Tengo un proyecto que convierte archivos Markdown a PDF, utilizando pandocuna plantilla PDF de LaTeX.
Tengo un problema extraño con las tablas. En muy pocos casos (algo así como 2 de cada 200 documentos), la tabla se inserta después de un salto de página. No estoy seguro si es un salto de página o no, ya que básicamente tengo muy poca experiencia en LaTeX, pero así parece.
Este es uno de los archivos Markdown que estoy convirtiendo:
... More stuff above
Lorem
- Lorem Ipsum is simply dummy text of the printing and typesetting industry. Lorem Ipsum has been the industry's standard dummy text ever since the 1500s.
# LOREM IPSUM
## Lorem Ipsum is simply dummy
Lorem Ipsum is simply dummy text of the printing and typesetting industry. Lorem Ipsum has been the industry's standard dummy text ever since the 1500s, when an unknown printer took a galley of type and scrambled it to make a type specimen book. It has survived not only five centuries, but also the leap into electronic typesetting.
| Column 1 | Column 2 |
| ---------------------------------------------- | --------------------------------------------------------------------------- |
| Lorem Ipsum is simply dummy text | Lorem Ipsum |
| Lorem Ipsum is simply dummy text of the | Lorem Ipsum is simply dummy text of the printing and typesetting industry. |
## Lorem Ipsum is simply dummy text of the
Lorem Ipsum is simply dummy text of the printing and typesetting industry. Lorem Ipsum has been the industry's standard dummy text ever since the 1500s, when an unknown printer took a galley of type and scrambled it to make a type specimen book.
... More stuff below
Mi pandoccomando es algo como esto (se ejecuta con Powershell, de eso se tratan las variables con signos de dólar):
pandoc --metadata=title:"asasas" `
--resource-path="$markdownPath" `
--template="$pdfTemplatePath" `
--fail-if-warnings `
--variable numbersections="true" `
--variable mainfont="Arial" `
--variable sansfont="Helvetica" `
--variable monofont="Courier" `
--variable fontsize=12pt `
--variable version=2.0 `
--variable geometry="left=20mm, top=10mm, right=20mm, bottom=20mm" `
--variable toc-own-page="true" `
--toc `
--toc-depth=5 `
--lua-filter="version_table.lua" `
--variable titlepage="true" `
--variable logo="PDF/logo.eps" `
--columns=50 `
-f markdown-implicit_figures+escaped_line_breaks+raw_tex `
-t latex `
-s `
-o "$outputFileName" `
"$tempFileName"
La plantilla PDF que estoy usando es muy similar aplantilla-látex-pandoc, probablemente construido encima de él.
Cuando ejecuto pandocel comando, así es como se ve el resultado de la tabla:
¿Alguna idea de cuál podría ser el problema? ¿Hay algo que debería probar que pueda ayudar?
Esta es la parte del archivo tex generado para la captura de pantalla anterior.
\PassOptionsToPackage{unicode}{hyperref}
\PassOptionsToPackage{hyphens}{url}
\PassOptionsToPackage{dvipsnames,svgnames*,x11names*,table}{xcolor}
%
\documentclass[
12pt,
a4paper,
,tablecaptionabove
]{scrartcl}
\usepackage{lmodern}
\usepackage{setspace}
\setstretch{1.2}
\usepackage{amssymb,amsmath}
\usepackage{ifxetex,ifluatex}
\usepackage[utf8x]{inputenc}
\ifnum 0\ifxetex 1\fi\ifluatex 1\fi=0 % if pdftex
\usepackage[T1]{fontenc}
% \usepackage[utf8x]{inputenc}
\usepackage{textcomp} % provide euro and other symbols
\else % if luatex or xetex
\usepackage{unicode-math}
\defaultfontfeatures{Scale=MatchLowercase}
\defaultfontfeatures[\rmfamily]{Ligatures=TeX,Scale=1}
\setmainfont[]{Arial}
\setsansfont[]{Helvetica}
\setmonofont[]{Courier}
\fi
% Use upquote if available, for straight quotes in verbatim environments
\IfFileExists{upquote.sty}{\usepackage{upquote}}{}
\IfFileExists{microtype.sty}{% use microtype if available
\usepackage[]{microtype}
\UseMicrotypeSet[protrusion]{basicmath} % disable protrusion for tt fonts
}{}
\makeatletter
\@ifundefined{KOMAClassName}{% if non-KOMA class
\IfFileExists{parskip.sty}{%
\usepackage{parskip}
}{% else
\setlength{\parindent}{0pt}
\setlength{\parskip}{6pt plus 2pt minus 1pt}}
}{% if KOMA class
\KOMAoptions{parskip=half}}
\makeatother
\usepackage{xcolor}
\definecolor{default-linkcolor}{HTML}{A50000}
\definecolor{default-filecolor}{HTML}{A50000}
\definecolor{default-citecolor}{HTML}{4077C0}
\definecolor{default-urlcolor}{HTML}{4077C0}
\IfFileExists{xurl.sty}{\usepackage{xurl}}{} % add URL line breaks if available
