Cableado de partes de texto

Question

Actualmente estoy intentando conectar partes de texto para describir algo como los permisos de archivos Unix o la salida de un

ls -al

Pero no tengo idea de cómo puedo crear algo como esto:

Estaba pensando en usar \patho \nodede Tikz

Pero no logré que funcionara.

Answer 1

¿Te refieres a algo como esto?

\documentclass[tikz]{standalone}
\usetikzlibrary{calc}
\begin{document}
\begin{tikzpicture}[blue]
\node (a) at (0,0) {-};
\node (b) at (1,0) {rwx};
\node (c) at (2,0) {rw-};
\node (d) at (3,0) {r-\--};
\draw (a.south west)--(a.south east);
\draw (b.south west)--(b.south east);
\draw (c.south west)--(c.south east);
\draw (d.south west)--(d.south east);
\draw (d.south)--($(d.south)+(0,-1)$)--($(d.south)+(1,-1)$) node[right,align=left,font=\scriptsize\sffamily] {Read, write and execute\\permissions for all other users};
\draw (c.south)--($(c.south)+(0,-2)$)--($(c.south)+(2,-2)$) node[right,align=left,font=\scriptsize\sffamily] {Read, write and execute permissions for\\members of the group owning the file};
\draw (b.south)--($(b.south)+(0,-3)$)--($(b.south)+(3,-3)$) node[right,align=left,font=\scriptsize\sffamily] {Read, write and execute permissions\\for the owner of the file};
\draw (a.south)--($(a.south)+(0,-4)$)--($(a.south)+(4,-4)$) node[right,align=left,font=\scriptsize\sffamily] {File type: ``---'' means a file.\\``d'' means a directory};
\end{tikzpicture}
\end{document}

Answer 2

Básicamente, robé la respuesta de JouleV y la revisé para usar el posicionamiento relativo y empaquetar los nodos más juntos. Específicamente, el espacio entre el texto de dos nodos adyacentes es 2 veces inner sep. Desafortunadamente, inner septambién se agrega a las líneas debajo del texto, por lo que tuve que reducir inner xsepy aumentar la separación usando [right=4pt].

Por cierto, el valor predeterminado inner sepes 0,333em.

\documentclass[tikz]{standalone}
\usetikzlibrary{calc}
\begin{document}
\begin{tikzpicture}[blue]
\begin{scope}[every node/.style={inner xsep=0pt, inner ysep=2pt}]
  \node (a) {-};
  \node[right=4pt] (b) at (a.east) {rwx};
  \node[right=4pt] (c) at (b.east) {rw-};
  \node[right=4pt] (d) at (c.east) {r-\--};
\end{scope}
\begin{scope}[every node/.style={below right, align=left, font=\scriptsize\sffamily}]
  \node (e) at (d.south east) {Read, write and execute\\permissions for all other users};
  \node (f) at (e.south west) {Read, write and execute permissions for\\members of the group owning the file};
  \node (g) at (f.south west) {Read, write and execute permissions\\for the owner of the file};
  \node (h) at (g.south west) {File type: ``---'' means a file.\\``d'' means a directory};
\end{scope}
\draw (a.south west)--(a.south east)
  (b.south west)--(b.south east)
  (c.south west)--(c.south east)
  (d.south west)--(d.south east)
  (a.south) |- (h.west)
  (b.south) |- (g.west)
  (c.south) |- (f.west)
  (d.south) |- (e.west);
\end{tikzpicture}
\end{document}
