Estoy intentando poner una mesa larga y tres imágenes en la misma página horizontal. Aquí hay un MWE:
\documentclass[11pt]{article}
\usepackage{graphicx}
\usepackage{tabularx}
\usepackage{booktabs}
\usepackage{lipsum}
\usepackage{pdflscape}
\usepackage{multirow}
\usepackage{afterpage}
\usepackage[a4paper, portrait, margin=1in]{geometry}
\begin{document}
\lipsum[1-2]
% want to put a table and images here
\afterpage{
\begin{landscape}
\begin{table}[ht]
\small
\centering
\def\arraystretch{1.5}
\begin{tabularx}{0.991\linewidth}{lccccccccccc} \toprule
& \multicolumn{3}{c}{No Clustering} & \multicolumn{4}{c}{$K$-means Clustering} & \multicolumn{4}{c}{Hierarchical Clustering} \\
& \multicolumn{3}{c}{--} & \multicolumn{4}{c}{$K=19$} & \multicolumn{4}{c}{$K=5$} \\
\cmidrule(r){2-4} \cmidrule(lr){5-8} \cmidrule(l){9-12}
% this is what has to be replaced with xtable
& Lasso & Elastic Net & pcLasso & gLasso & ogLasso & sgLasso & pcLasso & gLasso & ogLasso & sgLasso & pcLasso \\ \midrule
\multirow{2}{*}{Parameters} & $\lambda = 0.0041$ & $\lambda = 0.0051$ & $\lambda = 0.0055$ & $\lambda = 0.0036$ & $\lambda = 0.078$ & $\lambda = 0.024$ & $\lambda = 0.0055$ & $\lambda = 0.0030$ & $\lambda = 0.078$ & $\lambda = 0.024$ & $\lambda = 0.0055$ \\
& -- & $\alpha = 0.8$ & $\texttt{rat} = 1$ & -- & -- & $\alpha = 0.2$ & $\texttt{rat} = 0.9$ & -- & -- & $\alpha = 0.4$ & $\texttt{rat} = 0.95$ \\ %\addlinespace
Misclass. & $5/36$ & $3/36$ & $2/36$ & $2/36$ & $14/36$ & $3/36$ & $2/36$ & $3/36$ & $14/36$ & $14/36$ & $2/36$ \\
Deviance & $0.24$ & $0.083$ & $0.45$ & $0.18$ & $1.24$ & $1.46$ & $0.44$ & $0.28$ & $1.24$ & $1.46$ & $0.44$ \\
Sig. Coef. & $14$ & $28$ & $16$ & $443$ & $1$ & $52$ & $76$ & $2714$ & $1$ & $772$ & $46$ \\
Sig. Groups & -- & -- & -- & $1$ & $0$ & $1$ & $15$ & $2$ & $0$ & $1$ & $5$ \\
%
\bottomrule
\end{tabularx}
\caption{The performance of various models on the leukemia data set.}
\end{table}
\begin{figure}[ht]
\centering
\includegraphics[width = 0.48\textwidth]{img1.pdf}
\includegraphics[width = 0.48\textwidth]{img2.pdf}
\includegraphics[width = 0.48\textwidth]{img3.pdf}
\caption{The ROC curves for the leukemia data set.}
\label{leuk_ROC}
\end{figure}
\end{landscape}
}
\lipsum[3-7]
\end{document}
El objetivo es que la tabla se extienda a lo largo de la página y las tres imágenes se alineen debajo de ella. Sin embargo, aquí está mi resultado:
Claramente, no funcionó. ¿Alguna sugerencia sobre cómo se puede solucionar esto?
EDITAR
Hice una pequeña modificación al código y cambié el resultado. Pero la cuestión aún persiste.
Respuesta1
Simplemente reemplazando [ht]tanto [p]para la tabla como para la figura, los puse en una página horizontal. ( draftse agrega para ignorar las imágenes que faltan).
\documentclass[11pt,draft]{article}
\usepackage{graphicx}
\usepackage{tabularx}
\usepackage{booktabs}
\usepackage{lipsum}
\usepackage{pdflscape}
\usepackage{multirow}
\usepackage{afterpage}
\usepackage[a4paper, portrait, margin=1in]{geometry}
\begin{document}
\lipsum[1-2]
% want to put a table and images here
\afterpage{
\begin{landscape}
\begin{table}[p]
\small
\centering
\def\arraystretch{1.5}
\begin{tabularx}{0.991\linewidth}{lccccccccccc} \toprule
& \multicolumn{3}{c}{No Clustering} & \multicolumn{4}{c}{$K$-means Clustering} & \multicolumn{4}{c}{Hierarchical Clustering} \\
& \multicolumn{3}{c}{--} & \multicolumn{4}{c}{$K=19$} & \multicolumn{4}{c}{$K=5$} \\
\cmidrule(r){2-4} \cmidrule(lr){5-8} \cmidrule(l){9-12}
% this is what has to be replaced with xtable
& Lasso & Elastic Net & pcLasso & gLasso & ogLasso & sgLasso & pcLasso & gLasso & ogLasso & sgLasso & pcLasso \\ \midrule
\multirow{2}{*}{Parameters} & $\lambda = 0.0041$ & $\lambda = 0.0051$ & $\lambda = 0.0055$ & $\lambda = 0.0036$ & $\lambda = 0.078$ & $\lambda = 0.024$ & $\lambda = 0.0055$ & $\lambda = 0.0030$ & $\lambda = 0.078$ & $\lambda = 0.024$ & $\lambda = 0.0055$ \\
& -- & $\alpha = 0.8$ & $\texttt{rat} = 1$ & -- & -- & $\alpha = 0.2$ & $\texttt{rat} = 0.9$ & -- & -- & $\alpha = 0.4$ & $\texttt{rat} = 0.95$ \\ %\addlinespace
Misclass. & $5/36$ & $3/36$ & $2/36$ & $2/36$ & $14/36$ & $3/36$ & $2/36$ & $3/36$ & $14/36$ & $14/36$ & $2/36$ \\
Deviance & $0.24$ & $0.083$ & $0.45$ & $0.18$ & $1.24$ & $1.46$ & $0.44$ & $0.28$ & $1.24$ & $1.46$ & $0.44$ \\
Sig. Coef. & $14$ & $28$ & $16$ & $443$ & $1$ & $52$ & $76$ & $2714$ & $1$ & $772$ & $46$ \\
Sig. Groups & -- & -- & -- & $1$ & $0$ & $1$ & $15$ & $2$ & $0$ & $1$ & $5$ \\
%
\bottomrule
\end{tabularx}
\caption{The performance of various models on the leukemia data set.}
\end{table}
\begin{figure}[p]
\centering
\includegraphics[width = 0.48\textwidth]{img1.pdf}
\includegraphics[width = 0.48\textwidth]{img2.pdf}
\includegraphics[width = 0.48\textwidth]{img3.pdf}
\caption{The ROC curves for the leukemia data set.}
\label{leuk_ROC}
\end{figure}
\end{landscape}
}
\lipsum[3-7]
\end{document}
