Diagrama de flujo horizontal de diagrama inteligente

Question

Quiero conectar mi bloque DT a LL en el siguiente gráfico

El siguiente código es:

\begin{center}
\begin{figure}


\smartdiagramset{set color list={blue!10, blue!30,blue!50},back arrow disabled=true,
additions={
additional item offset=0.4cm,
additional arrow color=blue!30,
additional arrow tip=stealth,
additional arrow line width=1pt,
additional item border color=gray,
additional item shape=rounded corners,
additional item bottom color=blue!30,
additional item shadow=drop shadow
}
}
\smartdiagramadd[flow diagram:horizontal]{WRA, LL, CM}{
above of module2/DT
}
%\smartdiagramconnect{->}{module2/additional-module2n}
\end{figure}
\end{center

}

Sin embargo, cuando intento conectar el nuevo bloque al módulo 2, aparece un error. Se desconoce el "módulo adicional2". ¿Alguna pista?

Answer 1

Editar: Tu problema lo puedes resolver de dos maneras:

• Agregando a additionsla línea de código additional connections disabled=false,:
• O al código del diagrama agregar\smartdiagramconnect{to-}{module2/additional-module1}

Primer ejemplo:

\documentclass[rgb]{article}
\usepackage{smartdiagram}
\usesmartdiagramlibrary{additions}

\begin{document}
    \begin{figure}
    \centering
\smartdiagramset{set color list={blue!10, blue!30,blue!50},back arrow disabled=true,
additions={
additional item offset=0.4cm,
additional connections disabled=false,  % NEW
additional arrow color=red,             % changed color ...
additional arrow tip=stealth,
additional arrow line width=2pt,        % changed thickness
additional item border color=gray,
additional item shape=rounded corners,
additional item bottom color=blue!30,
additional item shadow=drop shadow
}
}
\smartdiagramadd[flow diagram:horizontal]%
    {WRA, LL, CM}%
    {above of module2/EDT}
%
\caption{Smart diagram}
\label{fig:smartdiagram}
    \end{figure}
\end{document}

Segundo caso:

\documentclass[rgb]{article}
\usepackage{smartdiagram}
\usesmartdiagramlibrary{additions}

\begin{document}
    \begin{figure}
    \centering
\smartdiagramset{set color list={blue!10, blue!30,blue!50},back arrow disabled=true,
additions={
additional item offset=0.4cm,
additional arrow color=red,             % changed color ...
additional arrow tip=stealth,
additional arrow line width=2pt,        % changed thickness
additional item border color=gray,
additional item shape=rounded corners,
additional item bottom color=blue!30,
additional item shadow=drop shadow
}
}
\smartdiagramadd[flow diagram:horizontal]%
    {WRA, LL, CM}%
    {above of module2/EDT}
\smartdiagramconnect{to-}{module2/additional-module1}
%
\caption{Smart diagram}
\label{fig:smartdiagram}
    \end{figure}
\end{document}

En ambos casos el resultado es el mismo:
