Discrepancia entre títulos de capítulo/bibliografía/índice en el libro KOMA-Script

Discrepancia entre títulos de capítulo/bibliografía/índice en el libro KOMA-Script

Estoy usando KOMA-Script Book y hay una extraña discrepancia entre los títulos en lo que respecta a la distancia entre la parte superior de la página y la parte inferior del texto.

Estoy usando LyX y por eso los títulos de Índice y Bibliografía se generan automáticamente. El título del capítulo se ingresa manualmente.

El título de la Bibliografía está bien en relación con los títulos de los Capítulos, pero el título del Índice está muy alejado:

Discrepancia entre el título del capítulo y el título del índice

Nota: Se agregó una línea roja para ayudar a ilustrar la diferencia.

¿Hay alguna forma de cambiar el título del Índice específicamente para que se alinee con los demás?

Revisé mi preámbulo y no hay nada en él que debería estar causando este problema.

Gracias de antemano por cualquier ayuda que pueda brindar.

Actualización: a continuación se muestra un ejemplo de trabajo mínimo. Tenga en cuenta que debido a que el documento fue creado en LyX, contiene un código específico de LyX:

#LyX 2.2 created this file. For more info see http://www.lyx.org/
\lyxformat 508
\begin_document
\begin_header
\save_transient_properties true
\origin unavailable
\textclass scrbook
\begin_preamble
%% Paragraphs
\usepackage{parskip}
\setlength{\parskip}{3mm plus1mm minus1mm}

%% Links
\usepackage{hyperref}
\usepackage{xcolor}
\definecolor{Muted}{rgb}{0.200, 0.200, 0.200}
\hypersetup{
    pdfnewwindow=true,      % links in new PDF window
    colorlinks=true,       % false: boxed links; true: colored links
    linkcolor= Muted,          % color of internal links (change box color with linkbordercolor)
    citecolor= Muted,        % color of links to bibliography
    filecolor= Muted,      % color of file links
    urlcolor= Muted           % color of external links
}

%% Footnotes
\usepackage{perpage}
\MakePerPage{footnote}

%% Footnote Symbols
%% use daggers and double daggers as footnote symbols
%%
%% define which symbols are to be used
\makeatletter
\newcommand*{\myfnsymbolsingle}[1]{%
  \ensuremath{%
    \ifcase#1% 0
    \or % 1
      {\dagger }
    \or % 2
      \ddagger
    \or % 3
      \dagger\dagger
    \or % 4
      \ddagger\ddagger
    \or % 5
      \dagger\dagger\dagger
    \or % 6
      \ddagger\ddagger\ddagger
    \else % >= 7
      \@ctrerr
    \fi
  }%
}
\makeatother
%% redefine the command for creating footnotes
\newcommand*{\myfnsymbol}[1]{%
  \myfnsymbolsingle{\value{#1}}%
}
%% multiply the symbols for iterations above the upper bound, if needed
\usepackage{alphalph}
\newalphalph{\myfnsymbolmult}[mult]{\myfnsymbolsingle}{}
\renewcommand*{\thefootnote}{%
  \myfnsymbolmult{\value{footnote}}%
}
%% add space between the footnote character and text in the footer
\usepackage{scrextend}
\deffootnote[1em]{1.5em}{1em}{%
        \textsuperscript{\thefootnotemark}~%
}

%% Bibliography
\usepackage[super,sort&compress]{natbib}
\setcitestyle{citesep={, }}

