Espacio entre la tabla y el título* Dentro de la tabla

Question

Estoy insertando dos tabulars en uno tablepara los Paneles A y B. tableTiene uno captiony cada uno tabulartambién tiene uno caption*de la siguiente manera.

\documentclass{article}
\usepackage{caption}
\begin{document}
\begin{table}
\centering
\caption{SHORT TITLE}
\caption*{Panel A. LONG DESCRIPTION}
\begin{tabular}{*5c} \hline
0 & 0 & 0 & 0 & 0 \\
0 & 0 & 0 & 0 & 0 \\ \hline
\end{tabular}

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
%             I ALSO NEED A GAP HERE             %
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%

\caption*{Panel B. LONG DESCRIPTION}
\begin{tabular}{*5c} \hline
0 & 0 & 0 & 0 & 0 \\
0 & 0 & 0 & 0 & 0 \\ \hline
\end{tabular}
\end{table}
\end{document}

Y descubrí que la brecha entre el primero tabulary el segundo caption*es demasiado estrecha. Los otros tres espacios ( caption- caption*, caption*- tabular, caption*- tabular) están bien. ¿Por qué tienen diferentes brechas?

También probé subtables de la siguiente manera, pero aún así la estrecha brecha se ve fea.

\documentclass{article}
\usepackage{caption,subcaption}
\begin{document}
\begin{table}
\centering
\caption{SHORT TITLE}
\begin{subtable}{\textwidth}
\centering
\subcaption{Panel A. LONG DESCRIPTION}
\begin{tabular}{*5c} \hline
0 & 0 & 0 & 0 & 0 \\
0 & 0 & 0 & 0 & 0 \\ \hline
\end{tabular}
\end{subtable}

%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
%              STILL NO GAP APPLIED              %
%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%

\begin{subtable}{\textwidth}
\centering
\subcaption{Panel B. LONG DESCRIPTION}
\begin{tabular}{*5c} \hline
0 & 0 & 0 & 0 & 0 \\
0 & 0 & 0 & 0 & 0 \\ \hline
\end{tabular}
\end{subtable}
\end{table}
\end{document}

Aquí agrego mi versión ( \vspace{10pt}para \caption*y \vspace{6pt}para \subcaption*) pero no sé si es la mejor.

\documentclass{article}
\usepackage{caption}
\begin{document}
\begin{table}
\centering
\caption{SHORT TITLE}
\caption*{Panel A. LONG DESCRIPTION}
\begin{tabular}{*5c} \hline
0 & 0 & 0 & 0 & 0 \\
0 & 0 & 0 & 0 & 0 \\ \hline
\end{tabular}\vspace{10pt}

\caption*{Panel B. LONG DESCRIPTION}
\begin{tabular}{*5c} \hline
0 & 0 & 0 & 0 & 0 \\
0 & 0 & 0 & 0 & 0 \\ \hline
\end{tabular}
\end{table}
\end{document}

Answer 1

Quizás este ejemplo ayude.

\documentclass{article}

\RequirePackage{float}
\RequirePackage{caption}

\begin{document}

\centerline{SHORT TITLE}

    \begin{table}[H]
        \centering
        \caption*{Panel A. LONG DESCRIPTION}
        \begin{tabular}{*5c} \hline
            0 & 0 & 0 & 0 & 0 \\
            0 & 0 & 0 & 0 & 0 \\ \hline
        \end{tabular}
    \end{table}
        %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
                     I ALSO NEED A GAP HERE             %
        %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
    \begin{table}[H]
            \centering
        \caption*{Panel B. LONG DESCRIPTION}
        \begin{tabular}{*5c} \hline
            0 & 0 & 0 & 0 & 0 \\
            0 & 0 & 0 & 0 & 0 \\ \hline
        \end{tabular}
    \end{table}

\end{document}

O este: (también puedes usar \subcaption*{⟨heading⟩})

\documentclass{article}
\usepackage{subcaption}
\begin{document}

\begin{table}
    \caption{FULL CAPTION}
    \begin{subtable}[t]{.5\linewidth}
      \centering
     \subcaption{    Panel A. LONG DESCRIPTION \\LONG DESCRIPTION }
        \begin{tabular}{*5c} \hline
            0 & 0 & 0 & 0 & 0 \\
            0 & 0 & 0 & 0 & 0 \\ \hline
        \end{tabular}
    \end{subtable}%
    \begin{subtable}[t]{.5\linewidth}
      \centering
    \subcaption{  Panel B. LONG DESCRIPTION \\ LONG DESCRIPTION}
      \begin{tabular}{*5c} \hline
        0 & 0 & 0 & 0 & 0 \\
        0 & 0 & 0 & 0 & 0 \\ \hline
      \end{tabular}
    \end{subtable}
\end{table}

\end{document}

ACTUALIZARdespués del comentario. Pon todo en un ambiente de mesa.

\documentclass{article}

\RequirePackage{float}
\RequirePackage{caption}

\begin{document}

\begin{table}

\caption{SHORT TITLE 1}

    \begin{table}[H]
        \centering
        \caption*{Panel A. LONG DESCRIPTION}
        \begin{tabular}{*5c} \hline
            0 & 0 & 0 & 0 & 0 \\
            0 & 0 & 0 & 0 & 0 \\ \hline
        \end{tabular}
    \end{table}
    %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
                 I ALSO NEED A GAP HERE             %
    %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
    \begin{table}[H]
        \centering
        \caption*{Panel B. LONG DESCRIPTION}
        \begin{tabular}{*5c} \hline
            0 & 0 & 0 & 0 & 0 \\
            0 & 0 & 0 & 0 & 0 \\ \hline
        \end{tabular}
    \end{table}

\end{table}

\noindent ANOTHER GAP HERE

\begin{table}[H]

    \caption{SHORT TITLE 2}

    \begin{table}[H]
        \centering
        \caption*{Panel C. LONG DESCRIPTION}
        \begin{tabular}{*5c} \hline
            0 & 0 & 0 & 0 & 0 \\
            0 & 0 & 0 & 0 & 0 \\ \hline
        \end{tabular}
    \end{table}
    %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
PLUS ANOTHER GAP HERE               %
    %%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%%
    \begin{table}[H]
        \centering
        \caption*{Panel D. LONG DESCRIPTION}
        \begin{tabular}{*5c} \hline
            0 & 0 & 0 & 0 & 0 \\
            0 & 0 & 0 & 0 & 0 \\ \hline
        \end{tabular}
    \end{table}

\end{table}

\end{document}