\IfFileExists{bookmark.sty}{\usepackage{bookmark}}{\usepackage{hyperref}}
\hypersetup{
pdftitle={asasas},
hidelinks,
breaklinks=true,
pdfcreator={LaTeX via pandoc with the Eisvogel template}}
\urlstyle{same} % disable monospaced font for URLs
\usepackage[margin=2.5cm,includehead=true,includefoot=true,centering,left=20mm, top=10mm, right=20mm, bottom=20mm]{geometry}
\usepackage[export]{adjustbox}
\usepackage{graphicx}
\usepackage{longtable,booktabs}
% Correct order of tables after \paragraph or \subparagraph
\usepackage{etoolbox}
\makeatletter
\patchcmd\longtable{\par}{\if@noskipsec\mbox{}\fi\par}{}{}
\makeatother
% Allow footnotes in longtable head/foot
\IfFileExists{footnotehyper.sty}{\usepackage{footnotehyper}}{\usepackage{footnote}}
\makesavenoteenv{longtable}
\usepackage{graphicx,grffile}
\makeatletter
\def\ScaleWidthIfNeeded{%
\ifdim\Gin@nat@width>\linewidth
\linewidth
\else
\Gin@nat@width
\fi
}
\def\ScaleHeightIfNeeded{%
\ifdim\Gin@nat@height>0.9\textheight
0.9\textheight
\else
\Gin@nat@width
\fi
}
\makeatother
\setkeys{Gin}{width=\ScaleWidthIfNeeded,height=\ScaleHeightIfNeeded,keepaspectratio}%
\setlength{\emergencystretch}{3em} % prevent overfull lines
\providecommand{\tightlist}{%
\setlength{\itemsep}{0pt}\setlength{\parskip}{0pt}}
\setcounter{secnumdepth}{5}
\usepackage{float}
\floatplacement{figure}{H}
\title{asasas}
\date{}
\ifnum 0\ifxetex 1\fi\ifluatex 1\fi=0 % if pdftex
\usepackage[shorthands=off,main=english]{babel}
\else
\usepackage{polyglossia}
\setmainlanguage[]{english}
\fi
\usepackage{pagecolor}
\usepackage{afterpage}
\usepackage{multicol}
\PassOptionsToPackage{hyphens}{url}
\usepackage{csquotes}
\definecolor{caption-color}{HTML}{777777}
\usepackage[font={stretch=1.2}, textfont={color=caption-color}, position=top, skip=4mm, labelfont=bf, singlelinecheck=false, justification=raggedright]{caption}
\setcapindent{0em}
\definecolor{blockquote-border}{RGB}{221,221,221}
\definecolor{blockquote-text}{RGB}{119,119,119}
\usepackage{mdframed}
\newmdenv[rightline=false,bottomline=false,topline=false,linewidth=3pt,linecolor=blockquote-border,skipabove=\parskip]{customblockquote}
\renewenvironment{quote}{\begin{customblockquote}\list{}{\rightmargin=0em\leftmargin=0em}%
\item\relax\color{blockquote-text}\ignorespaces}{\unskip\unskip\endlist\end{customblockquote}}
\definecolor{heading-color}{RGB}{40,40,40}
\addtokomafont{section}{\color{heading-color}}
\usepackage{titling}
\title{asasas}
\author{}
% tables
\definecolor{table-row-color}{HTML}{F5F5F5}
\definecolor{table-rule-color}{HTML}{999999}
\arrayrulecolor{table-rule-color} % color of \toprule, \midrule, \bottomrule
\setlength\heavyrulewidth{0.3ex} % thickness of \toprule, \bottomrule
\renewcommand{\arraystretch}{1.3} % spacing (padding)
\let\oldlongtable\longtable
\let\endoldlongtable\endlongtable
\renewenvironment{longtable}{
\rowcolors{3}{}{table-row-color!100} % row color
\oldlongtable} {
\endoldlongtable
\global\rownum=0\relax}
\setlength{\parindent}{0pt}
\setlength{\parskip}{6pt plus 2pt minus 1pt}
\setlength{\emergencystretch}{3em} % prevent overfull lines
\usepackage{fancyhdr,lastpage}
\fancypagestyle{eisvogel-header-footer}{
\fancyhead{}
\fancyfoot{}
\lhead[]{asasas}
\chead[]{}
\rhead[asasas]{}
\lfoot{{Version: 2}{, effective date: 01-Sep-2020}}
\cfoot[]{}
\rfoot{{\thepage} of \pageref{LastPage}}
\renewcommand{\headrulewidth}{0.4pt}
\renewcommand{\footrulewidth}{0.4pt}
}
\pagestyle{eisvogel-header-footer}
\ifx\paragraph\undefined\else
\let\oldparagraph\paragraph
\renewcommand{\paragraph}[1]{\oldparagraph{#1}\mbox{}}
\fi
\ifx\subparagraph\undefined\else
\let\oldsubparagraph\subparagraph
\renewcommand{\subparagraph}[1]{\oldsubparagraph{#1}\mbox{}}
\fi
\usepackage[table]{xcolor}
\usepackage{tabularx}
\usepackage{colortbl}
\begin{document}
\arrayrulecolor{table-rule-color}
\restoregeometry
{
\setcounter{tocdepth}{5}
\tableofcontents
\newpage
}
\hypertarget{process-description}{%
\section{LOREM IPSUM}\label{process-description}}
Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lorem Ipsum has been the
industry's standard dummy text ever since the
1500s, when an unknown printer took a galley of
type and scrambled it to make a type specimen
book. It has survived not only five centuries, but
also the leap into electronic typesetting.