%% Fonts
\usepackage{fontspec}
\setmainfont[
BoldFont={Kaiti TC Bold},
ItalicFont={Baskerville Italic},
BoldItalicFont={Baskerville Bold Italic}
] {Kaiti TC}
\end_preamble
\use_default_options true
\maintain_unincluded_children false
\language english
\language_package default
\inputencoding auto
\fontencoding global
\font_roman "default" "Kaiti SC"
\font_sans "default" "Kaiti SC"
\font_typewriter "default" "Baskerville"
\font_math "auto" "auto"
\font_default_family default
\use_non_tex_fonts true
\font_sc false
\font_osf false
\font_sf_scale 100 100
\font_tt_scale 100 100
\graphics default
\default_output_format default
\output_sync 0
\bibtex_command default
\index_command default
\paperfontsize 12
\spacing single
\use_hyperref true
\pdf_title "Dao De Jing"
\pdf_author "Laozi, Firstname Lastname"
\pdf_subject "Chinese philosophy"
\pdf_keywords "philosophy, non-duality, nonduality, Chinese"
\pdf_bookmarks true
\pdf_bookmarksnumbered false
\pdf_bookmarksopen false
\pdf_bookmarksopenlevel 1
\pdf_breaklinks false
\pdf_pdfborder false
\pdf_colorlinks false
\pdf_backref false
\pdf_pdfusetitle true
\papersize custom
\use_geometry true
\use_package amsmath 1
\use_package amssymb 1
\use_package cancel 1
\use_package esint 1
\use_package mathdots 1
\use_package mathtools 1
\use_package mhchem 1
\use_package stackrel 1
\use_package stmaryrd 1
\use_package undertilde 1
\cite_engine basic
\cite_engine_type default
\biblio_style plain
\use_bibtopic false
\use_indices false
\paperorientation portrait
\suppress_date true
\justification true
\use_refstyle 1
\index Index
\shortcut idx
\color #008000
\end_index
\paperwidth 6in
\paperheight 9in
\leftmargin 0.8in
\topmargin 0.8in
\rightmargin 0.6in
\bottommargin 0.8in
\headheight 0.1in
\headsep 0.3in
\footskip 0.3in
\secnumdepth -2
\tocdepth 0
\paragraph_separation indent
\paragraph_indentation 0pt
\quotes_language english
\papercolumns 1
\papersides 2
\paperpagestyle default
\tracking_changes false
\output_changes false
\html_math_output 0
\html_css_as_file 0
\html_be_strict false
\end_header

\begin_body

\begin_layout Title
Title
\end_layout

\begin_layout Author

\size small
Author
\end_layout

\begin_layout Standard
\begin_inset CommandInset toc
LatexCommand tableofcontents

\end_inset


\end_layout

\begin_layout Standard
\begin_inset ERT
status open

\begin_layout Plain Layout

%% add spacing above the Index entry in the TOC
\end_layout

\begin_layout Plain Layout


\backslash
addtocontents{toc}{
\backslash
vspace{20pt}}
\end_layout

\end_inset


\end_layout

\begin_layout Chapter
Introduction
\end_layout

\begin_layout Part
Part 1
\end_layout

\begin_layout Chapter*
Chapter 1
\end_layout

\begin_layout Standard
This is text with an index entry at the end.
\begin_inset Index idx
status collapsed

\begin_layout Plain Layout
index entry
\end_layout

\end_inset


\end_layout

\begin_layout Standard
\begin_inset ERT
status open

\begin_layout Plain Layout


\backslash
addtocontents{toc}{
\backslash
vspace{18pt}}
\end_layout

\end_inset


\end_layout

\begin_layout Chapter
Glossary
\end_layout

\begin_layout Labeling
\labelwidthstring 00.00.0000

\family typewriter
\series bold
example
\family default
\series default
This is example text.
\end_layout

\begin_layout Standard
\begin_inset Newpage newpage
\end_inset


\end_layout

\begin_layout Standard
\begin_inset ERT
status open

\begin_layout Plain Layout


\backslash
raggedright
\end_layout

\begin_layout Plain Layout


\backslash
addcontentsline{toc}{chapter}{Bibliography} %% show in TOC
\end_layout

\end_inset


\end_layout

\begin_layout Bibliography
\begin_inset CommandInset bibitem
LatexCommand bibitem
label "1"
key "Item-1"

\end_inset

Bibliography item 1
\end_layout

\begin_layout Standard
\begin_inset CommandInset index_print
LatexCommand printindex
type "idx"

\end_inset


\end_layout

\end_body
\end_document

Genero un .pdf a través de XeTeX en LyX y resulta en el mismo problema que mencioné.

Además, aquí hay una exportación .tex del mismo archivo:

%% LyX 2.2.1 created this file.  For more info, see http://www.lyx.org/.
%% Do not edit unless you really know what you are doing.
\documentclass[12pt,english]{scrbook}
\usepackage{fontspec}
\setmainfont[Mapping=tex-text]{Kaiti SC}
\setsansfont[Mapping=tex-text]{Kaiti SC}
\setmonofont{Baskerville}
\usepackage[paperwidth=6in,paperheight=9in]{geometry}
\geometry{verbose,tmargin=0.8in,bmargin=0.8in,lmargin=0.8in,rmargin=0.6in,headheight=0.1in,headsep=0.3in,footskip=0.3in}
\setcounter{secnumdepth}{-2}
\setcounter{tocdepth}{0}
\setlength{\parindent}{0pt}
\usepackage{makeidx}
\makeindex
\usepackage[unicode=true,
 bookmarks=true,bookmarksnumbered=false,bookmarksopen=false,
 breaklinks=false,pdfborder={0 0 1},backref=false,colorlinks=false]
 {hyperref}
\hypersetup{pdftitle={Dao De Jing},
 pdfauthor={Laozi, Firstname Lastname},
 pdfsubject={Chinese philosophy},
 pdfkeywords={philosophy, non-duality, nonduality, Chinese}}

