Acabo de leer una pregunta sobre cómo etiquetar la longitud del segmento, pero es bastante difícil para mí ya que todas las preguntas anteriores usaban un ángulo para etiquetar la longitud/distancia y no entendía el concepto. ¿Alguien podría enseñarme sobre el concepto de etiquetar la longitud de un segmento?

Daré mi experimento y un problema que necesito para describirlo en TikZ.

Aquí está el código que he probado:

\begin{tikzpicture}
\tikzset{
mydot/.style={
fill,
circle,
inner sep=1.5pt
}
}
\path (0:4.5) coordinate (A) (0:1.5) coordinate (B) (0:0) coordinate (C);
\draw (A)
-- (B) node [midway, above]{$x$} -- (C) node [midway, above]{$y$}  -- (A) -- cycle;
\node[mydot,label={below left:$A$}] at (A) {};
\node[mydot,label={below left:$B$}] at (B) {};
\node[mydot,label={below left:$C$}] at (C) {};
\draw[|<->|] ($(A)!5mm!90:(C)$)--node[fill=white] {$z$} ($(C)!5mm!0:(A)$);
\end{tikzpicture}

En realidad, este código lo copié de una pregunta publicada anteriormente, pero lo arreglé para mi caso aquí.

Aquí está la imagen recortada del problema que quería describirlo en TikZ.

El problema

Por cierto, me gustaría tener el segmento horizontal. Gracias, entonces.

Respuesta1

Algo como esto

ingrese la descripción de la imagen aquí

\begin{tikzpicture}
\tikzset{
    mydot/.style={
        fill,
        circle,
        inner sep=1.5pt
    }
}
\coordinate  (A) at(0,0) ;
\coordinate  (B)  at (3,0);
\coordinate  (C) at (6,0);
\coordinate  (D) at (9,0);
% (3,0) coordinate (B) (6,0) coordinate (C) (9,0) coordinate (D);
\draw (A) -- node [midway, above]{\scriptsize $x=21-14$}
(B)  -- node [midway, above]{\scriptsize $y=13-x$}
(C)   --
(D);
\node[mydot,label={below left:$A$}] at (A) {};
\node[mydot,label={below left:$B$}] at (B) {};
\node[mydot,label={below left:$C$}] at (C) {};
\node[mydot,label={below left:$D$}] at (D) {};
\draw[|<->|,red,line width=1pt] ($(A)!10mm!-90:(C)$)--node[fill=white] {$13$} ($(C)!10mm!90:(A)$);
\draw[|<->|,blue,line width=1pt] ($(B)!15mm!-90:(D)$)--node[fill=white] {$14$} ($(D)!15mm!90:(B)$);
\draw[|<->|,green,line width=1pt] ($(A)!20mm!-90:(D)$)--node[fill=white] {$21$} ($(D)!20mm!90:(A)$);
\end{tikzpicture}

editar - etiqueta encima del segmento

ingrese la descripción de la imagen aquí

\begin{tikzpicture}
\tikzset{
    mydot/.style={
        fill,
        circle,
        inner sep=1.5pt
    }
}
\coordinate  (A) at(0,0) ;
\coordinate  (B)  at (3,0);
\coordinate  (C) at (6,0);
\coordinate  (D) at (9,0);
% (3,0) coordinate (B) (6,0) coordinate (C) (9,0) coordinate (D);
\draw (A) -- node [midway, above]{\scriptsize $x=21-14$}
(B)  -- node [midway, above]{\scriptsize $y=13-x$}
(C)   --
(D);
\node[mydot,label={below left:$A$}] at (A) {};
\node[mydot,label={below left:$B$}] at (B) {};
\node[mydot,label={below left:$C$}] at (C) {};
\node[mydot,label={below left:$D$}] at (D) {};
\draw[|<->|,red,line width=1pt] ($(A)!10mm!90:(C)$)--node[fill=white] {$13$} ($(C)!10mm!-90:(A)$);
\draw[|<->|,blue,line width=1pt] ($(B)!15mm!90:(D)$)--node[fill=white] {$14$} ($(D)!15mm!-90:(B)$);
\draw[|<->|,green,line width=1pt] ($(A)!20mm!90:(D)$)--node[fill=white] {$21$} ($(D)!20mm!-90:(A)$);
\end{tikzpicture}

Respuesta2

Editar: Se considera comentario de @jsbibra.

Como esto:

ingrese la descripción de la imagen aquí

\documentclass[tikz, margin=3mm]{standalone}
\usetikzlibrary{arrows.meta,
                positioning,
                quotes}
\usepackage{amsmath}


\begin{document}
    \begin{tikzpicture}[x=7mm,
dot/.style = {circle, fill, inner sep=1.5pt,
              label=#1,
              node contents={}},
arr/.style = {{Bar[width=3mm].Straight Barb[]}-{Straight Barb[].Bar[width=3mm]},
              shorten >=-0.5\pgflinewidth, shorten <=-0.5\pgflinewidth,
              very thin},
every edge quotes/.style = {font=\small, auto=center}
                        ]
\node (a) [dot=${A=0}$];
\node (b) [dot=$B$, right= 7 of a];
\node (c) [dot=${C=13}$, right=13 of a];
\node (d) [dot=${D=21}$, right=21 of a];
%
\draw (a) to["${\begin{aligned}
                \overline{AB} & = \overline{AD}-\overline{BD}\\
                              & = 21-14=\color{red}7
                \end{aligned}}$"]   (b)
          to["${\begin{aligned}
                \overline{BC} & = \overline{AC}-\overline{AB}\\
                              & = 13-7=\color{red}6
                \end{aligned}}$"]   (c)   -- (d);
% aux coordinate and dimension BD
\coordinate[below=6mm of b] (b1);
\draw[arr]  (b1) to ["${\overline{BD} = 14}$" fill=white]  (b1-|d);
\end{tikzpicture}
\end{document}
