Estoy intentando generar la siguiente figura usando tikz:

ingrese la descripción de la imagen aquí

Sin embargo, mi mejor intento me lleva a esto (que no es exactamente lo que quiero):

ingrese la descripción de la imagen aquí

Aquí hay un MWE (hay un texto que es diferente; pero ese no es el punto de la pregunta):

\documentclass{standalone}
\usepackage{tikz}
\usetikzlibrary{fit, calc, matrix, positioning, arrows, intersections, through, backgrounds, patterns}

\begin{document}
\begin{figure}[!htb]
\centering
\begin{tikzpicture}[my plot/.style={thick, smooth, samples=100, domain=0:1}, my grid/.style={densely dotted,opacity=0.5, every node/.style={black,opacity=1}}, my axis/.style={latex-latex},scale=0.75]
\coordinate (start plot) at (0,{(0)});
\coordinate (end plot) at (4,{(4)});
\draw[my axis] ([shift={(-0cm,0cm)}]start plot |- end plot) node[above] {$h_2$} |- node[coordinate](origin){} ([shift={(0cm,-0cm)}]start plot -| end plot) node[right] {$h_1$};
\def\x{0.5}\def\y{4}\def\p{0.55}
\coordinate (Ux) at (4.5,{(0)});
\coordinate (Uy) at (0,{(1.5)});
\coordinate (Ua) at (0,{(6)});
\coordinate (Ub) at (6,{(0)});
\coordinate (Uc) at (3,{(0)});
\coordinate (Ud) at (0,{(3)});
\coordinate (Ue) at (1.5,{(0)});
\coordinate (Uf) at (0,{(4.5)});
\coordinate (Ug) at (0,{(0)});
\coordinate (Uh) at (4.5,{(4.5)});
\coordinate (Ui) at (2,{(2)});
\coordinate (Uj) at (1.5,{(1.5)});
\coordinate (Uk) at (3,{(3)});
\coordinate (Ul) at (1.5,{(4)});
\coordinate (Um) at (4,{(1.5)});
\draw[my grid] (Uy) |- node[left,font=\scriptsize]{$1$} cycle;
\draw[my grid] (Uc) |- node[below,font=\scriptsize]{$2$} cycle;
\draw[my grid] (Ud) |- node[left,font=\scriptsize]{$2$} cycle;
\draw[my grid] (Ue) |- node[below,font=\scriptsize]{$1$} cycle;
\draw[fill] (Ug) circle (2pt);
\draw[fill] (Uj) circle (2pt);
\draw[fill] (Uk) circle (2pt);
\node [below] at (Ug) {\footnotesize{$h(T,R)=H(B,L)$}};
\node [below, xshift=10pt] at (Uj) {\footnotesize{$h(T,L)$}};
\node [right] at (Uk) {\footnotesize{$h(B,R)$}};
\node [left] at (Uj) {\footnotesize{$C(G)$}};
\draw[-] (Uj) -- (Ug);
\draw[-] (Uk) -- (Uj);
\draw[-] (Uj) -- (Ul);
\draw[-] (Uj) -- (Um);
\end{tikzpicture}
\end{document}

Mi principal problema aquí es que literalmente no tengo idea de cómo obtener la gráfica con ejes xey negativos. ¿Alguien podría ayudarme a obtener el resultado deseado?

¡Gracias a todos!

Respuesta1

Aquí hay un pequeño código con un dibujo similar. No cambié la fuente porque no sé su nombre.

\documentclass{article}

\usepackage{tikz}

\begin{document}

    \begin{tikzpicture}[scale = 2]
    % axis drawing
    \draw [->] (0,-2) -- (0,2);
    \draw [->] (-2,0) -- (2,0);

    \node[below] at (-1,0) {$-1$};
    \node[below] at (1,0) {$1$};
    \node[left] at (0,-1) {$-1$};
    \node[left] at (0,1) {$1$};
    \node[right] at (2,0) {$h_1$};
    \node[above] at (0,2) {$h_2$};

    % diagonal drawing
    \draw[thick] (-1,1) -- (1,-1);
    \draw[fill] (-1,1) circle [radius=0.05];
    \draw[fill] (1,-1) circle [radius=0.05];

    \node[below right] at (1,-1) {$h(H,H) = h(T,T)$};
    \node[above left] at (-1,1) {$h(T,H) = h(H,T)$};
    \node[below] at (-1,0.7) {$C(G)$};

    % axis 2 drawing
    \draw (1,2.1) -- (1,1) -- (2.1,1);
    \node[right] at (2.1,1) {$R_2=1$};
    \node[above] at (1,2.1) {$R_1=1$};

    \end{tikzpicture}

\end{document}

dibujo grafico

Respuesta2

Debo confesar que me perdí en tu MWE... en consecuencia, no pude encontrar dónde cometes errores en la colocación de los elementos de la imagen. Más bien vuelvo a dibujar la imagen dada desde cero (no es gran cosa, es bastante simple):

\documentclass [tikz, margin=3mm]{standalone}
\usetikzlibrary{arrows}
\usepackage{sansmath}

\begin{document}
    \begin{tikzpicture}[
every node/.style = {font=\sansmath, color=blue!70!black}
TL/.append style = {font=\sffamily\scriptsize}% TL: Tick Labels
                        ]
% axis
\draw[->] (-3,0)   -- (3,0) node[right] {$h_1$};
\draw[->] (0,-2.5) -- (0,3) node[above] {$h_2$};
% tick
\foreach \i in {-2,-1,1,2}
    \draw (\i,2pt) -- ++ (0,-4pt)   node[TL,below] {\i}
          (2pt,\i) -- ++ (-4pt,0)   node[TL, left] {\i};
% curve (line)
\draw[thick,*-*]    (-1,1) node[left]  {$h(T,H)=h(H,T)$}
                --  (1,-1) node[right] {$h(H,H)=h(T,T)$};
% R coordinate system?
\draw   (1,2) node[above]  {$R_1=1$}
    |-  (2,1) node[right]  {$R_2=1$};
\end{tikzpicture}
\end{document}

ingrese la descripción de la imagen aquí
