¿Cómo dibujar este diagrama de árbol?

Question

¿Cómo puedo dibujar este diagrama de árbol en LaTex?

Answer 1

¡Bienvenido a TeX-SE! Esto es para darte unacomenzar. Estoy convencido de que tupodríaTambién agregue Hy Tprogramáticamente, pero ahora no tengo motivación para explicar esto (más aún porque no estoy seguro de si eso es lo que desea).

\documentclass{article}
\usepackage[edges]{forest}
\usetikzlibrary{arrows.meta}
\begin{document}
\begin{forest}
for tree={s sep=0cm,l sep=1.2cm,font=\sffamily,
where n children=0{rotate=90,anchor=west,edge={thick,-{Latex}}}{},
edge={thick}
}
  [H,alias=L1
   [H,alias=L2
    [H,alias=L3
     [H,alias=L4
      [H,alias=L5
       [HHHHH,alias=L6]
      ]
      [T
       [HHHHT]
      ]
     ]
     [T
      [H
       [HHHTH]
      ]
      [T
       [HHHTT]
      ]
     ]
    ]
    [T
     [H
      [H
       [HHTHH]
      ]
      [T
       [HHTHT]
      ]
     ]
     [T
      [H
       [HHTTH]
      ]
      [T
       [HHTTT]
      ]
     ]
    ]
   ]
   [T
    [H
     [H
      [H
       [HTHHH]
      ]
      [T
       [HTHHT]
      ]
     ]
     [T
      [H
       [HTHTH]
      ]
      [T
       [HTHTT]
      ]
     ]
    ]
    [T
     [H
      [H
       [HTTHH]
      ]
      [T
       [HTTHT]
      ]
     ]
     [T
      [H
       [HTTTH]
      ]
      [T
       [HTTTT]
      ]
     ]
    ]
   ]
  ]
\foreach \X [count=\Y] in {First,Second,Third,Fourth,Fifth}
{\node[anchor=east,font=\sffamily] at (L6.north|-L\Y){\X\ flip};}
\node[anchor=east,font=\sffamily] at (L6.north){Outcome};
\end{forest}
\end{document}

*NOTA**: Casi todo lo que sé sobre los bosques lo aprendí de algunas respuestas de cfr, quien realmente es un maestro forestal. Si considera votar esto, vote algunas respuestas de ella. De esa manera, seguramente emitirás un merecido voto a favor.

\documentclass{article}
\usepackage{adjustbox}
\usepackage[edges]{forest}
\usetikzlibrary{arrows.meta}
\begin{document}
\begin{adjustbox}{valign=t,width=0.5\textwidth}
\begin{forest}
for tree={s sep=0cm,l sep=1.2cm,font=\sffamily,
where n children=1{rotate=90,anchor=west,edge={thick,-{Latex}}}{},
edge={thick}
}
  [H,alias=L1
   [H,alias=L2
    [H,alias=L3
     [H,alias=L4
      [H,alias=L5
       [HHHHH,alias=L6
        [$5$,alias=L7]
       ]
      ]
      [T
       [HHHHT
        [$3$]
       ]
      ]
     ]
     [T
      [H
       [HHHTH
       [$3$]
       ]
      ]
      [T
       [HHHTT
        [$1$]
       ]
      ]
     ]
    ]
    [T
     [H
      [H
       [HHTHH
        [$3$]
       ]
      ]
      [T
       [HHTHT
        [$1$]
       ]
      ]
     ]
     [T
      [H
       [HHTTH
        [$1$]
       ]
      ]
      [T
       [HHTTT
        [$-1$]
       ]
      ]
     ]
    ]
   ]
   [T
    [H
     [H
      [H
       [HTHHH
        [$3$]
       ]
      ]
      [T
       [HTHHT
        [$1$]
       ]
      ]
     ]
     [T
      [H
       [HTHTH
        [$1$]
       ]
      ]
      [T
       [HTHTT
        [$-1$]
       ]
      ]
     ]
    ]
    [T
     [H
      [H
       [HTTHH
        [$1$]
       ]
      ]
      [T
       [HTTHT
        [$-1$]
       ]
      ]
     ]
     [T
      [H
       [HTTTH
        [$-1$]
       ]
      ]
      [T
       [HTTTT
        [$-3$]
       ]
      ]
     ]
    ]
   ]
  ]
\foreach \X [count=\Y] in {First,Second,Third,Fourth,Fifth}
{\node[anchor=east,font=\sffamily] at (L6.north|-L\Y){\X\ flip};}
\node[anchor=east,font=\sffamily] at (L6.north){Outcome};
\node[anchor=east,font=\sffamily] at (L7.west){Lands on};
\end{forest}
\end{adjustbox}
\begin{adjustbox}{valign=t,width=0.47\textwidth}
\begin{forest}
for tree={s sep=0cm,l sep=1.2cm,font=\sffamily,
where n children=1{rotate=90,anchor=west,edge={thick,-{Latex}}}{},
edge={thick}
}
  [T,alias=L1
   [H,alias=L2
    [H,alias=L3
     [H,alias=L4
      [H,alias=L5
       [THHHH,alias=L6
        [$3$,alias=L7]
       ]
      ]
      [T
       [THHHT
        [$1$]
       ]
      ]
     ]
     [T
      [H
       [THHTH
       [$1$]
       ]
      ]
      [T
       [THHTT
        [$-1$]
       ]
      ]
     ]
    ]
    [T
     [H
      [H
       [THTHH
        [$1$]
       ]
      ]
      [T
       [THTHT
        [$-1$]
       ]
      ]
     ]
     [T
      [H
       [THTTH
        [$-1$]
       ]
      ]
      [T
       [THTTT
        [$-3$]
       ]
      ]
     ]
    ]
   ]
   [T
    [H
     [H
      [H
       [TTHHH
        [$1$]
       ]
      ]
      [T
       [TTHHT
        [$-1$]
       ]
      ]
     ]
     [T
      [H
       [TTHTH
        [$-1$]
       ]
      ]
      [T
       [TTHTT
        [$-3$]
       ]
      ]
     ]
    ]
    [T
     [H
      [H
       [TTTHH
        [$-1$]
       ]
      ]
      [T
       [TTTHT
        [$-3$]
       ]
      ]
     ]
     [T
      [H
       [TTTTH
        [$-3$]
       ]
      ]
      [T
       [TTTTT
        [$-5$]
       ]
      ]
     ]
    ]
   ]
  ]
\end{forest}
\end{adjustbox}
\end{document}
