Hacer que la tabla larga (en modo horizontal) sea más ancha que el ancho del texto

Suponiendo que tengo una tabla que abarca varias páginas

\documentclass[DIV=8]{scrartcl}
\usepackage[utf8]{inputenc}
\usepackage[english]{babel}
\usepackage{booktabs,array,ragged2e,longtable}
\newcolumntype{P}[1]{>{\RaggedRight\arraybackslash}p{#1\textwidth}}

\usepackage{enumitem}
%% Create a very compact itemized list environment
\newlist{mylist}{itemize}{1}
\setlist[mylist]{label=\textbullet, nosep, wide,
                 leftmargin=*, % hanging indentation
                 before=\vspace{-0.50\baselineskip},
                 after =\vspace{-0.8\baselineskip}}
\begin{document}

% keep scope of longtable-related instructions local to current TeX group
\begingroup
\setlength\tabcolsep{0pt} % <--- important
\setlength\LTleft{0pt}
\setlength\LTright{0pt}

\begin{longtable}{@{\extracolsep{\fill}}P{0.38}P{0.38}P{0.2}}

\caption{My caption} \label{my-label}\\
\toprule
Column 1 & Column 2 & Column 3 \\
\midrule
\endfirsthead

\multicolumn{3}{l}{(Table \ref{my-label}, cont'd)}\\ % re-state table number
\addlinespace
\toprule
Column 1 & Column 2 & Column 3 \\
\midrule
\endhead

\bottomrule
\addlinespace
\multicolumn{3}{r}{(cont'd on next page)}\\
\endfoot

\bottomrule
\endlastfoot

\begin{mylist}
     \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor invidunt ut labore et dolore magna aliquyam erat, sed diam voluptua. At vero eos et accusam et justo duo dolores et ea rebum. Stet clita
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
    \item Lorem ipsum
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} \\

\addlinespace

\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} \\

\addlinespace

\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} \\

\addlinespace

\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} \\

%\addlinespace % omit if at page break

\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} \\

\end{longtable}
\endgroup % end of TeX group that encases the 'longtable' material

\end{document}

Código Copiado y pegado deaquí, gracias amico.

Quiero orientar la mesa en modo horizontal. Cuando uso begin{landscape}with \documentclass[DIV=8]{scrartcl}, el problema al que me enfrento es que la tabla es tan "larga/profunda" como el ancho de mi texto. Eso da como resultado solo dos o tres filas por página... ¿Hay alguna manera de decirle al látex que supere el ancho del texto con la tabla?

Respuesta1

Esto utiliza \newgeometryy \restoregeometrypara aumentar el área de texto. El \rulees sólo para demostrar el espacio disponible.

\documentclass[DIV=8]{scrartcl}
\usepackage{geometry}
\usepackage[utf8]{inputenc}
\usepackage[english]{babel}
\usepackage{pdflscape}
\usepackage{afterpage}
\usepackage{booktabs,array,ragged2e,longtable}
\newcolumntype{P}[1]{>{\RaggedRight\arraybackslash}p{#1\textwidth}}

\usepackage{enumitem}
%% Create a very compact itemized list environment
\newlist{mylist}{itemize}{1}
\setlist[mylist]{label=\textbullet, nosep, wide,
                 leftmargin=*, % hanging indentation
                 before=\vspace{-0.50\baselineskip},
                 after =\vspace{-0.8\baselineskip}}
\usepackage{lipsum}% mwe only
\begin{document}

% keep scope of longtable-related instructions local to current TeX group
\afterpage{%
\newgeometry{textwidth={\dimexpr \textwidth+2cm}}
\begin{landscape}
\noindent\rule{\linewidth}{\textheight}% show available space
\setlength\tabcolsep{0pt} % <--- important
\setlength\LTleft{0pt}
\setlength\LTright{0pt}

\begin{longtable}{@{\extracolsep{\fill}}P{0.38}P{0.38}P{0.2}}

\caption{My caption} \label{my-label}\\
\toprule
Column 1 & Column 2 & Column 3 \\
\midrule
\endfirsthead

\multicolumn{3}{l}{(Table \ref{my-label}, cont'd)}\\ % re-state table number
\addlinespace
\toprule
Column 1 & Column 2 & Column 3 \\
\midrule
\endhead

\bottomrule
\addlinespace
\multicolumn{3}{r}{(cont'd on next page)}\\
\endfoot

\bottomrule
\endlastfoot

\begin{mylist}
     \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor invidunt ut labore et dolore magna aliquyam erat, sed diam voluptua. At vero eos et accusam et justo duo dolores et ea rebum. Stet clita
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
    \item Lorem ipsum
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} \\

\addlinespace

\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} \\

\addlinespace

\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} \\

\addlinespace

\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} \\

%\addlinespace % omit if at page break

\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum dolor sit amet, consetetur sadipscing
    \item Lorem ipsum dolor sit
    \item Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} &
\begin{mylist}
    \item Lorem ipsum
    \item Lorem ipsum
\end{mylist} \\

\end{longtable}
\end{landscape}
\restoregeometry}

\lipsum[1-8]

\end{document}
