Estoy usando XeLaTeX (XeTeX 3.14159265-2.6-0.99992 (TeX Live 2015)) en OS X Sierra, compilando en un PDF a través derubber
\documentclass[letterpaper, 11pt]{article}
\usepackage{geometry}
\usepackage{amsmath}
% rubber: set program xelatex
\usepackage{unicode-math}
\setmathfont{STIX Two Math}
\setmainfont{STIX Two Text}
\begin{document}
This is the problem $\frac{\left(asdf\right)}{\left(ghjk\right)}$
\[ \frac{\frac{\left(asdf\right)}{\left(ghjk\right)}}{\frac{\left(asdf\right)}{\left(ghjk\right)}} \]
\[ \frac{\left(asdf\right)}{\left(ghjk\right)} \]
\begin{align*}
\frac{\frac{\left(asdf\right)}{\left(ghjk\right)}}{\frac{\left(asdf\right)}{\left(ghjk\right)}} \\
\frac{\left(asdf\right)}{\left(ghjk\right)}
\end{align*}
\end{document}
El uso de fuentes STIX 2.0.0 con Unicode-math y XeLaTeX hace que los paréntesis con \left(
y \right)
se representen incorrectamente (como un signo de interrogación encuadrado), mientras que los caracteres normales (
y )
se representan correctamente. No tengo el mismo problema con \left[
y \right]
.
La única diferencia en la salida del registro es un conjunto de las siguientes líneas:
Missing character: There is no Ⴞ in font STIX Two Math/OT:script=math;language= DFLT;! Missing character: There is no Ⴟ in font STIX Two Math/OT:script=math;language= DFLT;!
¿Alguien puede ayudarme a encontrar una solución para esto?
Ejemplo realmente mínimo:
\documentclass{article}
\usepackage{unicode-math}
\setmathfont{STIX Two Math}
\begin{document}
$\left(\right)$
$\scriptstyle\left(\right)$
$\scriptscriptstyle\left(\right)$
%\showoutput
\end{document}
Missing character: There is no Ⴞ in font STIX Two Math/OT:script=math;language=DFLT;!
Missing character: There is no Ⴟ in font STIX Two Math/OT:script=math;language=DFLT;!
Missing character: There is no ᆷ in font STIX Two Math/OT:script=math;language=DFLT;+ssty=0;!
Missing character: There is no ^^@ in font STIX Two Math/OT:script=math;language=DFLT;!
Missing character: There is no ᆸ in font STIX Two Math/OT:script=math;language=DFLT;+ssty=0;!
Missing character: There is no ^^@ in font STIX Two Math/OT:script=math;language=DFLT;!