\hypertarget{objective-and-benefits}{%
\section{OBJECTIVE AND
BENEFITS}\label{objective-and-benefits}}
\hypertarget{objective}{%
\subsection{Objective}\label{objective}}
Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lorem Ipsum has been the
industry's standard
\hypertarget{benefits}{%
\subsection{Benefits}\label{benefits}}
\begin{itemize}
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry.
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry.
\end{itemize}
\hypertarget{definition}{%
\section{DEFINITION}\label{definition}}
Lorem Ipsum
\begin{itemize}
\tightlist
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry.
\end{itemize}
Lorem Ipsum
\begin{itemize}
\tightlist
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lorem Ipsum has been the
industry's standard dummy text ever since the
1500s, when an unknown printer took
\end{itemize}
Lorem Ipsum
\begin{itemize}
\tightlist
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lorem Ipsum has been the
industry's standard dummy
\end{itemize}
Lorem Ipsum
\begin{itemize}
\tightlist
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lorem Ipsum has been the
industry's standard dummy text
\end{itemize}
Lorem
\begin{itemize}
\tightlist
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lorem Ipsum is
\end{itemize}
Lorem
\begin{itemize}
\tightlist
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lorem Ipsum is
\end{itemize}
\hypertarget{roles-responsibilities}{%
\section{LOREM IPSUM}\label{roles-responsibilities}}
Lorem
\begin{itemize}
\tightlist
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lorem Ipsum has been
the industry's standard dummy text ever since
the 1500s Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lorem Ipsum has been
the industry's standard dummy text ever since
the 1500s.
\end{itemize}
Lorem
\begin{itemize}
\tightlist
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lore
\end{itemize}
Lorem
\begin{itemize}
\tightlist
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry.
\end{itemize}
Lorem
\begin{itemize}
\tightlist
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lorem Ipsum has been
the industry's standard dummy text ever since
the 1500s.
\end{itemize}
Lorem
\begin{itemize}
\tightlist
\item
Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lorem Ipsum has been
the industry's standard dummy text ever since
the 1500s.
\end{itemize}
\hypertarget{lorem-ipsum}{%
\section{LOREM IPSUM}\label{lorem-ipsum}}
\hypertarget{lorem-ipsum-is-simply-dummy}{%
\subsection{Lorem Ipsum is simply
dummy}\label{lorem-ipsum-is-simply-dummy}}
Lorem Ipsum is simply dummy text of the printing
and typesetting industry. Lorem Ipsum has been the
industry's standard dummy text ever since the
1500s, when an unknown printer took a galley of
type and scrambled it to make a type specimen
book. It has survived not only five centuries, but
also the leap into electronic typesetting.
\begin{longtable}[]{@{}ll@{}}
\toprule
\begin{minipage}[b]{0.36\columnwidth}\raggedright
Column 1\strut
\end{minipage} &
\begin{minipage}[b]{0.58\columnwidth}\raggedright
Column 2\strut
\end{minipage}\tabularnewline
\midrule
\endhead
\begin{minipage}[t]{0.36\columnwidth}\raggedright
Lorem Ipsum is simply dummy text\strut
\end{minipage} &
\begin{minipage}[t]{0.58\columnwidth}\raggedright
Lorem Ipsum\strut
\end{minipage}\tabularnewline
\begin{minipage}[t]{0.36\columnwidth}\raggedright
Lorem Ipsum is simply dummy text of the\strut
\end{minipage} &
\begin{minipage}[t]{0.58\columnwidth}\raggedright
Lorem Ipsum is simply dummy text of the printing
and typesetting industry.\strut
\end{minipage}\tabularnewline
\bottomrule
\end{longtable}
\end{document}