\makeatletter
\@ifundefined{date}{}{\date{}}
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%% User specified LaTeX commands.
%% Paragraphs
\usepackage{parskip}
\setlength{\parskip}{3mm plus1mm minus1mm}

%% Links
\usepackage{hyperref}
\usepackage{xcolor}
\definecolor{Muted}{rgb}{0.200, 0.200, 0.200}
\hypersetup{
    pdfnewwindow=true,      % links in new PDF window
    colorlinks=true,       % false: boxed links; true: colored links
    linkcolor= Muted,          % color of internal links (change box color with linkbordercolor)
    citecolor= Muted,        % color of links to bibliography
    filecolor= Muted,      % color of file links
    urlcolor= Muted           % color of external links
}

%% Footnotes
\usepackage{perpage}
\MakePerPage{footnote}

%% Footnote Symbols
%% use daggers and double daggers as footnote symbols
%%
%% define which symbols are to be used
\makeatletter
\newcommand*{\myfnsymbolsingle}[1]{%
  \ensuremath{%
    \ifcase#1% 0
    \or % 1
      {\dagger }
    \or % 2
      \ddagger
    \or % 3
      \dagger\dagger
    \or % 4
      \ddagger\ddagger
    \or % 5
      \dagger\dagger\dagger
    \or % 6
      \ddagger\ddagger\ddagger
    \else % >= 7
      \@ctrerr
    \fi
  }%
}
\makeatother
%% redefine the command for creating footnotes
\newcommand*{\myfnsymbol}[1]{%
  \myfnsymbolsingle{\value{#1}}%
}
%% multiply the symbols for iterations above the upper bound, if needed
\usepackage{alphalph}
\newalphalph{\myfnsymbolmult}[mult]{\myfnsymbolsingle}{}
\renewcommand*{\thefootnote}{%
  \myfnsymbolmult{\value{footnote}}%
}
%% add space between the footnote character and text in the footer
\usepackage{scrextend}
\deffootnote[1em]{1.5em}{1em}{%
        \textsuperscript{\thefootnotemark}~%
}

%% Bibliography
\usepackage[super,sort&compress]{natbib}
\setcitestyle{citesep={, }}

%% Fonts
\usepackage{fontspec}
\setmainfont[
BoldFont={Kaiti TC Bold},
ItalicFont={Baskerville Italic},
BoldItalicFont={Baskerville Bold Italic}
] {Kaiti TC}

\makeatother

\usepackage{xunicode}
\usepackage{polyglossia}
\setdefaultlanguage{english}
\begin{document}

\title{Title}

\author{{\small{}Author}}

\maketitle
\tableofcontents{}

%% add spacing above the Index entry in the TOC
\addtocontents{toc}{\vspace{20pt}}

\chapter{Introduction}

\part{Part 1}

\chapter*{Chapter 1}

This is text with an index entry at the end.\index{index entry}

\addtocontents{toc}{\vspace{18pt}}

\chapter{Glossary}
\begin{labeling}{00.00.0000}
\item [{\texttt{\textbf{example}}}] This is example text.
\end{labeling}
\newpage{}

\raggedright
\addcontentsline{toc}{chapter}{Bibliography} %% show in TOC
\begin{thebibliography}{1}
\bibitem[1]{Item-1}Bibliography item 1
\end{thebibliography}
\printindex{}
\end{document}

Respuesta1

Si agrega el \usepackage{idxlayout}a su preámbulo, el título de "Índice" se colocará de la misma manera que los otros capítulos.

