Escribí un resumen ejecutivo para mi tesis, pero las figuras y tablas que incluyo en este resumen ejecutivo están numeradas de la siguiente manera: 0.1, 0.2, etc.
Me preguntaba si esto está oficialmente aceptado o no y, de no ser así, si hay alguna manera de cambiar la numeración. Me gusta que la numeración en el resto de los capítulos muestre el número del capítulo, pero el cero en el resumen ejecutivo parece un poco extraño. ¡Gracias por la ayuda! Te dejo mi código aquí:
\documentclass{article}
\usepackage[utf8]{inputenc}
\usepackage[super]{natbib}
\usepackage{comment}
\usepackage{graphicx}
\usepackage{float}
\usepackage{hyperref}
\hypersetup{
colorlinks,
citecolor=black,
filecolor=black,
linkcolor=black,
urlcolor=black
}
\usepackage{amsmath}
\usepackage{mathtools}
\usepackage{amssymb}
\usepackage{amsfonts}
\usepackage{caption}
\usepackage{adjustbox}
\usepackage{lipsum}
\usepackage{lscape}
\usepackage{multicol}
\usepackage{longtable}
\usepackage{chngcntr}
\counterwithin{figure}{section}
\counterwithin{table}{section}
\captionsetup[figure]{font=small,labelfont=bf}
\captionsetup[table]{font=small,labelfont=bf}
\usepackage[justification=centering]{caption}
\usepackage{eurosym}
\usepackage{mhchem}
\usepackage{multirow}
\usepackage{eurosym}
\usepackage{relsize}
\usepackage[table, dvipsnames]{xcolor}
\renewcommand*\descriptionlabel[1]{\hspace\leftmargin$#1$}
\usepackage{enumitem}
\usepackage{lscape}
\newcolumntype{C}{>{\Centering\hspace{0pt}}p{0.1\textwidth}}
\usepackage[output-decimal-marker={,}]{siunitx}
\usepackage{booktabs, makecell, tabularx}
\newcolumntype{L}{>{\raggedright\arraybackslash}X}
\newcolumntype{M}{p{\dimexpr 0.25\textwidth-2\tabcolsep}}
\newcolumntype{P}[1]{>{\centering\arraybackslash}p{#1}}
\usepackage{longtable,array,ragged2e}
\newlength\mylen
\setlength\mylen{\dimexpr0.25\textwidth-1.5\tabcolsep-0.25\arrayrulewidth\relax}
\newcolumntype{Z}{>{\RaggedRight}p{\mylen}}
\usepackage{booktabs,tabularx}
\makeatletter
\newcommand*{\rom}[1]{\expandafter\@slowromancap\romannumeral #1@}
\makeatother
\def\changemargin#1#2{\list{}{\rightmargin#2\leftmargin#1}\item[]}
\let\endchangemargin=\endlist
\bibliographystyle{abbrvnat}
\setcitestyle{authoryear,open={(},close={)}}
\begin{document}
\section*{Management Summary}
The supplier selection problem is one of the crucial activities of the procuring department in an organization when no single supplier can satisfy all....
\begin{figure}[htbp]
\centerline{\includegraphics[scale=.43]{Model blackbox.png}}
\begin{changemargin}{0.5cm}{0.5cm}
\vspace*{-2mm}
\caption{Can Order Allocation Model (COAM) framework.}
\end{changemargin}
\label{fig}
\end{figure}
To test the financial benefits, five different versions of the model were built....
\end{document}
Respuesta1
Agregué a su MWE pero no perdí el tiempo eliminando todo el código irrelevante que proporcionó y que no tenía relación con su problema.
% fignumprob.tex SE 561990
\documentclass{article}
\usepackage[utf8]{inputenc}
\usepackage[super]{natbib}
\usepackage{comment}
\usepackage{graphicx}
\usepackage{float}
\usepackage{hyperref}
\hypersetup{
colorlinks,
citecolor=black,
filecolor=black,
linkcolor=black,
urlcolor=black
}
\usepackage{amsmath}
\usepackage{mathtools}
\usepackage{amssymb}
\usepackage{amsfonts}
\usepackage{caption}
\usepackage{adjustbox}
\usepackage{lipsum}
\usepackage{lscape}
\usepackage{multicol}
\usepackage{longtable}
\usepackage{chngcntr}
\counterwithin{figure}{section}
\counterwithin{table}{section}
\captionsetup[figure]{font=small,labelfont=bf}
\captionsetup[table]{font=small,labelfont=bf}
\usepackage[justification=centering]{caption}
\usepackage{eurosym}
\usepackage{mhchem}
\usepackage{multirow}
\usepackage{eurosym}
\usepackage{relsize}
\usepackage[table, dvipsnames]{xcolor}
\renewcommand*\descriptionlabel[1]{\hspace\leftmargin$#1$}
\usepackage{enumitem}
\usepackage{lscape}
\newcolumntype{C}{>{\Centering\hspace{0pt}}p{0.1\textwidth}}
\usepackage[output-decimal-marker={,}]{siunitx}
\usepackage{booktabs, makecell, tabularx}
\newcolumntype{L}{>{\raggedright\arraybackslash}X}
\newcolumntype{M}{p{\dimexpr 0.25\textwidth-2\tabcolsep}}
\newcolumntype{P}[1]{>{\centering\arraybackslash}p{#1}}
\usepackage{longtable,array,ragged2e}
\newlength\mylen
\setlength\mylen{\dimexpr0.25\textwidth-1.5\tabcolsep-0.25\arrayrulewidth\relax}
\newcolumntype{Z}{>{\RaggedRight}p{\mylen}}
\usepackage{booktabs,tabularx}
\makeatletter
\newcommand*{\rom}[1]{\expandafter\@slowromancap\romannumeral #1@}
\makeatother
\def\changemargin#1#2{\list{}{\rightmargin#2\leftmargin#1}\item[]}
\let\endchangemargin=\endlist
\bibliographystyle{abbrvnat}
\setcitestyle{authoryear,open={(},close={)}}
\begin{document}
\listoffigures %% PW ADDED THIS
\section*{Management Summary}
\renewcommand{\thefigure}{\arabic{figure}} %% PW ADDED THIS
\renewcommand{\thetable}{\arabic{table}} %% PW ADDED THIS
The supplier selection problem is one of the crucial activities of the procuring department in an organization when no single supplier can satisfy all....
\begin{figure}[htbp]
\centerline{\includegraphics[scale=.43]{Model blackbox.png}}
\begin{changemargin}{0.5cm}{0.5cm}
\vspace*{-2mm}
\caption{Can Order Allocation Model (COAM) framework.}
\end{changemargin}
\label{fig}
\end{figure}
To test the financial benefits, five different versions of the model were built....
\section{Main document} %% PW ADDED THESE
\renewcommand{\thefigure}{\thesection.\arabic{figure}}
\renewcommand{\thetable}{\thesection.\arabic{table}}
\lipsum[1]
\begin{figure}
\centering
MAIN ILLUSTRATION
\caption{A figure}
\end{figure}
\end{document}
Utilice \renewcommand{figure}(y tabla) en los lugares apropiados para obtener la numeración que desea. No sé cómo quiere que se vea su Lista de Figuras pero me parece extraño que el de Resumen de Gestión esté etiquetado 1pero el de Documento Principal esté etiquetado 1.1. Si no te gusta esto haz otra pregunta.
La articleclase no proporciona capítulos de los que habla en su pregunta. --- GOM
