageref{LastPage} pages each signed by me) is true to the best of my knowledge and belief and I make it knowing that, if it is tendered in evidence, I shall be liable to prosecution if I have wilfully stated in it, anything which I know to be false, or do not believe to be true.
\end{tcolorbox}
\begin{tcolorbox}[nobeforeafter,witness]
Signature: \hdashrule{29em}{1pt}{1.5mm} Date: \textbf{\today}
\end{tcolorbox}
\begin{tcolorbox}[witness,breakable,boxrule=1pt,toprule at break=1pt,extras={toprule at break=1pt} ]
\Blindtext[14]
\end{tcolorbox}
\end{document}
Se deben adaptar las distancias individuales. No tengo el formulario original a mano.