ingrese la descripción de la imagen aquí

%% LyX 2.2.1 created this file.  For more info, see http://www.lyx.org/.
%% Do not edit unless you really know what you are doing.
\documentclass[12pt,english]{scrbook}
\usepackage{fontspec}
\setmainfont[Mapping=tex-text]{Kaiti SC}
\setsansfont[Mapping=tex-text]{Kaiti SC}
\setmonofont{Baskerville}
\usepackage[paperwidth=6in,paperheight=9in]{geometry}
\geometry{verbose,tmargin=0.8in,bmargin=0.8in,lmargin=0.8in,rmargin=0.6in,headheight=0.1in,headsep=0.3in,footskip=0.3in}
\setcounter{secnumdepth}{-2}
\setcounter{tocdepth}{0}
\setlength{\parindent}{0pt}
\usepackage{makeidx}
\makeindex
\usepackage[unicode=true,
 bookmarks=true,bookmarksnumbered=false,bookmarksopen=false,
 breaklinks=false,pdfborder={0 0 1},backref=false,colorlinks=false]
 {hyperref}
\hypersetup{pdftitle={Dao De Jing},
 pdfauthor={Laozi, Firstname Lastname},
 pdfsubject={Chinese philosophy},
 pdfkeywords={philosophy, non-duality, nonduality, Chinese}}

\makeatletter
\@ifundefined{date}{}{\date{}}
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%% User specified LaTeX commands.
%% Paragraphs
\usepackage{parskip}
\setlength{\parskip}{3mm plus1mm minus1mm}

%% Links
\usepackage{hyperref}
\usepackage{xcolor}
\definecolor{Muted}{rgb}{0.200, 0.200, 0.200}
\hypersetup{
    pdfnewwindow=true,      % links in new PDF window
    colorlinks=true,       % false: boxed links; true: colored links
    linkcolor= Muted,          % color of internal links (change box color with linkbordercolor)
    citecolor= Muted,        % color of links to bibliography
    filecolor= Muted,      % color of file links
    urlcolor= Muted           % color of external links
}

%% Footnotes
\usepackage{perpage}
\MakePerPage{footnote}

%% Footnote Symbols
%% use daggers and double daggers as footnote symbols
%%
%% define which symbols are to be used
\makeatletter
\newcommand*{\myfnsymbolsingle}[1]{%
  \ensuremath{%
    \ifcase#1% 0
    \or % 1
      {\dagger }
    \or % 2
      \ddagger
    \or % 3
      \dagger\dagger
    \or % 4
      \ddagger\ddagger
    \or % 5
      \dagger\dagger\dagger
    \or % 6
      \ddagger\ddagger\ddagger
    \else % >= 7
      \@ctrerr
    \fi
  }%
}
\makeatother
%% redefine the command for creating footnotes
\newcommand*{\myfnsymbol}[1]{%
  \myfnsymbolsingle{\value{#1}}%
}
%% multiply the symbols for iterations above the upper bound, if needed
\usepackage{alphalph}
\newalphalph{\myfnsymbolmult}[mult]{\myfnsymbolsingle}{}
\renewcommand*{\thefootnote}{%
  \myfnsymbolmult{\value{footnote}}%
}
%% add space between the footnote character and text in the footer
\usepackage{scrextend}
\deffootnote[1em]{1.5em}{1em}{%
        \textsuperscript{\thefootnotemark}~%
}

%% Bibliography
\usepackage[super,sort&compress]{natbib}
\setcitestyle{citesep={, }}

%% Fonts
\usepackage{fontspec}
\setmainfont[
BoldFont={Kaiti TC Bold},
ItalicFont={Baskerville Italic},
BoldItalicFont={Baskerville Bold Italic}
] {Kaiti TC}

\makeatother

\usepackage{xunicode}
\usepackage{polyglossia}
\setdefaultlanguage{english}

\usepackage{idxlayout}
\begin{document}

\title{Title}

\author{{\small{}Author}}

\maketitle
\tableofcontents{}

%% add spacing above the Index entry in the TOC
\addtocontents{toc}{\vspace{20pt}}

\chapter{Introduction}

\part{Part 1}

\chapter*{Chapter 1}

This is text with an index entry at the end.\index{index entry}

\addtocontents{toc}{\vspace{18pt}}

\chapter{Glossary}
\begin{labeling}{00.00.0000}
\item [{\texttt{\textbf{example}}}] This is example text.
\end{labeling}
\newpage{}

\raggedright
\addcontentsline{toc}{chapter}{Bibliography} %% show in TOC
\begin{thebibliography}{1}
\bibitem[1]{Item-1}Bibliography item 1
\end{thebibliography}
\printindex{}
\end{document}

información relacionada
