Quiero trazar 16 datos (el tamaño de cada dato es 150 kb) mediante pgfplot yLuaLatexsobre elAl dorsositio web. Pero no pude tener el resultado en pdf.
Hay un error:Caducado. Lo sentimos, su compilación tardó demasiado en ejecutarse y se agotó el tiempo de espera. Esto puede deberse a un error de LaTeX o a una gran cantidad de imágenes de alta resolución o diagramas complicados.
Y también le pongo elarchivo de registro aquí.
Por favor déjame saber cómo puedo resolver el problema.
Gracias.
============================================
Aquíson mis datos y mi codigo:
\documentclass[border=5pt]{standalone}
\usepackage{tikz,pgfplots,pgfplotstable}
%
\pgfplotsset{compat=newest}
\usepgfplotslibrary{colorbrewer}
%For rung by LuaLatex
%\tikzexternalize
\tikzset{external/system call={lualatex \tikzexternalcheckshellescape -halt-on-error - interaction=batchmode -jobname "\image" "\texsource"}}
%
\begin{document}
%
\begin{tikzpicture}[scale=0.8]
\pgfplotsset{every axis plot post/.append style={mark=none,line width=0.8pt}}
\pgfplotsset{cycle list/RdYlGn,
cycle list/OrRd,
cycle list/PiYG,
cycle list/Dark2}
\pgfplotsset{every major tick/.style={black}, every minor tick/.style={black!60}}
\begin{axis}[
%
xmin=7.9,
ymin=3.99,
xmax=16.2,
ymax=5.4,
xtick distance=1.0,
ytick distance=0.2,
minor x tick num={1},
minor y tick num={1},
%
y tick label style={
/pgf/number format/.cd,fixed,fixed zerofill,precision=1,/tikz/.cd
},
x tick label style={
/pgf/number format/.cd,
fixed,fixed zerofill,precision=1,/tikz/.cd
},
%
%Changing y axis Unite
y filter/.code={\pgfmathdivide{#1}{1000000}},
%
tick label style={font=\small},
xlabel style={font=\small,xshift=-0.2cm,yshift=0.1cm},
ylabel style={font=\small,yshift=-0.1cm,xshift=-0.1cm},
ylabel={TDO Frequency (MHz)},
xlabel={Field (T)},
%
legend style={font=\footnotesize,at={(0.49,-0.2)},anchor=north,legend columns=2},
%
axis background/.style={shade,top color=gray!60,bottom color=white},
%
restrict y to domain=3.99:5.4,
restrict x to domain=7.9:16.2
]
%=======================================================
\addplot+[index of colormap=1 of PiYG] table [x={Field_356}, y={Counter_356}] {356.dat};
\addlegendentry{C$_{356}$, $\theta$ = 38.8}
%=======================================================
\addplot+[index of colormap=3 of PiYG] table [x={Field_357}, y={Counter_357}] {357.dat};
\addlegendentry{C$_{357}$, $\theta$ = 38.8}
%=======================================================
\addplot+[index of colormap=1 of OrRd] table [x={Field_358}, y={Counter_358}] {358.dat};
\addlegendentry{C$_{358}$, $\theta$ = 49.0}
%=======================================================
\addplot+[index of colormap=3 of OrRd] table [x={Field_359}, y={Counter_359}] {359.dat};
\addlegendentry{C$_{359}$, $\theta$ = 49.0}
%=======================================================
\addplot+[index of colormap=1 of Dark2] table [x={Field_360}, y={Counter_360}] {360.dat};
\addlegendentry{C$_{360}$, $\theta$ = 59.3}
%=======================================================
\addplot+[index of colormap=3 of Dark2] table [x={Field_361}, y={Counter_361}] {361.dat};
\addlegendentry{C$_{361}$, $\theta$ = 59.3}
%=======================================================
\addplot+[index of colormap=4 of Dark2] table [x={Field_362}, y={Counter_362}] {362.dat};
\addlegendentry{C$_{362}$, $\theta$ = 69.5}
%=======================================================
\addplot+[index of colormap=9 of RdYlGn] table [x={Field_363}, y={Counter_363}] {363.dat};
\addlegendentry{C$_{363}$, $\theta$ = 69.5}
%=======================================================
\addplot+[index of colormap=8 of RdYlGn] table [x={Field_364}, y={Counter_364}] {364.dat};
\addlegendentry{C$_{364}$, $\theta$ = 79.8}
%=======================================================
\addplot+[index of colormap=7 of RdYlGn] table [x={Field_365}, y={Counter_365}] {365.dat};
\addlegendentry{C$_{365}$, $\theta$ = 79.8}
%=======================================================
\addplot+[index of colormap=6 of RdYlGn] table [x={Field_366}, y={Counter_366}] {366.dat};
\addlegendentry{C$_{366}$, $\theta$ = 90.0}
%=======================================================
\addplot+[index of colormap=5 of RdYlGn] table [x={Field_367}, y={Counter_367}] {367.dat};
\addlegendentry{C$_{367}$, $\theta$ = 90.0}
%=======================================================
\addplot+[index of colormap=4 of RdYlGn] table [x={Field_368}, y={Counter_368}] {368.dat};
\addlegendentry{C$_{368}$, $\theta$ = 100.2}
%=======================================================
\addplot+[index of colormap=3 of RdYlGn] table [x={Field_369}, y={Counter_369}] {369.dat};
\addlegendentry{C$_{369}$, $\theta$ = 100.2}
%=======================================================
\addplot+[index of colormap=2 of RdYlGn] table [x={Field_370}, y={Counter_370}] {370.dat};
\addlegendentry{C$_{370}$, $\theta$ = 110.5}
%=======================================================
\addplot+[index of colormap=1 of RdYlGn] table [x={Field_371}, y={Counter_371}] {371.dat};
\addlegendentry{C$_{371}$, $\theta$= 110.5}
%=======================================================
\end{axis}
\end{tikzpicture}
\end{document}
