Soy bastante nuevo en todo esto. Soy profesor de física y simplemente intento hacer algunas hojas de preguntas bonitas para mis alumnos.
Actualmente estoy luchando por conseguir imágenes para colocarlas JUNTO al texto. Sé que existen comandos de minipágina, pero me preguntaba si hay algo un poco más fácil.
Aquí está mi código:
\documentclass[10pt, a4paper, oneside, notitlepage]{article}
\usepackage{graphicx,wrapfig}
\usepackage{geometry, rotating, sidecap}
\geometry{
a4paper,
total={180mm,267mm},
left=10mm,
top=15mm,
}
\begin{document}
\thispagestyle{empty}
{\large\bf{Car Stopping Distances}}
\begin{enumerate}
\item The UK {\emph {Highway Code}} has a table of "Typical Stopping Distances" on straight roads in dry conditions. The diagram is based on this information.
%\begin{wrapfigure}{h}{0.3\textwidth}
%\centering
%\includegraphics[width=0.25\textwidth]{highwaycode}
%\end{wrapfigure}
\begin{figure}[h]
\centerline{\includegraphics[width=0.8\textwidth]{highwaycode}}
\end{figure}
\\The shaded arrows represent the "thinking distance", the unshaded part the "braking distance", and the whole arrow the "stopping distance".
\begin{enumerate}
\item Make a table of the thinking distances d$_{think}$ and sketch a graph of d$_{think}$ against speed v, from v = 0 to v = 70 mph
\item Deduce a relation between these two variables
\item Predict the thinking distance for a police car travelling at 90 mph
\item How would the driver's consumption of alcohol/illegal substances affect the stopping distances? Explain your answer
\end{enumerate}
\item
\begin{enumerate}
\item Using the {\emph {Highway Code}} data from the previous question, make a table of the braking distances d$_{brake}$ and sketch a graph of d$_{brake}$ against v, from v = 0 to v = 70 mph.
\item The relationship here is that d$_{brake}$ = $k$v$^{2}$, where $k$ is a constant. Test this statement by calculating $k$ for three numerical values of d$_{brake}$ and v.
\item Use the data to calculate the acceleration when braking from {\bf(i)} 50 mph, {\bf(ii)} 70 mph
\end{enumerate}
\item In France the motorways have different speed limits depending on the road condition.
They are:
\begin{itemize}
\item when dry 130 kmh$^{-1}$
\item when wet 110 kmh$^{-1}$
\end{itemize}
Using the $\frac{5}{8}$ ratio, translate these into mph, and comment on the French system.\\
% \begin{minipage}[]{0.55\linewidth}
\item A person who is properly held by a seat belt has a good chance of surviving a car collision if the deceleration does not exceed 30g. Assuming uniform deceleration at this rate, calculate the distance that the front section of the car must crumple if a crash occurs at 65 kmh$^{-1}$
%\begin{wrapfigure}{h}{0.6\textwidth}
%\centering
%\includegraphics[width=0.25\textwidth]{crumple}
%\end{wrapfigure}
\begin{figure}[h]
\centerline{\includegraphics[width=0.35\textwidth]{crumple}}
\end{figure}
\end{enumerate}
\end{document}
Cualquier consejo sería muy apreciado, ¡gracias!
Respuesta1
Esta solución crea un entorno textbox(nombre horrible) que toma una imagen como argumento (o un \parboxo minipagesi es necesario). Se diferencia de wrapfigure en quevoluntadTrabajar con listas, pero no dará forma a los párrafos. Dado que cada uno \itemes un párrafo separado, eso no debería ser un problema.
Simplemente mantenga todos sus entornos correctamente anidados. Puede utilizar la [resume*]función del paquete enumitem para agregar más elementos externos textbox.
\documentclass[10pt, a4paper, oneside, notitlepage]{article}
\usepackage{graphicx,wrapfig}
\usepackage{geometry, rotating, sidecap}
\geometry{
a4paper,
total={180mm,267mm},
left=10mm,
top=15mm,
}
\newsavebox{\tempbox}% reserve global name
\makeatletter
\newenvironment{textbox}[1]% #1 = image (possibley parbox or minipage with \caption)
{\savebox\tempbox{\def\@captype{figure}#1}% measure image (also preserve for \endtextbox)
\minipage[t]{\dimexpr \linewidth-\columnsep-\wd\tempbox}}%
{\endminipage\hfill\raisebox{\dimexpr \ht\strutbox-\ht\tempbox}{\usebox\tempbox}}
\makeatother
\begin{document}
\thispagestyle{empty}
{\large\bf{Car Stopping Distances}}
\begin{enumerate}
\item The UK {\emph {Highway Code}} has a table of "Typical Stopping Distances" on straight roads in dry conditions. The diagram is based on this information.
\begin{textbox}{\includegraphics[width=0.3\textwidth]{example-image-a}}
The shaded arrows represent the "thinking distance", the unshaded part the "braking distance", and the whole arrow the "stopping distance".
\begin{enumerate}% second layer
\item Make a table of the thinking distances d$_{think}$ and sketch a graph of d$_{think}$ against speed v, from v = 0 to v = 70 mph
\item Deduce a relation between these two variables
\item Predict the thinking distance for a police car travelling at 90 mph
\item How would the driver's consumption of alcohol/illegal substances affect the stopping distances? Explain your answer
\end{enumerate}
\end{textbox}
\item
\begin{enumerate}
\item Using the {\emph {Highway Code}} data from the previous question, make a table of the braking distances d$_{brake}$ and sketch a graph of d$_{brake}$ against v, from v = 0 to v = 70 mph.
\item The relationship here is that d$_{brake}$ = $k$v$^{2}$, where $k$ is a constant. Test this statement by calculating $k$ for three numerical values of d$_{brake}$ and v.
\item Use the data to calculate the acceleration when braking from {\bf(i)} 50 mph, {\bf(ii)} 70 mph
\end{enumerate}
\item In France the motorways have different speed limits depending on the road condition.
They are:
\begin{itemize}
\item when dry 130 kmh$^{-1}$
\item when wet 110 kmh$^{-1}$
\end{itemize}
Using the $\frac{5}{8}$ ratio, translate these into mph, and comment on the French system.\\
\begin{textbox}{\includegraphics[width=0.35\textwidth]{example-image-b}}
\item A person who is properly held by a seat belt has a good chance of surviving a car collision if the deceleration does not exceed 30g. Assuming uniform deceleration at this rate, calculate the distance that the front section of the car must crumple if a crash occurs at 65 kmh$^{-1}$
\end{textbox}
\end{enumerate}
\end{document}
